INSTALLATION & OPERATION MANUAL /
EINBAU- & BEDIENUNGSANLEITUNG
ATW16 ATW20 ISUBWOOFERS
Thank you and congratulations! You have purchased one of the nest subwoofers available in its respec tive price class. This AXTON
ATW subwoofer will give you great bass performance and true audiophile sound quality. To maximize the performance of your sub,
it is recommended to follow the enclos ure suggestions given in this manual. lf for some reason, the provided system/enclosure data
can not be applied within your specic vehicle or car audio installation, please contact your authorized AXTON dealer to ask for
further assistance.
LIMITED WARRANTY
AXTON warrants any ATW woofer to be free of defects in material and workmanship for a period of TWO YEARS from the original
date of purchase at retail, contingent upon installation being performed or ap proved by an authorized AXTON dealer. Should ser-
vice be necessary during the afore mentioned period, AXTON will at its own discretion repair or replace the defective speaker at
no charge. Damage caused by the following is NOT covered under warranty: Abuse of speaker due to excessive amplier power,
clipping, inappropriate enclosure design, or any further physical damage (during transportation).
CABINET CONSTRUCTION & DAMPING
For best results, use 19 mm to 22 mm MDF or birch plywood
to build the enclosure. All enclos ure volumes given are precise
internal chamber volumes, where displacement of driver and
port(s) have been included already.
Each enclosure, no matter what tuning prin ciple, needs internal
damping: The sealed and ported cabinets should be lined out
internally with "eggcrate" PU-foam.
KEY FEATURES ATW WOOFERS
6.5" / 8" BACK VENTED STEEL BASKET
120 MM HIGH EFFICIENT SINGLE MAGNET
HIGH STRENGTH FIBERGLASS/FOAM/PAPER CONE
LONG-THROW CONEX™ SPIDER
LONG-LASTING RUBBER SURROUND
TSL VOICE-COIL FORMER
1.5” COPPER WIRE DOUBLE VOICE COIL
HYPER-EXTENDED CENTER POLE
WOVEN TINSEL WIRES
RUBBER MAGNET BOOT
GOLD PLATED TERMINAL
Exclusive Distributor for Europe: ACR AG ∙ Bohrturmweg 1 ∙ CH-5330 Bad Zurzach ∙ Switzerland
EU Legal Representative:
ACR S & V GmbH ∙ Industriestr. 35 ∙ D-79787 Lauchringen ∙ Germany Rev. A
TECHNICAL SPECIFICATIONS ATW16 ATW20
Usable Frequency Response 65 ‒ 400 Hz 55 ‒ 300 Hz
Continuous Power Handling 75 W RMS 75 W RMS
Peak Power Handling 150 W max 150 W max
Nominal lmpedance 2 x 2 ohms 2 x 2 ohms
Voice Coil Diameter 38 mm 38 mm
Sensitivity 84 86.7dB dB
Mounting Diameter 145 mm 184 mm
Mounting Depth 79 mm 80 mm
THIELE-SMALL PARAMETERS
Free-Air Resonance (Fs) 47.1 Hz 36.34 Hz
DC Resistance (Re) 4.5 ohms 4.4 ohms
Electrical Damping (Oes) 0.63 0.35
Mechanical Damping (Qms) 6.23 7.98
Total Damping (Ots) 0.34 0.33
Equivalent Volume of Compliance (Vas) 7.15 21.49liter liter
Moving Mass incl. Air Load (Mms) 42.4 57.86g g
Electrically Limited Cone Excursion (Xmax p-p) 6.7 mm 6.7 mm
Effective Cone Surface (Sd) 136.8 cm² 213.8 cm²
RECOMMENDED ENCLOSURES
SEALED ENCLOSURE
Internal Volume 10 15l l
PORTED ENCLOSURE
Internal Volume 18 20l l
Port Diameter/Length 1 x 7 cm ‒ 20 cm 1 x 7 cm ‒ 25 cm
