GENERAL SPECIFICATIONS
SPÉCIFICATIONS GÉNÉRALES
ESPECIFICACIONES GENERALES
THIELE SMALL PARAMTERS
PARAMÉTRES THIELE-SMALL
PARÁMETROS THIELE-SMALL
Speaker Size
Taille de haut-parleur
Tamaño de los altavoces
DCR
Sd
Fs
Qes
Qms
Qts
Vas
Mms
Mmd
BL
10” (250mm)
Subwoofer
800 Watts
250 Watts
2-Ohms DVC
30~800 Hz
87dB
4.2 Ohm (2.1 Ohm + 2.1 Ohm)
0.033329 m²
48.636 Hz
0.649
6.520
0.591
21.754 L
77.647 g
74.149 g
12.090
Xmax 10.65 mm
Speaker Type
Genre de haut-parleur
Tipo de altavoz
Peak Power
Gestion de la puissance maximale
Manipulación de potencia máxima
RMS Power
Gestion de la puissance continue
Manipulación de potencia continua
Impedance
Impédance
Impedancia
Frequency Response
Résponse en fréquence
Respuesta a la frecuencia
Sensitivity
Sensibilité
Sensibilidad
Owners's manual & Installation manual
Manuel du propriétaire et manuel d'installation
Manual de instrucciones y manual de instalación
CM2513WL
For more information please visit Clarion website or call 1-800-GO-CLARIONwww.clarion.comClarion Corporation of America Designed in California. Manufactured in China.
Color Output
RedRed
Green
Blue
Red + Green
Red + Blue
Green + Blue
Red + Green + Blue
Green
Blue
Yellow
Magenta
Light Blue
White
RGB Wire(s)
Note: When paired with an LED controller,
speaker LEDs can achieve up to 16 million color
variations
To activate speaker LED, Black wire must be connected to
+12V positive and RGB wires must be grounded. To
Ensure arrow is facing downward for
proper speaker orientation
10.83” (275mm)
8.66” (220mm)
5.04” (128mm)
6.99” (177.5mm)
Black - Negative
Red + Positive
Jumper Wire
10” (250MM) MARINE 2-OHMS DVC SUBWOOFER
CAISSON DE BASSES DVC MARINE 2 OHMS, 10 PO (250MM)
SUBWOOFER DVC MARINO DE 2-OHMS DE 10” (250MM)
4 3 2 1 2 1 2 1
Cutout
Hole
Dual Voice Coil Configurations
Option 1 (Default) Option 2
4-Ohm Configuration Cut White wire to create Dual 2-Ohm Configuration
4-Ohm
White
Red Black White Red
Black White
2-Ohm
2-Ohm
Red Black
White
4-Ohm
