HOTKEY PRESS FUNCTION
Cycles through software or hardware proles (depending on mode)
Adjusts backlighting brightness in 20% decrements
Disables the Windows key to prevent accidental keypresses*
* Can be programmed in iCUE to also disable other contextual menu key presses. Holding this key enters macro
recording mode.
GETTING TO KNOW YOUR KEYBOARD
SETTING UP YOUR KEYBOARD
Connect the detachable USB cable (P) to the keyboard USB Type-C port (M) and to an available
USB 3.0 or better Type-A port on your Windows® PC, Apple Mac®, or Microsoft Xbox®.*
*www.corsair.com/xbox-support
SOFTWARE MODE
When iCUE is running the keyboard operates in software mode and is controlled by iCUE
Install iCUE on a Windows PC or Apple Mac to connect all of your CORSAIR iCUE compatible
products together in a single interface, giving you complete control of everything from lighting
to powerful macros.
Download iCUE from www.corsair.com/downloads.
HARDWARE MODE
When iCUE is not running or the keyboard is connected to a device that does not support iCUE,
the keyboard operates in hardware mode which uses proles and settings saved to the
onboard storage.
With iCUE and the new dynamic prole system, you can create as many custom proles as can
t onto the 8MB of onboard storage. Each prole can store complex backlighting effects (up to 20
layers), actions & macros, and settings.*
AXON HYPER-PROCESSING TECHNOLOGY
FUNCTION HOTKEYS
Macros can be recorded at any time via the below process. In hardware mode your macros are
recorded to onboard storage and in software mode your macros are recorded to the current
iCUE prole.
MACRO RECORDING
Keyboard lighting effects can be controlled via the onboard shortcuts below when iCUE is not
running or the keyboard is connected to a device that does not support iCUE.
ONBOARD LIGHTING
With iCUE you can program vivid and
dynamic custom multi-layered lighting
effects, then save them to onboard storage.
CORSAIR AXON delivers a powerful and responsive keyboard experience with:
* The number of lighting effects layers per prole and total number of proles that can be saved
to onboard storage will vary based on complexity.
ENGLISH
ENGLISHENGLISHENGLISHENGLISH
1
2
3
4
C J K
P
Q
M O N
A D GF IB E H L
FACTORY RESET
To clear the onboard memory, hold the ESC key while plugging in the USB cable (P) to your
system, then release the ESC key after two seconds. The keyboard will then power on normally
and be reset to factory defaults.
> Hyper-fast keystroke detection and processing
> Up to 8,000Hz hyper-polling (adjustable in iCUE device settings)
> Up to 20-layer onboard lighting effects (programmable in iCUE per prole)
HOLD
(2 SECONDS)
PRESS KEYS
TO RECORD
PULSES WHITE WHITEBLINKS
PRESS KEY
OR FN + KEY
COMBINATION
TO SAVE
PRESS
RAPIDLY BLINKS WHITE HOLD CANCEL TO
Keys that can be recorded:
> Standard keys
Macros can be recorded to:
> Any standard key*
> FN + key*
* Hotkeys cannot be recorded
over with onboard macro
recording.
MACRO CLEANING PROCESS
NOTE: Saving a macro to a key or existing shortcut will overwrite that function until cleared.
With iCUE you can edit recorded macros and assign additional actions to keys.
MACRO RECORDING PROCESS
The Tournament Switch (N) is located on the backside of the keyboard and when turned on puts
the keyboard into a competition compliant mode that:
TOURNAMENT SWITCH
> Disables custom actions and macros to prevent accidental activation
> Changes backlighting to static single color to reduce distraction
> Offers standard operation without proles and prole switching
Other keyboard functions including the brightness key (B), Windows lock key (C), volume control
(J, K), and media keys (L) still function as normal.
To enable Tournament Mode:
1. Move the switch to the right position
> Indicator (O) will light up red when enabled
2. Flip up the switch cover to lock into place
A — PROFILE SWITCH HOTKEY
B — BRIGHTNESS HOTKEY
C — WINDOWS LOCK HOTKEY
D — MACRO RECORD INDICATOR
E — VOLUME MUTE INDICATOR
F — WIN LOCK INDICATOR
G — NUM LOCK INDICATOR
H — CAPS LOCK INDICATOR
I — SCROLL LOCK INDICATOR
J
— VOLUME MUTE HOTKEY
K — VOLUME ROLLER
L — MEDIA CONTROL HOTKEYS
M — USB TYPE-C PORT
N — TOURNAMENT SWITCH
O — TOURNAMENT MODE INDICATOR
P — DETACHABLE USB TYPE-C
TO A CABLE
Q — DETACHABLE MAGNETIC
PALM REST
With iCUE you can change the color of the RGB LED’s while in tournament mode.
SHORTCUT LIGHTING EFFECT
FN + 1 Spiral Rainbow
FN + 2 Rain
FN + 3 Rainbow Wave
FN + 4 Visor
FN + 5 Type Lighting (Per-key)
FN + 6 Type Lighting (Ripple)
FN + 7 Color Shift
FN + 8 Color Pulse
FN + 9 Color Wave
FN + 0 Static Color
(Press to cycle colors)
SHORTCUT FUNCTION
FN + ` Reset to Onboard
Stored Effect
FN + - Reduce Effect Speed*
FN + = Increase Effect Speed*
FN + [ Rotate Effect Left*
FN + ] Rotate Effect Right*
*Functions supported on select effects.
(2 SECONDS)
HOLD
(2 SECONDS)
PULSES WHITE
PRESS
RAPIDLY BLINKS WHITE
PRESS KEY
OR FN + KEY
COMBINATION
TO SAVE
HOLD TO CANCEL
(2 SECONDS)
