INTRODUCTION
M50 is Amplicomms’s new smartphone for seniors, offering an amplified
handsfree base. Its many features include:
1 - Easy-to-use interface, with two modes to choose from (Simple and light Android)
2 - Text <=>Speech support for messages, dialling, etc
3 - SOS button
4 - Base: desk top easy-charging base and Bluetooth handsfree device
A- SMARTPHONE DESCRIPTION
1 - Turn ON/OFF the screen;
Power ON/OFF ( Long press )
2 - Volume up key
3 - Volume down key
4 - Front camera
5 - Receiver
6 - Touch screen
7 - Task manager key (Android mode)
8 - Home key
9 - Back key
B- BASE DESCRIPTION
PACKAGE CONTENT
1. M50 smartphone
2. Base
3. Power adaptor with USB cable
4. Instructions manual
GET STARTED
Insert the SIM card (required) and the memory card (optional)
- With the SIM card golden contacts facing down, insert the SIM card into one
of the available slots until it stops as illustrated
- To expand the internal storage memory, you can insert a microSD memory
card (maximum capacity of 64 GB / not included). Insert the memory card into
the slot until it stops as illustrated
Note: Both card slots (SIM1=Micro, SIM2=Micro) support LTE (4G). If nano SIM card is
used, a SIM card adaptor is required ( provided by operator )
ATTENTION:
• Risk of swallowing small objects! The SIM card & memory card can be removed.
Small children can swallow them
• Do not bend or scratch the SIM card. Prevent any contact with water, dirt, or
electrical charges
• Turn off the phone and disconnect the charger before removing the battery cover
Insert the battery
- Insert the battery into battery compartment with golden contacts of the
battery pointing to the top right of the phone
- Press lightly on the bottom end of the battery until it snaps into place
Replace the battery cover
Replace and secure the battery cover until it clicks into place
5. Battery
6. Battery cover
7. Earphones
8. Lanyard
Charging your phone / using the base speaker
- Place the base on a flat surface. Plug provided USB cable to the base and to a
wall mains socket.
- To charge your phone, simply place it on the charger as depicted. M50 can
also be charged as a regular smartphone by plugging the USB cable directly
on the USB connector (Figure A, 12)
- When placed on the cradle, your phone will connect with the base via
Bluetooth. You can answer handsfree calls or listen to music on the base
loudspeaker.
(**A valid Bluetooth pairing between M50 and base is required)
ATTENTION:
• Only use battery, charger and accessories that have been approved for using
with this model. Connecting other accessories may be dangerous and may
invalidate the warranty.
Getting started guide
**Please read this “Getting Started guide” CAREFULLY before start using your
Amplicomms M50. Also check the Instructions Manual for more details.
**Google account is required for your phone to receive software updates. Please sign
in during phone set up or later.
** Pairing the phone with the base (step 8) is .mandatory
1. Insert the SIM card, battery and replace the battery cover.
2. Power up the base (use provided adaptor and USB cable).
3. Long press ON/OFF button to power up the phone.
4. The display will be lighted up.
5. Enter the SIM PIN code (Optional : Service provider dependent)
6. Select the desired language
7. Follow the setup wizard steps on the screen
8. Pair the phone with the base (mandatory step) to be able to answer a call in
handsfree mode and listen to audio sources (radio, music files). When the smartphone
is on its base but not paired, battery will charge but base keys (including the base’s
“Phone” button) will not be working.
• Swipe with your finger on the touch screen and press icon on page 2, Settings
then > .Connected devices Pair new device
• Place your M50 on the base charging cradle.
• Tap on when it appears in the device list, then click on “PAIR” M50 Smart Base
(“Allow access to your contacts and call history” is displayed. Tap on the square
to accept, then on “Pair”)
When the base is well paired, a sharp sound is emitted, and base led will turn to
steady blue. By pressing either or base keys you can check that base and
M50 are well paired:
icon will be displayed on the right side.
If base led still flashes in red, repeat step 8.
9. When completed, swipe with your finger on the touch screen and press
Select Home icon on page 2, to choose between Simple Smartphone and light
Android modes.
Simple Smartphone mode offers an extremely easy to use
interface, specifically designed for senior users. Check next
chapter to learn about phone operation in this mode.
Light Android mode presents the user with a simplified
version of a regular smartphone. If you chose this mode,
please read “USING YOUR M50 IN LIGHT ANDROID MODE”.
USING M50 IN SIMPLE SMARTPHONE MODE
When Simple smartphone mode is selected, your M50 will look simpler and easier
to use than a regular smartphone.
Setup Wizard
The first time you select Simple Smartphone mode, you will have the choice to
be guided along the most relevant settings by a Setup Wizard. These are:
a. Click Duration (sets click duration for alphanumeric keyboard and other keys**)
b. Wifi setup (if Wifi internet access is available)
c. Google Account
d. Copy Contacts
e. New Contacts
f. SOS and Support
g. Speed Dial
h. Favorite Contacts
i. WhatsApp
j. Advanced Settings
k. Exit Setup
Once you “Exit Setup”, the wizard is always available under Settings.
** Note all touch-screen clicks are by default long click when using Simple Smartphone
mode. A valid key press should have a confirmation vibration.
Click duration can be changed anytime through the wizard or in Advanced Settings.
Home Screen
1 - Silent / Vibrate only / Normal mode
2 - One Touch Speed Dials
3 - Calls Center
4 - Message Center - SMS, missed calls, WhatsApp, etc.
5 - Pictures Center - View photos and videos, use the camera
6 - Other functions such as Whatsapp, phonebook, applications, settings, etc
7 - Battery level
Turn the Phone ON/OFF
- Long press ON/OFF button (1 in the figure A)
- The display will be lighted up. (To turn off the phone: Power Off Turn off > )
Call from the 3 One-Touch speed dials
- Press one of the 3 One-Touch speed dials directly (2 in the figure)
- Press to end the call
Make a call
- Press Call Dial number 0......9 Del > > Enter the number (Press to delete)
- Press to dial
- Press to end the call
Call from phonebook
- Press Call > to search and select the number OR
- Press Call Search Search > > enter the 1st character of the contact > > select
the number
- Press to dial
- Press to end the call
Call Log
- Press Call Call Log Phonebook Call Log > or > to view the call log
- To call back the incoming call number, press the number
Receive a call
- Press to answer
- Press to end the call
- When the phone is on the base, you can use button to answer and end the
call in handsfree mode. You can also control the base loudspeaker volume
with and keys.
Adjust the earpiece loudness
- During a call, press Volume up/Volume down keys - to adjust the loudness
Ringer mode
- In idle mode, press > select the ringer mode between / / Sound Silent Vibrate
Message
- All types of messages (SMS, WhatsApp, missed call, etc...) are consolidated in
Message
- When there is a new message, the button will be highlighted with
a new indication
- To read the message, press on the new items to read the details or press
Read old message......
Write new message
- > Message Write a new message
- Input the sending number by > ORDial number Next
- Select from existing phonebook with
- Input from Keyboard > ORSend
- Select the pre-defined simple message by Next
Pictures
- Pictures View Pictures > > move to the next......
(Press All images to see all pictures > / to scroll throught them)
Camera
- Pictures > Take a picture > Camera > Capture to take photo or Record to take video
- Remeber to or the photo......Save Save and Send
Phone Book
Options in this menu:
1. View
2. Edit
3. New Contact
4. Call Log
ADD New contact
- > (or > > )Phone Book New Contact Settings Contacts New
- > input the name > Name Next
- > input the number > ......Number Next
- Save
- You will be asked if you wish to Add a photo from Images or from Camera.
Press Yes or No and follow the instructions on the screen
EDIT Contact
- > (or > > )Phone Book Edit Settings Contact Update
- Select a contact for editing
- > Edit the name > Name Next
- > Edit the number > Number Next......
- (To associate a photo to a contact, go to > > )Save Settings Contacts Photo
Settings
- > ......Settings
- Under the Settings menu, the following options can also be accessed:
1. Contacts
2. Speed Dial
3. Language
4. Advanced Settings
5. Setup Wizard
6. Premium Service
Edit the 3 One-Touch Speed Dial buttons
- > Settings Speed Dial
- Select the empty button
- Choose the number from contact list ( to next page)
- )Add contact to list (Add speed dial photo...... Go to Settings > Contacts > Photo
Add new contact to Favorite contacts in CALL button
- > > Settings Contacts Favorite
- Select the empty button
- Choose the number from contact list ( to next page)
- (Favorite contacts can be selected by pressing )Add contact to list Call
Click duration
Long press duration for menu buttons and text keyboard can be adjusted to be
faster or slower: > > Settings Setup Wizard Click Duration
Advanced Settings
- > Settings Advanced Settings
- Under the Advanced Settings menu, the following options can also be accessed:
1. Initial setting
2. Contacts
3. Personal Info
4. SOS and Support
5. Android settings
- Ringer melody and Volume
- Wifi
6. Medication Reminder
7. Display & Sound settings
8. .....
Talking Dialling Digits
- While pressing the numeric buttons, M50 will announce the corresponding
number (except when in silent mode)
(To disable this feature, go to > Advanced Settings menu Display & Sound
Settings Sound Settings > ......)
SOS Assistance button
- Long press SOS button (Fig. A, 17) for 3 seconds to dial out assistance numbers
- M50 will enter handsfree mode automatically
- In parallel, an SMS with geolocation information will be sent to the recipient of this
assistance call and up to other 5 recipients. (To stop the SOS action: Long press CANCEL)
Set SOS number
Make sure the desired phone number exists in the phonebook.
- > > > > Select the Settings Advanced Settings SOS and Support SOS number
numbers...... Save
- An SMS will be sent to the selected numbers to inform them
ATTENTION:
• Remember to set the SOS number and inform the recipient
• To have SOS function working normally, the network service must be active
• Sending SMS may require additional cost!
Torch
To switch on/off the flashlight, slide up or down the torch switch (Fig. A,10)
located on the left-hand side of the phone.
USING YOUR M50 IN LIGHT ANDROID MODE
When light Android mode is selected, your M50 will show a simplified smartphone
interface, with large icons and easy-to-navigate pages.
1 7
2
3
4
5
6
1
23
5
4
10 - Torch sliding switch
11 - Charging contacts
12 - USB connector
13 - Flashlight LED
14 - Headset jack
15 - Main camera
16 - Flash
17 - SOS button
18 - Speaker
19 - Lanyard hole
1
10 2
3
9
12
11
4
7
5
6
8
13
15
16
17
18 19
14
1 - Charging cradle and contacts
2 - Phone button (answer incoming call
when smartphone on the base)
3 - Volume - key
4 - Volume + key
5 - Usb connector (at the back)
Instructions Manual
M50
1
5
2
3 4
1
Produkt Specifikationer
| Mærke: | Amplicomms |
| Kategori: | Smartphones |
| Model: | M50 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Amplicomms M50 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Smartphones Amplicomms Manualer
20 April 2024
29 November 2023
23 December 2022
14 November 2022
9 November 2022
5 November 2022
19 Oktober 2022
11 Oktober 2022
4 Oktober 2022
Smartphones Manualer
- Smartphones Acer
- Smartphones Denver
- Smartphones Sencor
- Smartphones TCL
- Smartphones Sony
- Smartphones Samsung
- Smartphones Panasonic
- Smartphones Sony Ericsson
- Smartphones TP-Link
- Smartphones Philips
- Smartphones OK
- Smartphones LG
- Smartphones AEG
- Smartphones Doro
- Smartphones Gigaset
- Smartphones AT&T
- Smartphones Mitsubishi
- Smartphones Apple
- Smartphones Sharp
- Smartphones Konrow
- Smartphones Google
- Smartphones HP
- Smartphones Emporia
- Smartphones Garmin
- Smartphones Sanyo
- Smartphones Easypix
- Smartphones Motorola
- Smartphones Asus
- Smartphones Gigabyte
- Smartphones Toshiba
- Smartphones Kodak
- Smartphones InFocus
- Smartphones Lenovo
- Smartphones Infiniton
- Smartphones OnePlus
- Smartphones Nedis
- Smartphones Thomson
- Smartphones Aiwa
- Smartphones Nokia
- Smartphones Palm
- Smartphones Hisense
- Smartphones Hannspree
- Smartphones Trevi
- Smartphones Fysic
- Smartphones Mio
- Smartphones Blaupunkt
- Smartphones Honeywell
- Smartphones Razer
- Smartphones Medion
- Smartphones Intex
- Smartphones Haier
- Smartphones Huawei
- Smartphones Echo
- Smartphones Vivax
- Smartphones TAG Heuer
- Smartphones BenQ
- Smartphones Microsoft
- Smartphones Alcatel
- Smartphones Plum
- Smartphones Olympia
- Smartphones Xiaomi
- Smartphones Krüger&Matz
- Smartphones Dell
- Smartphones RugGear
- Smartphones Intermec
- Smartphones CAT
- Smartphones Oppo
- Smartphones Tesla
- Smartphones Polaroid
- Smartphones Crosscall
- Smartphones NGM
- Smartphones NEC
- Smartphones Alcatel-Lucent
- Smartphones Aspera
- Smartphones Kyocera
- Smartphones Energy Sistem
- Smartphones Bush
- Smartphones Binatone
- Smartphones Honor
- Smartphones Tiptel
- Smartphones Sagem
- Smartphones Nevir
- Smartphones TrekStor
- Smartphones Lava
- Smartphones Vivo
- Smartphones Vodafone
- Smartphones Overmax
- Smartphones Infinix
- Smartphones Archos
- Smartphones Alba
- Smartphones RCA
- Smartphones MaxCom
- Smartphones Pantech
- Smartphones ZTE
- Smartphones Verykool
- Smartphones Lark
- Smartphones Switel
- Smartphones Brondi
- Smartphones Garmin-Asus
- Smartphones Amazon
- Smartphones HTC
- Smartphones YEZZ
- Smartphones ITTM
- Smartphones ITT
- Smartphones BlackBerry
- Smartphones Evolveo
- Smartphones Coolpad
- Smartphones Wiko
- Smartphones ESTAR
- Smartphones Umidigi
- Smartphones ToughGear
- Smartphones BLU
- Smartphones Lexibook
- Smartphones Prestigio
- Smartphones MyPhone
- Smartphones Micromax
- Smartphones Cyrus
- Smartphones Energizer
- Smartphones Tecdesk
- Smartphones Bea-fon
- Smartphones Sonim
- Smartphones Hammer
- Smartphones Fairphone
- Smartphones GSmart
- Smartphones HMD
- Smartphones Unitech
- Smartphones Noabe
- Smartphones Volla
Nyeste Smartphones Manualer
19 December 2024
14 December 2024
14 December 2024
14 December 2024
14 December 2024
12 December 2024
23 November 2024
23 November 2024
23 November 2024
23 November 2024
