Side 1/3
1
ZTE MF62
User Manual
2 4 5 6 73 8 9
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057 Tel: +86-755-26779999
URL: http://www.zte.com.cn E-mail: mobile@zte.com.cn
Introduction
ZTE MF62 is a 3G/2G mobile hotspot device, working in GSM/GPRS/
EDGE/WCDMA/HSPA/HSPA+ network. The client devices could connect to
it via USB or Wi-Fi interface. The device supports data and SMS services,
enabling you to communicate anytime and anywhere.
This manual provides instructions on how to install and get started with the
product. For information about connection of services, please consult your
service provider.
Specication
Data Service
HSPA+: DL 21.6Mbps,
UL 5.76Mbps
WCDMA CS: 64kbps UL/DL
WCDMA PS: 384kbps UL/DL
Interface USB and Wi-Fi
Wi-Fi Standard 802.11b/g
Wi-Fi Security WEP/WPA/WPA2
USB Version USB 2.0 HIGH SPEED
USB Interface Type Micro USB
Weight 86g
Dimensions (W×H×D): 99.6mm*54mm*14.6mm
microSD card Support up to 32GB microSD card
Power Adapter 5V/700mA
Battery 1500mAh
*Standby time 100hours
*Working time 4hours
Operate system Windo ws 7, Windows Vista(32bit o r 6 4bit ),
Windows XP (SP2 or later), MAC (10.4 or later)
Web Browser IE (7.0 or later), Firefox (2.0 or later), Opera (10.0
or later), Safari (4.0 or later), Chrome (5.0 or later)
Operating temperature 0ºC ~ +35ºC
Storage temperature -20ºC ~ +50ºC
Charging temperature 0ºC ~ +45ºC
Humidity 5%~ 95%
Notes:
microSD is a trademark of SD Card Association.
The device’s standby and working time are only for your reference, and
based on ideal working environment.
Getting to Know Your Device
The following gure shows the appearance of the device, it is only for your
reference. The actual device may be different.
Right Side Front Left Side Bottom
Interface and Buttons
1. Power Hold the button to switch on/off the device.Power
2. Memory card slot
(microSD card)
It is where you insert the memory card (microSD
card).
3. WPS
This button is used to start/end Wi-Fi Protected
Setup authentication process and enable/disable
the Wi-Fi function.
• Hold it for 3 seconds to activate the WPS
function.
• When the WPS function is available, press it to
deactivate the WPS function.
• Press it to enable/disable Wi-Fi function.
4. LED Screen It indicates the signal type, signal strength, battery,
Wi-Fi, etc.
5. External Antenna
Connector
It is used to connect an external antenna to
enhance the signal strength.
6. Charger/USB port • Charge your device.
• Connect the client to your device via USB cable.
Notes:
• Hold the WPS Power and buttons simultaneously until the LED
screen turns off, and then release the buttons. The device will restart
automatically and restore to the factory default settings.
• Please use the original external antenna if necessary.
LED Indicator
When the device is powered on, the following icons will appear on the LED
screen, with the corresponding indicates listed in the table below:
Icon Indication
Network signal strength.
Network type. 2G or 3G icon will appear on the LED
screen according to the network being connected.
Connect to the Internet automatically.
Connect to the Internet manually.
Roaming network indication.
New message received.
Wi-Fi Status and number of the connecting users.
Battery power indication.
Hardware Installation
Inserting SIM Card and Battery
1. Slide the back cover and remove it.
2. Insert the SIM card into the SIM card holder.
3. Insert the battery as shown with the contacts located against the metal
springs, and press the battery down into the case.
4. Slide the back cover and lock the cover in its place.
Inserting microSD Card
1. Pull the microSD cover out of the card slot.
Notes:
Do not pull the cover rudely, as it is connected with the device.
2. Insert the microSD card into the microSD slot. The following picture
shows the correct inserting direction. You will hear a click when the
microSD card locks in place.
3. Close the microSD cover.
Switching On/Off Your Device
Hold the button to switch on/off the device.Power
Notes:
The device is powered on when the LED screen lights up.
Charging Your Device
You can charge your device by using USB cable or adapter.
1. Insert the charger lead carefully.
2. The plug only ts one way. Do not use excessive force to insert the plug.
LEGAL INFORMATION
Copyright © 2011 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without the prior written permission of ZTE
Corporation.
The manual is published by ZTE Corporation. We reserve the right to make
modications on print errors or update specications without prior notice.
Version No. : R1.0
Establish a connection between your device and
the client
Via USB Cable
1. Connect your device and the client with the USB cable.
2. Power on your device.
3. Follow the system prompts to complete the software installation.
Notes:
• If the system does not launch installation automatically, you can run the
installation program in path of My Computer > Mobile Hotspot.
• The driver of your device will be installed at the same time.
4. After the installation, the system will create a shortcut icon on your
desktop and a program group in the Mobile Hotspot Start→Programs
menu. The connection between your device and the client will be
established successfully a moment later.
Via Wi-Fi
1. Power on your device directly. It will take 1~2 minutes to initialize.
2. Use your normal Wi-Fi application on the client to search the available
wireless network.
Notes:
You need to check your Wireless Network Connection. Set the client
to obtain an IP address automatically in the Internet protocol (TCP/IP)
properties, and the client will get an IP address like “192.168.0.100”.
Working Mode
Your device supports three working modes. For the client, we only use PC or
laptop as the example in this document.
USB Mode: Connect to the device with the USB cable.
Wi-Fi Mode: Connect to the device via Wi-Fi.
Mixed Mode: Connect to the device with the above two connection methods.
Notes:
If you want to connect to the Internet by using Wi-Fi mode, make sure that
the client supports the Wi-Fi function.
The following picture is the application example. All of the client devices can
surf on the Internet at the same time.
