AirLive OD-2050HD

Live OD-2050HD

2-MegaPixel IR Outdoor Vandal

PoE IPCAM

Use

’s Manual

AirLive OD-2050HD

Owner's Record

The model and serial numbers are located at the bottom of device. Record these numbers

in the spaces provided below. Refer to these numbers whenever you call upon your dealer

regarding this product.

Model No. ____________________

Serial No. ____________________

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing to

qualified personnel only.

AirLive OD-2050HD ii

Notice: The changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the

equipment.

For customers in the U.S.A.

This equipment has been tested and found to comply with the limits for a digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

– Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in this

manual could void your authority to operate this equipment.

The shielded interface cable recommended in this manual must be used with this

equipment in order to comply with the limits for a digital device pursuant to Subpart B of

Part 15 of FCC Rules.

Declaration of Conformity

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

AirLive OD-2050HD

iii

IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no

change to the antenna or the device is permitted. Any change to the antenna or the device

could result in the device exceeding the RF exposure requirements and void user’s

authority to operate the device.

NOTICE TO USERS

part, may not be reproduced, translated or reduced to any machine readable form without

prior written approval.

WE PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE

OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY

DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR

ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE OR

SUCH OTHER INFORMATION. IN NO EVENT SHALL WE BE LIABLE FOR ANY

INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, WHETHER BASED ON

TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH

THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR

THE USE THEREOF.

We reserve the right to make any modification to this manual or the information contained

herein at any time without notice. The software described herein may also be governed by

the terms of a separate user license agreement.

Table of Contents

i AirLive OD-2050HD

Table of Contents

1. Introduction.................................................................................................................1

1.1 Overview..............................................................................................................1

1.2 Package Contents ...............................................................................................2

1.3 Connections.........................................................................................................3

1.4 Mounting the Camera ..........................................................................................5

2. Preparation..................................................................................................................6

2.1 Search and Set up by IPWizard II........................................................................6

2.1.1 Search .......................................................................................................6

2.1.2 View...........................................................................................................7

2.1.3 LAN ...........................................................................................................8

2.2 UPnP of Windows® XP, Vista or 7.......................................................................9

2.3 Install the Device behind a NAT Router .............................................................10

2.4 Access the Device from the Internet Explorer for the First Time ........................11

2.5 Logging in as an User........................................................................................12

2.6 Logging in as an Administrator ..........................................................................12

3. Operating the Network Camera ...............................................................................13

4. Administrating the Device........................................................................................18

4.1 Network: Configure Network Settings ................................................................19

4.1.1 Network ...................................................................................................19

4.1.2 HTTPS.....................................................................................................20

4.1.3 DDNS Service .........................................................................................21

4.1.4 PPPoE.....................................................................................................22

4.1.5 Streaming ................................................................................................23

4.1.6 UPnP .......................................................................................................24

4.1.7 Bonjour ....................................................................................................26

4.1.8 ONVIF......................................................................................................26

4.1.9 IP Filter ....................................................................................................27

4.1.10 IP Notification ........................................................................................28

4.2 Camera: Adjust Camera Parameters.................................................................30

4.2.1 Picture .....................................................................................................30

4.2.2 Privacy Mask ...........................................................................................32

4.2.3 PTZ Setting..............................................................................................33

4.2.4 Preset Setting ..........................................................................................34

4.2.5 Tour Setting.............................................................................................34

4.3 System: Configure and Maintain System...........................................................35

4.3.1 System ....................................................................................................35

4.3.2 Date & Time.............................................................................................36

Table of Contents

AirLive OD-2050HD ii

4.3.3 Maintenance ............................................................................................38

4.4 Video: Configure Profile.....................................................................................40

4.4.1 Common..................................................................................................40

4.4.2 Video Profile ............................................................................................41

4.4.3 ROI ..........................................................................................................42

4.5 Audio: Audio Parameters ...................................................................................42

4.6 User: Manage User Name, Password and Login Privilege ................................43

4.7 E-Mail: Setup E-Mail Configuration....................................................................44

4.8 Object Detection: Setup Object Detection .........................................................45

4.9 Storage ..............................................................................................................46

4.10 Event Server: Setup FTP/TCP/HTTP/SAMBA Server Configuration ...............47

4.11.1 FTP Server ............................................................................................47

4.11.2 TCP Server............................................................................................48

4.11.3 HTTP Server..........................................................................................49

4.11.4 SAMBA Server ......................................................................................50

4.11 Event Schedule: Configure the Event Schedule ..............................................51

4.12.1 Setting ...................................................................................................51

4.12.2 Record...................................................................................................54

5. Appendix....................................................................................................................56

Appendix A: Alarm I/O Connector ............................................................................56

Appendix B: Troubleshooting & Frequently Asked Questions..................................58

Appendix C: PING IP Address .................................................................................63

Appendix D: Bandwidth Estimation..........................................................................64

Appendix E: Specifications ......................................................................................65

Appendix F: Configure Port Forwarding Manually ...................................................67

Appendix G: DDNS Application ...............................................................................70

Appendix H: Power Line Frequency ........................................................................75

Appendix I: 3GPP ....................................................................................................77

Appendix J: Enable UPnP of Windows XP ..............................................................78

1. Introduction

AirLive OD-2050HD User’s Manual

1. Introduction

1.1 Overview

The OD-2050HD is the high-end network camera with IP66 rated weather and vandal

proof housing. The built-in IR LED can provide additional light source when the

environment is dim or even dark. It also equips a 3~9mm varifocal lens and can be used in

various situations, no matter the installer needs a wide angle or a telescopic view.

OD-2050HD is a member of AirLive's 2.0 Mega pixels IP camera family With its full blown

network functions, such as H.264 video streaming, Power over Ethernet, and ONVIF, it can

be easily integrated into your existing network. What's more, installer can also choose

AirLive's NVR or CamPro Professional as the back-end recording solution, and take it into

middle-to-large surveillance project.

The video quality of OD-2050HD can be up to 1080P@30fps, which means it can provide

a smoother and more detailed image. The high video quality can help user to review the

recorded events in a more clear and distinct way. OD-2050HD suites applications such as

parking lots, warehouses, loading/unloading bays, seaports and airports.

1. Introduction

AirLive OD-2050HD User’s Manual 2

Features

 16:9 Full HD Video Resolution, Support up to 1080P@30fps

 IP66 Weather and Vandal Proof housing for Outdoor Environment

 Built-in IR LED and IR-Cut Removable for Day & Night Use

 Support 802.3af Power over Ethernet

 With 3~9mm, Auto Iris, Varifocal Lens for Wide or Telescopic View

 UPnP for Fast and Easy Installation

 Support Two-Way Audio

 Multiple H.264, Motion JPEG and MPEG-4 Video Streams

 With Free Bundle 64 Channel Surveillance Software

 Use in Hallway, Warehouses, Loading/Unloading Bays and Lobby

Minimum System Requirements

 Microsoft Internet Explorer 7.0 or later

 Microsoft Media Player 11.0 or later (to playback recorded file)

 VGA Monitor resolution 1280 x 1024 or higher

 Pentium-4 3.6 GHz or higher

 Memory Size: 1GB or more

 Windows XP, Vista, 7

1.2 Package Contents

User can find the following items in the package:

Item Descriptions

OD-2050HD

Power Adapter dedicates 12V DC electric

power output to Network Camera.

User’s Manual CD provides installation

software, application program, important

information and instructions for operating the

Network Camera.

1. Introduction

AirLive OD-2050HD User’s Manual

Quick Start Guide provides important

information and instructions for installing this

device.

Note: Using a power supply with a different voltage than the one included with the Network

Camera will cause damage and void the warranty for this product.

1.3 Connections

OD-2050HD

1. RJ45 LAN socket

Connect to PC or Hub/Switch.

For connections to 10Base-T Ethernet or 100Base-TX Fast Ethernet cabling. This Ethernet

port built N-Way protocol can detect or negotiate the transmission speed of the network

automatically. Please use Category 5 cable to connect the Network Camera to a 100Mbps

Fast Ethernet network switch or hub.

In the LAN socket, there are two LEDs embedded:

LAN LED (green color)

This LED will be flashing while network accessing via Ethernet.

1. Introduction

AirLive OD-2050HD User’s Manual 4

Power (orange color)

This LED is used to indicate whether DC power is on or not. In addition, this LED will be

flashing while the wireless accessing of the Camera.

2. DI/DO connector

DI/ DO: Connect to sensor in and alarm out devices

Name Cable Color Function

12VDC Brown/White DC 12V (50mA maximum)

GND Blue/White GND

NC Purple/White Do not connect

NC Gray Do not connect

DI Green/White Digital signal input

DO Orange/White Digital signal output

3. Factory Default Reset

This button is used to restore the all factory default settings. Sometimes restarting the

device will make the system back to a normal state. However, if the system still got

problems after restart, user can restore the factory default settings and install it again.

Restore the device

(i) Press the button down continuously.

(ii) Hold the button at least 5s seconds and release it. Then the device has been

restored to default settings and reboot again.

Note: Restoring the factory default setting will lose the all previous settings included IP

address forever. User needs to run the IPWizard II program to search the device and

configure it to let the device work properly again.

4. DC-in Jack

The input power is 12VDC.

Note: Please use the bundle adapter for the Network Camera, otherwise it could damage

the hardware.

5. MIC in (audio in)

Connect a microphone to the network camera.

6. Line out (audio out)

Connect a loud speaker to the network camera. This function is for voice alerting and

two-way audio.

7. BNC Connector

The composite video format will be sent out through this connector. User might connect

the IP Camera to a monitor or DVR via this connector.

1. Introduction

AirLive OD-2050HD User’s Manual

1.4 Mounting the Camera

Ceiling Mount

Fix the camera with as below.

Install the Camera in LAN

1. Plug an Ethernet cable into the Camera

Connect an Ethernet cable to the LAN socket and attach it into the network.

2. Connect the external power supply to Camera

Connect the attached power adapter to the DC power jack of the camera.

Note: Use the power adapter, 12VDC, included in the package and connect it to wall outlet

for AC power.

Once you have installed the camera well and powered it on, the power LED (orange) will

turn on later. The power LED turned on, it means the system is booting up successfully.

Furthermore, if you have a proper network connection, and access to the camera, the LAN

LED (green) will flash.

2. Preparation

AirLive OD-2050HD User’s Manual 6

2. 0Preparation

2.1 Search and Set up by IPWizard II

When you installed the Camera on a LAN environment, you have two easy ways to search

your Cameras by IPWizard II or UPnP™ discovery. Here is the way to execute IPWizard II

to discover Camera’s IP address and set up related parameter in a Camera.

2.1.1 Search

When launch the IPWizard II, a searching window will pop up. IPWizard II is starting to

search Network Cameras on the LAN. The existed devices will be listed as below.

2. Preparation

AirLive OD-2050HD User’s Manual 8

2.1.3 LAN

In case you want to change the IP related parameters of wired interface, please select the

device you want to configure and click the LAN button. Relative settings will be carried out

as below.

You could modify the relative settings of the selected device. Click “<<” button will quit the

LAN setting procedure and click “>>” button will move to next page as below.

2. Preparation

AirLive OD-2050HD User’s Manual

In case, you do not want to change username and/or password, then just click “Submit”

button to perform your setting accordingly. Click “<<” button will go back to previous page.

If you like to change username and/or password of the device, just click the check button.

Then, the related fields will show up as below.

After keying in new username and password, click “Submit” button to perform your setting

accordingly. Click “<<” button will go back to previous page.

2.2 UPnP of Windows® XP, Vista or 7

UPnP™ is short for Universal Plug and Play, which is a networking architecture that

provides compatibility among networking equipment, software, and peripherals. This

device is an UPnP enabled device. If the operating system, Windows XP, Vista or 7, of

your PC is UPnP enabled, the Network Camera will be very easy to be found.

Please refer to Appendix J to enable UPnP settings only if your operating system of PC is

running Windows XP.

Note: Windows 2000 does not support UPnP feature.

To discover your device, go to your Desktop and click My Network Places.

Produkt Specifikationer

Mærke:	Airlive
Kategori:	Overvågningskamera
Model:	OD-2050HD

Har du brug for hjælp?

Hvis du har brug for hjælp til Airlive OD-2050HD stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Overvågningskamera Airlive Manualer

Airlive AirCam PTZB-630MAI Manual

13 Marts 2025

Airlive DM-720 Manual

11 Januar 2025

Airlive SmartCube 300W Manual

21 August 2024

Airlive POE-280HD Manual

16 August 2024

Airlive OD-2025PHD Manual

16 August 2024

Airlive POE-260CAM Manual

16 August 2024

Airlive OD-2050HD Manual

15 August 2024

Airlive IP-150CAM Manual

15 August 2024

Airlive FE-501OD Manual

15 August 2024

Airlive POE-200HD Manual

14 August 2024

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

Tesla Smart Camera 360 4G Battery Manual

20 Marts 2025

Tesla Smart Camera Outdoor 2K Manual

20 Marts 2025

Tesla Smart Camera Omni 360 Manual

20 Marts 2025

Wisenet PNM-9022V Manual

8 Marts 2025

Wisenet TNV-8010C Manual

8 Marts 2025

Wisenet PNM-7002VD Manual

8 Marts 2025

Wisenet QNE-8021R Manual

8 Marts 2025

Wisenet PNM-8082VT Manual

8 Marts 2025

Wisenet XNF-9010RV Manual

8 Marts 2025

Wisenet TNU-6321 Manual

8 Marts 2025
