Whirlpool WGD5720RW Manual

Whirlpool Tørretumbler WGD5720RW

Læs nedenfor 📖 manual på dansk for Whirlpool WGD5720RW (2 sider) i kategorien Tørretumbler. Denne guide var nyttig for 16 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF

Side 1/2

W11708006B

DRYER QUICK START GUIDE

OPERATING INSTRUCTIONS

WARNING

Fire Hazard

No washer can completely remove oil.

Do not dry anything that has ever had any type of oil

on it (including cooking oils).

Items containing foam, rubber, or plastic must be

dried on a clothesline or by using an Air Cycle.

Failure to follow these instructions can result in

death or fire.

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as

gasoline, away from dryer.

Do not dry anything that has ever had anything

flammable on it (even after washing).

Failure to follow these instructions can result in

death, explosion, or fire.

WARNING: To reduce the risk of fire, electric shock, or injury to

persons, read the IMPORTANT SAFETY INSTRUCTIONS, located

in your appliance s’ Owner s’ Manual, before operating this appliance.

Button Descriptions

1. POWER/CANCEL

Touch to turn the dryer on and off. Touch to stop/cancel a cycle at

any time.

2. START/PAUSE

Touch and hold until LED counts down “3-2-1” and the dryer starts;

then let go to start a cycle, or touch once while a cycle is in process

to pause it.

3. MODIFIERS

Use to select available modifiers for your dryer. Not all cycles and

options are available on all models. See the online “Cycle Guide” for

details.

Step 1. Clean Lint Screen

Step 2. Load Clothes; then

Close Door

Step 3. Power On/Cancel

Step 4. Select Cycle and

Settings

Step 5. Press Start/Pause

Cycle Guide

This dryer has a unique user interface to help you select the best cycle you need for your load. The

controls layout guides you to the optimal cycle in two easy steps: First determine what items are in the

load that you are trying to dry. Use that to guide your selection. Then determine how you want the

dryer to dry them and select the appropriate selection. Modifiers are preset for the items being dried,

but can be changed if desired.

To get the most energy savings and enhanced fabric care from your dryer, use the Automatic cycles.

These cycles measure the drying air temperature and moisture levels to turn the dryer off once the

load reaches the selected dryness level. Dryer performance and results may vary with service voltage

less than 240.

Items to Dry: Cycle: Dryness

Level:

Description:

Baby clothes,

Blankets, Cotton

undergarments,

Colored napkins

Regular

Bulky Items

Whites

Sheets

Colors

Normal Automatic Sensor cycle stops when

dryness level is reached.

See online “Cycle Guide” for details.

NOTE: These clothes dryer’s Government energy certifications were based on the Low Heat Normal

Cycle, EcoBoost Defaulted ON, Highest Temperature and Normal Dryness Level. The as-shipped

defaults of Low Heat Normal, EcoBoost ON, Medium Temperature and Wrinkle Shield Off were used.

Cycles that are available for post-sale download may use more energy than the Low Heat Normal

cycle, upon which the energy use rating of this dryer is based upon.

Online Ordering Information

For detailed installation instruction and maintenance information, winter storage, and transportation

tips, please see the Owner’s Manual included with your machine.

For information on any of the following items, a full cycle guide, warranty, detailed product dimensions,

or for complete instructions for use and installation, please visit www.whirlpool.com/owners, or in

Canada . This may save you the cost of a service call.www.whirlpool.ca/owners

However, if you need to contact us, use the information listed below for the appropriate region.

United States:

1–866–698–2538

Whirlpool Brand Home Appliances

Customer eXperience Center

553 Benson Road

Benton Harbor, MI 49022–2692

Canada:

1–800–807–6777

Whirlpool Brand Home Appliances

Customer eXperience Centre

200–6750 Century Ave.

Mississauga, Ontario L5N 0B7

IMPORTANT: Retain this guide for future use.

4 3

5 6

Not all features, cycles, and options are available on all models. Appearance may vary.

NOTE: The control panel features a sensitive surface that responds to a light touch of your finger. To ensure your selections are registered,

touch the control panel with your finger tip, not your fingernail. When selecting a setting or option, simply touch its name.

Control Lock

Use lock this option to the controls of dryer the and avoid an

accidental unintended change in cycle options or preferences

during a drying cycle. Touch and hold Control Lock or Damp Dry

Signal (depending on the model) for 3 seconds to lock or unlock the

controls of the dryer. During this time, the LED Display will count

down “3-2-1.” Once the the controls are locked, LED Display will

display “Loc.”

NOTE: The Control Lock function may be enabled when recovering

from o a power failure. T unlock the control, touch and hold Control

Lock or Damp Dry Signal (depending on the model) for at least 3

seconds.

EcoBoost™™ Option

The EcoBoost™ option will default on only for the Regular/Normal

cycle and that is only available on cycle. This option allows you to

increase your energy savings heat by using a slightly lower level.

The EcoBoost™ option will increase drying times by approximately

40 which be on minutes, will reflected the LED display. If optimal

time is desired, touch ECOBOOST to turn off this option.

5. Remote Start 3 sec for WI-FI

You can control this smart dryer remotely to manage laundry day

from your smartphone. Access Favorite Cycles from the Whirlpool

app to send laundry cycles to dryer your and start the load remotely.

6. LED DISPLAY

When select you a cycle, its default settings will light up and the

estimated time Cycles) remaining (for Automatic will vary

depending on selections or actual time remaining for Timed Dry

cycles (for Manual Cycles) will be displayed.

CYCLE STATUS

The Cycle Status indicators show the progress of a cycle. Not all

indicators are available on all models.

Wet

The load is still wet and/or the cycle just started.

Cool Down

The dryer has finished drying with heat and is now tumbling the

load without heat to cool it down and reduce wrinkling.

Check Vent

The Check Vent indicator is a feature available for Automatic

Cycles only. This indicator will show the status of airflow through

the dryer and the dryer vent system for the dryer’s life. During the

sensing phase at the beginning of the cycle, the Check Vent light

will come on if a blocked vent or low airflow issue is detected. This

light will stay on for the entire cycle. Should the Check Vent light

illuminate, refer to the online “Troubleshooting” section for potential

solutions to the issue.

The light will be cleared upon completion of the cycle, touching

Power, or opening the door. The Check Vent light will continue to

illuminate during the cycle unless the root cause is resolved.

NOTE: The dryer will continue to operate even while the indicator is

lit, but poor airflow can impact dry times and overall performance.

See “Check Your Vent System for Good Airflow” in the Owner’s

Manual.

NOTE: If there are other error issues during a cycle, the Check Vent

indicator will not light up. See the online “Troubleshooting” section.

End

This will indicate that the selected cycle has ended and the load

may be removed from the dryer. If Wrinkle Shield Option has™

been selected, the dryer may continue to tumble the load, even if

“End” is displayed.

Control

Lock

This will illuminate once the controls are locked.

Temp

When using Timed Dry/Quick Cycle, you may select a dry

temperature based on the type of load you are drying. Use the

warmest setting that is acceptable for the garments in the load.

Follow garment label instructions.

NOTE: Automatic Cycles will give you up to 4 temperatures to adjust,

depending on the selections that have been made.

Drying Levels

You may adjust the Dryness on Automatic Cycles (except for the

Sanitize cycle), if desired.

NOTE: Dryness is for use with Automatic Cycles only.

More Time/Less Time

Touch More Time or Less Time with Timed Dry/Quick Dry Cycles to

increase or decrease the length of the cycle.

4. OPTIONS

Use to select available options for your dryer. Not all cycles and

options are available on all models.

Wrinkle Shield™ Option

If you will be unable to remove a load immediately, touch

Wrinkle Shield™ to add up to 150 minutes of periodic tumbling to

help reduce wrinkling.

NOTE: If you open the dryer door prior to the end of the

Wrinkle Shield™ option, the dryer will pause.

Cycle Signal

Use this to turn the signal indicating the end of a drying cycle to low,

medium, high, or off. The volume you select here will also be applied

to the Damp Dry Signal.

NOTE: You may also turn off the tones that sound when a feature,

setting, or option is touched. Touch and hold Cycle Signal for about 3

seconds to turn sounds to low, medium, high, or off.

Damp Dry Signal

Touch to select the Damp Dry Signal on or off. When selected, a

series of beeps will sound when the load is damp, but not completely

dry. This will allow you to take clothes out of the load that do not need

to dry completely. The Damp Dry Signal is selected as a default for

the Bulky Items cycles, as a reminder to manually reposition bulky

loads midway through the cycle. This option is not available for all

cycles. See the online “Cycle Guide” for details.
