Side 1/16
Tumble Dryer
Instruction Book
Safety Advice 3-4
Electrical Requirements 4
Features - Get to know the main parts of your Dryer 5
Where to put and vent your Dryer 5
How to use your Dryer 6
Sorting your laundry 7
Wash Care Labels 8
Items requiring special attention 9
The Controls 10
Guide to Drying Times 11
How to Remove and Clean the Fluff Filter 12
Caring for your Dryer 12
If something goes wrong 13
If it still won’t work 14
Contents
2
Retention of this Instruction Book
This Instruction Book must be kept handy for reference as it contains important details on the safe
and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind, make sure
this Book is also provided so the new owner can become familiar with the appliance and safety
warnings.
3
For your safety
NEVER Allow children to play with or otherwise interfere with the dryer.
NEVER Allow the air inlet at the back of the dryer, the air outlet or vent hose
to be obstructed.
NEVER Direct the vent hose outlet towards the air intake at the back of the
machine.
NEVER Allow the tumble dryer to recycle exhaust air.
NEVER Switch the machine off leaving a hot load in the drum.
NEVER Tumble dry without the filter in position.
NEVER Exceed the maximum load capacity recommended or place
dripping wet items in the drum.
NEVER Use the dryer on a carpeted floor where the pile height would
prevent air from entering the dryer from the base.
NEVER Allow lint to collect around the dryer.
NEVER Add liquid or sheet fabric conditioner to the dryer, use liquid
conditioner in the final rinse of your wash.
NEVER Use the dryer for commercial drying, the dryer is only suitable for
domestic use.
NEVER Dry Acrylics on the high heat setting.
NEVER Tumble dry articles that have NOT been well washed in water and
detergent then well rinsed and spun.
NEVER Tumble dry articles that have had chemicals used for cleaning.
NEVER Dry articles that are contaminated with flammable substances such
as: petrol, oil, paint, hair lacquer, creams, cooking fat or oil.
NEVER Tumble dry: rubber, foam rubber, plastic, plastic foam, nappy pants
or liners, polythene or paper.
Large, very bulky items including duvets and sleeping bags.
NEVER Never attempt to stand on top of your dryer, it is not designed for
such use and you could injure yourself or damage the dryer by such
abuse.
NEVER Switch electricity On or Off with wet hands.
IMPORTANT
Using your Tumble Dryer is easy.
Nevertheless, for your own safety and to get the best results it is important to know your Dryer
by reading right through this handbook before using your dryer for the first time.
A CHILD COULD CLIMB INTO OR TAMPER WITH AN UNATTENDED
TUMBLE DRYER.
WHEN THE MACHINE IS NOT IN USE SWITCH OFF, REMOVE THE PLUG AND CLOSE
THE DOOR.
IMPORTANT
4
For your safety
ALWAYS When the dryer is not in use, switch off, remove plug,and
close the door.
ALWAYS Comply with the specified electrical requirements.
ALWAYS Ensure that your dryer is installed correctly and has adequate
ventilation. (see “Where to put and vent your dryer”)
ALWAYS Use the vent hose for optimum drying performance.
ALWAYS Finish every programme with the cool tumble cycle provided on
the control.
ALWAYS Clean the filter, it is essential that the filter is kept clear of fluff
at all times.
ALWAYS Observe the rules for drying garments:
In particular woollen articles should not be dried in a
tumble dryer unless they are labelled ‘Superwash’,
‘Machine washable’ or have the ‘May be tumble dried’
symbol:
If in any doubt do not dry wool in the machine.
Unlike other materials, the mechanism of wool
shrinkage is irreversible, i.e. it will not stretch back to
the original size and shape.
ALWAYS Buy genuine accessories and spares.
Electrical Requirements
REFER TO THE R ATING PLATE FOR VOLTAGE AND CURRENT
REQUIREMENTS.(See diagram for location.)
The dryer should be connected to the mains supply via a suitable socket
which is after installing your dryer.accessible
The wires in the mains lead are coloured in accordance with the
following:
GREEN/YELLOW - EARTH
BLUE - NEUTRAL
BROWN - LIVE
If a replacement plug is to be fitted, the appropriate wire must be
connected to the correct terminal,the cut-off plug must be disposed of
safely. DO NOT leave where it can be inserted into a socket and create a
shock hazard.
Should the mains lead ever require replacing at any time please
contact your nearest Service Centre. A charge will be made for the
replacement of the mains lead or if you require a longer lead.
The mains lead must only be replaced by a specially prepared cable
obtainable from your Spares Stockist and fitted by a qualified
electrician.
WARNING: This appliance must be earthed!
Changing the
mains cable
NOTE: IF IN DOUBT ABOUT ANY OF THE ABOVE CONSULT A
QUALIFIED ELECTRICIAN.
CAUTION:
When the dryer is in use avoid touching the rear of
the dryer as it may be hot!
5
Features - Get to know the main parts of your dryer
Where to put and vent your dryer
Your tumble dryer should NOT be located adjacent to a gas hob,cook-
er, heater, or eye level grill as flames from the burners could cause
damage to your machine.
The dryer should be placed where air can freely circulate around it,
preferably near a window that can be opened to reduce the possibili-
ty of condensation occuring while the dryer is in use.
When operating the dryer, there has to be adequate ventilation to
avoid the back flow of gases into the room from appliances burning
other fuels,including open fires.
A vent hose is recommended for optimum performance.
DO NOT operate the dryer in an enclosed environment, ensure
the dryer is adequately ventilated.
DO NOT allow clothes, towels etc., to hang down the front of the
dryer into the airstream. This obstructs the airflow and may dam-
age the dryer.
Ensure that the end of the hose is not directed towards the air
intake grille at the rear of the dryer.
NOTE: The vent hose should not exceed 2.4 metres in length, and
should be kept free of any possible accumulation of fluff lint (and
water) by frequently shaking it out. Always ensure that the hose
is not squashed.
Filter Assembly
(on inside of the door)
Mains On/Off
Indicator Light
(if fitted)
Heat Selector Switch
Exhaust Air Grille
Door Release
Timer Knob
Window Vent Kit
Wall Hanging Kit
A venting kit is available as an optional extra, which will take the moist air
directly from the dryer and out through an open window.
The venting kit is fitted to the front of the door.
This allows the dryer to be mounted on a wall of suitable strength to take
the weight. Alternatively it should be used when the dryer is mounted on
top of a work surface to secure the dryer to the wall.
WARNING:
DO NOT DISCHARGE THE EXHAUST AIR INTO A FLUE WHICH IS
USED FOR EXHAUSTING FUMES FROM OTHER APPLIANCES
BURNING GAS OR OTHER FUELS.
6
How to use your dryer
1. Plug in, switch on
electricity.
2. Sort your laundry
(see section “Sorting
Your Laundry”)
3. Open the door.
Check that the fluff
filter is clean
(see section How to
remove and clean
the fluff filter).
4. Load the dryer
placing the clothes
carefully in the
drum, pushing
them well towards
the back and away
from the door seal.
Close the door.
5. Select the
relevant heat setting
(see section “Sorting
your Laundry”).
Push IN for full heat, for cottons, linens and syn-
thetics.
Low setting - button OUT for acrylics and
acrylic mixtures.
6. Turn the Timer clock-
wise to select the required
drying time. (See Section
The Controls”.)
The dryer will start
7. When finished
open the door and
take out the laundry.
Clean and replace the
fluff filter.
WARNING: WHEN
SWITCHING ON OR
OFF, PLEASE
ENSURE THAT YOUR
HANDS ARE DRY
WARNING: WHEN
SWITCHING ON OR
OFF, PLEASE
ENSURE THAT YOUR
HANDS ARE DRY
Button IN
HIGH HEAT
Button OUT
LOW HEAT
Never switch the dryer off with a hot load in the drum.
You must terminate every programme with the Cool Tumble Phase.
8. Switch off electricity
and remove plug from
socket.
7
Sorting your laundry
1. Always separate laundry into the correct fabric groups before
washing and drying.
2. See that all zips are closed, hooks and eyes are fastened and belt,
strings etc. are tied loosely in bows, you will normally have done this
for each item before the washing stage.
3. It is important to extract as much water as possible from each
item before drying.This saves you time and money.
4. Make sure that the items to be dried are suitable for tumble
drying, or are not of a type requiring special attention (see“Wash
Care Labels section).
Your dryer will hold a load of 3kg (6.6lb) dry weight of natural fabrics. if
you are drying items of man-made fibres (synthetic or acrylics), the
maximum load should not exceed 2kg (4.4lb) dry weight.
This difference is that man-made fibres require more space to tumble-dry
without creasing.
To help you estimate how many items it takes to make up a drying load,
the charts below show the approximate weights of some everyday
washing items.
If you group small cotton or terry-towelling items with a synthetic fabric
load they could be damp at the end of the drying cycle. If this happens
simply give them an additional short period of drying to finish them off.
Maximum
load size
Typical load
WARNING:CLOTHES SHOULD NEVER BE LOADED DRIPPING WET
WARNING: DO NOT OVERLOAD AS THIS COULD RESULT IN
REDUCED DRYING PERFORMANCE AND A POSSIBLE FIRE
HAZARD.
Clothes
Blouse Cotton 150g 5oz
Other 100g 31/2oz
Dress Cotton 500g 1lb 2oz
Other 350g 12oz
Jeans 700g 1lb 6oz
10 Nappies 1000g 2lb 3oz
Shirt Cotton 300g 10 1/2oz
Other 200g 7oz
T-Shirt 125g 41/2oz
Household Items
Duvet cover Cotton 1500g 3lb 5oz
(Double) Other 1000g 2lb 3oz
Large Tablecloth 700g 1lb 6oz
Small Tablecloth 250g 9oz
Tea Towel 100g 31/2oz
Bath Towel 700g 1lb 8oz
Hand Towel 350g 12oz
Double Sheet 500g 1lb 2oz
Single Sheet 350g 12oz
8
Wash Care Labels
Most of today’s fabrics can be tumble dried in your Dryer with no
trouble at all, but there are certain fabric finishes which should be dried
away from direct heat.
The majority of garments now have wash-care labels on them, giving full
washing and drying instructions. These should always be followed
carefully especially when you are drying something for the first time.
Typical symbols are:
May be tumble dried
Do not tumble dry
Or:
Tumble dry at high heat setting
Tumble dry at low heat setting
Those containing foam rubber or rubber-like materials or plastic
film (e.g. pillows,cushions,PVC rainwear), or any other articles which
are inflammable or contain inflammable substances (e.g.towels
contaminated with hair lacquer
Fibreglass (e.g.some types of curtains)
Items which have been dry cleaned
Woollens.Woollen items need as much care in drying as they do
in washing.The movement of the tumble-drying action causes the
woollen fibre to shrink and distort.
Garments with the ITCL Code (see ‘Items Requiring Special
Attention’).
Do not tumble dry.
Large bulky items e.g.continental quilts, sleeping bags, pillows,
cushions, double blankets and large bedspreads.These expand
when drying and would prevent airflow through the Dryer.
WARNING: THE DRYER IS INTENDED FOR USE ONLY WHERE
WATER SOLUTION IS USED FOR THE CLEANING PROCESS.MISUSE
OF A TUMBLE DRYER MAY CREATE A FIRE HAZARD.
Items not suitable for tumble drying
9
Items requiring special attention
The drying requirements of blankets and bedspreads will, of course, vary
tremendously according to size and weight. Some, however are simply
too big.if you have difficulty getting them into the Dryer, the machine will
have difficulty drying them properly. Blankets (and Garments) made from
Acrylic fibres (e.g.Acilan, Courtelle, Orion and Dralon) must be dried with
special care on Low heat setting.Overdrying should be avoided to ensure
heat creasing does not occur.
Your dryer will cope with such clothes very well, but you should always
read the manufacturers drying instructions attached to the garment
before you begin.
Starched articles should be dried together in the same load to avoid the
distribution of starch to non-starched items. You should use a slightly
heavier starch solution than you would when drying the items on the
washing line. Make sure that as much of the solution is removed from the
load as possible before placing it in the Dryer.
Remove the items from the dr yer as soon as they reach ironing
dampness. If they are overdried the starch will powder, leaving the fabric
limp - which rather defeats the purpose of the exercise!
To make sure all your tumble dried clothes come out really fresh and soft
we recommend you use a liquid fabric conditioner in the final rinse of
your wash. A liquid fabric conditioner restores bounce and softness and
helps eliminate static cling.
Garments with the ITCL Code may be cleaned using one of the Home
Dry Cleaning Kits available.
The instructions supplied with the Home Dry Cleaning Kit must be strictly
followed.
Blankets and
Bedspreads
Permanently
pleated or creased
garments
Starched articles
Fabric conditioner
Home Dry Cleaning
WARNING: ON NO ACCOUNT SHOULD LIQUID FABRIC
CONDITIONER BE ADDED TO THE DRYER ITSELF.
10
The Controls
Turn the Timer clockwise to select the required drying time.
The drying time for both heat settings is controlled by the timer. All you
have to do is turn the Timer Control clockwise slightly past the required
time and then back to the required time.
Do not rotate the knob beyond 120 (maximum drying time) or past the
zero stop. If you have selected more time than you require turn the knob
anti-clockwise to select the correct time required.
This operation also starts the dryer, provided the door is closed and the
machine is plugged in.The “Guide to Drying Times” section will tell you
how much time you’ll need for various loads.
Setting the timer
Door Release
Heat Selection
Mains Light
(if fitted)
To open door, grip the handle and pull towards you.
If the door is opened while the Dryer is in use, the drying programme cuts
out automatically and the machine stops. When the door is closed the
Dryer will restart but you will not need to reset the Timer Control.
You can however reset the Timer Control at any stage, should you wish.
Select the appropriate button for low heat or for high heat.
With the switch IN High Heat is selected
With the switch OUT Low Heat is selected
The choice of FULL HEAT or LOW HEAT depends upon the fabric you wish
to dry (see section Sorting your Laundry”)
This light indicates that there is power being supplied to the dryer when
plugged into a suitable socket.
WARNING: CHILDREN HAVE BEEN KNOWN TO CLIMB INTO
TUMBLE DRYERS AND INJURE THEMSELVES. ALWAYS ENSURE
THAT THE MACHINE IS SWITCHED OFF AT THE MAINS WHEN THE
DRYER IS NOT BEING USED.


Produkt Specifikationer

Mærke: Creda
Kategori: Tørretumbler
Model: T 301UWE

Har du brug for hjælp?

Hvis du har brug for hjælp til Creda T 301UWE stil et spørgsmål nedenfor, og andre brugere vil svare dig




Tørretumbler Creda Manualer

Creda

Creda T 301UWE Manual

29 August 2024
Creda

Creda TVU1 Manual

29 August 2024
Creda

Creda T510 Manual

29 August 2024
Creda

Creda TS22VW Manual

29 August 2024
Creda

Creda TVS3 Manual

29 August 2024
Creda

Creda T33V Manual

29 August 2024
Creda

Creda T522 Manual

29 August 2024
Creda

Creda T530 Manual

29 August 2024
Creda

Creda T520 Manual

29 August 2024
Creda

Creda T632CW Manual

29 August 2024

Tørretumbler Manualer

Nyeste Tørretumbler Manualer

Maytag

Maytag MED4005SW Manual

11 Februar 2025
Haier

Haier HD80-E929E-DE Manual

11 Februar 2025
Samsung

Samsung DV90T6440LB Manual

10 Februar 2025
LG

LG DX6701B Manual

6 Februar 2025
LG

LG DX8601WE Manual

6 Februar 2025
Bosch

Bosch WTE8631PEE Manual

1 Februar 2025
Hotpoint

Hotpoint NTM1192UK Manual

1 Februar 2025
Hotpoint

Hotpoint NTM1182UK Manual

30 Januar 2025
