PAD-INGENDM
INSTALLATION:
1. MOUNTING OPTIONS
Card Reader Rotating Desk Mount
for Ingenico Lane/3000/5000/7000/8000
CONTENTS:
INSTRUCTION MANUAL
X4
Mounting on Table without Anchors Mounting on Table with Anchors
1A. Using a screwdriver (not included) rotate in (4) screws (B) through
the base drill holes into the surface as illustrated, until securely fasened.
**USE TO TIGHTEN OR LOOSEN
ADJUSTABLE JOINT AS NEEDED
(4) (4) (4)
A
B C D
X4 X1
X1
1B. Insert (4) anchors (C) into pre-drilled holes in surface. Using a
screwdriver (not included) rotate in (4) screws (B) through the base drill
holes into the anchors in the surface until securely fasened.
2. Attaching Card Reader to Desk Mount
2A. Take the compatible
card reader (not
included) and align the
holes of the back center
adapter to the desk
mount adapter holes.
Rotate in screw until
secure as illustrated
3. Cable Routing
3A. Locate the holes in
the central kiosk core at
the top top and bottom.
Connect one end of
wire to your device. Fish
it through the top hole
and then out the
bottom. Connect other
end to the designated
end power source.
