Refer to the following scenarios to determine an appropriate network mode.
Determine Network Mode
*Images may dier from your actual products.
©2023 TP-Link 7106510694 REV1.0.0
Wi-Fi 6 Portable Router
Quick Installation Guide
Recommended
Scenarios
Mode
Switch I Want to...
Network
Mode
Hardware Information
Button Description
DescriptionButton
This switch is used to change the
operation mode of the router.
Note: If you toggle this switch
accidentally, set it back to the original
mode within 3 seconds. The mode of
the router won’t change.
Press the button for 1 second and
immediately press the WPS button on
your client to start the WPS process.
Press and hold the button for about 6
seconds until the LED blinks red to
reset the router to its factory default
settings.
WPS/Reset Button
Mode Switch
Interface Description
DescriptionInterface
In / Router 3G/4G USB Modem USB Tethering / mode, it
functions as a WAN port.
In Hotspot / Access Point / Range Extender / Client mode, it
functions as a LAN port.
For connecting your PC or other wired devices to the
router.
Use this USB 2.0 port to connect your 3G/4G USB modem,
mobile device, or USB storage device to the router.
Your mobile device can be charged when it is connected to
the powered-on router via the USB port (5 V/0.5 A).
This port is used to connect the USB-C charger
provided in the package.
1 Gbps
WAN Port
1 Gbps
LAN Port
3G/4G USB Port
Power Port
Mode Switch
IndicationStatus
The router has started up but is
disconnected from the internet.
Solid Red
Blinking Red The router is being reset. Do not power
o your router.
LED Indication
Blinking Blue
The router is starting up / being upgraded /
establishing the WPS connection.
The router is switching modes and will reboot.
The router is connected to the internet or
the main network, or the WPS connection is
successfully established.
Solid Blue
During Travel
LED
Router Mode
5. Connect your device to the router (wireless or wired).
4. Wait until the router’s LED turns solid (blue or red) before moving on.
2
Internet
Wired Network
3
Notes:
1. On the Select Connection Type page, if you are not sure, click AUTO DETECT.
2. You can customize your
Network Name
and (SSID)
Password
for the 2.4GHz/5GHz wireless
network during the Quick Setup, but you need to reconnect your wireless devices to the new
Wi-Fi network(s).
1. Set the Mode Switch to . Router
2. Connect the router’s WAN port to the existing wired network with an Ethernet
cable.
3. Power on the router.
7. Start the Quick Setup, make sure the operation mode is Router/USB Internet,
and click .NEXT
6. Launch a web browser and enter http://tplinkwifi.net http://192.168.0.1 or in
the address bar. Create a password to log in.
8. Router Select as your network mode, and click NEXT.
9. Follow the step-by-step instructions to set up the internet connection, and
enjoy the internet.
http://tplinkwi.net
Let’s Get Started
WAN
1
Requirements
A USB cable.
At Home
(e.g., home, oce, etc.)
Hotspot Hotspot Turn an existing public Wi-Fi into a private network (wired and
wireless).
Access Point
Range Extender
Client
Expand an existing Wi-Fi network for better Wi-Fi coverage.
Connect a wired-only device, such as a smart TV, media player,
or game console, to a Wi-Fi network.
Turn an existing wired-only network into a wireless network.
AP/RE
During Travel
(e.g., hotel, airport, cafe,
cruise ship, RV, camp, etc.)
Router 3G/4G USB Modem
Share the internet with more wireless devices when the wired
network is limited to one device at a time.
Share a 3G/4G USB modem’s data with other devices.
USB Tethering Share a mobile device’s cellular data with other devices.
Router
(Default Mode)
An existing wired network provided by a
modem or other network device.
A 3G/4G USB modem (with a SIM card
inserted).
A mobile device (with a SIM card inserted).
A public Wi-Fi.
An existing wired network provided by a
router, switch, etc.
An existing Wi-Fi network.
An existing Wi-Fi network.
5. Launch a web browser and enter http://tplinkwifi.net http://192.168.0.1 or in
the address bar. Create a password to log in.
4. Connect your device to the router (wireless or wired).
http://tplinkwi.net
Let’s Get Started
6. Start the Quick Setup, make sure the operation mode is Router/USB Internet,
and click .NEXT
7. Select your network mode, and click NEXT.
8. Follow the step-by-step instructions to set up the internet connection, and
enjoy the internet.
Note: You can customize your Network Name (SSID) Password and for the 2.4GHz/5GHz
wireless network during the Quick Setup, but you need to reconnect your wireless devices to
the new Wi-Fi network(s).
1. Set the Mode Switch to . Router
2. Power on the router.
3. Wait until the router’s LED turns solid (blue or red), which indicates that the
router has started up, and then connect the router’s port to your 3G/4G USB
USB modem or mobile device.
USB Tethering Mode
3G/4G USB Modem Mode
3G/4G USB Modem Mode / USB Tethering Mode
1
2
3
• If you are sharing a 3G/4G USB modem's data, select 3G/4G USB Modem.
• If you are sharing a mobile device’s data, select USB Tethering.
Note: When USB tethering, avoid connecting the tethered mobile device to the router's Wi-Fi.
Hotspot Mode
Public Hotspot
2
1
2. Power on the router.
3. Wait until the router’s LED turns into solid red before moving on.
5. Launch a web browser and enter http://tplinkwifi.net http://192.168.0.1 or in
the address bar. Create a password to log in.
4. Connect your device to the router (wireless or wired).
http://tplinkwi.net
Let’s Get Started
6. Start the Quick Setup, make sure the operation mode is Hotspot NEXT, and click .
7. Follow the step-by-step instructions to set up the internet connection, and
enjoy the internet.
Notes:
1. On the Select Connection Type page, if you are not sure, use Dynamic IP in most cases or
consult the ISP.
2. If the public hotspot requires a Captive Portal Authentication, complete the authentication
during the Quick Setup before you can access the network. Refer to FAQ-Q6 for more details.
3. You can customize your
Network Name
and (SSID)
Password
for the 2.4GHz/5GHz wireless
network during the Quick Setup, but you need to reconnect your wireless devices to the new
Wi-Fi network(s).
1. Set the Mode Switch to .Hotspot
• Wireless: Connect your device to the router’s Wi-Fi. The default wireless network
names (SSIDs) and wireless password are printed on both the Wi-Fi info card and
the label at the bottom of the router.
• Wired: Turn o the Wi-Fi on your device and connect to the WAN LAN or port of the
router with an Ethernet cable.
