WIRELESS BICYCLE COMPUTER

USER GUIDE

After Sales Support

Now you have purchased a Bikemate

product you can rest

assured in the knowledge that as well as your 3 year parts

and labour guarantee you have the added peace of mind of

dedicated helplines and web support. The 3 year warranty

does not affect your statutory rights.

• Maximum speed (max 99.9 km/h or mph)

• Time (12 hr / 24 hr display)

• Average speed (0-99.9 km/h or mph)

• Scan function (for DST, MXS, AVS, TM)

• Cache memory (for TM, DST, AVS)

• Speed comparison (+/-)

• Speed trend ( or )

• Service indicator

• Odometer save function

• Temperature display (-10⁰C to +50⁰C )

• Temperature display setting (⁰F / ⁰C)

• Calories

• Fat Burning

• Automatic start/stop

Ride speed

This indicates the current speed

(0-99 km/h).

Daily distance (DST)

(step information function, reset function)

The distance travelled is displayed with

DST. The trip kilometre counter switches on

automatically with the tachometer. To set the trip kilo-

metre counter to 0, press the left button for about 2 sec-

onds in the DST function.

IRL

WIRELESS BICYCLE COMPUTER

Congratulations!

You have made an excellent choice with the purchase

of this quality Bikemate® product. By doing so you now

have the assurance and peace of mind which comes from

purchasing a product that has been manufactured to the

highest standards of performance and safety, supported

by the high quality standards of ALDI.

Total distance (ODO)

The kilometre counter adds up the total num-

ber of kilometres travelled and displays this

with ODO on the screen. The kilometre coun-

ter can only be reset to zero by removing the battery or by

simultaneously pressing both buttons for about 3 seconds.

Trip time (TM)

The trip time measurement function is in-

dicated by TM on the display. This function

automatically switches on with the speed-

ometer and is suspended each time the bike stops so that

only the actual travel time is measured. The clock is set

to 0 by pressing the left button in the DST function.

Maximum speed (MXS)

The maximum speed is indicated on the dis-

play with MXS and is saved automatically. To

delete the maximum speed, press and hold

the left button.

Time (12 hr / 24 hr)

By pressing the right-hand button you ar-

rive at the next function (time). To set the

time, press the left button for 3 seconds. By

doing so you can then select whether the time is shown

in the 12 hour or 24 hour mode by pressing the right

button. After selecting the display press the left but-

ton which makes the hour indicator flash. You can now

set the hours with the right button. To set the minute

indicator, please press the left button again. The minute

indicator then flashes which you can set by pressing the

right button. After setting the time press the left button.

Average speed (AVS)

The average speed is displayed by AVS. This

function is connected with the trip timer so

that only the average speed for the actual

trip is saved.

Scan function (SCAN)

After setting the scan function all functions

(DST, MXS, AVS, TM) are displayed automati-

cally one after the other.

Cache memory

Pressing the left button, the computer

has a unique cache memory with which

the display can be retained at the end of a

journey leg and the values for TM, DST and AVS can

be reviewed at a later date (the memory is shown by

pressing the right-hand button). This is especially

practical for measuring the time if you go past the fin-

ish line in a race because the automatic stop clock can-

not be stopped manually. It works in such a way that on

cycling past the finish line press the left button for a

time so that the display is retained.

Speed comparison

(cadence)

A “+” or “-” sign is shown on the right-hand

side of the speed display to indicate wheth-

er you are travelling faster or slower than the average

speed (AVS). A “-” sign indicates that you are travelling

below the average speed.

Speed trend

(acceleration and deceleration)

A symbol that represents a cyclist is shown

on the left-hand side of the speed display. A bike trav-

elling forwards indicates that you are accelerating. A

bike travelling backwards indicates that you are getting

slower.

Odometer save function

The save function (SAVE) enables you to save

the distance covered (ODO) which is important

information for you. This information is also retained after

changing the battery. Press the right button to call up the

“ODO” mode after changing the battery and the re-setting

of the wheel sizes, and save the information under “ODO”.

Afterwards press and hold the left button for two seconds

until the last setting flashes. Press the right button to set

the display, confirm this with the left button and make the

entry. Repeat the above process to set the required value

for the odometer display. Press the left button once again

and return to “ODO” mode.

Temperature display settings

Optionally, the bike computer can display the

temperature in ⁰C (Celsius) or F (Fahrenheit).

For temperature indication keep the left but-

ton depressed for 2 seconds. ⁰C is shown. By pressing the

right button the temperature is converted to F. Confirm the

choice with the left button.

Calorie counter (CAL)

The average energy use in calories (cal) is au-

tomatically counted by means of the calorie

counter. To reset the calorie counter hold the

left button for 2 seconds in CAL mode. Press the right but-

ton to obtain the monitoring function FAT.

Fat burning (FAT)

This approximate value applies to the amount

of fat (in g) burnt during the trip. To reset the

value for fat to zero hold the left button down

for about 2 seconds. Press the right button to obtain the

monitoring function SCAN FUNCTION.

Computer installation

Push the bike computer into the installation bracket until it

clicks into place. Press the release button to detach the bike

computer. (See Fig. 1.)

Left Right

release

button

Fig. 1

We want you to be completely satisfied with your

purchase so this Bikemate® product is backed by a

comprehensive manufacturer’s 3 year warranty and an

outstanding after sales service through our dedicated

Helpline.

We hope you will enjoy using your purchase for many

years to come. If you require technical support or in

the unlikely event that your purchase is faulty please

telephone our Helpline for immediate assistance. Faulty

product claims made within the 3 year warranty period

will be repaired or replaced free of charge provided that

you have satisfactory proof of purchase (keep your till

receipt safe!). This does not affect your statutory rights.

However, be aware that the warranty will become null

and void if the product is found to have been deliberately

damaged, misused or disassembled.

Functions

If you press the lower button the individual functions are

listed on the display.

Functions

• Ride speed (0 – 99.9 km/h or mph)

• Daily distance (max 999.9 km or miles)

• Total distance (max 999.9 km or miles)

• Trip time (0:59’ 59’ - hours, minutes, seconds)

MODEL: E83005

AFTER SALES SUPPORT

GB 00800 / 68546854 monz-gb@teknihall.com

IRL 00800 / 68546854 monz-ie@teknihall.com

(free of charge)

MODEL: E83005

AFTER SALES SUPPORT

GB 00800 / 68546854 monz-gb@teknihall.com

IRL 00800 / 68546854 monz-ie@teknihall.com

(free of charge)

PRODUCED IN CHINA FOR:

ALDI STORES LTD. PO BOX 26, ATHERSTONE,

WARWICKSHIRE, CV9 2SH.

ALDI STORES (IRELAND) LTD.

PO BOX 726, NAAS, CO. KILDARE.

Visit us at www.aldi.com
