Side 1/2

ALL-IN-1

LITHIUM BEARD & MUSTACHE

T R I M M E R • R E C H A R g E A B L E

Instruction Booklet

For your safety and continued enjoyment

of this product, always read the instruction

booklet carefully before using.

Model GMTL1

IMPORTANT SAFETY

INSTRUCTIONS

When using electrical appliances, especially when

children are present, basic safety precautions should

always be taken, including the following:

READ ALL INSTRUCTIONS

BEFORE USING

FOR HOUSEHOLD USE ONLY

KEEP AWAY FROM WATER

DANGER – Any appliance is

electrically live, even when the switch is off.

To reduce the risk of death or injury by electric shock:

1. Always unplug appliance from electrical

outlet immediately after using (except when

charging unit).

2. Do not place or store appliance where it could

fall or be pulled into a tub or sink.

3. Do not use appliance while bathing or in the

shower.

4. Do not place appliance in, or drop into water or

other liquids.

5. If appliance has fallen into water, do not

reach for it. Unplug immediately.

6. Unplug this appliance before cleaning.

WARNING – To reduce the risk

of burns, electric shock, fire, or injury to persons:

1. Never leave a plugged-in appliance unattended.

2. This appliance should not be used by, on, or near

children or individuals with certain disabilities.

3. Use appliance only for its intended use as

described in this manual. Use only attachments

recommended by the manufacturer. Do not use an

extension cord to operate the appliance.

4. Never operate the appliance if it has a

damaged cord or plug, is not working properly,

has been dropped or damaged, or dropped into

water. Return the appliance to a Conair Service

Center for examination and repair.

5. Keep the appliance cord away from heated

surfaces.

6. Do not pull, twist or wrap the cord around the

appliance.

7. Never drop or insert any object into any opening

on the appliance.

8. Do not place the appliance on any surface while

it is operating.

9. Do not use the appliance with a damaged or bro-

ken comb or with teeth missing from the blades, as

injury may result. Before each use, make certain

the blades are aligned properly and oiled.

10. Do not use the appliance outdoors or where

aerosol (spray) products are being used or oxygen

is being administered.

11. THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.

SAVE THESE

INSTRUCTIONS

USER MANUAL

Before using the Class 2 Power Supply,

read these instructions carefully.

Use with adapter C12

Rated input voltage:

100–240V AC, 50/60Hz 0.2A Max

Rated output: 4.5V DC 1000mA

OPERATION

1. For dry location use only. Do not expose to water.

2. When not in use, unplug unit completely.

3. Unit will become warm during operation.

CAUTION

1. Dry location use only. Do not expose to liquids,

vapor, or rain.

2. Ensure jack is plugged into the trimmer unit

before plugging the adapter into the outlet.

3. Do not operate any appliance that has a damaged

output cord or housing.

4. Always unplug the unit before cleaning or when

not in use.

5. This power unit is intended to be correctly

oriented in a vertical or floor mount position.

6. Be sure voltage is correct before plugging in.

For connection to a supply not in the U.S.A. use an

attachment plug adapter of the proper configuration

for power outlet.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference,

and (2) this device must accept any interference

received, including interference that may cause

undesired operation.

Warning: Changes or modification to this unit not

expressly approved by the party responsible for

compliance could void the user’s authority to operate

the equipment.

TROUBLESHOOTING

If your rechargeable trimmer does not seem to be

taking a charge, take the following troubleshooting

steps before returning it for repair:

1. Be sure the electrical outlet is working by

plugging in another appliance to test the outlet.

2. Make sure the electrical plug is not connected

to a switch that turns power off when lights are

turned off.

OPERATING

INSTRUCTIONS

1. Before using the trimmer for the first time,

charge continuously for 2 hours. Maximum bat-

tery capacity will be reached only after 3 charg-

ing and discharging cycles.

2. Plug the adapter into any wall outlet (at the

voltage listed on the label affixed to the adapter).

Unplug adapter when not in use.

3. The adapter may become warm while charging.

This is normal.

4. Preserving the batteries: In order to maintain the

optimum capacity of the rechargeable batteries, the

trimmer should be recharged for 2 hours approxi-

mately every 6 months.

USER MAINTENANCE

INSTRUCTIONS

TAKING CARE OF YOUR TRIMMER

OILING THE BLADES (OIL INCLUDED)

About once a month you should oil the trimmer blades

with the oil provided in your kit. It is best to do this over

a piece of newspaper. Turn the trimmer on and hold it so

that the blades are pointed downward. Spread one drop

of oil across the blades, then turn the trimmer off and

wipe away the excess oil with a soft cloth.

Be careful not to use too much oil and don’t oil your

trimmer more than necessary, as this could damage the

motor. (Never attempt to oil the motor bearing, as it is

permanently lubricated.) Keep oil away from children.

BLADE CARE

Because the trimmer blades are precision-made

for a very special use, they should always be

handled with care and cleaned regularly to ensure

maximum performance. Each time you finish using

the trimmer, take the cleaning brush provided and

brush away any loose hair that has collected in the

blades. You can also remove the blade attachment

and rinse under warm water only. Do NOT use hot

water as this might cause damage. Use a clean

cloth to dry the attachment, reattach and then store

the trimmer to protect the blades until the next use.

DO NOT RINSE TRIMMER HANDLE OR ADAPTER

Be especially careful when changing or adjusting the

blades. When you have your trimmer serviced, be

sure that both blades are sharpened or replaced at

the same time.

To promote the long life of the trimmer, use it only for

the purpose intended by the manufacturer – to trim

your beard and mustache.

GROWING A BEARD AND MUSTACHE

There are three key factors that will determine which

beard or mustache style is best for you:

1. The shape and dimensions of your face.

2. The natural growth of your beard/mustache.

3. The thickness of your beard/mustache. If you are

unsure about the type of beard or mustache that

would most suit your face, speak with a professional

hair stylist and ask for an opinion on what style would

be best. Once your beard or mustache has been

styled, it is essential that you maintain its appear-

ance. To do this, use your trimmer to trim your beard/

mustache weekly.

For the best trimming results, your beard should be

slightly damp (NOT WET) when using your trimmer.

This will prevent the trimmer from removing more

hair than desired.

TYPES OF BEARDS/MUSTACHES

GETTING STARTED

OUTLINING YOUR BEARD

1. It is always best to begin with a clean, slightly

damp beard.

2. After you have combed through your beard in the

direction it grows naturally, you will want to outline

the desired shape, beginning under your jawline.

3. Begin defining your beard’s

shape under your chin and wor

upward on each side of your fac

toward your ears. Then defin

the upper outline of your beard

across your cheeks, past your sideburns, and toward

your hairline.

TRIMMING YOUR BEARD

1. The trimmer includes a 6-position comb for use with

the hair trimming blade (4–18mm) which provides

lengths of 4/25" (shortest) to 7/10" (longest).

2. To use the 6-position comb, slide

the unit over the trimmer blade and

snap it down into position. At first,

until you become familiar with the

adjustments, use the longest trim

setting. (You can always go back and make your beard

a little shorter.)

3. Begin trimming your beard using smooth, even

strokes. Start with your sideburns and work downward

toward your chin. (Never attempt to trim against the

natural growth of your beard because the hair will be

cut too short.)

4. If you decide you want

a closer trim, you can now

adjust the 6-position comb

attachment to a shorter

setting (such as 3/32" or

5/32") and go over your beard again until you achieve

the desired length.

HOW TO GET THE STUBBLE LOOK

This trimmer includes 1 stubble comb

that allows you to achieve close stubble

or shadow looks. The stubble comb fits

on the blade just like the jawline combs;

note Blending the Jawline section for

specifics on how comb/jawline combs

attach.

BLENDING THE JAWLINE

1. The two jawline comb attachments will help you

to achieve a neat, finished trim under your chin. To

use one of the attachment combs, press it down

over the trimmer blades until it clicks into position.

2. Hold the trimmer in an upright position and begin

trimming under your jawline, using short, even

strokes.

3. After your beard is blended, turn off the trimmer

and remove the attachment comb by gently pulling

up on tab.

JAWLINE COMB I JAWLINE COMB II

TRIMMING YOUR MUSTACHE

1. For best results, start

with a clean, slightly damp

mustache.

2. Comb through your mus-

tache in the direction it grows.

3. Place the 6-position comb over the facial hair

blade and snap it into position. It is a good idea to

start with the longest trim-setting adjustment. (You

can always go back and cut your mustache more

closely with a shorter setting.)

ALWAYS TRIM YOUR MUSTACHE

FROM THE TOP DOWN

4. After your mustache has

been trimmed to the desired

length, remove the 6-position

comb and, using the blades

only, define the outline of the

bottom of your mustache.

SHAVING FOIL

Your trimmer includes a shaving foil. When attached,

it will allow you to shave close and around your

facial hair to provide an extra-clean look. Just move

the shaving head in up-and-down gentle strokes

to remove any stray hairs. Be sure not to press too

hard, as that could cause some skin irritation.

After each use clean the shaving head as follows:

1. Make sure the trimmer is off.

2. Remove the shaving head from the unit.

3. Remove the foil head from the shaving head

(press the two buttons on either side of the shaving

head and pull the foil head away).

4. Use the cleaning brush to gently remove any

hairs from the cutter and shaving head.

Do not rinse or oil the foil head as it is perma-

nently lubricated.

NOSE/EAR & DETAIL TRIMMER

For easy, safe grooming of long nose/ear hairs and

fine lines and accurate detailing. Attach the nose/

ear & detail trimmer and hold unit to areas that

need trimming.

• Switch the trimmer on.

• Gently move the blade through the area of hair

you wish to trim.

• The trimmer will work most efficiently when cut-

ting through hair at its own speed.

• Never turn the trimmer off while in the hair.

ON/OFF SWITCH

To operate, simply slide switch toward blade. To stop,

slide away from blade.

CARE OF YOUR TRIMMER

REPLACEMENT (REMOVAL) OF BLADE SET

To remove the blade set from

your trimmer, make sure the

trimmer is in the OFF position.

Remove the blade set by placing

thumb against the smaller cutter

and pushing forward, releasing the

cutter assembly from the trimmer

housing.

BATTERY REMOVAL

1. Using a small Phillips head screwdriver, remove the

screws at the back of the trimmer.

2. Remove the bottom housing and cut the battery

out. Bring the battery to the nearest collection center

for proper disposal. DO NOT throw the battery into the

normal municipal waste system.

GMTL1 LITHIUM BEARD/MUSTACHE TRIMMER

2 Jawline Combs

6-Position

Comb Attachment

Stubble Comb

Facial Hair Blade

Trimmer

Lubricating OilCleaning Brush

Adapter

N /ENose/Ear/Detail/D il

Multi-Use Trimmer

LIMITED TWO-YEAR WARRANTY

(U.S. AND CANADA ONLY)

Conair will repair or replace (at our option) your

unit free of charge for 24 months from the date of

purchase if the appliance is defective in workman-

ship or materials.

To obtain service under this warranty, return the

defective product to the service center listed on

back, together with your purchase receipt and

$3.00 for postage and handling. California residents

need only provide proof of purchase and should call

1-800-3-CONAIR for shipping instructions. In the

absence of a purchase receipt, the warranty period

shall be 24 months from the date of manufacture.

ANY IMPLIED WARRANTIES, OBLIGATIONS, OR

LIABILITIES, INCLUDING BUT NOT LIMITED TO

THE IMPLIED WARRANTY OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE,

SHALL BE LIMITED IN DURATION TO THE

24-MONTH DURATION OF THIS WRITTEN, LIMITED

WARRANTY. Some states do not allow limitations

on how long an implied warranty lasts, so the above

limitations may not apply to you.

IN NO EVENT SHALL CONAIR BE LIABLE FOR

ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL

DAMAGES FOR BREACH OF THIS OR ANY OTHER

WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER.

Some states do not allow the exclusion or limitation

of special, incidental, or consequential damages, so

the above limitation may not apply to you.

This warranty gives you specific legal rights, and you

may also have other rights, which vary from state

to state.

Please register this product at:

www.conair.com/registration

Service Center

Conair Corporation

Service Department

7475 North Glen Harbor Blvd.

Glendale, AZ 85307

15PG017304 IB-14016

SHEAD-GMTL1

BLD-161

2JAW-GMTL1

BLD-165

6POS-GMTL1

STUB-1

CUT HERE

TRIMMER REPLACEMENT PARTS & ACCESSORIES ORDER FORM

Pricing in effect through June 1, 2018. Orders postmarked after this date

will be accepted, and the customer will be notified if pricing has changed.

Trimmer Attachment Blade BLD-161 $6.50

Shaving Foil SHEAD-GMTL1 $6.50

Stubble Comb STUB-1 $2.25

6-Position Comb Attachment 6POS-GMTL1 $2.25

Nose/Ear/Detail Trimmer BLD-165 $5.50

2 Jawline Combs $5.502JAW-GMTL1

ITEM PRICE PART # QUANTITY AMOUNT

Subtotal

Sales Tax*

TOTAL

Mail to:

Conair Corporation

Service Department

150 Milford Road

East Windsor, NJ 08520-9730

Enclose check or money order made payable to Conair. (We cannot accept cash, stamps or

C.O.D. orders.) *CT, IL, AZ, and PA residents should add applicable state sales tax. Minimum

order of $10.00 or a $2.00 handling charge will be added to order.

All prices include handling and return postage. Prices are subject to change without notice.

Prices are valid only for shipments within the continental United States. Please allow 4–6 weeks

for delivery.

To avoid delays, please print clearly.

We must have a street address, as UPS cannot deliver to a P.O. box.

NAME _________________________________________________________________________________________________

ADDRESS ___________________________________________ APT. ______________________________________________

CITY ________________________________________________STATE _________ ZIP________________________________

TELEPHONE ( ) _____________________________________________________________

(We call only if we have a question about your order.)

For information on other Conair

haircut kit parts call: 1-800-3-CONAIR.

Produkt Specifikationer

Mærke:	Conair
Kategori:	Ikke kategoriseret
Model:	GMTL1R

Har du brug for hjælp?

Hvis du har brug for hjælp til Conair GMTL1R stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret Conair Manualer

Conair NPTCCA01 Manual

10 December 2024

Conair True Glow PB8NPRF Manual

10 December 2024

Conair NPTCCA02 Manual

10 December 2024

Conair MiniPRO CS80N Manual

1 Oktober 2024

Conair MASK2 Manual

1 Oktober 2024

Conair skn SFB11GK Manual

1 Oktober 2024

Conair Man GMTL6000 Manual

6 September 2024

Conair LNT1 Manual

6 September 2024

Conair Man GMT189R Manual

6 September 2024

Conair InfinitiPRO 998 Manual

3 September 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Smeg KIT6PX Manual

23 December 2024

Smeg KIT6CX Manual

23 December 2024

Smeg GTA-6 Manual

23 December 2024

Lucide Casper i 79166/19/12 Manual

23 December 2024

Lucide Merlina 78193/30/66 Manual

23 December 2024

Lucide Pippa 77583/81/30 Manual

23 December 2024

Lucide Pia 45380/04/30 Manual

23 December 2024

Lucide Pia 45280/01/30 Manual

23 December 2024

Lucide Anaka 45179/03/30 Manual

23 December 2024

Lucide Zych 45156/01/97 Manual

23 December 2024
