PRODUCT OVERVIEW

TECHNICAL DATA

Top View

Please read the instruction manual carefully before operating your new hob.

Model Power supply

AC 220-240V

50-60Hz

Size (mm) Built-in hole Size

(mm)

592x522x90 560x490

1800W

/1200W

(Boost 2100W) (Boost 1500W)

Power

Heating area

(210mm)

Heating area

(180mm)

Heating area

(140mm)

Good Bad Bad Bad Bad Bad Bad

(recessed base) (convex base) (undersize) (oversize) (moisture on hotplate) (no utensil)

Power level

Default working timer (hour)

Before using your New Induction Hob

• Read this guide, taking special note of the ‘Safety Warnings’ section.

• Remove any protective film that may still be on your Induction hob.

If the display flashes “ ” alternately with the heat setting

This means that:

• you have not placed a pan on the correct cooking zone or,

• the pan you’re using is not suitable for induction cooking or,

• the pan is too small or not properly centred on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.

The display will automatically turn off after 1 minutes if no suitable pan is placed on it.

When You Have Finished Cooking

1.Turn the knob counterclockwise to " 0 "position, the corresponding heating zone display will flash “ for 5s, then stop heating.

Note:The knob is forbidden to directly adjust clockwise from P to 0.

2. Beware of hot surfaces indicator “H”will show which cooking zone is hot to touch. It will disappear when the surface has

cooled down to a safe temperature. It can also be used as an energy saving function - if you want to heat further pans, use the

hotplate that is still hot.

Choosing the right Cookware

• Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging

or on the bottom of the pan.

• You can check whether your cookware is suitable by carrying out a magnet test. Move a magnet towards the

base of the pan. If it is attracted, the pan is suitable for induction.

• If you do not have a magnet:

1. Put some water in the pan you want to check.

2. If “ ” does not flash in the display and the water is heating, the pan is suitable.

• Cookware made from the following materials is not suitable: pure stainless steel, aluminium or copper without

a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

Do not use cookware with jagged edges or a curved base.

Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking

zone. Use pans whose diameter is as large as the graphic of the zone selected.Using a pot a slightly wider

energy will be used at its maximum efficiency.If you use smaller pot efficiency could be less than expected.Pot

less than 140 mm could be undetected by the hob. Always centre your pan on the cooking zone.

Always lift pans off the Induction hob – do not slide, or they may scratch the glass.

1 2

CAID604K

862x522x90 835x490

1800W 1200W

(Boost 2100W)

1800W

(Boost 2100W) (Boost 1500W)

CAID905K

CAID604K CAID905K

1800W

(boost 2100W)

1800W

(boost 2100W)

1800W(boost 2100W)

(boost 1500W)

1200W

(boost 1500W)

Knob ON/OFF Control Knob ON/OFF Control

1200W

(boost 1500W)

1200W

1800W

(boost 2100W)

1800W

(boost 2100W)

(boost 1500W)

1200W

Congratulations on the purchase of your new Induction Hob.

We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to

install correctly and operate it.

For installation, please read the installation section.

Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.

Safety Warnings

Your safety is important to us. Please read this information before using your cooktop.

Installation

Electrical Shock Hazard

• Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it.

• Connection to a good earth wiring system is essential and mandatory.

• Alterations to the domestic wiring system must only be made by a qualified electrician.

• Failure to follow this advice may result in electrical shock or death.

Cut Hazard

• Take care - panel edges are sharp.

• Failure to use caution could result in injury or cuts.

Important Safety Instructions

• Read these instructions carefully before installing or using this appliance.

• No combustible materials or products should be placed on this appliance at any time.

• Please make this information available to the person responsible for installing the appliance.

• In order to avoid a hazard, this appliance must be installed according to these instructions for installation.

• This appliance must be installed and earthed only by a suitably qualified person.

• This appliance should be connected to a circuit which incorporates an isolating switch, providing full disconnection from the

power supply.

• Failure to install the appliance correctly could invalidate any warranty or liability claims.

Operation and Maintenance

Electrical Shock Hazard

• Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, immediately switch off the

appliance at the mains power supply (wall switch) and contact a qualified technician.

• Switch the cooktop off at the wall before cleaning or maintenance.

• Failure to follow this advice may result in electrical shock or death.

Health Hazard

• This appliance complies with electromagnetic safety standards.

• However, persons with cardiac pacemakers or other electrical implants (such as insulin pumps) must consult with their

doctor or implant manufacturer before using this appliance to make sure that their implants will not be affected by the

electromagnetic field.

• Failure to follow this advice may result in death.

Hot Surface Hazard

• During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.

• Do not let your body, clothing or any item other than suitable cookware contact the induction glass until the surface is cool.

• Metallic since objects such as knives, forks, spoons and lids should not be placed on the hob surface they can get hot.

• Keep children away.

• Handles of saucepans may be hot to touch. Ensure that the saucepan handles do not overhang other cooking zones that

are switched on. Make sure children can’t reach the cookware handles.

• Failure to follow this advice could result in burns and scalds.

Cut Hazard

• The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted. Use with extreme care and

always store safely and out of reach of children.

• Failure to use caution could result in injury or cuts.

Important Safety Instructions

• Never leave the appliance unattended when in use. Boil-over causes smoking and greasy spillovers may ignite.

• Never use your appliance as a work or storage surface.

• Never leave any objects or utensils on the appliance.

• Do not place or leave any magnetisable objects (e.g. credit cards, memory cards)or electronic devices (e.g. computers, MP3

players) near the appliance as they may be affected by its electromagnetic field.

• Never use your appliance for warming or heating the room.

• After use, always turn off the cooking zones and the cooktop as described in this manual (i.e. by using the touch controls). Do

not rely on the pan detection feature to turn off the cooking zones when you remove the pans.

• Do not allow children to play with the appliance nor sit, stand or climb on it.

• Do not store items of interest to children in cabinets above the appliance. Children climbing on the cooktop could be seriously injured.

• Do not leave children alone or unattended in the area where the appliance is in use.

• Children or persons with a disability which limits their ability to use the appliance should have a responsible and competent

person to instruct them in its use. The instructor should be satisfied that they can use the appliance without danger to

themselves or their surroundings.

• Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should

be done by a qualified technician.

• Do not use a steam cleaner to clean your cooktop.

• Do not place or drop heavy objects on your cooktop.

• Do not stand on your cooktop.

• Do not use pans with jagged edges or drag pans across the induction glass surface as this can scratch the glass.

• Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop as these can scratch the induction glass.

•This appliance is intended to be used in a household or similar environments such as staff kitchen areas in shops, offices and

other residential environments.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in

order to avoid a hazard.

•the appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or instruction.

•children being supervised not to play with the appliance.

•Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.

•After use, switch off the hob element by its control and do not rely on the pan detector.

•WARNING: The appliance and its accessible parts become hot during use.

Care should be taken to avoid touching heating elements.

•WARNING: Unattended cooking on the hob with fat or oil can be dangerous and may result in a fire. NEVER try to extinguish

such fire with water, rather switch off the appliance and then cover the flame with a lid or a fire blanket.

•WARNING: Do not store items on the cooking surfaces as this presents a fire hazard.

•WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of an electric shock.

•The appliance is not intended to be operated by means of an external timer or separate remote-control system.

CAUTION: The cooking process has to be supervised.

WARNING: In order to prevent tipping of the appliance, it must be stabilised prior to installation. Please refer to the installation instructions.

WARNING:Only use hob guards that are either provided or deemed suitable by the manufacturer for use with this induction hob.

The use of inappropriate guards can cause accidents. The use of inappropriate guards can cause accidents.

This appliance incorporates an earth connection for functional purposes only.

WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire

with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.

WARNING: Danger of fire: do not store items on the cooking surfaces.

CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.

NOTICE: The crystallite glass is still hot after use, please do not touch!

POWER LIMIT WORKING MODE (CAID905K)

All 5 zones cannot be operated simultaneously on full power as it would exceed the power limit.

The left two heating zones can operate on the full power setting. The right two and the middle heating zones, if operated

simultaneously, exceed 3600W. This means when selecting the higher settings for these zones, they will adjust automati-

cally to ensure the total power is less than 3600W.

Boost Control

Turn the knob clockwise to the "P "position, the corresponding heating zone will enter the BOOST function,

the display will show " " , the BOOST function can run for up to 5 minutes, after 5 minutes, the power will

automatically drop to the 9 level, the display will show " " .

To start cooking

Note Before power on, the knobs must be adjusted to the "0 " position.：

1. Touch the ON/OFF control.

• With the power switched on, the buzzer will beep once, all displays will show “–”, indicating that the

induction hob has entered standby mode.

2. Place a suitable pan on the cooking zone that you wish to use.

• Make sure the bottom of the pan and the surface of the cooking zone are clean and dry.

3.Power level setting

• Turn the knob clockwise to the required power level (1~P), the corresponding heating zone display will

flash the selected level for 5s, then start to work.

Note:The knob is forbidden to directly adjust counterclockwise from 0 to P .

• If you don’t choose a heat setting within 1 minute, the induction hob will automatically switch off. You will

need to start again at step1.

• You can modify the heat setting at any time during cooking.

Overheating Protection

The appliance is equipped with a temperature sensor which can monitor the temperature inside the induction hob.

When an excessive temperature is monitored, the Induction hob will stop operation automatically.

Detection of Small Articles

When an unsuitably sized or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork, key) has

been left on the hob, the display flashes “ ” and the hob will automatically go in the standby mode in 1 minute. The

fan will keep cooling down the induction hob for a further 2 minutes.

Auto Shutdown Protection

Auto shutdown is a safety protection function for your induction hob. It will automatically turn off after a certain period of

time. The default working times for various power levels are shown in the below table:

Heat setting Suitability

1-2

3-4

5-6

7-8

● Delicate warming for small amounts of food

● Melting chocolate, butter, and foods that burn quickly

● Gentle simmering ● Slow warming

● Reheating ● Rapid simmering ● Cooking rice

● Pancakes

● Cooking pasta

● Stir-frying ● Searing ● Bringing soup to the boil ● Boiling water

Cooking Guidelines

Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost.

At extremely high termperatures oil and fat will ignite spontaneously and this presents a serious fire risk.

Heat Settings

The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the

amount you are cooking. Experiment with the induction hob to find the settings that best suit you.

V20231216

Cod 0070305158-C：

Produkt Specifikationer

Mærke:	Artusi
Kategori:	Ovn
Model:	CAID905KX

Har du brug for hjælp?

Hvis du har brug for hjælp til Artusi CAID905KX stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ovn Artusi Manualer

Artusi AO750MBP Manual

5 November 2024

Artusi ACS45MB Manual

2 September 2024

Artusi AFG913X/1 Manual

2 September 2024

Artusi AFG915X/1 Manual

2 September 2024

Artusi AFG999X Manual

1 September 2024

Artusi AFG999W Manual

1 September 2024

Artusi CAGH7000B Manual

1 September 2024

Artusi AFG999B Manual

1 September 2024

Artusi CAID905KX Manual

31 August 2024

Artusi CAGH75X-1 Manual

31 August 2024

Ovn Manualer

Nyeste Ovn Manualer

Bosch PID61RHB1E Manual

21 December 2024

Bosch NGM5059UC Manual

21 December 2024

Bosch NGM5453UC Manual

21 December 2024

Electrolux GK58TSITO Manual

21 December 2024

Electrolux EOT2515XG Manual

21 December 2024

Electrolux EOT3215XFG Manual

21 December 2024

Electrolux EOT1513XG Manual

21 December 2024

Bosch HEG517BB4 Manual

21 December 2024

Bosch HEG217AB4 Manual

21 December 2024

Bosch HEG278AB3 Manual

21 December 2024
