Switch di condivisione periferica a 2/4 porte US234 / US434 / US3324 / US3344 www.aten.com

Conmutador 2/4-Puertos para compartir perifericos US234 / US434 / US3324 / US3344 www.aten.com

2/4-Port-Peripheriefreigabe-Switch US234 / US434 / US3324 / US3344 www.aten.com

Commutateur de partage de périphérique 2/4 ports US234 / US434 / US3324 / US3344 www.aten.com

US234 / US434 / US3324 / US3344 2/4-Port Peripheral Sharing Switch www.aten.com

Hardware Review

US234 / US434 / US3324 / US3344 Front and Top View

1 Console Indicator LED

2 USB 3.1 Gen 1 Device Ports

3 Micro USB Power Input

4 Remote Port Selector

US234 / US434 / US3324 / US3344 Rear View

5 PC Ports

6 Remote Port Selector Jack

Hardware Installation

1 Plug the USB 3.1 Gen 1 Type-A or Type-C end of the included USB cables into

your computers (US234 / US3324: up to 2 computers; US434 / US3344: up

to 4 computers) and plug the USB 3.1 Gen1 Type-B end of the included USB

cables into the back of the US234 / US434 / US3324 / US3344.

2 Plug your USB peripheral devices into the US234 / US434 / US3324 / US3344.

3 Plug the Remote Port Selector into the Remote Port Selector jack on the

US234 / US434 / US3324 / US3344.

4 Switch from one computer to another by pressing the Remote Port Selector.

The Console Indicator LED will light to indicate which computer is connected.

5 (Optional) Connect the Micro USB Power Input port to a power source to

support applications with higher power requirements.

other trademarks are the property of their respective owners.

This product is RoHS compliant.

Part No. PAPE-1223-F51G Printing Date: 03/2018

US234 / US434

2x4 / 4x4 USB 3.1 Gen1 Peripheral Sharing Switch

US3324 / US3344

2x4 / 4x4 USB 3.1 Gen1 Peripheral Sharing Switch

Quick Start Guide

Support and Documentation Notice

All information, documentation, ﬁ rmware, software utilities, and

speciﬁ cations contained in this package are subject to change without

prior notiﬁ cation bythe manufacturer.

To reduce the environmental impact of our products, ATEN

documentation and software can be found online at

http://www.aten.com/download/

Technical Support

www.aten.com/support

이 기기는 가정용(B급) 전자파적합기기로서 주로 가정에서 사용하는 것을 목적

으로 하며, 모든 지역에서 사용할 수 있습니다.

EMC Information

FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE

STATEMENT:

This equipment has been tested and found to comply with

the limits for a Class B digital service, pursuant to Part

15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. Any changes or modiﬁ cations made

to this equipment may void the user s authority to operate

this equipment. This equipment generates, uses, and can

radiate radio frequency energy. If not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna;

- Increase the separation between the equipment and receiver;

- Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected;

- Consult the dealer/an experienced radio/television technician for help.

FCC Caution: Any changes or modiﬁ cations not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Scan for

more information

US234 / US434 / US3324 / US3344 2/4-портовый периферийный коммутатор общего доступа www.aten.com

US234 / US3324 Package Contents

1 USB 3.1 Gen Peripheral Sharing Switch

2 USB 3.1 Gen 1 Type-B to Type-A Cables 1.2M

1 USB 3.1 Gen 1 Type-B to Type-C Cable 1.8M (US3324 only)

1 Remote Port Selector

1 User Instructions

US434 / US3344 Package Contents

1 USB 3.1 Gen 1 Peripheral Sharing Switch

2 USB 3.1 Gen 1 Type-B to Type-A Cables 1.2M

2 USB 3.1 Gen 1 Type-B to Type-A Cables 1.8M

2 USB 3.1 Gen 1 Type-B to Type-C Cables 1.8M (US3344 only)

1 Remote Port Selector

1 User Instructions

AHardware Review

BHardware Installation

US234/US3324 Front ViewUS234/US3324 Top View

US234/US3324 Rear View

US434/US3344 Front ViewUS434/US3344 Top View

US434/US3344 Rear View

PC 2

PC 1

PC 4 (US3344)*

PC 3 (US3344)*

USB 3.1 Gen1

Graphics Adapter

HD Camera

Printer

*Note: The US434 / US3344 is pictured above. The US234 / US3324 only has 2 PC ports.

Keyboard / Mouse

Hardwareübersicht

US234 / US434 / US3324 / US3344 – Ansicht von vorne und Ansicht von

oben

1 Konsolenanzeige-LED

2 USB-3.1-Gen-1-Geräteanschlüsse

3 Micro-USB-Stromeingang

4 Remote-Port-Wähler

US234 / US434 / US3324 / US3344 – Ansicht von hinten

5 PC-Ports

6 Remote-Anschlusswähler-Buchse

Hardwareinstallation

1 Verbinden Sie das USB 3.1-Gen-1-Type-A- oder Type-C-Ende der

mitgelieferten USB-Kabel mit Ihren Computern (US234 / US3324:bis zu 2

Computer; US434 / US3344:bis zu 4 Computer) und schließen Sie das USB

3.1-Gen-1-Type-B-Ende der mitgelieferten USB-Kabel an der Rückseite des

US234 / US434 / US3324 / US3344 an.

2 Schließen Sie Ihre USB-Peripheriegeräte am US234 / US434 / US3324 /

US3344 an.

3 Schließen Sie den externen Anschlusswähler an der Buchse des externen

Anschlusswählers am US234 / US434 / US3324 / US3344 an.

4 Schalten Sie durch Betätigung des externen Anschlusswählers zwischen

den Computern um. Die Konsolenanzeige-LED zeigt durch Auﬂ euchten an,

welcher Computer verbunden ist.

5 (Optional) Verbinden Sie zur Unterstützung von Geräten mit höherem

Leistungsbedarf den Micro-USB-Stromeingang mit einer Stromquelle.

Revisión de hardware

Vista frontal y superior del US234 / US434 / US3324 / US3344

1 Indicador LED de consola

2 Puertos de dispositivo USB 3.1 Gen 1

3 Entrada de alimentación micro USB

4 Selector de puerto remoto

Vista posterior US234 / US434 / US3324 / US3344

5 Puertos de PC

6 Conector del selector de puerto remoto

Instalación de hardware

1 Conecte un extremo del USB 3.1 Gen 1 Tipo A o Tipo C de los cables USB

incluidos en sus PC (US234 / US3324: hasta 2 PCs; US434 / US3344: hasta 4

PCs) y conecte el otro extremo del cable USB 3.1 Gen1 Tipo B incluido en la

parte posterior de los modelos US234 / US434 / US3324 / US3344.

2 Conecte sus dispositivos periféricos USB en el US234 / US434 / US3324 /

US3344.

3 Conecte el selector de puerto remoto en el conector de selector de puerto

remoto en el US234 / US434 / US3324 / US3344.

4 Cambie de un PC a otro presionando el selector de puerto remoto. El LED

indicador de la consola se encenderá para indicar qué PC está conectado.

5 (Opcional) Conecte el puerto de entrada de alimentación Micro USB a una

fuente de alimentación para admitir aplicaciones con mayores requisitos de

alimentación.

Descrizione hardware

Vista frontale e dall'alto di US234 / US434 / US3324 / US3344

1 LED console

2 Porte dispositivo USB 3.1 Gen 1

3 Ingresso alimentazione micro USB

4 Selettore porta remota

Vista posteriore di US234 / US434 / US3324 / US3344

5 Porte PC

6 Jack selettore porta remota

Installazione dell'hardware

1 Collegare l'estremità USB 3.1 Gen 1 Tipo A o Tipo C dei cavi USB in dotazione

ai computer (US234 / US3324:ﬁ no a 2 computer; US434 / US3344:ﬁ no a

4 computer) e collegare l'estremità USB 3.1 Gen 1 Tipo B dei cavi USB in

dotazione al retro di US234 / US434 / US3324 / US3344.

2 Collegare le periferiche USB a US234 / US434 / US3324 / US3344.

3 Inserire il selettore porta remota nel jack selettore porta remota di US234 /

US434 / US3324 / US3344.

4 Passare da un computer all'altro premendo il selettore porta remota. Il LED

console si accende per indicare il collegamento del computer.

5 (Opzionale) Collegare la porta di ingresso alimentazione micro USB

all'alimentazione per supportare le applicazioni con requisiti di alimentazione

più elevati.

Обзор аппаратного обеспечения

US234 / US434 / US3324 / US3344 Вид спереди и сверху

1 Светодиодный индикатор консоли

2 Порты устройства USB 3.1 Gen 1

3 Вход питания Micro USB

4 Селектор удаленных портов

US234 / US434 / US3324 / US3344 Вид сзади

5 Порты ПК

6 Селекторный разъем удаленных портов

Установка аппаратного обеспечения

1 Подключите разъем Gen 1 Тип-А или Тип-С входящих в комплект

кабелей USB 3.1 к компьютерам (US234 / US3324:до 2 компьютеров;

US434 / US3344:до 4 компьютеров), а разъем Gen1 Тип-В входящих в

комплект кабелей USB 3.1 к задней панели US234 / US434 / US3324 /

US3344.

2 Подключите периферийные USB устройства к US234 / US434 /

US3324 / US3344.

3 Подключите селектор удаленных портов к соответствующему разъему

на панели US234 / US434 / US3324 / US3344.

4 Для переключения от одного компьютера к другому нажимайте на

Селектор удаленных портов. Светодиодный индикатор консоли

загорается, определяя подключенный компьютер.

5 (Дополнительно) Подключите к входному порту питания Micro USB

источник питания для поддержки приложений с высоким потреблением

энергии.

Aperçu du matériel

Vues avant et supérieure du US234 / US434 / US3324 / US3344

1 DEL d'indication de console

2 Ports appareils USB 3.1 Gen 1

3 Entrée d'alimentation Micro USB

4 Sélecteur de port distant

Vue arrière du US234 / US434 / US3324 / US3344

5 Ports PC

6 Prise du sélecteur port distant

Installation du matériel

1 Branchez l'extrémité USB 3.1 Gen 1 Type-A ou Type-C des câbles USB inclus

sur vos ordinateurs (US234 / US3324 : jusqu'à 2 ordinateurs ; US434 /

US3344 : jusqu'à 4 ordinateurs) et branchez l'extrémité USB 3.1 Gen1 Type-B

des câbles USB inclus sur l'arrière du US234 / US434 / US3324 / US3344.

2 Branchez vos périphériques USB sur le US234 / US434 / US3324 / US3344.

3 Branchez le sélecteur de port distant sur la prise de sélecteur de port distant

sur le US234 / US434 / US3324 / US3344.

4 Basculez d'un ordinateur à l'autre en appuyant sur le sélecteur de port distant.

La DEL d'indication de console s'allume pour indiquer l'ordinateur connecté.

5 (Facultatif) Connectez le port d'alimentation Micro USB à une source

d'alimentation pour soutenir les applications avec des exigences d'alimentation

plus élevées.
