Crestron TPMC-9L
Isys® 9” Wall Mount Touch Screen
Operations & Installation Guide
This document was prepared and written by the Technical Documentation department at:
Regulatory Compliance
Federal Communications Commission (FCC) Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Industry Canada (IC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
As of the date of manufacture, the TPMC-9L has been tested and found to comply with specifications for CE
marking and standards per EMC and Radiocommunications Compliance Labelling.
The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, Adagio, Core 3, Core 3 UI, Cresnet, Crestron Home, Crestron Toolbox, Crestron VisionTools, Isys, Rava,
SmartObjects, SystemBuilder, TouchPoint and VT Pro-e are either trademarks or regist c. in ered trademarks of Crestron Electronics, In
the United States and/or other countries. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation
in the United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
©2012 Crestron Electronics, Inc.
Crestron TPMC-9L Isys
®
9” Wall Mount Touch Screen
Contents
Isys® 9” Wall Mount Touch Screen: TPMC-9L 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Applications.................................................................................................................4
Specifications ..............................................................................................................5
Physical Description....................................................................................................8
Setup ........................................................................................................................................ 12
Network Wiring.........................................................................................................12
Identity Code ............................................................................................................. 12
Configuring the Touch Screen................................................................................... 13
Mounting Options......................................................................................................27
Touch Screen Mounting ............................................................................................27
Touch Screen Removal.............................................................................................. 31
Hardware Hookup .....................................................................................................31
Recommended Cleaning............................................................................................32
Programming Software............................................................................................................ 33
Software Requirements for the PC............................................................................ 33
Programming with Crestron SystemBuilder.............................................................. 33
Programming with SIMPL Windows ........................................................................ 33
Programming with VisionTools ................................................................................ 36
Push Button Programming ........................................................................................40
Uploading and Upgrading........................................................................................................ 41
Establishing Communication.....................................................................................41
Programs, Projects and Firmware.............................................................................. 43
Program Checks ........................................................................................................ 43
Problem Solving ...................................................................................................................... 44
Troubleshooting......................................................................................................... 44
Check Network Wiring..............................................................................................45
Reference Documents................................................................................................ 46
Further Inquiries........................................................................................................46
Future Updates ..........................................................................................................46
Return and Warranty Policies .................................................................................................. 47
Merchandise Returns / Repair Service ...................................................................... 47
Crestron Limited Warranty........................................................................................47
Operations & Installation Guide – DOC. 7030B Contents •
•
•
•• i
Crestron TPMC-9L Isys
®
9” Wall Mount Touch Screen
Isys® 9” Wall Mount
Touch Screen: TPMC-9L
Introduction
The Isys® TPMC-9L Wall Mount Touch Screen from Crestron® delivers high end
style and performance in a compact, cost effective flush mount design. Featuring a
generous 9” (~229 mm) widescreen display, advanced Core 3 UI™ touch screen
graphics, high performance H.264 video and Rava™ SIP Intercom, the TPMC-9L
delivers a world of control capability, yet leaves a very small footprint. The addition
of 12 optional push buttons provides quick access to commonly used functions.
Features and Functions
• Stylish flush mount design for in-wall and lectern installation
• Generous 9” (~229 mm) widescreen color touch screen
• 16-bit color graphics powered by Core 3™
• 800 x 480 WVGA display resolution
• Automatic brightness control
• Native H.264 streaming video for viewing Web cameras and HD
sources
• Wired composite video input
• Rava SIP Intercom and phone technology
• WAV file customizable audio feedback
• Crestron Home® CAT5 video connectivity
• High speed Ethernet and Cresnet
® communications
• Built-in USB port for direct program upload
• Includes faceplate with 12 “hard key” push buttons
• Custom button engraving available as solid or backlit text
• No-button blank faceplate also provided
• Wall, lectern and rack mounting options
• Available with almond, black or white textured finish
Operations & Installation Guide – DOC. 7030B Isys
® 9” Wall Mount Touch Screen: TPMC-9L •
•
•
•• 1
Isys
®
9” Wall Mount Touch Screen Crestron TPMC-9L
Advanced Touch Screen Control
A Crestron touch screen offers an ideal user interface for controlling all the
technology in a home, boardroom, classroom, courtroom or command center. Touch
screens do away with piles of remote controls, cluttered wall switches and cryptic
computer screens, simplifying and enhancing the technology. For controlling home
theater, multimedia presentation, audio, video, lighting, HVAC and other systems,
Crestron touch screens are fully customizable with easy to use controls and icons,
true feedback and real time status display, full-motion video windows and advanced
navigation of digital media servers, tuners and other devices.
Powered by Core 3
Crestron touch screens have always offered the ultimate user experience. With Core
3 UI, they also deliver the ultimate value, enabling the creation of dynamically rich
user interfaces with incredible efficiency and unparalleled functionality. User Core 3
UI, programmers can swiftly integrate fluid gesture-driven controls, animated
feedback, metadata, embedded apps and full-motion video for a deeply engaging and
ultra-intuitive touch screen experience.
Some Core 3 UI enhancements:
• Cool looking graphical buttons, sliders, knobs and gauges are intuitive and
fun to use.
• Kinetic effects enhance the feeling of realism with lists and toolbars that
scroll with momentum at the flick of a fingertip.
• Drag and drop objects snap into place offering an easy way to assign assets
to rooms.
• Desktop widgets personalize the touch screen with animated clocks,
calendars, weather, news and other information.
• Customizable themes allow a completely different look and feel for every
user, event or season.
• Fully developed SmartObjects™ enable sophisticated control over complex
devices with minimal programming.
• Smart resizing scales objects perfectly and instantly for faster GUI
development, even across different sized touch screens.
Integrated Video
High performance streaming video capability makes it possible to view security
cameras and other video sources over the network right on the touch screen. Native
support for H.264 and MJPEG formats allows the TPMC-9L to display live video
images from Web cameras and servers such as the Crestron CEN-NVS200 Network
Video Streamer (sold separately). A wired video input is also provided to allow
viewing of a composite video source. Video images can be displayed full frame or in
fully scalable windows anywhere on the touch screen.
2 •
•
•
•• Isys® 9” Wall Mount Touch Screen: TPMC-9L Operations & Installation Guide – DOC. 7030B
Crestron TPMC-9L Isys
®
9” Wall Mount Touch Screen
Rava SIP Intercom
Rava SIP Intercom technology enables hands free VoIP communication between any
two Rava-enabled Crestron touch screens. Rava works over Ethernet, supporting
2-way intercom, video intercom*, paging and room monitoring without any special
wiring. VoIP phone capability is also possible through integration with a
SIP-compatible IP phone system or SIP server, allowing hands free telephone
functionality complete with speed dialing, caller ID, custom ringers and other
enhancements. Built-in echo cancellation affords true duplex performance for clear,
seamless voice communication using the TPMC-9L’s integrated microphone and
speakers.
Audio Feedback
Customized WAV files can be loaded on the TPMC-9L to add another dimension to
the touch screen graphics using personalized sounds, button feedback and voice
prompts.
Push Button Options
The TPMC-9L features a faceplate containing 12 programmable “hard key” push
buttons, elegantly trimmed by illuminated button dividers. Integral to the faceplate,
the push buttons are positioned along the left and right edges of the touch screen,
making it possible to align them with text and graphics onscreen. Custom engraving
of the buttons is available, with a choice of solid or backlit text. A plain, no-button
faceplate is also included, allowing a very clean appearance with no push buttons.
Auto-Brightness Control
The TPMC-9L maintains optimal visibility under varying lighting conditions,
adjusting its button backlighting and display brightness smoothly and automatically
according to changes in the ambient light level in the room.
High Speed Connectivity
Both Cresnet® and high speed Ethernet are standard on the TPMC-9L, providing for
easy network integration and seamless communications with Crestron control
systems and other network devices.
Versatile Flush Mount Design
The TPMC-9L is designed for easy flush mount installation in a wall, lectern or
similar flat surface. Mounting clips furnished with the TPMC-9L facilitate a clean
installation in drywall and many furniture applications. Additional mounting options
are available separately.
* H.264-compatible IP camera required.
Operations & Installation Guide – DOC. 7030B Isys
® 9” Wall Mount Touch Screen: TPMC-9L •
•
•
•• 3
Isys
®
9” Wall Mount Touch Screen Crestron TPMC-9L
Applications
The following diagram shows a TPMC-9L in a typical application.
TPMC-9L in a Typical Application
4 •
•
•
•• Isys® 9” Wall Mount Touch Screen: TPMC-9L Operations & Installation Guide – DOC. 7030B
Crestron TPMC-9L Isys
®
9” Wall Mount Touch Screen
Specifications
Specifications for the TPMC-9L are listed in the following table.
TPMC-9L Specifications
SPECIFICATION DETAILS
Touch Screen Display
Display Type TFT active matrix color LCD
Size 9 inch (229 mm) diagonal
Aspect Ratio 15:9 WVGA
Resolution 800 x 480 pixels
Brightness 350 nits
Contrast 700:1
Color Depth 24-bit, 16.7 M colors
Illumination Edge lit fluorescent with auto-brightness
control
Viewing Angle ± 88º horizontal, ± 88º vertical
Touch Screen Resistive membrane
Memory
DDR SDRAM 256 MB
Flash 2 GB
Maximum Project Size 40 MB
Graphic Engine Core 3 UI, 16-bit color depth (non-palette),
VT Pro-e® programmable, supports pre-Core
3 projects
Communications
Ethernet 10/100, auto-switching, auto-negotiating,
auto-discovery, full/half duplex, DHCP, for
control and console
Cresnet Cresnet slave mode for control and console
USB USB 1.1 client for console
Video
Analog Input Signal Types Composite
Analog Formats NTSC 480i, PAL 576i
Analog Color Depth 24-bit, 16.7 M colors
Streaming Formats H.264 (MPEG-4 part 10 AVC, MJPEG
Audio
Features Built-in microphone and speakers, Rava SIP
Intercom, Crestron IP Intercom
Audio Feedback WAV format, 8 & 16-bit PCM, 8 - 44.1 kHz
sampling rates, mono & stereo
Power Requirements
Cresnet Power Usage 23 Watts (0.96 Amps @ 24 Volts DC)
Default IP ID1 03
Minimum 2-Series Control
System Update File2, 3
Version 3.155.1240 or later
(Continued on following page)
Operations & Installation Guide – DOC. 7030B Isys
® 9” Wall Mount Touch Screen: TPMC-9L •
•
•
•• 5
Isys
®
9” Wall Mount Touch Screen Crestron TPMC-9L
TPMC-9L Specifications (Continued)
SPECIFICATION DETAILS
Environmental
Temperature 32º to 112º F (0º to 45º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 78 BTU/Hr
Enclosure
Construction Plastic, flush mountable using (4) clips
provided (additional mounting kits sold
separately)
Faceplate Plastic, button and no-button faceplates
included (optional solid or backlit button
engraving sold separately)
Dimensions
Height 7.52 in (191 mm)
Width 10.83 in (275 mm)
Depth 1.86 in (48 mm)
Weight 2.6 lbs (1.2 kg)
Available Models
TPMC-9LA-T Isys 9” Wall Mount Touch Screen,
Almond Textured
TPMC-9LB-T Isys 9” Wall Mount Touch Screen,
Black Textured
TPMC-9LW-T Isys 9” Wall Mount Touch Screen,
White Textured
Included Accessories
TPMC-9L-FP[A,B,W]-
T_BLANK
Button Faceplate without Engraving,
(specify color)
TPMC-9L-FP[A,B,W]-T-NB No-button Faceplate, (specify color)
Available Accessories
BB-9L Pre-Construction Wall Mount Back Box
BBI-9L Back Box – International Version
CEN-NVS200 Network Video Streamer
CRESCAT Crestron Home® CAT5 AV Cable
CRESNET Cresnet Control Cable
MMK-9L Mud Ring
PMK-9L Pre-Construction Wall Mount Kit
RMK-9L Rack Mount Kit
TMK-9L Trim Ring
TPMC-9L-FP[A,B,W]-
T_ENGRAVED
Button Faceplate with Custom Engraving
(specify color)
TPMC-9L-FP-BKLT-[A,B,W]-
T_ENGRAVED
Backlit Button Faceplate with Custom
Engraving (specify color)
VMK-WIN Touchpoint® Virtual Mouse & Keyboard
Software for Windows®
WMKB-6L Replacement Wall Mount Clips
(Continued on following page)
6 •
•
•
•• Isys® 9” Wall Mount Touch Screen: TPMC-9L Operations & Installation Guide – DOC. 7030B
Crestron TPMC-9L Isys
®
9” Wall Mount Touch Screen
TPMC-9L Specifications (Continued)
SPECIFICATION DETAILS
Available Accessories
(Continued)
WMKM-9L Post-Construction Wall Mount Kit
with Mud Ring
WMKT-9L Lectern or Post-Construction Wall Mount Kit
with Trim Ring
1. Refer to “Identity Code” on page 12 for details.
2. The latest software versions can be obtained from the Crestron Web site. Refer to the NOTE
following these footnotes.
3. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
NOTE: Crestron software and any files on the Web site are for authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIPs) only. New users
must register to obtain access to certain areas of the site (including the FTP site).
Operations & Installation Guide – DOC. 7030B Isys
® 9” Wall Mount Touch Screen: TPMC-9L •
•
•
•• 7
Produkt Specifikationer
| Mærke: | Crestron |
| Kategori: | overvåge |
| Model: | Isys TPMC-9L |
Har du brug for hjælp?
Hvis du har brug for hjælp til Crestron Isys TPMC-9L stil et spørgsmål nedenfor, og andre brugere vil svare dig
overvåge Crestron Manualer
5 September 2024
21 August 2024
21 August 2024
20 August 2024
20 August 2024
20 August 2024
20 August 2024
20 August 2024
19 August 2024
19 August 2024
overvåge Manualer
- overvåge Bosch
- overvåge SilverCrest
- overvåge Acer
- overvåge Denver
- overvåge TCL
- overvåge Sony
- overvåge Samsung
- overvåge Panasonic
- overvåge Philips
- overvåge Vitek
- overvåge IFM
- overvåge LG
- overvåge Pioneer
- overvåge Mitsubishi
- overvåge Sharp
- overvåge Behringer
- overvåge Emos
- overvåge Epson
- overvåge Neumann
- overvåge Smart
- overvåge HP
- overvåge AOC
- overvåge Sanyo
- overvåge Akuvox
- overvåge Asus
- overvåge Gigabyte
- overvåge Toshiba
- overvåge Pyle
- overvåge InFocus
- overvåge Lenovo
- overvåge Asrock
- overvåge Yamaha
- overvåge Abus
- overvåge Optoma
- overvåge Da-Lite
- overvåge Westinghouse
- overvåge Element
- overvåge Thomson
- overvåge Hyundai
- overvåge Yorkville
- overvåge JBL
- overvåge Hisense
- overvåge DataVideo
- overvåge RCF
- overvåge Maxell
- overvåge Hannspree
- overvåge Omron
- overvåge Blaupunkt
- overvåge JVC
- overvåge Honeywell
- overvåge Hitachi
- overvåge Medion
- overvåge Citizen
- overvåge Haier
- overvåge Huawei
- overvåge König
- overvåge ProXtend
- overvåge Deltaco
- overvåge NewStar
- overvåge Alpine
- overvåge 3M
- overvåge Festo
- overvåge Danfoss
- overvåge Sunny
- overvåge BlueBuilt
- overvåge Tripp Lite
- overvåge BenQ
- overvåge Packard Bell
- overvåge Mad Catz
- overvåge Jensen
- overvåge Plantronics
- overvåge Xiaomi
- overvåge Peerless-AV
- overvåge Viewsonic
- overvåge Dell
- overvåge Schneider
- overvåge ELO
- overvåge Fujitsu
- overvåge Cooler Master
- overvåge Zalman
- overvåge PreSonus
- overvåge MSI
- overvåge Ricoh
- overvåge NEC
- overvåge Godox
- overvåge APC
- overvåge CTOUCH
- overvåge Ikan
- overvåge AJA
- overvåge GlobalTronics
- overvåge Velleman
- overvåge Marshall
- overvåge JUNG
- overvåge Fostex
- overvåge Salora
- overvåge Focal
- overvåge Genelec
- overvåge KRK
- overvåge NZXT
- overvåge Newline
- overvåge Hikvision
- overvåge Samson
- overvåge Yealink
- overvåge Allen & Heath
- overvåge Midas
- overvåge Simrad
- overvåge Renkforce
- overvåge Marshall Electronics
- overvåge Caliber
- overvåge I3-Technologies
- overvåge Viessmann
- overvåge Brandson
- overvåge Orion
- overvåge QSC
- overvåge BOOX
- overvåge Hanwha
- overvåge LaCie
- overvåge ARRI
- overvåge Onyx
- overvåge ITek
- overvåge Prowise
- overvåge Seiki
- overvåge Ozone
- overvåge M-Audio
- overvåge Bauhn
- overvåge Christie
- overvåge V7
- overvåge Provision-ISR
- overvåge Vorago
- overvåge Atomos
- overvåge EMachines
- overvåge Eurolite
- overvåge Mackie
- overvåge ACTi
- overvåge Faytech
- overvåge Krom
- overvåge Voxicon
- overvåge Chauvet
- overvåge Shure
- overvåge Vimar
- overvåge Continental Edison
- overvåge Dynaudio
- overvåge Iiyama
- overvåge PeakTech
- overvåge Dahua Technology
- overvåge AG Neovo
- overvåge Speco Technologies
- overvåge Prestigio
- overvåge Joy-It
- overvåge Boss
- overvåge IStarUSA
- overvåge SPL
- overvåge Kogan
- overvåge Barco
- overvåge SMART Technologies
- overvåge Insignia
- overvåge LC-Power
- overvåge AMX
- overvåge Tannoy
- overvåge Qian
- overvåge Xoro
- overvåge HyperX
- overvåge TVLogic
- overvåge Geovision
- overvåge Postium
- overvåge Planar
- overvåge Ernitec
- overvåge Bearware
- overvåge Sonifex
- overvåge TV One
- overvåge AVer
- overvåge Alienware
- overvåge Aputure
- overvåge Maxdata
- overvåge Sunstech
- overvåge Marquant
- overvåge Kubo
- overvåge Swissonic
- overvåge IHealth
- overvåge Peaq
- overvåge Avocor
- overvåge Interlogix
- overvåge Eizo
- overvåge Kindermann
- overvåge EverFocus
- overvåge POSline
- overvåge Peerless
- overvåge Monoprice
- overvåge Promethean
- overvåge Odys
- overvåge HKC
- overvåge Ibm
- overvåge Drawmer
- overvåge Iadea
- overvåge Advantech
- overvåge Kali Audio
- overvåge Ganz
- overvåge Extron
- overvåge Legamaster
- overvåge Ikegami
- overvåge Pelco
- overvåge Approx
- overvåge Belinea
- overvåge Palmer
- overvåge Adam
- overvåge GVision
- overvåge Posiflex
- overvåge Jay-tech
- overvåge MicroTouch
- overvåge X-Rite
- overvåge EKO
- overvåge IBoardTouch
- overvåge Mirai
- overvåge Elite Screens
- overvåge Hollyland
- overvåge Mitsai
- overvåge Skytronic
- overvåge COMMBOX
- overvåge Yiynova
- overvåge Lilliput
- overvåge LightZone
- overvåge AOpen
- overvåge Planet Audio
- overvåge EC Line
- overvåge Datacolor
- overvåge Fluid
- overvåge Atlona
- overvåge HELGI
- overvåge Desview
- overvåge Syscom
- overvåge Allsee
- overvåge Alogic
- overvåge Night Owl
- overvåge ProDVX
- overvåge Varad
- overvåge DoubleSight
- overvåge CTL
- overvåge Game Factor
- overvåge Nixeus
- overvåge Chimei
- overvåge Blue Sea
- overvåge AMCV
- overvåge Hamlet
- overvåge Wyse - Dell
- overvåge SWIT
- overvåge Feelworld
- overvåge GeChic
- overvåge Oecolux
- overvåge ADS-TEC
- overvåge Casalux
- overvåge Positivo
- overvåge Jupiter
- overvåge Transvideo
- overvåge Innocn
- overvåge KeepOut
- overvåge Shimbol
- overvåge Raysgem
- overvåge Motrona
- overvåge AORUS
- overvåge Elvid
- overvåge Wohler
- overvåge Portkeys
- overvåge Mimo Monitors
- overvåge Gamber-Johnson
- overvåge Enttec
- overvåge American Dynamics
- overvåge AIS
- overvåge Eve Audio
- overvåge Wortmann AG
- overvåge Viotek
- overvåge Vidi-Touch
- overvåge KTC
- overvåge CoolerMaster
- overvåge Atlantis Land
- overvåge HEDD
- overvåge Colormetrics
- overvåge Monkey Banana
- overvåge SmallHD
- overvåge UPERFECT
- overvåge Freedom Scientific
- overvåge OSEE
- overvåge CSL
- overvåge Mybeo
- overvåge IOIO
- overvåge DTEN
- overvåge Cocopar
- overvåge Titan Army
- overvåge Delvcam
- overvåge Xenarc
- overvåge Wimaxit
Nyeste overvåge Manualer
4 April 2025
5 Marts 2025
5 Marts 2025
27 Februar 2025
21 Februar 2025
18 Februar 2025
11 Februar 2025
11 Februar 2025
11 Februar 2025
11 Februar 2025
