Side 1/3

STOP. COMB. CHECK.

For best results, do as the professionals do:

comb hair often, and check clipping results as

you comb. This way you avoid uneven sides,

bangs, neckline, etc.

SHORT CUTS TO PERFECT

FLAT TOPS, CREW CUTS, ETC.

Always cut from the back of the neck to the

crown, using the longest comb setting.

Hold the comb attachment flat against the

head and slowly move the clipper up through

the hair. Use the same technique for the sides,

cutting from the bottom to the upper side of

the head.

For the front to the crown, cut the hair against

the direction in which it grows. Then even it

up with the sides.

For a flat top, use the flat comb, not the

attachment comb. Just cut hair on top of the

head over flat comb. (see above).

To taper hair down to the neckline, use

attachment comb #1. Comb hair andcheck

for uneven spots. Outline sideburns and neck

areas (see “Outlining”).

H O M E H A I R C U T T I N G K I T

MULTI-PURPOS

includes clipper,

trimmer and nose/e

detailer for all your

grooming needs

CLIPPER

TRIMMER

& NOSE/EAR DETAILER

3 1 kit-in-

Instructions for Clipper Care and Use

Model HCT401

IMPORTANT SAFETY

INSTRUCTIONS

When using electrical appliances, especially

when children are present, basic safety pre-

cautions should always be taken, including

the following:

READ ALL INSTRUCTIONS

BEFORE USING

FOR HOUSEHOLD USE ONLY

KEEP AWAY FROM WATER

DANGER

– Any appliance is electrically

live, even when the switch is off.

To reduce the risk of death or injury by electric

shock:

1. Always unplug this appliance from electri -

cal outlet immediately after using.

2. Unplug this a ppliance before cleaning. Unplug

the appliance when not in use.

3. Do not place or store a ppliance where it can fall

or be pulled into a tub or sink.

4. Do not use while bathing or in a shower.

5. Do not place in, or drop into water or other

liquid.

6. Do not reach for an appliance that has

fallen into water. Unplug immediately.

WARNING

– To reduce the risk of burns,

electric shock, fire, or injury to persons:

1. This appliance should never be left unattended

when plugged in. Do not pull, twist, or wrap line

cord around appliance.

2. This appliance should not be used by, on, or

near children or individuals with certain dis-

abilities.

3. Use this a ppliance only for its intended purpose

as described in this manual. Do not use attach-

ments not recommended by the manufacturer.

Do not use an extension cord to operate this

appliance.

4. Never opera te this appliance if it has a dam-

aged cord or plug, if it is not working properly or

if it has been dropped or damaged, or dropped

into water. Return the appliance to a service

center for examination and repair.

5. Keep the cord a way from heated surfaces.

6. Never drop or insert an y object into any opening

on this appliance.

7. Do not place a ppliance on any surface while it

is operating.

8. Do not use this a ppliance with a

damaged or broken comb or with teeth miss-

ing from the blades as injury may occur. Before

use, make certain blades are aligned properly.

(See “Care of your Clippers.”)

9. Do not use outdoors or opera te where aerosol

(spray) products are being used or where oxy-

gen is being administered.

10. Never opera te the appliance with the air open-

ings blocked or while on a soft

surface, such as a bed or couch, where the air

openings may be blocked. Keep the air

openings free of lint, hair, and other debris.

11. Always attach plug to appliance first, then to

outlet. To disconnect, turn all con trols to “OFF”,

then remove plug from outlet.

12. Avoid skin contact with moving blade.

13. Keep lubricating oil out of reach of children.

14. When using the appliance with its cord, be

mindful of tangles or kinks in the cord. If

the cord does become tangled during use,

turn the unit off and straighten cord before

operating again.

SAVE THESE

INSTRUCTIONS

OPERATING

INSTRUCTIONS

This appliance is intended for household use.

Use on Alternating Current 120V/60 hertz only.

This appliance has a polarized plug (one blade

is wider than the other). As a safety feature, this

plug will fit in the outlet only one way. If the plug

does not fit fully in the outlet, reverse the plug. If

it still does not fit, contact a qualified electrician

to install the proper outlet. Do not attempt to

defeat this safety feature.

Your new Conair® haircut kit has everything you

need to achieve professional haircuts at home. It

features a powerful clipper with adjustable taper

control and stainless steel blades for cutting

precision, a nose/ear trimmer and a detail trim-

mer that is great for necks, sideburns, goatees

and mustache trimming. Also included are 10

attachment combs (1/8" (3 mm), 1/4" (6 mm),

3/8" (9.5 mm), 1/2" (13 mm), 5/8" (16 mm), 3/4"

(19 mm), 7/8" (22 mm), 1" (25 mm) for different

hair lengths (left and right ear combs), barber

scissors, barber cape, deluxe storage case, bar-

ber comb with straight teeth, styling comb with

angled teeth, and 3 styling clips to assist you in

cutting longer hair styles. It also comes with lubri-

cating oil, a cleaning brush and a blade guard for

easy maintenance of the clipper blades.

THE CONAIR GUIDE

TO CUTTING HAIR AT HOME

Before you start:

1. Inspect your clipper. Make sure it’s free of hair

and dirt, properly oiled, and running smoothly.

2. Place a towel around the neck of the person.

3. Seat the person so that his or her head is at

your eye level. This gives you greater visibility

and control.

4. First, comb hair until it’s tangle-free. Then

hold clipper in a comfortable grip. Now you’re

ready to cut.

MEDIUM TO LONG CUT

To begin with, cut only a small amount of hair until

you become used to the length each attachment

leaves the hair. Try the longest attachment on the

clipper first. If you want a shorter cut, you can

then use shorter combs.

• Short attachment comb (number 1) cuts hair

to 1/8” (3mm).

• Medium-Short attachment comb (number 2)

cuts hair to 1/4” (6mm).

• Medium-Long attachment comb (number 3)

cuts hair to 3/8” (9.5mm).

• Long attachment comb (number 4) cuts hair

to 1/2” (12.5mm).

• Long attachment comb (number 5) cuts hair

to 5/8" (16mm).

• Long attachment comb (number 6) cuts hair

to 3/4" (19mm).

• Long attachment comb (number 7) cuts hair

to 7/8" (22mm).

• Long attachment comb (number 8) cuts hair

to 1” (25mm).

• Left ear attachment comb lightly tapers over

left ear.

• Right ear attachment comb lightly tapers over

right ear.

Attach combs by

holding them teeth

up, then snapping

onto the bottom of the

clipper blade.

To remove comb

attachments, place

index finger and

thumb as illustrated;

then pull out and up.

NOTE: Never push or shove the clipper

through the hair to make it move

more quickly. Professional experience

shows that the clipper works most

efficiently when it cuts through the

hair at its own speed.

To begin cutting hair:

1. The hair should be combed in its natural

direction.

2. Using the largest

attachment comb, trim

sides from the bottom

upward. Hold clipper

lightly against the hair

with teeth of the attach-

ment comb pointing

up ward, yet flat against

the head. Gradually lift

the clipper upward and

outward through the hair,

trimming just a little at

a time.

Repeat around sides and

back of head.

If you want hair to be

even shorter:

A) Apply more pressure

to the head with the

attachment comb that

is in place. This takes a

little practice, of course.

OR B) Just switch to

a shorter attachment

comb.

Remember, it’s better to

leave too much hair than

too little. For longer hair

on top, use the barber comb and lift hair on

the top of the head, cutting over the comb. Or

hold the hair between the fingers and cut to

desired length. Always working from the front

to the back of the head, gradually cut the hair

shorter by reducing the space between the

comb or fingers and the head. Comb often to

check for uneven strands, and to get rid of

trimmed hair.

OUTLINING:

Outlining requires no attachments. Comb

hair into the desired style. Position the clip-

per between the sideburns and the ear (see

below), making sure the corner edge of the

blade is against the hairline. With the outline

of the hair as your guide, slowly move the

clipper over, around and behind the ears.

For the back of the neck and the sideburns,

hold the clipper upside down (see above)

and, holding it against the skin at the length

desired, move the clipper downward.

USER-MAINTENANCE

INSTRUCTIONS

CARE OF YOUR CLIPPERS

IF YOU DETERMINE THAT BLADE

ALIGNMENT IS INCORRECT:

Conair® hair clippers are carefully inspected to

insure that the blades are in perfect alignment.

Of course you will need to realign the blades

after removal for cleaning or replacement, or

if they should be knocked out of alignment.

How can you tell if blades need realigning?

Simply match them up, point for point, to

conform with FIG. 1 below:

FIG. 1

To prevent the clipper from contacting the skin

or cutting too closely, make certain that the

end top blade teeth are 1/32” to 1/16” back

from bottom blade.

To Align Blades:

1. Add two or three drops

of Conair Lubricating Oil

(included).

2. Turn clipper on for a minute

to disperse oil evenly over

blades, then turn off.

3. Unplug clipper and slightly

loosen screws. (See FIG. 2)

FIG. 2

4. Position the extreme left-hand tooth

of the top blade so that it either covers or

appears on the left of the first small tooth on

the bottom blade.

5. Make sure that the big tooth on the

bottom blade touches the extreme right hand

tooth of the top blade.

SPECIAL OIL

To maintain the blades of your Conair clipper,

oil them after every three or four haircuts.

Gently place a few drops of oil on the teeth

of the blades, using the special Conair oil

included with your set. Turn the clipper on

for a minute, then turn off. This light, natural

oil was formulated specifically for the Conair

high-speed

clipper. Be cause it is the right oil to use, it

will not slow down the blades. Never use

any other product. There is no substitute for

Conair oil.

POWER SCREW

The power screw permits you to adjust

power to your clipper. You may need to make

this adjustment if the power in your house is

low. (The Conair

clipper was designed for

household use.)

1. With a screwdriver or a dime, turn the power

screw counter clockwise until the arm strikes

coil, making a clacking noise. (FIG.1)

FIG. 1

2. Then turn the screw clockwise, until the noise

stops and then turn about 45 degrees more.

This is the maximum power setting. (FIG. 2)

FIG. 2

OIL BLADE BEFORE USE.

ADJUSTABLE TAPER LEVER

Just like professional clippers, the Conair

taper lever is positioned at your thumb. You

can hold the clipper in your hand and adjust

the lever at the same time... while you’re

clipping.

This taper lever eliminates the need for

an attachment comb because it lets you

gradually adjust the closeness of the cut. For

the closest cut and the shortest hair, push

taper lever up as far as it will go. To increase

cutting length, slowly push lever down. If

you push to the lowest position, it will leave

hair about the same length as the short

attachment.

Because a different cutting edge is used in

each setting, the taper lever lengthens the

life of your blades.

Packed-in hair can slow down any clipper.

To remove hair without removing the blades,

do what the professionals do:

keeping the clipper on, quickly push the taper

lever back and forth from “close” to “longer”

cut a few times.

If you do this after every clipping, especially

with heavy hair cutting, the blades should

remain free of cut hair.

Close Cut

Longer Cut

If clipper stops cutting and this action doesn’t

help, check the blades. If they’ve become dull,

replace them or return them to a Conair service

center. We’ll be glad to

sharpen them for you. For new blades, send

check or money order for $6.50 (see order

blank) which includes postage and handling

(If $10 minimum is met) to:

Conair Corporation

150 Milford Rd.

East Windsor, NJ 08520

NOTE: Never pull on the clipper cord. Never

twist or wrap the cord around the clipper. Lay

it flat with the cord coiled up when not in use.

Bottom Blade

Adjustable

Taper Lever

Top Blade

WARNING:

IF YOU THINK

THE POWER IS OFF

WHEN THE SWITCH

IS OFF,

YOU'RE WRONG.

KEEP AWAY FROM WATER

Everyone knows that electricity and water

are a dangerous combination. But did you

know that an electric appliance is still

electrically alive even if the switch is off? If

the plug is in, the power is on. So when you

are not using your appliances, keep them

unplugged.

ALWAYS UNPLUG

SMALL APPLIANCES

LIMITED FIVE YEAR WARRANTY

Conair will repair or replace (at our option) your

unit free of charge for 60 months from the date

of purchase if the appliance is defective in

workmanship or materials.

To obtain service under this warranty, return the

defective product to the service center listed on back,

together with your purchase receipt and $3.00 for

postage and handling. California residents need only

provide proof of purchase and should call 1-800-

366-0937 for shipping instructions. In the absence of

a purchase receipt, the warranty period shall be 60

months from the date of manufacture.

ANY IMPLIED WARRANTIES, OBLIGATIONS, OR

LIABILITIES, INCLUDING BUT NOT LIMITED TO

THE IMPLIED WARRANTY OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE,

SHALL BE LIMITED IN DURATION TO THE 60

MONTH DURATION OF THIS WRITTEN, LIMITED

WARRANTY. Some states do not allow limitations

on how long an implied warranty lasts, so the above

limitations may not apply to you.

IN NO EVENT SHALL CONAIR BE LIABLE FOR

ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL

DAMAGES FOR BREACH OF THIS OR ANY

OTHER WARRANTY, EXPRESS OR IMPLIED,

WHATSOEVER. Some states do not allow the exclu-

sion or limitation of special, incidental, or conse-

quential damages, so the above limitation may not

apply to you.

This warranty gives you specific legal rights, and

you may also have other rights, which vary from

state to state.

Please register this product at

www.conair.com/registration

Service Center

Conair Corporation

Service Department

7475 North Glen Harbor Blvd.

Glendale, AZ 85307

150 Milford Road, East Windsor, NJ 08520

7475 North Glen Harbor Blvd., Glendale, AZ 85307

12PG129785 IB-11276

Once again, thanks for buying a

Conair product.

Your Conair ® clipper blades are made of high

carbon stainless steel. They are engineered

for precise, professional results. If blades feel

like they are pulling or grabbing hair, it means

they are losing their sharpness and should be

replaced as soon as possible.

Attachment combs should also be replaced if

they are lost or broken. It is easier to cut hair

with the accuracy of a pro when the necessary

tools are at your fingertips.

Conair makes a variety of accessories for

different haircut kits. If your haircut kit does not

include them, you may want to consider adding

them to your professional haircutting tools.

Left and right ear attachment combs provide

effortless, precise cutting around the ears. Styling

clips hold hair in place when you are sectioning

hair. A styling comb makes it easy to taper or

cut hair at an angle. A barber cape ensures a

comfortable and neat haircut and a convenient

storage pouch keeps all your essentials in one

place.

Last but not least, an easy-to-follow 30-minute

“Haircuts at Home” video is available. It

demonstrates basic haircutting techniques and

follows four popular haircuts step by step. It

will give you the confidence and instruction

you need to give great looking haircuts to every

member of your family.

EXCITING ITEMS

FROM CONAIR

Cordless/rechargeable

multi-use trimmer

with 4 total blade

attachments for all your

grooming needs.

Model GMT189RGB

The first cordless,

rechargeable

angled shaving head with

an universal grip, 3-position

taper control, 3 attachment

combs and trimmer

attachment.

Model HG300

Model COMB-10

Model COMB-11

Model COMB-13

Model COMB-12

Model HCNB-1

Model CAPE-1

Model HC OIL

Model HC VIDEO

Model SC- 1

Model BLD- 8

Model BG30

Model CLP- 1

CUT HERE

HAIRCUT KIT REPLACEMENT PARTS & ACCESSORIES ORDER FORM

Pricing in effect through December 31, 2013. Orders postmarked after this date

will be accepted, and the customer will be notified if pricing has changed.

ITEM PART # PRICE QUANTITY AMOUNT

Set of 4 Attachment Combs:1/8", 1/4", 3/8", 1/2".

Fits all clippers (HC200, HC220, HC240, HC102 $5.00 COMB-10

HC300, HC318, HC414, HC275, HC222)

Set of 2 Attachment Combs: left ear and right ear. Fits all clippers (see COMB-10).except HC222 $1.75COMB-11

1" Comb fits all clippers COMB-12 $1.75

3 attachment combs 5/8", 3/4", 7/8". Fits all clippers $5.00COMB-13

Neck Brush $1.50HCNB-1

Deluxe Black Vinyl Cape with Velcro Collar $5.00CAPE-1

Lubricating Oil (pkg. of 3 tubes) $2.00HC OIL

30 Minute Haircut Video $8.95HC VIDEO

Barber Scissors $2.00SC-1

Blade Set for HC200 Detent Clipper BLD-8 $6.50

Blade Guard $1.00BG30

Styling Clips (set of 3) $1.50CLP-1

Subtotal

Enclose check or money order made payable to Conair. (We cannot accept cash, stamps or C.O.D. orders.) CT, IL, AZ, and PA residents *Sales Tax

should add applicable state sales tax. Minimum order of $10.00 or a $2.00 handling charge will be added to order.

A l l p r i c e s i n c l u d e h a n d l i n g a n d r e t u r n p o s t a g e . P r i c e s a r e s u b j e c t t o c h a n g e w i t h o u t n o t i c e .

Prices are valid only for shipments within the Continental United States. Please allow 4-6 weeks for delivery. TOTAL

To avoid delays, please print clearly.

We must have a street address, as UPS cannot deliver to a P.O. box. Mail to:

Conair Corporation

NAME____ _________________________________________________________________________________ Service Department

150 Milford Road

ADDRESS APT. __________________________________________ __________________________________ East Windsor, NJ 08520-9730

CITY ZIP _______________________________________STATE _______________________ ______________
