Whirlpool FFD 9469 CV GCC Manual

Whirlpool Vaskemaskine FFD 9469 CV GCC

Læs nedenfor 📖 manual på dansk for Whirlpool FFD 9469 CV GCC (4 sider) i kategorien Vaskemaskine. Denne guide var nyttig for 6 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF

Side 1/4

Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your appliance on

www.whirlpool.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more detailed

instructions on how to remove them, see the Installation Guide.

PROGRAMME CHART

1. “ON/OFF” button

2. Programme selector

3. “Temperature” button

4. “Spin” button

5. “Start delay” button

6. “Start/Pause” button

7. Option buttons

8. “Key lock“button

INDICATORS

Door can be opened

Washing phase

Indicates washing phase of the cycle

Failure: Call Service

Refer to Troubleshooting section

Failure: Water lter clogged

Water cannot be drained; water lter

might be blocked

Failure: Water tap closed

No or not sucient inlet water. “Beep”

sound every 5 seconds.

In the event of any failures, refer to the

Troubleshooting section in USER MANUAL

CONTROL PANEL

2.1. 6.3. 4. 5.

8.7. 7.

PRODUCT DESCRIPTION

1. Worktop

2. Detergent dispenser

3. Control panel

4. Door handle

5. Door

6. Water lter - behind plinth

7. Plinth (removable)

8. Adjustable feet (4)

DETERGENT DISPENSER

Main wash compartment

Detergent for the main wash, stain remover

or water softener. For a liquid detergent it is

recommended to use removable plastic partition

A (supplied) for a proper dosage. If powder

detergent is used, place the partition into slot B.

Prewash compartment

Detergent for the prewash.

Softener compartment

Fabric softener. Liquid starch.

Pour in softener or starch solution only up to the “max” mark.

Release button 

Press to remove tray for cleaning.



This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of the

programmes, without options.

** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

*** The duration of the programme is shown on the display.

6th Sense - the sensor technology adapts water, energy and programme duration to your wash

load.

1) Test wash cycle according to UAE.S 5010-2 : 2019 regulations:

Set WHITE wash program at a temperature of 60°C for the Standard Cotton 60°C.

Cotton Eco - Test wash cycles in compliance with regulations 1061/2010

These are the reference programs for the energy label. Set this wash cycles with a

temperature of 40°C or 60°C. They are the most ecient programmes in terms of energy

and water consumption for washing normally soiled cotton laundry. The actual water

temperature may dier from the declared one.

For all Test Institutes:

Long wash cycle for cottons: set wash cycle with a temperature of 40°C.Cotton

Synthetic program along: set wash cycle Synthetics

with a temperature of 40°C.

Max load 9 Kg

Power consumption in o -mode 0.5 W / in left-on mode 8 W Detergents and additives Recommended

detergent

Residual

dampness % (**)

Energy

consumption kWh

Total water lt

Programme Temperatures Max.

spin

speed

(rpm

Max

load

(kg

Duration

(Minutes Prewash Main

wash Softener Powder Liquid

Default Range

Mixed 40°C - 40°C 9.0 –

1000 ***   –– – –

White (1) 60°C - 90°C 9.0

1400 ***     (90°) – – –

Cotton 40°C - 60°C 9.0 255 –

1400     49 1,10 97

Cotton

60°C 60°C 9.0 260 –

1400     53 0,70 56

40°C 9.0 255 –1400     49 1,10 97

Bed linen 60°C - 60°C 9.0 –1400 ***     – – –

Sport 40°C - 40°C 4.0 –

600 ***   –– – –

Duvet 30°C - 30°C 3.5 –

1000 ***   –– – –

Steam Refresh – – - 2.0 – – – – – – – –***

Spin & Drain – – 9.0 – – – – – – – –

1400 ***

Rinse & Spin – – 9.0 – –1400 *** – – – – –

Rapid 30’ 30°C - 30°C 4.5 –

800 ***   –– – –

Colours 15° 15°C 15°C 4.5 – 1000 ***   –– – –

Silk 30°C - 30°C 1.0 –

- ***   – – – –

Wool 40°C - 40°C 800 2.0 –

***   –– – –

Delicates 30°C - 30°C - 1.0 –

***   –– – –

Synthetics 40°C - 60°C 1200 4.5 –

175     35 0,80 55

 Dosing required Dosing optional
