SAROS ICE6LPT
Saros® Express Low-Profile 6.5” 2-Way In-Ceiling Speaker
crestron.com | 800.237.2041
>Low-profile 2-way in-ceiling speaker
>Requires only 5-1/8” (130 mm) mounting depth
>6.5” woofer with damped cloth surround
>Dual front ports for enhanced low-frequency response
>Wide-dispersion, horn-loaded dome tweeter
>Built-in 30 Watt 70/100V multi-tap transformer
>“Zero-bezel” frameless grille for a clean,
contemporary appearance
>Integral metal back can with side-entry cable clamp
>Two-step toggle clamps for fast, easy installation
>Includes tile bridge for installation in a drop-tile ceiling
>Meets the requirements for installation in an environmental
air-handling space
>60 Watts program power handling at 8 Ohms
>85Hz-20kHz frequency response
>95° nominal coverage pattern
>Available in black or white
>Paintable to blend with surroundings
Saros® Express speakers by Crestron® deliver easy installation and
excellent performance in a range of popular sizes for cost-sensitive
commercial applications. Ideal for use in background music, paging, and
sound reinforcement systems, Saros Express speakers are engineered to
achieve full, even coverage and clear sound quality at an affordable cost.
The Saros Express ICE6LPT model is a 2-way in-ceiling speaker featuring
a 6-1/2 inch woofer and wide-dispersion, horn-loaded 1 inch dome
tweeter. Its low-profile enclosure allows for installation in constricted
ceiling spaces as shallow as 5-1/8 inches (130 mm). A built-in 30 Watt
multi-tap transformer allows for use with 70 and 100 Volt distributed
speaker systems. Power handling at 8 Ohms is 60 Watts (program), with a
frequency response from 85 Hz to 20 kHz (±3 dB).
Like its more expensive sibling, the Saros IC6LPT, the Saros Express
ICE6LPT is smartly designed for quick and easy installation and reliable
performance. Its “zero-bezel” frameless grille achieves an unobtrusive
and contemporary appearance well-suited for use in restaurants and night
clubs, retail spaces, houses of worship, convention facilities, universities,
and office buildings. Installing the grille requires no hardware or tools,
utilizing powerful magnets to hold it in place. A safety tether is included to
prevent the grille from ever falling from the ceiling.
Unitized construction of the speaker enclosure simplifies specification and
installation for use in new and existing ceilings. Mounting the speaker is
facilitated using rugged, 2-step toggle clamps integrated into the
enclosure. Each toggle clamp offers two positions to accommodate
standard and extra thick surfaces up to 2.4 inches (61 mm). A tile bridge
is included to provide proper support when installed in a typical drop-tile
ceiling. The tile bridge is adjustable to enable off-center speaker
positioning, and can be folded to fit through the speaker cutout in blind-
mount situations. Two rigging points are also provided on the side of the
speaker enclosure for securing to the building structure using the optional
safety tether kit (SPKA-ST-15
[1]).
An integral metal back can is employed to meet the requirements for
installation in an environmental air-handling (plenum) space. The wiring
connection is accessible behind a rear cover panel by removing a single
screw. Wiring enters through a side-mounted cable clamp attached to the
cover panel. Connecting the wiring behind the cover panel is facilitated
using a detachable screw terminal block with provisions for easy
parallel wiring in a multi-speaker application. Setting the 70/100V
transformer tap is performed via a screwdriver-adjustable control located
on the front baffle behind the grille.
Saros Express ICE6LPT speakers are available in white or black, and can
be painted to blend with the ceiling surface. They are priced individually,
but must be ordered in pairs.
SPECIFICATIONS
Features & Performance
Woofer: 6.5 inch (165 mm) treated paper w/ring mode decoupled cloth
surround & steel basket
Tweeter: 0.98 inch (25 mm) treated cloth dome, horn loaded
Crossover Frequency: 2.5 kHz
Impedance: 8 Ohms nominal with transformer set to “8Ω”
Transformer Taps: 3.75W/7.5W/15W/30W at 70V;
7.5W/15W/30W at 100V
Frequency Response: 85 Hz to 20 kHz (±3 dB)
Frequency Range: 70 Hz to 20 kHz (-10 dB)
Power Handling: 60 Watts program (8 Ohms)
