Side 1/2
© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com axxessinterfaces.com • metraonline.com
Axxess Integrate Axxess Integrate
Installation Instructions for AX-MAZCAM
REV. 1/25/16 REV. 1/25/16
Installation Instructions for AX-MAZCAM
FEATURES
• Retains the factory back-up camera to an aftermarket radio
Allows an aftermarket camera to be added to the factory screen
INTERFACE COMPONENTS
AX-MAZCAM harness
AX-MAZCAM
Mazda Back-Up Camera Retain/Add-On
2007-2015
MAZDA
CX-5 2013-2015
CX-7 2007-2012
CX-9 2007-2015
Mazda6 2011-2015
• Cutting tool • Tape • Crimping tool
• Connectors (example: butt connectors, bell caps, etc.)
APPLICATIONS
TOOLS REQUIRED
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a bet ter tomorrow.
Metra recommends MECP
certified technicians
Connections to be made
The AX-MAZCAM can be connected two different ways
To retain the factory back-up camera to an aftermarket radio:
Connect the wire to chassis ground.Black
Connect the Yellow wire to accessory power.
Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.
Connect the reverse wire from the aftermarket radio, to the reverse signal in the vehicle.
To allow an aftermarket camera to be added to the OEM screen:
Connect the wire to the ground wire of the aftermarket camera.Black
Connect the Yellow wire to battery wire of the aftermarket camera.
Connect the female Yellow RCA jack to the aftermarket camera.
CAUTION!
Metra recommends disconnecting the negative battery terminal before beginning any instal
-
lation, unless the vehicle manufacturer recommends against so. Please check with your local Dealership
for more information. All accessories, switches, climate controls panels, and especially air bag indicator
lights must be connected before reconnecting the battery or cycling the ignition. Also, do not remove the
factory radio with the key in the on position, or the vehicle running. It would be best to remove the key
from the ignition and then wait a few seconds before removing the factory radio.
