Operation Guide 5041

MO0806-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out of your

purchase, be sure to read this manual carefully.

Starting second hand movement and digital display

To conserve battery power, the watch is shipped from the

factory with its functions disabled. Pressing any one of the

watch’s three buttons will activate its functions, which will

cause the second hand to start moving and the digital

display to activate.

Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage

or loss suffered by you or any third party arising through the use of this product or

its malfunction.

About This Manual

•Button operations are indicated using the letters shown

in the illustration.

•Each section of this manual provides you with the

information you need to perform operations in each

mode. Fur ther details and technical information can be

found in the “Reference” section.

Hour hand

Minute hand

Date

Second hand

(Timekeeping/

Stopwatch)

24-hour hand

Stopwatch

minute hand

Stopwatch second hand

▲

Hand Setting Mode Alarm Mode

World Time Mode

General Guide

•Press C to change from mode to mode.

•About one or two seconds after you enter the World Time Mode, Alarm Mode, or

Hand Setting Mode, the hands will move to the position that indicates the current

setting of the mode.

•In the Timekeeping Mode (except when a setting screen is on the display), press B

to illuminate the face of the watch for about one second.

Timekeeping Mode

Press C.

Stopwatch Mode

▲

Radio-controlled Atomic Timekeeping

This watch receives a time calibration signal and updates its time setting accordingly.

•Supported time calibration signals: Germany (Mainflingen), England (Anthorn).

•See the information under “Signal Reception Troubleshooting” if you experience

problems with time calibration signal reception.

Current Time Setting

This watch adjusts its time setting automatically in accordance with a time calibration

signal. You also can perform a manual procedure to set the time and date, when

necessary.

•The first thing you should do after purchasing this watch is to specify your

Home City, which is the city where you normally will use the watch. For more

information, see “To specify your Home City”.

•When using the watch outside the areas covered by the time signal transmitters, you

will have to adjust the current time setting manually as required. See

“Timekeeping”

for more information about manual time settings.

To specify your Home City

1. In the Timekeeping Mode, hold down A for about five

seconds until the watch beeps twice.

•The second hand will move to the city code of the

currently selected Home City. This is the city code

setting mode.

2. Use B to move the second hand to the city code you

want to use as your Home City.

•Each press of B causes the second hand to advance

clockwise to the next city code.

•Time calibration signal reception is supported when

any one of the city codes shown in the table below is

selected as your Home City.

Second hand

City code

•For full information on city codes, see the “City Code Table”.

• In addition to the above, you also can select city codes that are outside the ranges

of the time calibration signal transmitters supported by this watch.

3. After the Home City setting is the way you want, press to return to theA

Timekeeping Mode.

•Normally, your watch should show the correct time as soon as you specify your

Home City code. If it does not, it should adjust automatically after the next auto

receive operation. You also can perform manual receive or you can set the time

manually.

German/U.K. Signal

City Code

LON

PA R

ATH

City Name

London

Paris

Athens

•Even if the time calibration signal is received correctly, there are some times when

the analog hands may not indicate the correct time. If this happens, use the

procedures under “Adjusting the Home Positions” to check the home positions of the

hands, and make adjustments as required.

Time Calibration Signal Reception

There are two different methods you can use to receive the time calibration signal:

auto receive and manual receive.

•Auto Receive

With auto receive, the watch receives the time calibration signal automatically up to six

times a day. When any auto receive is successful, the remaining auto receive

operations are not performed. For more information, see “About Auto Receive”.

•Manual Receive

Manual receive lets you start a time calibration receive operation with the press of a

button. For more information, see “To perform manual receive”.

12 o’clock

Important!

•When getting ready to receive the time calibration signal, position the watch as

shown in the nearby illustration, with its 12 o’clock side facing towards a window.

This watch is designed to receive a time calibration signal late at night. Because of

this, you should place the watch near a window as shown in the illustration when you

take it off at night. Make sure there are no metal objects nearby.

•Make sure the watch is facing the right way.

•Proper signal reception can be difficult or even impossible under the conditions listed

below.

•Signal reception normally is better at night than during the day.

•Time calibration signal reception takes from two to seven minutes, but in some

cases it can take as long as 14 minutes. Take care that you do not perform any

button operations or move the watch during this time.

Inside or

among

buildings

Inside a

vehicle

Near a

construction

site, airport,

or other

sources of

electrical

noise

Near high-

tension power

lines

Among or

behind

mountains

Near

household

appliances,

office

equipment,

or a mobile

phone

Approximate Reception Ranges

Anthorn

Mainflingen

500 kilometers

1,500 kilometers

U.K. signal transmitter

approximate reception

range as of April 2007

•In April 2007, the U.K. signal transmitter was moved from Rugby to Anthorn, which

resulted in a slight shift in the approximate reception range of the signal. The shift is

so slight that there is virtually no change in the ability to receive the signal.

•Even when the watch is within the reception range of a transmitter, signal reception

may be impossible at times due to the effects of geographic contours, structures,

weather, the season of the year, the time of day, radio interference, etc. Note that the

signal becomes weaker at distances of approximately 500 kilometers from the

transmitter, which means that the influence of the conditions listed above becomes

even greater.

Produkt Specifikationer

Mærke:	Casio
Kategori:	Ur
Model:	EQW-500DBE-1AVER
Vægt:	91.8 g
Dimensioner (BxDxH):	46 x 13.7 x 49 mm
Armbånd, materiale:	Resin
Urkassens materiale:	Rustfrit stål
Kalender:	Ja
Stopur:	Ja
Batterilevetid:	2 År
LED-baggrundsbelysning:	Ja
Batteritype:	CR1616
Antal understøttede batterier:	1
Urets glastype:	Mineral
Alarmfunktion:	Ja
Vandbestandig dybde:	100 m
Verdenstid funktkon:	Ja
Radiosignal modtager:	DCF/MSF
