READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH

INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

OSCILLATING CERAMIC TOWER HEATER

with REMOTE CONTROL

MODEL 2PY99/8132

IMPORTANT INSTRUCTIONS - OPERATING MANUAL MODEL 2PY99/8132

DESCRIPTION

The AirKing Oscillating Ceramic Heater features 2 heat settings and a

fan only setting. The heater oscillates 120 and comes with a remote°

control for convenience. This unit also features a built in timer to allow up

to 7 hours of operation before automatic shutdown and comes with a 6ft.

(1.82m) 16/3 grounded cordset.

SPECIFICATIONS

Motor..................................120 V/60 Hz

Control................................Manual/Remote

Settings...............................High and Low Heat; Fan only

Air Flow Distribution............120˚

Approvals............................UL/CUL listed. Close mesh

blower guard meets OSHA requirements.

Rev. B 12/05 1 8132ESF Rev. B 12/05 2 8132ESF

GENERAL SAFETY INFORMATION

1. Read all instructions before using Heater.

2. Use this Heater only as described in this manual. Any other use not

recommended by the manufacturer may cause fire, electrical shock, or

injury to persons.

3. Make certain that the power source conforms to the electrical require-

ments of the Heater.

4. Extreme caution is necessary when any Heater is used by or near

children or invalids and whenever the Heater is left operating unat-

tended.

5. The power cord is equipped with a three-prong grounded plug that must

be inserted into a matching receptacle Under no circumstances . should

the ground prong be cut off the plug. Where a two-prong wall recep-

tacle is encountered, it must be replaced with a properly grounded

three-prong receptacle installed in accordance with the National Elec-

trical Code (NEC) and all applicable local codes and ordinances. This

work must be done by a qualified electrician, using copper wires only.

DO NOT USE A THREE-PRONG ADAPTER. IMPROPER CONNEC-

TION MAY CAUSE THIS RISK OF ELECTROCUTION. USE OF SUCH

ADAPTERS IS NOT PERMITTED IN CANADA.

6. Where possible, avoid the use of extension cords because the exten-

sion cord may overheat and cause a risk of fire. If they must be used,

minimize the risk of overheating by ensuring that they are UL listed, a

minimum No. 14 AWG, rated not less than 1875 watts. Never use a

single extension cord to operate more than one Heater.

7. Do not operate any Heater with a damaged cord or plug or after the Heater

malfunctions, has been dropped or damaged in any manner. Return Heater

to authorized service facility for examination, electrical or mechanical ad-

justment or repair.

8. Unplug power cord before servicing or moving the Heater. Always un-

plug Heater when not in use.

WARNING: DO NOT DEPEND ON THE ON/OFF SWITCH AS

THE SOLE MEANS OF DISCONNECTING POWER WHEN SER-

VICING OR MOVING THE HEATER. ALWAYS UNPLUG THE

POWER CORD.

9. Do not insert or allow fingers or foreign objects to enter any ventilation

or exhaust opening as it may cause an electric shock or fire, or damage

the Heater. Do not block or tamper with the Heater in any manner while

it is in operation.

10. To prevent a possible fire, do not block air intakes or exhaust in any

manner. Do not place on soft surfaces, like a bed, where openings may

become blocked.

11. Always place the Heater on a stable, flat, level surface when operating, to avoid

the chance of the Heater overturning. Locate the Power Cord so the Heater or

other objects are not resting on it. Do not run Power Cord under carpeting. Do

not cover Power Cord with throw rugs, runners, or the like. Arrange Power

Cord away from room traffic and where it will not be tripped over.

12. This Heater is hot when in use. To avoid burns, do not let bare skin

touch hot surfaces. Always use handle when moving this Heater. Keep

combustible materials, such as furniture, pillows, bedding, papers, clothes

and curtains at least 3 feet (0.9 m) from the front of the Heater and keep

them at least 1 foot (0.3 m) from the sides and rear.

13. A Heater has hot and arcing or sparking parts inside. It must NOT be

used in potentially dangerous locations such as flammable, explosive,

chemical-laden or wet atmospheres. This Heater is intended for gen-

eral use ONLY.

14. This Heater is not intended for use in wet or damp locations. Never

locate a Heater where it may fall into a bathtub or other water container.

15. Do not use Heater outdoors.

WARNING: REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK – DO NOT USE THIS HEATER WITH ANY SOLID STATE

SPEED CONTROL DEVICES.

SAVE THESE

INSTRUCTIONS

Oscillation Function:

1. Pressing the

Oscillation Button

(OSC)

will allow the Heater to

oscillate back and forth. To stop the oscillation, press the

Oscil-

lation Button

(OSC)

once again.

OPERATION

(Figure 1)

1. Carefully remove the Heater from the plastic bag and the carton.

2. Place the Heater on a firm and level surface.

WARNING: Plastic or rubber tabs, like the feet on this unit, may

stick to furniture surfaces and/or hardwood floors. The unit may

leave a residue that could darken, stain or leave permanent blem-

ishes on the finish of certain furniture surfaces, including wood sur-

faces, and/or hardwood floors.

3. Plug the cord set into a 120V electrical outlet. Be sure plug fits

tightly in outlet.

4. When the Heater is initially plugged in, there will be a ‘beep’ and

the

Power Light

will come on indicating that there is power to

the unit. The

Power Light

will remain lit until the Heater is un-

plugged from the electrical outlet.

5. Turn the Heater ON by pressing the

Power Button

6. When initially turned on, the Heater will be in

High

heat (1500

Watts) on

Max

. (The High light will be steady and the Max light

will be blinking).

7. Press the

Power Button

once and the Heater will be in

Low

Heat (900 Watts), indicated by the steady light beside

Low

8. Pressing the

Power Button

a third time will turn the Heater OFF.

9. When the Heater is turned OFF, the red light on the Heater will

remain lit until the Heater is unplugged from the electrical outlet.

Timer Function

(Figure 2)

1. The Timer Function may be activated when the Heater display is

in any speed or temperature. This function allows you to set the

length of time the Heater will run before turning itself off, from 1

hour to 7 hours. Pressing the

Timer Button

will increase the length

of time, in combinations of 1, 2 and 4 hours. Continuously press-

ing the button will result in the timer being set for 7 hours. The

Heater will turn off when the set time has elasped. The unit can

be turned back on by pressing the

Power Button

Temperature Function

(Figure 2)

1. To set the room at a specific temperature, press the

Tempera-

ture Button (TEMP)

to the desired setting. The light under the

chosen temperature will continue to blink until the room reaches

the desired temperature.

Figure 1

Display when Heater is initially turned on

Temperature Function

Figure 2

Figure 3

Timer Function

REMOTE CONTROL:

All the functions performed with the Remote Control work identically

to the manual controls.

(Figure 4)

1. Install the two “AAA” batteries supplied.

2. Do not mix old and new batteries. Do not mix alkaline, standard

(carbon-zinc) or rechargeable (nickel-cadmium) batteries.

SAFETY FEATURE

1. A thermal overload protector is built in to prevent overheating.

2. When an overheat temperature is reached, the Heater will be

automatically shut off. It can only resume operation when the

user resets the unit.

To Reset Heater:

1. Unplug the Heater and wait 10 minutes for the Heater to cool down.

2. After the Heater has cooled down, plug the unit into a 120V~

electrical outlet and follow the operation instructions described

in this manual.

TROUBLE SHOOTING TIPS

If your heater shuts off unexpectedly or fails to operate, the

previously mentioned safety feature may have been activated to

prevent overheating.

1. Be sure the power cord is plugged into a working electrical outlet.

2. Check your Thermostat setting. The Heater may be off because

it has reached the desired temperature setting.

MAINTENANCE

WARNING: ALWAYS UNPLUG THE CORD BEFORE MOV-

ING OR SERVICING.

WARNING: DO NOT IMMERSE HEATER IN WATER.

CLEANING: IMPORTANT! Clean the Heater grill and side in-

takes with the vacuum brush attachment of your vacuum cleaner.

This will remove lint and dirt from the inside of the Heater. Clean

the body of the Heater with a soft cloth.

DO NOT ATTEMPT TO TAKE APART THE HEATER.

CAUTION: Do not use gasoline, benzine, thinner, harsh

cleaners, etc., as they will damage the Heater. NEVER

use ALCOHOL OR SOLVENTS.

SERVICING: All other servicing, with the exception of general

user-maintenance, should be performed by an authorized ser-

vice representative.

STORAGE: Store the Heater with these instructions in the original

carton in a cool, dry place.

MODEL

2PY99/8132

SETTINGS

HIGH LOW FAN

BTU 5118 3070 Ø

Amps 12.5 7.0 0.288

Watts 1500 900 33.4

dB A 47 <40 47

( ) = More Heat

( ) = Less Heat

( ) = Power

( ) = Oscillation

( ) = High / Low Setting

( ) = Timer

Figure 4

Front View

of Remote

Back View

of Remote
