V-TAC VT-8141 Manual

V-TAC Lettelse VT-8141

Læs nedenfor 📖 manual på dansk for V-TAC VT-8141 (1 sider) i kategorien Lettelse. Denne guide var nyttig for 10 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF

Side 1/1

LED CABINET LIGHT

WITH PIR SENSOR

INSTALLATION INSTRUCTION

Caution, risk of electric shock.

This marking indicates that this

product should not be disposed

of with other household wastes.

PARTS OF ITEM

WARNING

• Please make sure to turn oﬀ the power before starting the installation.

• Installation must be performed by a qualiﬁed electrician.

• The light source of this luminaire is not replaceable, when the light source reaches its end of life

the whole luminaire should be replaced.

• Keep children away from this product or accessories.

• Do not use or store this product in a hot and humid place, or in a place with a lot of dust or oily

smoke.

• Avoid strong vibration, shock, or excessive force to this product.

• Do not disassemble, repair, process or modify this product. Also, do not use it for any other

purpose.

• When cleaning this product, do not use anything that contains volatile organic solvents such as

benzine and thinner.

• If the battery of the target device becomes hot or you feel something is wrong while charging, stop

using it immediately and contact us.

• When disposing of this product, follow the instructions of each local government and dispose of it

correctly.

• For indoor use only.

FEATURES

• The LED light with motion sensor detects the movement of a person entering the detection area

and automatically turns on the LED light and turns it oﬀ after a while.

(Motion sensing mode only takes eﬀect at night or in a dark environment)

• Can be installed and used in closets, cabinets, kitchens, living rooms, entrances, etc.

SENSING ACCURACY

After receiving this product, please check whether the motion sensing mode is eﬀective. Please turn the

switch to "AUTO" in a dark environment. After detecting human movement, the light will automatically light

up.

NOTE: that in daylight or in suﬃcient light In the case of, the motion sensing mode is invalid.

SENSING AREA

INTRODUCTION & WARRANTY

TECHNICAL DATA

YEARS

WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these

instructions carefully before starting the installation and keep this manual handy for future reference.

If you have any another query, please contact our dealer or local vendor from whom you have

purchased the product. They are trained and ready to serve you at the best. The warranty is valid for

2 years from the date of purchase. The warranty does not apply to damage caused by incorrect

installation or abnormal wear and tear. The company gives no warranty against damage to any

surface due to incorrect removal and installation of the product. The products are suitable for 10-12

Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is

warranted for manufacturing defects only.

NOTE:

• Please charge in time when the light is dimmed.

• The numerical value of the LED light lighting time is an actual measurement value. It may vary

depending on the usage environment.

CHARGING METHOD

• Please use an independent USB port or 5V/1A charger device ﬁrst. If there is no such device,

you can connect this product to a personal computer. Please connect it when the personal

computer is turned on.

• Connect the a USB connector of the battery part to the USB port that can supply power.

Charging will start automatically and the indicator light on the sensor will glow red.

• When charging is complete, the indicator light will turns green.

1.Using The 3M buckle to absorb the built-in

magnet of the light.

* Please refrain from installing in a place where the surface is painted.

* 3M tape is hard to peel oﬀ once it is stuck, but once it is peeled oﬀ, the adhesive force will decrease,

please try to avoid secondary pasting.

* This product is not waterproof, please make sure to use it in a dry environment.

2. Tear oﬀ the 3M adhesive tape and stick the

lamp on the position where you want to install.

PRODUCT INFORMATION

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU

FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST

DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B

Model VT-8141 VT-8142 VT-8143

Watts 1.5W 2W 2.5W

Lumens 110lm 160lm 260lm

Beam Angle 180° 180° 180°

Body Type Aluminum Aluminum Aluminum

Dimension 300*40*11mm 400*40*11mm 600*40*11mm

Battery LITHIUM 1500mA LITHIUM 2200mA LITHIUM 3000mA

Charging Time 4 Hours 7 Hours6Hours

Working Time 5~6 Hours 6~7 Hours 7~8 Hours

Sensor Mode PIR Sensor PIR Sensor PIR Sensor

Detection Angle 120° 120° 120°

Detection Distance 3M~5M 3M~5M 3M~5M

Delay Time 15s 15s 15s

Input Voltage DC: 5V, 1A DC: 5V, 1A DC: 5V, 1A

MULTI-LANGUAGE

MANUAL QR CODE

Please scan the QR code

to access the manual in

multiple languages.

DIY

WORK MODES
