Side 1/3
Magnetic Front Panel
Removable Dust Filter
4x 120mm Fans
Glass Side Panel
2.5” HDD/SSD Brackets
2.5” / 3.5” HDD/SSD Tray
A
B
C
A
B
C
C
D
D
E
F
E
F
تﺎﻔﺻاﻮﻤﻹا
EN DESPECIFICATIONS TECHNISCHE DATEN ES ESPECIFICACIONES
RU ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ
KR 사양 JP 仕様 繁體 規格
简体 规格
FR SPÉCIFICATIONS
PT ESPECIFICAÇÕES
AR
TU TEKNİK ÖZELLİKLER
VALOR MESH Chassis
x18
x6
Motherboard & SSD Screws
PSU Screws
HDD Screws
Motherboard Standoff
Nut Setter
2.5”/3.5” HDD/SSD Tray
Cable Ties
x8
x3
x5
x1
ةﻮﺒﻌﻹا تﺎﻳﻮﺘﺤﻣ
EN PACKAGE CONTENTS DE LIEFERUMFANG
ES CONTENIDO DEL PAQUETE RU КОМПЛЕКТНОСТЬ
KR 패키지�콘텐츠 JP パッケージの内容
KR 액세서리�박스�콘텐츠
JP 付属品ボックスの内容
繁體 包裝內容物 简体 包裝內容
繁體 配件 简体 配件
FR CONTENU DE L’EMBALLAGE
PT CONTEÚDO DO PACOTE
AR
1.
Accessory Box
3.
VALOR MESH Quick Installation Guide
2.
EN ACCESSORY BOX CONTENTS
FR CONTENU DE LA BOÎTE D’ACCESSOIRES ES CONTENIDO DE LA CAJA DE ACCESORIOS
PT CONTEÚDOS DA CAIXA DE ACESSÓRIOS RU СОДЕР ЖИМОЕ КОРОБКИ ДЛЯ ПРИНАДЛЕЖНОСТЕЙ
TU AKSESUAR KUTUSU İÇERİĞİ AR تاراﻮﺴﺴﻛﻹا ﺔﺒﻼﻋ تﺎﻳﻮﺘﺤﻣ
DE MITGELIEFERTES ZUBEHÖR
TU PAKET İÇERİĞİ
Power
Button
USB 3.0 Connector
(USB 3.2 Gen 1)
Audio Connector
Power Connector
Power LED Connector
Reset Connector
HDD LED Connector
Reset
Button
Hybrid
Audio Port
2 X USB 3.2 Gen 1
KR 전면 I/O 포트, 버튼�및�케이블 JP フロントI/Oポート、ボタンおよびケーブル
繁體 I/O介面埠與線材 简体 I/O面板接口与线材
AR ﺔﻴﻣﺎﻣﻷا جﺮﺨﻹا ﻞﺧﺪﻹا ﺬﻓﺎﻨﻣو تﻼﺑﺎﻜﻹاو رارزﻷا/
EN FRONT I/O PORTS, BUTTONS and CABLES
FR PORTS E/S FRONTAUX, BOUTONS et CÂBLES
ES PUERTOS, BOTONES y CABLES DE E/S FRONTALES
PT PORTAS DE E/S FRONTAIS, BOTÕES e CABOS
RU ФРОНТАЛЬНЫЕ ПОРТЫ ВВОДА/ВЫВОДА, КНОПКИ И КАБЕЛИ
TU ÖN G/Ç BAĞLANTI NOKTALARI, DÜĞMELER VE KABLOLAR
DE VORDERE I/O-ANSCHLÜSSE, TASTEN UND KABEL
KR 크기�및�호환성 JP 寸法と互換性
繁體 尺寸和支援度 简体 尺寸和兼容性
AR ﻖﻓاﻮﺘﻹاو دﺎﻌﺑﻷا
EN DIMENSIONS and COMPATIBILITY
FR DIMENSIONS et COMPATIBILITÉ
ES DIMENSIONES y COMPATIBILIDAD
PT DIMENSÕES e COMPATIBILIDADE
RU РАЗМЕРЫ И СОВМЕСТИМОСТЬ
TU BOYUTLAR VE UYUMLULUK
DE ABMESSUNGEN UND KOMPATIBILITÄT
VGA Length
CPU Air Cooler Height
PSU Length
Up to 305mm ( )with pre-installed fans
Up to 166mm
160mm - 180mm
KR 전면�패널�및�먼지�필터�제거 JP 前面パネルとダストフィルターの取り外し
繁體 拆裝前面板與濾網 简体 拆卸前面板與滤网
AR ﺔﺑﺮﺗﻷا ﺢﺷﺮﻣو.ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮﻼﻹا ﻚ
ُﻓ
EN REMOVING THE FRONT PANEL AND THE DUST FILTER
FR DÉPOSE DU PANNEAU AVANT et DU FILTRE À POUSSIÈRE
ES QUITAR EL PANEL FRONTAL y EL FILTRO DE POLVO
PT REMOVENDO O PAINEL FRONTAL e O FILTRO DE POEIRA
RU СНЯТИЕ ПЕРЕДНЕЙ ПАНЕЛИ И ВОЗДУШНОГО ФИЛЬТРА
TU ÖN PANELİN VE TOZ FİLTRESİNİN ÇIKARILMASI
DE FRONTBLENDE UND STAUBFILTER ABNEHMEN
KR 유리�측면�패널�제거 JP ガラス製側面パネルの取り外し
繁體 拆裝玻璃側板 简体 拆卸玻璃侧板
AR ﺔﻴﺒﻧﺎﺠﻹا ﺔﻴﺟﺎﺟﺰﻹا ﺔﺣﻮﻼﻹا ﺔﻹازإ
EN REMOVING THE GLASS SIDE PANEL
FR DÉPOSE DU PANNEAU LATÉRAL EN VERRE
ES QUITAR EL PANEL LATERAL DE VIDRIO
PT REMOVENDO O PAINEL LATERAL DE VIDRO
RU СНЯТИЕ СТЕКЛЯННОЙ БОКОВОЙ ПАНЕЛИ
TU CAM YAN PANELİN ÇIKARILMASI
DE GLASSEITENBLENDE ABNEHMEN
KR 전원�공급�장치�설치 JP 電源装置の取り付け
繁體 安裝電源 简体 电源安装
AR ﺔﻗﺎﻄﻹﺎﺑ داﺪﻣﻹا رﺪﺼﻣ ﺐﻴﻛﺮﺗ
EN POWER SUPPLY INSTALLATION
FR INSTALLATION DE L’ALIMENTATION
ES INSTALACIÓN DE LA FUENTE DE ALIMENTACIÓN
PT INSTALAÇÃO DA FONTE DE ALIMENTAÇÃO
RU УСТАНОВКА БЛОКА ПИТАНИЯ
TU GÜÇ KAYNAĞI KURULUMU
DE NETZTEIL INSTALLIEREN
Website QSG
VALOR MESH
COMPACT MID-TOWER CHASSIS
3.5" Drive Bay 2
PCI-E Slots 7 Horizontal
2.5” Drive Bay
Fan Pre-Installed 120mm x4
I/O Ports 2 x USB 3.2 Gen 1, 1 x Hybrid Audio Port
1 x Reset Button, 1 x Power Button
2+1 (Combo 3.5” / 2.5”)
Color
Form Factor
Black / White
Side Panels 3mm Tempered Glass (Left Side)
Dimensions
(H x W x D)
460 x 210 x 371mm
18.10 x 8.28 x 14.60inch
Mini-ITX, Micro-ATX, ATX
Material SPCC
Radiator Support
FRONT
TOP
REAR
360 / 280 / 240mm x 1
240mm x 1
120mm x 1
Fan Mounts
FRONT
TOP
REAR
140mm x 2 / 120mm x 3
140mm x 2 / 120mm x 2
120mm x 1
x1
Up to 305mm (with pre-installed fans)
Compatibility
VGA Length : Up to 335mm
CPU Air Cooler Height : Up to 166mm
PSU Length : 160mm - 180mm
Up to 305mm (with pre-installed fans)
460mm
210mm371mm
Mini-ITX Micro-ATX ATX
1. 2.
3. 4.
