Creating and playing self-

executable ﬁ le

You can play the created ﬁ le

independently without the Digital

Voice Management software.

1. Highlight a recorded ﬁ le, click

2. Select the destination folder

from the pop up window and

click .Save

3. Go to the destination folder

and double-click the created

ﬁ le.

4. Click Play to start playback.

Adjust the volume on the

right.

General controls

WARNING: TO PREVENT FIRE OR ELECTRICAL

SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO

RAIN OR MOISTURE.

FCC information

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference,

and (2) this device must accept any

interference received, including

interference that may cause undesired

operation.

This equipment has been tested and

found to comply with the limits for

a Class B digital device, pursuant to

Part 15 of FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses, and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee

that interference will not occur in a

particular installation. If this equipment

does cause harmful interference to

radio or television reception, which

can be determined by turning the

equipment off and on, the user is

encouraged to try to correct the

interference by one or more of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between

the equipment and receiver.

• Connect the equipment into an

outlet on a circuit different from

that to which the receiver is

connected.

Service information

This product should be serviced only by

those specially trained in appropriate

servicing techniques. For instructions on

how to obtain service, refer to the war-

ranty included in this user manual.

For your records

In the event that service should be

required, you may need the model

number and the serial number. In the

space below, record the date and place

of purchase and the serial number:

Model No.:

Date of Purchase:

Place of Purchase:

Serial No.:

• Consult the dealer or an

experienced radio/TV technician for

help.

Changes or modiﬁ cations not expressly

approved by the party responsible

for compliance could void the user’s

authority to operate the equipment.

user manual

manual de usuario

EN/E

It is important to read this instruction prior to using your new product for the ﬁ rst time.

Es importante leer este manual antes de usar por vez primera su equipo.

VR5220

v5.0 (EN/E)

RCA

DTA800A

RCA

VR5220

This Class B digital apparatus complies

with Canadian ICES-003.

Cet appareil numérique de la classe

B est conforme à la norme NMB-003

du Canada.

The descriptions and characteristics

given in this document are given as a

general indication and not as a guar-

antee. In order to provide the highest

quality product possible, we reserve

the right to make any improvement or

modiﬁ cation without prior notice.

Maintenance

Clean the unit with a soft cloth, or

a damp chamois leather. Never use

solvents.

Precautions for the unit

• Do not use the unit immediately

after transportation from a

cold place to a warm place;

condensation problem may be

resulted.

• Avoid shock to the unit especially

during recording. Recorded data

can be damaged.

• Do not store the unit near ﬁ re,

places with high temperature or

places with direct sunlight.

• Do not operate or store unit

in places with frequent static

electricity or electrical noise (e.g.

speaker, TV set).

• Clean the unit with a soft cloth or

a damp chamois leather. Never use

solvents.

• The unit must only be opened by

qualiﬁ ed personnel.

• Do not expose this appliance to

rain or moisture.

Important battery

precautions

• Any battery may present a risk of

ﬁ re, explosion, or chemical burn

if abused. Do not try to charge a

battery that is not intended to be

recharged, do not incinerate, and

do not puncture.

• Non-rechargeable batteries, such as

alkaline batteries, may leak if left

in your product for a long period

of time. Remove the batteries from

the product if you are not going to

use it for a month or more.

• If your product uses more than

one battery, do not mix types

and make sure they are inserted

correctly. Mixing types or inserting

incorrectly may cause them to leak.

• Discard any leaky or deformed

battery immediately. They may

cause skin burns or other personal

injury.

• Please help to protect the

environment by recycling or

disposing of batteries according

to federal, state, and local

regulations.

Power Supply

• (battery power) 2 x “AAA”

ESD Remark: In case of misfunction

due to electrostatic discharge just reset

the product (disconnect and reconnect

of the power source may be required)

to resume normal operation.

Before you begin

Unpacking your player

You should have the following:

• one voice recorder

• one user manual

• one quick start guide

Installing batteries

This player can be operated by 2

“AAA” batteries (not included).

1. Slide the battery compartment

door to open.

2. Insert the two supplied

“AAA” batteries with

polarities matching

indications.

3. Replace the battery

compartment door.

Refer to the battery level indicator

on display for batteries level.

Replace with new batteries when

the indicator is empty.

Auto power shut down

The player will be automatically

turned off if left idle for three

minutes.

Using earphones and

external microphone

• When earphones are

connected, sound output from

speaker will be muted.

• When external microphone

is connected, no record

can be made from built-in

microphone.

Player on/off

Press to turn on the player. on

Press off to turn off the player.

Keys lock

To avoid accidental key activation,

slide the key lock selector toward

the lock icon ( ) to lock the keys.

Reverse the step to unlock them.

Display Display messages

The messages show at the bottom of the display during operation. Refer

to the below for their meanings:

Setting day and time

With day and time set, you can

always read on the display the

recording date and time of your

recorded messages. Normal

recording is still possible without

setting. However, no correct

recording date and time can

be referenced in your recorded

messages.

To set the date and time:

1. Press on to turn on the

player.

2. In stop mode,

press and hold

info/menu for

about 2 seconds

and then release

the button. The

ﬁ rst menu item FOLDER

ﬂ ashes on the display.

3. Press info/menu repeatedly

until YY ﬂ ashes on the

display.

4. Press or / Vol +/– to

adjust the value (default year:

2009) and then press info/

menu to conﬁ rm.

• If day and time have not been

set previously, the player goes

to step 4 automatically after

turn on.

Basic operations

Selecting folders and ﬁ les

To select folders:

1. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes on

the display.

2. Press /

or VOL

+ –/ to select a speciﬁ c folder

(A/B/C/D).

3. Press .

To select ﬁ les:

1. Select the folder you need.

2. Press to select /

the ﬁ le you want.

• If the ﬁ le you want is

in the current folder,

you can press / to select

it directly in both stop and

play modes.

Basic playback

To play back recorded ﬁ les:

1. Select a folder and a ﬁ le.

2. Press to start playback.

3. Press to pause playback,

press again to resume.

4. You can press to Vol +/–

adjust listening volume.

5. Press and hold or to

make quick search within a

ﬁ le.

• Quick search skips by second

within the ﬁ rst minute of

a recording. After that, the

search skips by minute. To

resume searching by second,

release the button once and

then press and hold or

again.

6. Press or once to skip

one ﬁ le forward or backward.

7. Press to stop playback.

To display ﬁ le Information:

Press info/menu repeatedly to

show various information of the

current ﬁ le:

• Current clock time

• Record date of current ﬁ le

• Record time of current ﬁ le

• Bookmark (if available) of

current location

• Remaining record time

• Elapsed play time (during

playback)

/ or Vol + –/

Press info/menu

Press to conﬁinfo/menu rm and

exit settings.

Bookmark

To create bookmarks:

• Once is pressed (refer to

step 4 in the section “Editing

mode”), the bookmark icon

ﬂ ashes and a newly created

bookmark number shows on

the display.

• You can create up to 29

bookmarks in a ﬁ le. When

the maximum limit is reached,

FULL will be shown.

• The minimum interval

between bookmarks is 3

seconds.

To skip to a bookmark anytime

during playback:

1. During playback, press

to go to the bookmark (if

available).

2. Press again to go to the

next bookmark.

Recording

Setting recording mode

Manual Recording

1. While playback is stopped,

select a destination folder

(A/B/C/D) (refer to “Basic

operations”).

2. Press to start recording.

(recording time will be

displayed once you press the

button)

3. To pause recording, press

once, press again to resume

recording.

4. To stop recording, press .

AVR (Automatic Voice

Recording)

This feature allows the player to

sense sound and to record only

when you are speaking into the

microphone. When dictation stops

for about three seconds, recording

will pause and then start again

automatically when you resume

dictation.

1. While playback is stopped,

select a destination folder

(A/B/C/D) (refer to “Basic

operations”).

2. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes on

the display.

3. Press info/menu

repeatedly until

AVR ﬂ ashes on

the display.

4. Press / or

VOL +/– to select between

AVR ON AVR OFF. and

5. Press to exit the player

menu.

6. Press to enter AVR mode.

7. Start dictation. Recording

starts automatically.

8. During AVR

recording, adjust

the sensitivity of

the microphone by pressing

Vol +/–, SEN with sensitivity

level will show on display (e.g.

increase sensitivity level when

recording source is far from

the player or the recording

environment is quiet).

9. Press to end AVR recording.

• Repeat step 2-5 and select

AVR OFF for de-selection.

• During recording, the

recording indicator

lights. When in AVR

standby mode or when

recording is paused, the

recording indicator ﬂ ashes.

• You can record up to 99

ﬁ les in one folder, not

exceeding 396 ﬁ les in total.

When the maximum limit

is reached, will be FULL

shown.

• The ﬁ rst syllable or two

may be lost when you

start recording because

this ‘sound’ is used to turn

on the AVR feature. It is

a good practice to make

some ‘sounds’ or say a short

word to activate the AVR

before you begin actual

dictation.

• To view the remaining

time and other recording

information, press info/

menu repeatedly during

recording.

Setting recording quality

To select among three

recording qualities (default

is SP):

Deﬁ nition:

• LP (Long Play) – allows

about 202 hours recording.

Recording format: .voc

• – allows SP (Standard Play)

about 35 hours recording.

Recording format: .voc

• – allows HQ (High Quality)

about 17 hours recording.

Recording format: .wav

1. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes on

the display.

2. Press info/menu

repeatedly until

LP SP HQ , or

shows on the

display.

3. Press / or

VOL +/ ,– to select among LP

SP and HQ.

4. Press to exit the player

menu.

Setting recording

condition

To select between two

recording conditions (default

is DICT):

Deﬁ nition:

• – in a CONF (Conference)

more open area and recording

source is far from the player.

• – in a more DICT (Dictation)

enclosed area and recording

source is close to the player.

1. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes on

the display.

2. Press info/menu

repeatedly until

DICT CONF or

ﬂ ashes on the

display.

3. Press / or

VOL +/– to select between

DICT and CONF.

4. Press to exit the player

menu.

• For conferences, to

obtain optimum

recording quality,

place the recorder with the

microphone freely exposed

to the sound source as

close as convenient. A

built-in automatic recording

level control will set the

optimum record level during

manual recording. Avoid

recording near unwanted

noise sources, such as air

conditioners or fans.

• If power supplied from

the battery fails suddenly

(e.g. batteries are removed

accidentally) during

recording, the recoding in

progress will be interrupted.

The recorded ﬁ le may also

be corrupted and cannot be

played back.

Erasing ﬁ les and bookmarks

• File numbers that

come after erased one

will be moved forward

by one automatically.

• Press to cancel erasing all

ﬁ les. The undeleted ﬁ les

are saved automatically.

• Formatting the internal

memory may be required

when encountering

compatability problem, etc.

• You may also format the

player when connected to

a PC (by right-clicking on

the player’s drive name or

letter and select “Format”

from the menu). Make sure

you select FAT or FAT32 as

the ﬁ le system.

Advanced operations

Cut

To erase unwanted parts from

the current ﬁ le:

1. Start playback of the desired

ﬁ le.

2. Press to mark the start of x

the unwanted part, CUT-S

shows on display.

3. Press to mark the end of x

the unwanted part, CUT-E

shows on display.

4. Press again to conﬁx rm

cutting within 3 seconds.

Otherwise, the cutting

operation will be canceled.

• You may also press to cancel

the cutting operation.

• Do not power off the player if

WAIT appears on the display.

• Insert, Append and

Cut will only update

the recorded time

length, without changing

recording time and date.

• All bookmarks will be

deleted after Insert,

Append or Cut is

performed.

Computer system

requirements

• PC with Windows VistaTM or

Windows® XP (Service Pack 1

or higher) or Windows® 2000

(Service Pack 3 or higher).

MAC OS is NOT supported.

• 20MB free hard disk space for

software

• USB port 1.1 or 2.0

• Installed sound card

Connecting to computer

Connect the player before launch-

ing the Digital Voice Manager.

1. Extend the USB connector on

the player and connect it to

your computer’s USB port.

2. shows on the player’s PCLINK

display. The player appears

as a removable drive in your

computer.

Installing Digital Voice

Manager

1. Connect the player with the

computer as instructed in the

previous section.

2. The ﬁ rst time you connect

the player to your computer,

the Digital Voice Manager

application will start

installation automatically.

Follow the instructions on the

screen for installation.

• If the installation does not

start automatically, open My

Computer and double-click

the player driver icon. Then

double-click rcaDVM_setup

to start the installation.

• If RCA Detective feature is

selected during installation,

the Digital Voice Manager

application will open

automatically once you

connect the player to your

computer.

• When the player

is in Menu mode,

during playback or

recording, a connection

between the player and

the computer will not be

established. Quit the above

modes before connecting to

the computer.

• Data transfer is possible

even if no batteries are

installed in the player.

• Do not disconnect the USB

connection during ﬁ les

transfer.

• The Digital Voice Manager

software can also be

downloaded from

www.rcaaudiovideo.com.

Connecting to computer Using Digital Voice Manager

The RCA Digital Voice Manager

can perform playback, organize

your bookmarks of the recorded

ﬁ les and create self-executable

voice ﬁ le from the recorded ﬁ les.

Launching the software

1. To launch the software, click

Start, select All Programs,

select RCA Digital Voice

Recorder RCA , then select

Digital Voice Manager.

• If RCA Detective feature is

selected during installation

of Digital Voice Manager,

the application will open

automatically once you

connect the player to your

computer.

2. All the drives in the computer

except the removable Digital

Voice Recorder are shown in

the top while the removable

Digital Voice Recorder is

shown in the bottom.

Playback and editing

operations

1. To organize your ﬁ les, click

the corresponding buttons to

cut, delete, copy and paste a

ﬁ le (or by drag and drop).

2. To play the recorded ﬁ les,

highlight the ﬁ le and click the

PLAY/PAUSE button on the

left of the toolbar.

All drives in

the computer

Removable

Digital Voice

Recorder

3. Adjust the volume on the

right of the toolbar.

• Click the corresponding

buttons in the toolbar to fast

backward/forward, skip to a

speciﬁ c time in the ﬁ le and

stop playback of a recorded

ﬁ le.

• To adjust the playback speed,

click Normal Speed and

select desired speed from the

pull down menu.

4. To skip to a bookmark, select

Play from the menu at

the top, then select Goto

Bookmark and select your

desired bookmark.

• To edit bookmarks, click the

corresponding buttons to add

or clear the bookmarks.

cut paste

copy delete

play/pause skip forward stop clear bookmark

skip backward add bookmark

skip to a

speciﬁ c time

adjust volume

Creating wave ﬁ le

Self-executable ﬁ le may be

blocked by some e-mail ﬁ lters.

When recordings are made in LP

or quality, you may select to SP

create wave ﬁ le if you want to

send your recorded messages by

e-mail.

1. Highlight a recorded ﬁ le, click

2. Select the destination folder

from the pop up window and

click .Save

3. The created ﬁ le could be

found in the destination

folder.

Transfer ﬁ les with Digital

Voice Manager

Your player is associated with

a drive letter. You can drag the

voice ﬁ les you want to transfer

to your player to the A/B/C/D

folder in the drive.

Your ﬁ les can be found in these

folders in the player once it is

disconnected from the computer.

You can also drag the voice ﬁ les

you want to transfer from the

A/B/C/D folder in the drive to your

computer.

Do not rename, delete

and transfer (drag-and-

drop) voice ﬁ les to your

player directly in Windows

Explorer. Use the Digital Voice

Manager to rename, delete

and transfer voice ﬁ les.

Using your player as a ﬁ le

storage device

The player can function as a

detachable data storage device.

You can take along your favorite

pictures and documents wherever

you go. Simply cut-and-paste or

drag-and-drop ﬁ les to or from it

via USB connection, the player will

appear as a removable drive in

Windows

Disconnecting from computer

After you have copied ﬁ les to

or from the player, you can

disconnect the player from the

computer.

1. Click the icon from the

System Tray and select

Unplug or Eject hardware.

Select the drive corresponding

to your player.

2. The Stop a Hardware player

screen will appear. Select the

player to be stopped again

for conﬁ rmation and click OK.

3. Now you can disconnect the

player from the computer.

If you want to go back to

USB mode for ﬁ le transfer

at this stage, you need to

unplug and connect the

player to the PC again.

Player doesn’t turn on

• Check that batteries are properly

inserted and not exhausted.

• Make sure battery compartment

door is properly closed.

• Make sure LOCK function is not

activated.

Display keeps ﬂ ashing when

player is off

• You may not have set the time.

Refer to section “Setting date

and time”.

Cannot record

• Make sure LOCK function is not

activated.

• Make sure memory is not full.

• You have recorded 99 ﬁ les in one

folder. Try record in a new folder.

• You may have formatted the

player with incorrect ﬁ le system

(e.g. NTFS or MAC format).

Refer to section “Erasing ﬁ les

and bookmarks” and format the

player again.

Incorrect recording date and

time during playback

• You may have not set the date

and time before recording. Refer

to section “Setting date and

time”.

No sound from speaker during

playback

• Make sure volume is not set to 0.

• Headphones should not be

connected.

Cannot edit

• Make sure PLAY ALL function is

not activated.

Cannot activate the player after

pressing on keys

• Remove the batteries to reset the

player.

Recordable time becomes shorter

• You may have set the recording

quality to ‘High Quality’, refer

to section ‘Setting Recording

Quality’.

• Delete the Digital Voice Manager

setup software from the player to

free up more memory space.

Cannot perform playback

• Make sure you have selected

folder with recorded messages.

• Make sure LOCK function is not

activated.

• Make sure the ﬁ le is playable,

which must be of 8-bit PCM or

designated RCA format. Other

formats (e.g. mp3, wma) cannot

be shown in the player for

playback.

Cannot erase recorded ﬁ le(s)

• Make sure you follow each step

under section “Erasing ﬁ les and

bookmarks” carefully.

Cannot stop recording when AVR

• If AVR ON sensitivity is set to

HIGH, recording may not be

stopped in noisy environment. Try

setting the sensitivity to LOW.

Cannot keep the saved setting

• If the batteries are removed,

saved settings may be removed.

Cannot open recorded ﬁ les in the

computer.

• You must use the provided DVM

software to open the ﬁ les.

• To download the software, go to

www.rcaaudiovideo.com

• On a Mac computer, only .WAV

ﬁ le on the player can be played

directly via application such as

Quicktime.

DVM software cannot work

properly with other RCA Digital

Voice Recorders.

• You must use the designated

DVM software for different RCA

Digital Voice Recorder models.

Go to www.rcaaudiovideo.com to

download the correct software.

Troubleshooting tips

To access the player menu:

Press and hold for info/menu

about 2 seconds and then release

the button. The ﬁ rst menu item

FOLDER ﬂ ashes on the display.

To change settings in the

menu:

1. In the player menu, press

info/menu repeatedly to view

the following menu items:

Folder (A/B/C/D)

Record conditions (DICT/CONF)

Record quality (LP/SP/HQ)

AVR (on/off)

Playback speed (FAST/SLOW)

Playback mode (one/all)

Tone (on/off)

Year

Player menu

Day (month/day)

12/24 hour time

Time (hour/minute)

Exit player menu

2. Press / / or VOL + – to

make selections or adjust

values.

3. Press to conﬁ rm your

selection and exit setting.

Audiovox Electronics Corp.,

150 Marcus Blvd., Hauppauge,

NY 11788

Trademark(s) © Registered

Marca(s) © Registrada(s)

Marque(s) © Deposée(s)

www.rcaaudiovideo.com

Printed in China/Impreso en China

5. After year is set, you will then

be guided to set month, day,

12/24 hour display, hour and

minute. Follow the operations

in step 4 for settings.

Turn off the player ﬁ rst

before replacing batteries.

If power interruption

exceeds 20 seconds, date and

time have to be set again.

Warranty information

12 Month Limited Warranty

Applies to RCA Audio/Video Products

• AUDIOVOX ELECTRONICS CORP. (the

Company) warrants to the original

retail purchaser of this product

that should this product or any

part thereof, under normal use and

conditions, be proven defective in

material or workmanship within

12 months from the date of

original purchase, such defect(s)

will be repaired or replaced with

reconditioned product (at the

Company’s option) without charge

for parts and repair labor.

• To obtain repair or replacement

within the terms of this Warranty,

the product is to be delivered with

proof of warranty coverage (e.g.

dated bill of sale), speciﬁ cation of

defect(s), transportation prepaid, to

the Company at the address shown

below.

• This Warranty does not extend

to the elimination of externally

generated static or noise, to

correction of antenna problems,

loss/interruptions of broadcast or

internet service, to costs incurred for

installation, removal or reinstallation

of product, to corruptions caused

by computer viruses, spyware or

other malware, to loss of media,

ﬁ les, data or content, or to

damage to tapes, discs, removable

memory devices or cards, speakers,

accessories, computers, computer

peripherals, other media players,

home networks or vehicle electrical

systems.

• This Warranty does not apply to

any product or part thereof which,

in the opinion of the Company,

has suffered or been damaged

through alteration, improper

installation, mishandling, misuse,

neglect, accident, or by removal

or defacement of the factory

serial number/bar code label(s).

THE EXTENT OF THE COMPANY’S

LIABILITY UNDER THIS WARRANTY

IS LIMITED TO THE REPAIR OR

REPLACEMENT PROVIDED ABOVE

AND, IN NO EVENT, SHALL THE

COMPANY’S LIABILITY EXCEED

THE PURCHASE PRICE PAID BY

PURCHASER FOR THE PRODUCT.

• This Warranty is in lieu of all other

express warranties or liabilities. ANY

IMPLIED WARRANTIES, INCLUDING

ANY IMPLIED WARRANTY OF

MERCHANTABILITY, SHALL BE

LIMITED TO THE DURATION OF

THIS WRITTEN WARRANTY. ANY

ACTION FOR BREACH OF ANY

WARRANTY HEREUNDER INCLUDING

ANY IMPLIED WARRANTY OF

MERCHANTABILITY MUST BE

BROUGHT WITHIN A PERIOD OF 24

MONTHS FROM DATE OF ORIGINAL

PURCHASE. IN NO CASE SHALL THE

COMPANY BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL

DAMAGES FOR BREACH OF THIS OR

ANY OTHER WARRANTY. No person

or representative is authorized

to assume for the Company any

liability other than expressed herein

in connection with the sale of this

product.

• Some states do not allow

limitations on how long an implied

warranty lasts or the exclusion

or limitation of incidental or

consequential damage so the

above limitations or exclusions may

not apply to you. This Warranty

gives you speciﬁ c legal rights and

you may also have other rights

which vary from state to state.

How to make a warranty claim:

• If your product is capable of

storing content (such as an mp3

player, digital voice recorder, etc), it

is recommended to make periodic

backup copies of content stored

on the product. If applicable,

before shipping a product, make

a back up copy of content or data

stored on the device. Also, it is

advisable to remove any personal

content which you would not want

exposed to others. IT IS LIKELY

THAT CONTENTS AND DATA ON

THE DEVICE WILL BE LOST DURING

SERVICE AND REFORMATTING.

AUDIOVOX ACCEPTS NO LIABILITY

FOR LOST CONTENT OR DATA,

OR FOR THE SECURITY OF ANY

PERSONAL CONTENT OR DATA ON

THE RETURNED DEVICE. Product

will be returned with factory

default settings, and without

any pre-loaded content which

may have been installed in the

originally purchased products.

Consumer will be responsible

for reloading data and content.

Consumer will be responsible to

restore any personal preference

settings.

• Properly pack your unit. Include

any remotes, memory cards, cables,

etc. which were originally provided

with the product. However

DO NOT return any removable

batteries, even if batteries

were included with the original

purchase. We recommend using

the original carton and packing

materials.

• Include evidence of purchase date

such as the bill of sale. Also print

your name and address and a

description of the defect. Send via

standard UPS or its equivalent to:

Audiovox Electronics Corp.

Attn: Service Department.

150 Marcus Blvd.

Hauppauge N.Y. 11788

1-877-833-3491

• Insure your shipment for loss or

damage. Audiovox accepts no

liability in case of damage or loss

en route to Audiovox.

• Pay any charges billed to you by

the Exchange Center for service

not covered by the warranty.

• A new or refurbished unit will be

shipped to you freight prepaid.

What we will do:

Provide you with a new, or at our op-

tion, a refurbished unit. The exchange

unit is under warranty for the remain-

der of the original product’s warranty

period.

For Canada Customers, please ship

to:

Audiovox Return Centre

c/o Genco

6685 Kennedy Road,

Unit#3, Door 16,

Mississuaga, Ontario

L5T 3A5

1. USB connector – press the

button on the back and then

slide to extend or retreat the

connector.

2. info/menu – press and hold

to access the player menu.

Press repeatedly to show

information of current ﬁ le.

3. on – turns on player, starts

or pauses playback.

4. Recording indicator

5. Built-in microphone

6. + / – skips / searches –

backward or forward, selects /

browses in the player menu.

7. off – turns off player, stops

playback or recording.

8. Key lock selector

9. External microphone jack

10. External earphones jack

11. + Vol – – adjusts volume,

selects / browses in the player

menu.

12. , rec/bookmark – starts

and pauses recording, inserts

bookmarks.

13. x erase, – erases ﬁ les,

bookmarks or format memory.

14. Battery compartment door

Player controls

1. Folder (A/B/C/D)

2. Recording in progress

3. File selected

4. Total number of ﬁ les in a

folder

5. Playback in progress

6. Remaining time for recording

7. Recording date

8. Area for displaying messages

(refer to the next section)

9. Battery level indicator

10. Key lock function activated

11. Bookmark

12. Recording conditions

13. Playback speed

14. Playback mode: play one or

play all

15. Automatic voice recording

activated

16. Recording quality

17. Month (MM), Day (DD) and

Year (YY)

Erasing mode

To erase ﬁ les or bookmarks,

while playback is stopped:

1. Press once.x

2. Press / to select one of

the erasing options:

• Delete the current ﬁ le (DEL

01)

• Delete all ﬁ les in the current

folder (DEL AL)

• Format the memory of the

player (FORMAT (Caution! )

All data inside the memory

will be erased)

• Delete all bookmarks in the

current ﬁ le (DEL BK)

3. With one of the above

options selected, press and

hold x for about 3 seconds

to conﬁ rm your selection and

start the deletion.

Play one/all

To play a speciﬁ c ﬁ le or all

ﬁ les in a folder:

1. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes on

the display.

2. Press info/menu

repeatedly until

ONE ALL or

ﬂ ashes on display.

3. Press / or

VOL +/– to select

between .ONE and ALL

4. Press to exit the player

menu.

• If ONE is selected, the player

will stop after the selected ﬁ le

is played. If ALL is selected,

the player will stop after all

ﬁ les in a folder are played.

Tones

To activate or deactivate the

beep sound when any key is

pressed (except during play-

back and recording):

1. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes on

the display.

2. Press info/

menu repeatedly

until TONE or

NOTONE shows

on display.

3. Press / or

VOL +/– to set beep sound

ON/OFF.

4. Press to exit the player

menu.

Speed

To adjust the playback speed:

1. Press and hold info/menu

for about 2 seconds and then

release the button. The ﬁ rst

menu item FOLDER ﬂ ashes

on the display.

2. Press info/menu

repeatedly until

SPEED shows on

display.

3. Press / or

VOL +/– to select

among FAST SLOW, and

no speed indication (normal

speed).

4. Press to exit the player

menu.

• The above operations can also

be done during playback.

Editing

CAUTION

• The edit function does not

operate when battery power

is too low.

• Make sure PLAY ALL ﬁ les is

not selected. Inserting new

segments, adding appendix

and cutting cannot be

performed when PLAY ALL

ﬁ les is selected.

• After editing a message,

WAIT may be displayed. Do

not power off the player until

WAIT disappears. Otherwise,

the memory which is

rearranging could not be read

or released until the player is

formatted.

Editing mode

To insert bookmarks, new

segments or appendix to a

recorded ﬁ le:

1. Select the desired ﬁ le and

start playback.

2. Press during playback to

enter editing mode. Playback

is paused.

3. Press / to select one of

the editing options:

• Insert an interception point

(bookmark) into the current

ﬁ le for quick reference (ADD

BK)

• Insert a new segment into the

current ﬁ le (INSERT)

• Insert an appendix at the end

of the current ﬁ le (APPEND)

4. With one of the above

options selected, press

again to conﬁ rm your

selection and start the editing.

• Refer to the following

sections for details.

Insert

To insert a new segment into

the current ﬁ le:

1. Once is pressed

(refer to step 4

in the section

“Editing mode”),

pause mode is

released and

the REC icon shows. The

recording of a new segment is

started from where the pause

mode is released.

2. Press to stop the recording

of new segment.

• Do not power off the player if

WAIT appears on the display.

Append

To insert an appendix at the

end of the current ﬁ le:

1. Once is pressed (refer to

step 4 in the section “Editing

mode”), the icon shows REC

and the recording of appendix

is started.

2. Press to stop the recording

of the appendix.

• Do not power off the player if

WAIT appears on the display.

12 HOUR

24 HOUR

ADD BK

APPEND

BATTLO

CUT-E

CUT-S

DEL 01

DEL AL

DEL BK

FORMAT

FULL

INSERT

LOCKED

NO BK MK

NO TONE

OFF

PAUSE

PCLINK

SEN MI

SPEED

TONE

VOL 15

WAIT

12 hour time display mode

24 hour time display mode

Insert bookmark

Appendix (Adding Appendix)

Batteries are weak

Cut End (Cutting)

Cut Start (Cutting)

Delete the current ﬁ le

Delete all ﬁ les in a folder

Delete all bookmarks in the current ﬁ le

Format the memory

Memory full

Insertion (Inserting New Segments)

Key locked

No bookmark created in the current ﬁ le

No beeping sound (Setting Beep Sound)

Off (Automatic Voice Recording)

On (Automatic Voice Recording)

Playback or recording is paused

Player is connected to the computer

Sensitivity Level (AVR)

Speed of playback

Beeping sound on (Setting Beep Sound)

Volume (Setting Volume)

Memory rearrangement/System is busy

Press info/menu

Manufacturer/Responsible party

Audiovox Electronics Corp,

150 Marcus Blvd, Hauppauge, NY 11788

1-317-810-4880

(The English version serves as the ﬁ nal

reference on all products and opera-

tional details should any discrepancies

arise in other languages.)

To delete all bookmarks

created in the current ﬁ le:

Refer to section “Erasing ﬁ les and

bookmarks”.

All drives in

the computer

Removable

Digital Voice

Recorder

new bookmark

number

bookmark

icon

Produkt Specifikationer

Mærke:	Audiovox
Kategori:	Mp3-afspiller
Model:	VR5220

Har du brug for hjælp?

Hvis du har brug for hjælp til Audiovox VR5220 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Mp3-afspiller Audiovox Manualer

Audiovox RP5120 Manual

29 August 2024

Audiovox RP5130 Manual

29 August 2024

Audiovox M-6316PL Manual

29 August 2024

Audiovox M-6408BL Manual

29 August 2024

Audiovox SL5008 Manual

29 August 2024

Audiovox M-6316RD Manual

29 August 2024

Audiovox TH1611 Manual

29 August 2024

Audiovox VR5220 Manual

29 August 2024

Audiovox M4204 Manual

29 August 2024

Audiovox M-6408PL Manual

29 August 2024

Mp3-afspiller Manualer

Nyeste Mp3-afspiller Manualer

Philips GoGear HDD6330 Manual

21 December 2024

Philips GoGear SA5124 Manual

21 December 2024

Yarvik Funkick PMP228 Manual

17 December 2024

Yarvik Funkick PMP222 Manual

17 December 2024

Yarvik Funkick PMP227 Manual

17 December 2024

Yarvik Funkick PMP221 Manual

17 December 2024

Yarvik Funkick PMP220 Manual

17 December 2024

Yarvik Funkick PMP224 Manual

17 December 2024

Yarvik Joy PMP204 Manual

17 December 2024

Yarvik Joy PMP202 Manual

17 December 2024
