INSTALLATION MANUAL
CENA SERIES SPRING-FIT™ CEILING SPEAKERS
STEP 1 STEP 2
Cut a hole on the desired mounting location in the
ceiling. Make sure the dimension is matching the
cut-out measurement for the installing loudspeaker
CENA306 = Ø 80 mm
CENA506 = Ø 150 mm
CENA706 = Ø 167 mm
CENA812 = Ø 207 mm
Double check if there are no cables or other
obstructions behind the mounting surface before
making the cut-out.
Connect the wires coming from the amplier to the
SnapConnect™ on the rear of the loudspeaker.
The correct power tapping is chosen by connecting the
appropriate terminals of the connector. A description
of the power tap selection is shown on the magnet
sticker on the rear side of the loudspeaker.
CENA306/506/706:
Red: 6 Watt / 1667 Ω
White: 3 Watt / 3333 Ω
Black: COM
CENA812:
Red: 12 Watt / 833 Ω
White: 6 Watt / 1667 Ω
Black: COM
Ø Diameter
STEP 3
Bend the spring loaded mounting arms inwards by
pushing them by ngers, making them t through the
provided ceiling cut-out.
STEP 4
Insert the speaker through the provided ceiling cut-
out, make sure the spring loaded mounting arms are
behind the clamping surface and release them. The
ceiling is clamped between the mounting arms and
the speaker bae and is installed correctly.
The speaker is now ready for use.
