Side 1/4
ONTDEK HET VOLLEDIGE ARTSOUND AANBOD OP WWW.ARTSOUND.BE
DISCOVER THE COMPLETE ARTSOUND RANGE AT WWW.ARTSOUND.BE
DÉCOUVREZ LA GAMME ARTSOUND COMPLÈTE SUR WWW.ARTSOUND.BE
sa House of Music nv
Ronse, Belgium
+32 9 380 81 80 +32 9 386 12 35
 ␣ www.artsound.be info@artsound.be
  @Art_Sound ArtSound.Audio
w
a
t
e
r
r
e
p
e
l
l
e
n
t
p
a
i
n
t
a
b
l
e
@
HPSQ525
170 75
170 148
HPSQ525
Ook verkrijgbaar in deze serie :
Cette gamme comprend également :
This range also includes:
HPRO525 - HPRO650 - HPRE650
EN Dear Customer, Congratulations on the purchase
of your loudspeaker(s). Please read these instructions
carefully and keep them for future reference.
INSTALLATION (FIG 2 PAG.2)
1 Remove the inwall speaker from the box. In the box,
you will find a stencil. Hold the stencil to the spot
where you want to mount the loudspeaker, and
using the pencil, draw an outline along the edge of
the stencil.
2 Drill one or more holes along the inside edge of the
pencilled-in line. For square or rectangular spea-
kers, it is easier to drill four holes, whereas for a
round speaker one hole is probably sufficient.
3 Using the jig saw, saw along the edge so that you are
left with a nice, round, square or rectangular hole.
4 Now hold the inwall speaker tight. You can remove the
grille by simply pulling on it. Only the magnet holds
it in place.
5 Pull the clamps back in and turn them all inward. Con-
nect the loudspeaker cable. If you forget to do this,
you will have to remove it again later!
6 Place the inwall speaker in the hole. Tighten the
screws. This will cause the clamps at the back to
automatically turn back outwards so that the loud-
speaker will lock in place.
7 If you like, you can also paint the grill with spray
paint.
8 If you would like to remove the loudspeaker or paint
the grill, you must remove the grill first. You can do
this by simply pulling on it. Only the magnet holds
it in place.
TROUBLESHOOTING
Should you experience problems, please contact your
certifi ed dealer. He or she will ask you several specifi c
questions. In order to be able to answer these ques-
tions, please check the following in advance:
• You can’t hear any sound; in other words, the loud-
speaker is either no longer producing sound, or is only
playing the high or low tones.
• Is the other loudspeaker still producing sound? Or are
both of them defective? If so, it is best to check your
amplifi er.
• The loudspeaker(s) is (are) cracking.
• If you lightly press the loudspeaker driver (woofer), is
there any friction?
If you know the answers to these questions in advance,
your dealer will be better able to help you in diagnosing the
problem. Thank you in advance for your cooperation.
TECHNICAL SPECIFICATIONS
• system : 2-way coaxial
• woofer : 5,25” aluminium cone rubber edge
• tweeter : 0,75” swivel neodymium alu. dome
• max. power : 60W
• sensitivity : 84dB
• impedance : 8 Ω
• frequency range : 80Hz - 20kHz
• dimensions cut-out (Ø) : 148 x 148mm
• dimensions (Ø x d) : 170 x 170 x 75mm
• weight / piece : 1kg
• colour : white
• extra : paintable - swivel tweeter - water repellent
• options : KITSQ1
WARRANTY
2 years after date of purchase for normal use.
Invoice terms and conditions apply.
• L'autre enceinte fonctionne-t-elle encore ? Ou sont-
elles toutes les deux défectueuses ? Dans ce cas,
mieux vaut vérifi er votre amplifi cateur.
• L'enceinte/les enceintes émet(tent) des craque-
ments.
• Si vous enfoncez légèrement le moteur de l'enceinte
(woofer), celui-ci frotte-t-il ?
De la sorte, votre revendeur saura dans quelle direc-
tion s'orienter pour poser son diagnostic. Merci de
votre collaboration.
FICHE TECHNIQUE
• système : 2 voies coaxial
• woofer : 5,25” cône alu. bord caoutchouc
• tweeter : 0,75” dôme pivotant néodyme alu.
• puissance max. : 60 W
• sensibilité : 84 dB
• impédance : 8 Ω
• plage de fréquences : 80 Hz - 20 kHz
• dim. de découpe (Ø) : 148 x 148 mm
• dimensions (Ø x d) : 170 x 170 x 75 mm
• poids / pièce : 1 kg
• coleur : blanc
• compléments : peut être peint - tweeter pivotant
résistant aux éclaboussures
• options : KITSQ1
GARANTIE
2 ans à partir de la date d'achat, dans le cadre d'une
utilisation normale. Les conditions de la facture
s'appliquent.
