Side 1/2

22 PI EC E C OR D/C ORD LESS HA IR CUT K I T

[rechargeable]

Fig 1

Fig 2

✁

Instructions for Care and Use

MODEL HC318R

IMPORTANT SAFETY

INSTRUCTIONS

When using electrical appliances, especially

when children are present, take basic safety

precautions, including the following:

READ ALL INSTRUCTIONS

BEFORE USING

KEEP AWAY FROM WATER

DANGER – any appliance is electrically

live, even when the switch is off.

To reduce the risk of death or injury by electric

shock:

1. Unplug this appliance before cleaning.

2. Do not place or store appliance where it can fall

or be pulled into a tub or sink.

3. Do not use while bathing or in a shower.

4. Do not place in, or drop into water or other liquid.

5. Do not reach for an appliance that has fallen into

water. Unplug immediately.

6. Except when charging, always unplug this

appliance from electrical outlet immediately

after using.

DO NOT REACH

INTO THE WATER

WARNING – To reduce the risk of burns,

electric shock, fire, or injury to persons:

1. This appliance should never be left unat-

tended when plugged in. Do not pull, twist,

or wrap line cord around appliance.

2. This appliance should not be used by, on, or near

children or individuals with certain disabilities.

3. Use this appliance only for its intended purpose

as described in this manual. Do not use attach-

ments not recommended by the manufacturer.

Do not use an extension cord to operate this

appliance.

4. Never operate this appliance if it has a

damaged cord or plug, or if it is not work-

ing properly, if it has been dropped or

damaged, or dropped into water. Return

the appliance to a service center for

examination and repair.

5. Keep the cord away from heated surfaces.

6. Never drop or insert any object into any open-

ing on this appliance.

7. Do not place appliance on any surface while

it is operating.

8. Do not use this appliance with a damaged or

broken comb or with teeth missing from the

blades as injury may occur. Before use, make

certain blades are aligned properly. (See

“Care of your Clippers”)

9. Do not use outdoors or operate where aerosol

(spray) products are being used or where

oxygen is being administered.

10. Never operate the appliance with the air

openings blocks or while on a soft surface,

such as a bed or couch, where the air open-

ings may be blocked. Keep the air openings

free of lint, hair, and the like.

11. Always attach plug to appliance first, then

to outlet. To disconnect, turn all controls to

“OFF” then remove plug from outlet.

12. Avoid skin contact with moving blades.

13. When using the appliance with its cord,

be mindful of tangles or kinks in the cord.

If the cord does become tangled during use,

turn the unit off and straighten cord before

operating again.

14. Keep lubricating oil out of reach of children.

SAVE THESE

INSTRUCTIONS

OPERATING

INSTRUCTIONS

FOR RECHARGEABLE APPLICATION

Your new Conair Haircut Kit has everything you need

to achieve professional haircuts at home. Its power-

ful D.C. motor clipper with Stainless Steel blades for

long lasting cutting precision, features a new 5-posi-

tion adjustamatic taper control. What ever hair length

you set the lever for, the clipper will automatically cut

all hair in that section at the same desired length.

Also included are 10 attachment combs for differ-

ent hair lengths, barber scissors, a styling comb

with angled teeth, a barber comb with straight

teeth, a full length barber cape, a neck brush, a

hard case for easy storage, and 2 styling clips

to assist you in cutting longer hair styles. It also

comes with lubricating oil, a cleaning brush and

a blade guard for easy maintenance of the clip-

per blades.

This appliance is intended for household use. Comes

with an adapter used on 100-240V AC 50/60 HZ.

1. Before using the clipper for the first time,

charge continuously for 16 hours. Maximum

battery capacity will only be reached after

3 charging and discharging cycles.

2. After use, turn the switch to “Off” position.

Recharge batteries by connecting the charg-

ing jack into the receptacle at the end of the

clipper and plugging the adapter unit into

the electrical outlet. The charging indicator

lamp will light up to indicate that charging

has begun.

3. After recharging, store in a dry place, away

from small children.

4. Do not wrap cord around the clipper.

5. Preserving the batteries: in order to maintain

the optimum capacity of the rechargeable bat-

teries, the clipper should be recharged for 16

hours approximately every 3 months.

FOR DIRECT PLUG-IN OPERATION

1. Connect the charging jack into the receptacle

at the end of the clipper.

2. Plug the adapter unit into the electric outlet.

3. Turn the switch to “Off” position, let the clipper

charge for a few minutes first.

4. Turn the switch to “On” position.

5. Unplug the adapter unit after use.

6. After use, store in a dry place away from small

children.

7. Do not wrap cord around the clipper.

8. This power unit is intended to be correctly

oriented in a vertical or floor mount position.

CONTAINS NICKEL-

CADMIUM BATTERY.

MUST BE COLLECTED,

RECYCLED OR DISPOSED

OF PROPERLY. DO NOT

DISPOSE OF IN

MUNICIPAL WASTE.

BATTERY REMOVAL INSTRUCTIONS

1. Using a small Phillips screwdriver, remove the

screw on the bottom housing at back of the

clipper.

2. Remove the top housing by hand.

3. Now the battery is exposed so you can separate

the wire connectors. Carefully hold the wires on

each side of the connector and gently cut the

wires. The connector will separate and the bat-

teries can be removed from the inner housing.

Bring the battery to the nearest collection center

for disposal or call the toll-free RBRC informa-

tion line at 1-800-8-BATTERY. RBRC is a trade-

mark of The Rechargeable Battery Recycling

Corporation. DO NOT throw the batteries into the

normal municipal waste system.

Never use cord to pull clipper. Never twist or

otherwise obstruct cord. To store, coil cord loosely

and secure with a twist tie.

THE CONAIR GUIDE

TO CUTTING HAIR AT HOME

Before you start:

1. Inspect your clipper to make sure it is free

of hair and dirt, is properly oiled and is running

smoothly.

2. Place a towel or cape around the neck of the

person getting the haircut.

3. Sea t the person so that his/her head is at your eye

level. This gives you greater visibility and control.

4. Comb hair until it is tangle-free. Hold the clipper in

a comfortable grip. Now you’re ready to cut

MEDIUM TO LONG CUT

To begin, cut only a small amount of hair until

you become used to the length each attachment

leaves the hair. Try the longest attachment on the

clipper first. If you want a shorter cut, you can then

use shorter combs.

• Short attachment comb (number 1)

cuts hair to 1/8".

• Medium-Short attachment comb (number 2)

cuts hair to 1/4".

• Medium-Long attachment comb (number 3)

cuts hair to 3/8".

• Long attachment comb (number 4)

cuts hair to 1/2".

• Long attachment comb (number 5)

cuts hair to 5/8".

• Long attachment comb (number 6)

cuts hair to 3/4".

• Long attachment comb (number 7)

cuts hair to 7/8".

• Long attachment comb (number 8)

cuts hair to 1"

• Left ear attachment comb lightly tapers over

left ear.

• Right ear attachment comb lightly tapers over

right ear.

Attach combs by holding them teeth up then

snapping onto the bottom of the clipper blade.

NOTE: Never push

or shove the clipper

through the hair to

make it move more

quickly. Pro fes sional

experience shows

that the clipper

works most effi-

ciently when it cuts

through the hair at

its own speed.

To remove comb

attachments, place

index finger and

thumb as illustrated;

then pull out and up.

To begin cutting hair:

1. The hair should be combed

in its natural direction.

2. Using the largest

at tachment comb, trim

sides from the bottom

upwards. Hold clipper lightly

against the hair with teeth

of the attachment comb

pointing upward, yet flat

against the head. Gradually

lift the clipper upward and

outward through the hair,

trimming just a little at a

time. Re peat around sides

and back of head.

3. If you want hair to be

even shorter: Apply more

pressure to the head with

the attachment comb that

is in place. This takes a

little practice, of course.

Or, just switch to a

shorter attachment comb.

Remember, it’s better to

leave too much hair than

too little.

For longer hair on top, use

the barber comb and lift

hair on the top of the head,

cutting over the comb, or

hold hair between fingers

and cut to desired length.

Always working from the

front to the back of the

head, gradually cut the

hair shorter by reducing the space between

the comb or fingers and the head. Comb often

to check for uneven strands, and to get rid of

trimmed hair. For thicker hair and more cutting

power, press the turbo button on the side.

OUTLINING

Outlining requires no attachments. Comb the

hair into the desired style, Position the clip-

per between the sideburns and the ear (see

sketch) and make sure the corner edge of the

blade is against the hairline. With the outline of

the hair as your guide, slowly move the clip-

per over, around and behind the ears. For the

back of the neck and the sideburns, hold the

clipper upside down (see sketch) and, holding

it against the skin at the length desired, move

the clipper downward.

STOP. COMB. CHECK.

For best results, do as the professionals do:

comb the hair often and check results as you

comb. This way you can avoid uneven sides,

bangs, neckline, etc.

SHORTCUTS TO PERFECT

FLAT TOPS, CREW CUTS, ETC.

Always cut the hair from the back of the

neck toward the crown, using the longest

comb setting. Hold the comb attachment flat

against the head and slowly move the clipper

up through the hair. Use the same technique

for the sides, cutting from the bottom to the

upper side of the head.

For the front of the crown, cut the hair against

its natural direction. Then even it up with the

sides.

For a flat top use a flat comb, not the attach-

ment comb. Just cut top hair by running the

clipper over the comb.

To taper hair down to the neckline, use the lower

settings attachment comb. Comb the hair and

check for uneven spots. Outline the sideburns

and neckline areas (see Outlining).

USER-MAINTENANCE

INSTRUCTIONS

CARE OF YOUR CLIPPERS

DETACHABLE BLADE SET

Your clipper is equipped with a detachable

blade set for routine maintenance, cleaning and

replacement.

To remove the blade: the

front of the clipper should

be facing you, push up

under the blade with your

thumb and the blade will

pop-out. (See Fig 1)

To replace the blade: Make

sure the taper control is set

to the longest position and

with the back of the clip-

per facing you, insert the

bottom side (with screws)

of the blade into the clip-

per and push down until it snaps into place.

(See Fig 2)

MAINTENANCE OF THE BLADE

Always apply oil to the blades before, during

and after use. This will ensure maximum cut-

ting performance. Hold clipper away from your

body in a downward position and apply oil on

the front and sides of the cutter blade. Wipe

excess oil off with a soft, dry cloth.

SPECIAL OIL

To maintain the blades of your Conair

® clipper

in peak condition, oil them after every three or

four haircuts. Gently place a few drops of oil on

the teeth of the blades, using the special Conair

oil included with your set. Turn the clipper on

for a minute, then turn off. This light, natural

oil was formulated specifically for the Conair®

high-speed clipper. Be cause it is the right oil

to use, it will not slow down the blades. Never

use any other product; there is no substitute for

Conair oil.

5 DETENT TAPER CONTROL

Just like levers on professional clippers, the Conair

taper lever is positioned at your thumb so you can

hold the clipper in your hand and adjust the lever

at the same time... while you’re clipping. This taper

lever eliminates the need in some situations for

an attachment comb because it lets you gradually

adjust the closeness of the cut. For the closest cut

and the shortest hair, push taper lever up as far

as it will go to level #1. To increase cutting length,

slowly push lever down. If you push to the lowest

position level #5, it will leave hair about the same

length as the short

attachment comb.

Close Cut

Longer

Cut

Because a different cutting edge is used in

each setting, the taper lever lengthens the

life of your blades. Packed-in hair can slow

down any clipper. To remove it, without

removing the blades. Take your cleaning brush

and brush the hair from the blades. If you do

this after every clipping, especially with heavy

hair cutting, the blades should remain free of

cut hair. If clipper stops cutting and this action

doesn’t help, you might have to loosen the

blades to remove the hair.

For new blades, send check or money order for

$6.50 (which includes postage and handling) to:

Conair Corporation

150 Milford Rd.

East Windsor, NJ 08520

NOTE: Never pull on the clipper cord.

Never twist or wrap the cord around the

clipper; lay it flat with the cord coiled up

when not in use.

Bottom

Blade

Top

Blade

Adjustable

Taper

Lever

On/Off

Switch

Charging

light

Detachable

Blade Set WARNING:

IF YOU THINK

THE POWER IS OFF

WHEN THE SWITCH

IS OFF,

YOU'RE WRONG.

KEEP AWAY FROM WATER

Everyone knows that electricity and water are

a dangerous combination. But did you know

that an electric appliance is still electrically

alive even if the switch is off? If the plug is in

the power is on. So when you are not using

your appliances, keep them unplugged.

ALWAYS UNPLUG

SMALL APPLIANCES

LIMITED FIVE YEAR WARRANTY

Conair will repair or replace (at our option) your

unit free of charge for 60 months from the date

of purchase if the appliance is defective in

workmanship or materials.

To obtain service under this warranty, return the defec-

tive product to the service center listed below together

with your purchase receipt and $3.00 for postage and

handling. California residents need only provide proof of

purchase and should call 1-800-366-0937 for shipping

instructions. In the absence of a purchase receipt, the

warranty period shall be 60 months from the date of

manufacture.

ANY IMPLIED WARRANTIES, OBLIGATIONS,

OR LIABILITIES, INCLUDING BUT NOT LIMITED

TO THE IMPLIED WARRANTY OF MERCHANT-

ABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, SHALL BE LIMITED IN DURATION TO

THE 60 MONTH DURATION OF THIS WRITTEN,

LIMITED WARRANTY. Some states do not allow

limitations on how long an implied warranty lasts,

so the above limitations may not apply to you.

IN NO EVENT SHALL CONAIR BE LIABLE FOR

ANY SPECIAL, INCIDENTAL, OR CONSEQUEN-

TIAL DAMAGES FOR BREACH OF THIS OR ANY

OTHER WARRANTY, EXPRESS OR IMPLIED,

WHATSOEVER. Some states do not allow the

exclusion or limitation of special, incidental, or

consequential damages, so the above limitation

may not apply to you.

This warranty gives you specific legal rights, and

you may also have other rights, which vary from

state to state.

Once again, thanks for buying a

Conair product.

Your Conair® clipper blades are made of high

carbon stainless steel. They are engineered

for precise, professional results. If blades feel

like they are pulling or grabbing hair, it means

they are losing their sharpness and should be

replaced as soon as possible.

Attachment combs should also be replaced if

they are lost or broken. It is easier to cut hair with

the accuracy of a pro when the necessary tools

are at your fingertips.

Conair makes a variety of accessories for dif-

ferent haircut kits. If your haircut kit does not

include them, you may want to consider adding

them to your professional haircutting tools.

Left and right ear attachment combs provide

effortless, precise cutting around the ears. Styling

clips hold hair in place when you are sectioning

hair. A styling comb makes it easy to taper or cut

hair at an angle. A barber cape ensures a comfort-

able and neat haircut and a convenient storage

pouch keeps all your essentials in one place.

To register your Conair product please simply go

to www.conair.com/registration and the site will

guide you to register your item.

Service Center

Conair Corporation

Service Department

7475 North Glen Harbor Blvd.

Glendale, AZ 85307

10PG112818 IB-9906

EXCITING NEW ITEMS

FROM CONAIR

The first cordless,

rechargeable

angled shaving head with

an universal grip, 3-position

taper control, 3 attachment

combs and trimmer

attachment.

Model HG300

Corded beard and

mustache trimmer with

5-position adjustable comb

and 2 jawline detailing

combs.

Model GMT8CS

Model COMB-10

Model COMB-11

Model COMB-13

Model HCNB-1

Model CAPE-1

Model HC OIL

Model HC VIDEO

Model SC-1

Model BLD-7

Model HC-1

Model CLP-1

Model DVD-1

Model COMB-12

CUT HERE

HAIRCUT KIT REPLACEMENT PARTS & ACCESSORIES ORDER FORM

Pricing in effect through June 1, 2011. Orders postmarked after this date will be accepted, and the customer will be notified if pricing has changed.

Subtotal

*Sales Tax

TOTAL

Enclose check or money order made payable to Conair. (We cannot accept cash, stamps or C.O.D. orders.) CT, IL, AZ, and PA residents

should add applicable state sales tax. Minimum order of $10.00 or a $2.00 handling charge will be added to order.

All prices include handling and return postage. Prices are subject to change without notice.

Prices are valid only for shipments within the Continental United States. Please allow 4-6 weeks for delivery.

To avoid delays, please print clearly.

We must have a street address, as UPS cannot deliver to a P.O. box.

NAME ________________________________________________________________________________

AddrEss __________________________________ Apt. ____________________________________

CItY ______________________________________ stAtE _______ ZIp _______________________

tELEpHONE ( ) __________________________________________________

(We call only if we have a question about your order.)

For information on other Conair® haircut kit parts call: 1-800-3-CONAIR.

Mail to:

Conair Corporation

Service Department

150 Milford Road

East Windsor,

NJ 08520-9730

Set of 4 Attachment Combs: 1/8", 1/4", 3/8", 1/2". Fits all clippers COMB-10 $5.00

Set of 2 Attachment Combs: left ear and right ear. Fits all clippers COMB-11 $1.75

1" Comb ﬁts all clippers COMB-12 $1.75

3 attachment combs: 5/8", 3/4", 7/8". Fits all clippers $5.00COMB-13

Neck Brush HCNB-1 $1.50

Deluxe White Vinyl Cape with Velcro Collar CAPE-1 $5.00

Lubricating Oil (pkg. of 3 tubes) HC OIL $2.00

Approximate 28 Minute haircut video in Spanish & English (Optional) $8.95HC VIDEO

Instructional DVD DVD-1 $5.00

Barber Scissors $2.00SC-1

Blade Set for HC318 BLD-7 $6.50

Blade Guard $1.00HC-1

Styling Clips (set of 3) CLP-1 $1.50

ITEM PART # PRICE QUANTITY AMOUNT

Produkt Specifikationer

Mærke:	Conair
Kategori:	Ikke kategoriseret
Model:	HC318RVW

Har du brug for hjælp?

Hvis du har brug for hjælp til Conair HC318RVW stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret Conair Manualer

Conair NPTCCA01 Manual

10 December 2024

Conair True Glow PB8NPRF Manual

10 December 2024

Conair NPTCCA02 Manual

10 December 2024

Conair MiniPRO CS80N Manual

1 Oktober 2024

Conair MASK2 Manual

1 Oktober 2024

Conair skn SFB11GK Manual

1 Oktober 2024

Conair Man GMTL6000 Manual

6 September 2024

Conair LNT1 Manual

6 September 2024

Conair Man GMT189R Manual

6 September 2024

Conair InfinitiPRO 998 Manual

3 September 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Smeg KIT6PX Manual

23 December 2024

Smeg KIT6CX Manual

23 December 2024

Smeg GTA-6 Manual

23 December 2024

Lucide Casper i 79166/19/12 Manual

23 December 2024

Lucide Merlina 78193/30/66 Manual

23 December 2024

Lucide Pippa 77583/81/30 Manual

23 December 2024

Lucide Pia 45380/04/30 Manual

23 December 2024

Lucide Pia 45280/01/30 Manual

23 December 2024

Lucide Anaka 45179/03/30 Manual

23 December 2024

Lucide Zych 45156/01/97 Manual

23 December 2024
