INSTRUCTIONS on INSTALLATION & USE for W200FW and W220VW

Creda recommends, for your own safety and to ensure you get the best possible results from your Washing

Machine, you read through this booklet and follow these steps thoroughly.

Choose a location for your washing

machine where possible on a solid floor,

with the electrical sockets and water

supply taps easily accessible.

Allow sufficient space: 600mm width,

600m depth and 900mm height.

DO NOT install in a bath or shower

room.

Dispose of packaging material in a safe

place and remove any labels.

Please read through thoroughly to

ensure you understand each stage

before you begin.

Read the rest of these instructions to get the best from your appliance, remember to fill in your guarantee registration.

Keep this Book in a safe place for quick reference.

STEP 1 STEP 2

A wash chart is provided to help you to

select your required programme.

Examples given for the maximum

washing load weight for different fabric

types.

STEP 4

WARNING: This appliance must be earthed.

Remember you will be charged for a service call if a

problem with your washing machine is caused by

incorrect installation or misuse.

Electrical Guide Installation Guide

Programme Selector Dial

Read through this section to familiarise

yourself with the different

compartments within the dispenser

drawer.

STEP 3 Dispenser Drawer

NOTE: Always follow manufacturer’s dosage

recommendations.

All available optional wash features are

explained within this section - These

allow you to adjust your selected wash

programme to suit your needs.

STEP 6 Options Guide

How to start your selected programme

and how to stop or change the

programme if so required.

STEP 5 Using your Machine

NOTE: Progress indicator lights show what stage in

the programme cycle has been reached.

We recommend the Persil range of

detergent products.

STEP 8 Troubleshooting

A picture guide provides a clear

explanation how to set a wash

programme.

DO NOT overload the washing machine.

STEP 7 A Typical Wash Programme

NOTE: Creda recommend, on completion of your

programme, that you switch off both the

electricity and water supply to the appliance.

Please refer to the Troubleshooting

section if you have any problems when

using your washing machine.

There may be nothing wrong!

NOTE: In addition to the temperature of the

incoming water, the selection of optional wash

features will affect the programme times.

READ BEFORE

CONTACTING

SERVICE!

Merloni Elettrodomestici UK Ltd, Morley Way, Peterborough, PE2 9JB.

PRINTED BY SIMLEX .FOUR ASHES, WOLVERHAMPTON. 09/2004 - 195046949.00

Creda guarantee After Sales Service

“Satisfaction guaranteed or your money back”

We give you a unique ‘satisfaction guaranteed’ promise - valid

for 90 days - after you have purchased your Creda appliance.

If there is a technical problem simply call Creda Repair service

or visit our web-site at www.theservic enec tre.co.uk and where

necessary, we will arrange for an engineer to call.

If the technical problem is not resolved under this guarantee,

we will replace your machine or, if you prefer, give you

your money back.

All Creda appliances carry a fully inclusive 12 month parts and

labour guarantee.

Guarantee terms and conditions

Your guarantee is only applicable in the United

Kingdom or Republic of Ireland and is subject to the

following provisions that your appliance:

●Has been installed and used correctly in accordance with

this instruction booklet.

●Has been used solely for domestic purposes and is located

on domestic premises (ie. not for commercial or trade

use).

●Has been properly connected to a suitable electrical

supply voltage as stated on the appliance rating plate.

●Has not been subject to misuse,accident, modified or

repaired by anyone other than one of our own service

engineers.

For pre purchase information on any other Creda

product,

call: 08701 54 64 74 or visit: www.creda.co.uk

Recycling & Disposal

Information

As part of Creda’s continued commitment to helping the environment,

we reserve the right to use quality recycled components to keep down

customer costs and minimise material wastage.

Please dispose of packaging and old appliances carefully.

To minimise risk of injury to children, remove the door, plug and cut

mains cable off flush with the appliance. Dispose of these parts

separately to ensure that the appliance can no longer be plugged into

a mains socket, and the door cannot be locked shut.

“No company is better positioned to offer an after sales service on

a Creda appliance than us - the manufacturer”.

As part of our commitment to you, all Creda appliances have the added

benefit of a fully inclusive parts and labour guarantee for the first 12

months. All in-guarantee repairs are guaranteed for the remainder of your

original guarantee period.

When the 12 months parts and labour guarantee expires we offer the

following after sales service options:

Repair Service and Information Help Desk

UK: 08709 066066

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the Model number and the Serial number

of your appliance.

Available 364 days a year with a fast, effective and value for money

service.We have the largest white goods repair service in the UK with over

1200 of our own fully trained engineers.

All chargeable repairs include a parts and labour guarantee for 12

months from the date of the repair.

If you require any information or have any questions about your

appliance, our operators are on hand with help and advice.

All this ensures that you will receive the best available after sales service

possible.

Extended Warranties

UK: 08709 088 088

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 502 200

Whether you have just one or a number of Creda appliances in your

kitchen, we offer two service cover plans to give you total peace of mind.

●Repair Protection Plan - FREE service repairs for a single Creda

appliance during the period of cover.

●Kitchen Cover - FREE service repairs for all your Creda

appliances less than 8 years old.

Genuine Parts and Accessories

UK: 08709 077 077

www.theservic enec tre o.c .uk

Republic of Ireland: (01) 842 6836

A wide range of genuine parts and accessories are available from our

hotline or through our web site.

Genuine parts and accessories, extended warranties and service

repairs are all available on our web-site at:

www.theservic enec tre.c .uko

Getting to Know your Appliance

Plumbing Indicator Line label

Hot Water inlet point and

supplied Hose (Red or Grey end)

Cold Water inlet point and

supplied Hose (Blue end)

Transit Bolts (both MUST be removed

before using your machine).

Control Panel

Interlocking door

and release lever

Rating Plate

Mains Cable

Drainage Hose

Hooked End Support

Dispenser Drawer

Model W220VW shows the maximum features available

Adjustable Feet

Wheels

Key Contacts

After Sales Service

Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in both the appliances and

services we offer.

Extended Warranties

UK: 08709 088 088

(Open 8 to 8 Mon - Sun)

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 502 200

Genuine Parts and Accessories

UK: 08709 077 077

(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)

www.theservic enec tre o.c .uk

Republic of Ireland: (01) 842 6836

Cleaning the Exterior:

Use a damp cloth or silicon polish to clean the exterior surfaces of the

appliance.

Cleaning the Door Bowl:

Clean the internal surface of the door bowl regularly with a soft cloth.

A build up of soap powder and water hardness residue may result in

water leaking from the door.

Repair Service and Information Desk

UK: 08709 066 066

(Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays)

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the following information:

The Model number (which can be found on

the control panel)

The Serial number (which can be found on the

inner door trim)

Cleaning the Dispenser Drawer & Compartments:

It is advisable to clean the dispenser drawer regularly:

1Pull the drawer out until it reaches its stop.

2Press the drawer release latch

down to remove the dispenser

drawer.

4Relocate the dispenser drawer and push it

firmly back into place.

Clean and dry the

dispenser drawer,

syphons, grate and

fabric conditioner exit

channel (A).

Also,regularly clean the

outlet pipe area (B).

●Do not try to clean any

part of the dispenser

drawer while the machine

is working.

WARNINGS:

●Do not clean any part of the

machine with abrasive cleaners,

scouring agents, acids, any

bleaches or metal polish, as

they may cause damage.

3CONNECT TO THE WATER

SUPPLY...

The Dispenser Drawer

STEP 3

Electricity Supply Installation

WARNING: The appliance must be earthed.

CE marking certifies that this appliance conforms to the following

EEC directives:

Low Voltage Equipment - 72/23/EEC & 93/68/EEC

Electromagnetic Compatibility - 89/336/EEC, 92/31/EEC & 93/68/EEC

Fuses

Your appliance comes fitted with a plug and a 13 amp (13A) fuse. If

you need to replace the fuse, use only those rated at 13 amp (13A)

and ASTA approved to BS1362.To change the fuse lift the holder to

vertical position and lift the fuse out.To replace the fuse, insert the

fuse and push fuse holder down into the locked position.Correct

replacement is identified by colour coding or the marking on base of

plug.

WARNING: Do not use the plug unless the fuse holder is in the locked

position and the top cover firmly replaced.

Changing the Mains Lead

If you have damaged the existing lead and need a new one, contact

Creda Service UK on: 08709 066 066 or www.theservicecentre.co.uk

(or in the Republic of Ireland on: 1850 302 200). A charge will be

made.We strongly advised that fitting a new lead is carried out by a

qualified electrician.

Seek professional advice if you need to use an extension lead.

Changing the Plug

If you need to change your plug, if it does not fit your socket: isolate

the machine from the mains supply. Cut off the supplied plug and

safely dispose of the discarded plug. DO NOT plug into any other

socket.

NOTE: If you change the plug,the colour of wires in the mains lead

may not match the colour of the markings which show the different

terminals in the plug.You must wire it as shown below:

Green and yellow (Earth)

wire to terminal marked ‘E’,

symbol , or coloured

green and yellow.

Blue (Neutral) wire to

terminal marked ‘N’ or

coloured black.

13A ASTA approved fuse to

BS1362.

Brown (Live) wire to terminal

marked ‘L’ or coloured red.

Adding Fabric Conditioner

Dispensing Powder Detergent

Dispensing Liquid Detergent

Index:

1. Drawer release latch

2. Pre-wash detergent compartment

Maximum 200ml powder or

100ml liquid

3. Main detergent compartment

Maximum 400ml powder or

200ml liquid

4. Grate

5. Fabric conditioner compartment

120ml maximum

To achieve the best wash results the

manufacturer’s recommended amount

of detergent should be measured and

added to the main detergent

compartment (II symbol) (max. 400ml).

Alternatively you can obtain a liquid

detergent flap, a barrier for the dispenser

drawer.

Contact Genuine Parts and Accessories

(see Key Contacts)

Pour the recommended

amount of fabric

conditioner into the

compartment

(flower symbol).

Do not exceed the

maximum fill line.

Pre-wash Programme A

When selecting programme A,

add detergent to both the

pre-wash compartment (Isymbol)

and the main wash compartment

( symbol).II

DO NOT use in drum dosing

devices with the Pre-wash

programme, A.

4DRAINAGE SYSTEM... we recommend one of the following:

1POLYSTYRENE BLOCK...

5LEVEL?...

NOTE: ALTHOUGH YOU MAY NEED TO

MOVE THE HOOKED END SUPPORT

ALONG THE GREY DRAINAGE HOSE,

DO NOT REMOVE IT.

WHICHEVER DRAINAGE METHOD

YOU USE, MAKE SURE THAT THE

HOOKED END SUPPORT IS FIXED

LEVEL TO, OR ABOVE THE ‘PLUMBING

INDICATOR LINE’*

(*see Getting to Know your Appliance)

This is part of the packaging and

should have come away with the

polystyrene base.

IF IT HAS NOT... REMOVE IT!

NOTE: YOU MAY NEED A SECOND

PERSON TO HELP YOU RAISE AND

LOWER THE APPLIANCE.

PLEASE USE THE NEW HOSES SUPPLIED, FITTED

TO THE MACHINE.

If you have no hot water supply...

Old hoses may

cause leaks due to

worn out washers.

YOUR MACHINE WILL BE NOISY IF THE TWO FRONT FEET ARE NOT

ADJUSTED SO THE MACHINE STANDS FIRM AND LEVEL.

Check both hot

and cold water

supplies are

running freely...

A cold fill adaptor is available from

your local authorised Service

Centre or by calling the Genuine

Parts & Accessories Hotline (see

Key Contacts).

Connect fill hoses to

water supply taps:

Red or Grey Hose end

to Hot and Blue Hose

end to Cold.

TURN BOTH TAPS ON...

Turn one both front feetor

clockwise until the machine

stands firm and level.

The spring on each foot will

stop them coming loose.

2REMOVE TWO TRANSIT FIXINGS... Follow these instructions to remove the TWO transit fixings.

IMPORTANT:

Situated, one either

side of the rear panel,

both transit bolts

(complete with

spacers) MUST be

removed before use...

Failure to do so may

cause damage to

your machine!

DO NOT REMOVE!

STANDPIPE METHOD UNDER SINK METHOD

Attach the GREY

drainage hose to the

under sink drainage

unit securely, using a

hose clip.

Fix the hooked

end support at

a minimum

800mm from

the floor.

cut off the blocked

end of the under sink

drainage unit.

7READY...

TO CHECK ALL PARTS OF THE INSTALLATION AND TO THOROUGHLY

CLEAN THE INSIDE OF YOUR MACHINE:

RUN PROGRAMME ‘B’ (refer to ‘Programme Selector Dial’, STEP 4).

6CONNECT TO THE POWER SUPPLY...

PLUG YOUR MACHINE INTO AN ELECTRICAL SOCKET WHICH IS

EASILY ACCESSIBLE. SWITCH ON

NOTE: We recommend extension

leads are not used.

Move your machine into position,

take care not to trap or kink the

hoses.

WITHOUT ANY LAUNDRY

WITHOUT ANY DETERGENT

and

THIS WILL TAKE APPROXIMATELY 2hours TO COMPLETE

.............................

Standpipe height:

minimum 500mm

from the floor.

Insert drainage hose

approximately 100mm

into the standpipe.

✗✗

It is important the transit

bolt and spacer come out

intact (see pic).

For safety, replace both

plastic covers over the

holes left by removing

the two bolts.

Use a crosshead

screwdriver to

remove the

plastic cover.

Unscrew the

bolt using a

13mm spanner.

STOP when 3

threads can be

seen.

Hold, slide

across and pull

to remove.

800mm

from floor

Hooked End Support

STEP 1 STEP 2

WARNING:

●Do not put any items into

the drawer, other than

detergents designed to be

released from the drawer, as

they may cause damage or

blockage.

We recommend the use of a detergent dosing ball, as provided by your detergent

manufacturer.

Produkt Specifikationer

Mærke:	Creda
Kategori:	Vaskemaskine
Model:	W220VW

Har du brug for hjælp?

Hvis du har brug for hjælp til Creda W220VW stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Vaskemaskine Creda Manualer

29 August 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

Vaskemaskine Manualer

Nyeste Vaskemaskine Manualer

Nabo WM 1600 Manual

21 November 2024

Otsein LB LTO129A Manual

20 November 2024

SanGiorgio ST6512EL Manual

20 November 2024

SanGiorgio FS614D9 Manual

20 November 2024

SanGiorgio PROGETTO F4 Manual

20 November 2024

SanGiorgio SG710 Manual

20 November 2024

SanGiorgio F814DIBC Manual

20 November 2024

SanGiorgio F812D Manual

20 November 2024

SanGiorgio S5510C Manual

20 November 2024

SanGiorgio F812L Manual

20 November 2024
