Smart App Sinewave Series

PR500LCDRT1U/PR750LCDRT1U/PR1000LCDRT1U

User’s Manual

K01-0000323-01

This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. Please read

and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install,

or operate.

CAUTION! The UPS must be connected to a grounded AC power outlet with fuse or circuit breaker protection. DO NOT plug the UPS into an

outlet that is not grounded. If you need to de-energize this equipment, turn off and unplug the UPS.

CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! CyberPower

Systems does not sell products for life support or

medical applications. DO NOT use in any circumstance that would affect operation or safety of any life support equipment, with any medical

applications, or patient care.

CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected.

CAUTION! For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible.

CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area, free of conductive

contaminants. Please see specifications for acceptable temperature and humidity range.

CAUTION! To reduce the risk of electric shock, do not remove the cover, except to service the battery. There are no serviceable parts inside,

except for the battery.

CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC power source before servicing the battery or installing a

computer component.

CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire, do not use with or near aquariums. Condensation from

the aquarium can come in contact with metal electrical contacts and cause the machine to short out.

CAUTION! DO NOT USE WITH LASER PRINTERS! The power demands of laser printers are too large for a UPS.

UNPACKING

Inspect the UPS upon receipt. The box should contain the following.

(1) UPS Unit; (1) User's Manual for UPS; (2) Rack Mount Brackets; (2) Wall Mount Brackets; (2) Stands (1) Emergency Power Off Cable (gray) (1)

PowerPanel® Business Edition Software CD; (1) Serial Interface Cable (RJ45/DB-9); (1) USB A+B type cable; (1) Warranty Registration Card.

OVERVIEW

The provides automatic voltage regulation for PR500LCDRT1U/PR750LCDRT1U/PR1000LCDRT1U

inconsistent utility power. The features 1030 Joules PR500LCDRT1U/PR750LCDRT1U/PR1000LCDRT1U

of surge protection, and provides battery backup during power outages. The PR500LCDRT1U

/PR750LCDRT1U/PR1000LCDRT1U ensures consistent power to your computer system and its included

software will automatically save your open files and shutdown your computer system during a utility power

loss.

AUTOMATIC VOLTAGE REGULATOR(AVR)

The stabilizes inconsistent utility power. The incoming utility power may be damaging to PR500LCDRT1U/PR750LCDRT1U/PR1000LCDRT1U

important data and hardware, but with Automatic Voltage Regulation, the computer will not experience damaging voltage levels. An Automatic

Voltage Regulator automatically increases low or decreases high voltage to a consistent, computer safe 110/120V. The unit powerful sealed

lead-acid batteries will provide power only if the incoming voltage drops below 80v or increases above 150V.

SYSTEM BLOCK DIAGRAM

HARDWARE INSTALLATION GUIDE

1. Your new UPS may be used immediately upon receipt. However, recharging the battery for at least four hours

is recommended to ensure that the battery's maximum charge capacity is achieved. Charge loss may occur

during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC outlet. The unit will

charge in both the on and off position.

2. If you will use the software, connect the serial interface cable to the serial port on the UPS and the computer. If

you would like to use USB cable, please connect the USB cable on the UPS then connect the USB cable to your

computer.

3. With the UPS unit off and unplugged, connect your computer, monitor, and any externally powered data

storage device (Hard drive, Tape drive, etc.) into the battery power supplied outlets. DO NOT plug a laser

printer, copier, space heater, vacuum, paper shredder or other large electrical device into the UPS. The power

demands of these devices will overload and possibly damage the unit.

4. Plug the UPS into a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch outlet is

protected by a fuse or circuit breaker and does not service equipment with large electrical demands (e.g. air

conditioner, refrigerator, copier, etc.). Avoid using extension cords.

5. Depress the power switch to turn the unit on. The power on indicator light will illuminate. If an overload is

detected, an audible alarm will sound and the unit will emit one long beep. To correct this, turn the UPS off and

unplug at least one piece of equipment from the battery power supplied outlets. Wait 10 seconds. Make sure the

circuit breaker is depressed and then turn the UPS on.

6. To maintain optimal battery charge, leave the UPS plugged into an AC outlet at all times.

7. To store your UPS for an extended period, cover it and store with the battery fully charged. Recharge the

battery every three months to ensure battery life.

8. Professional Rack Mount UPS provides one RJ45 and one USB port to allow connection and communication

between the UPS and computers or equipment. The Primary computers (with PowerPanel® Business Edition

installed) are the computers that you will use to control the UPS and make any changes to the operation of the

UPS. When there is a power failure, the computer which connects to Primary port will start to shutdown after a

user controlled delay. PowerPanel® Business Edition will save and close any open files prior to shutting the

system down.

9. EPO (Emergency Power Off) Port:

The feature is for the application to enable emergency power shutdown. Use the gray cable provided to connect

the UPS to a normally closed or normally open contact switch according to the circuit diagram. EPO function is

provided in the UPS. EPO remote switch which is a Push-Back button installed computer room outside by a

phone line and not connected any other equipment.

FRONT / REAR PANEL DESCRIPTION

1 Power Switch.

Master on/off switch for equipment connected to the UPS.

2. Power On Indicator

Indicates the power is on.

3. LCD Module Display

LCD shows all the UPS information with icons and messages.

4 LCD Display Toggle Button .

The button can be used to toggle between different data displays

on the LCD.

5 Battery Backup and Surge Protected Outlets .

Provides six battery powered, surge protected and AVR outlets

for connected equipment and ensures temporary uninterrupted

operation of connected equipment during a power failure.

Surge Only

Surge only outlet provide surge protection without backup and

AVR function.

Critical /Non-critical

When the UPS is overloaded, the circuit breakers will be tripped

to interrupt the power supply to the uncritical outlets while

continuing to supply the critical outlets. As well, as the battery

capacity depletes under the threshold value, the uncritical outlets

will be shut down and provide energy for critical outlets. The

threshold can be determined and set by users. Non-critical

outlets can also be turned on/off manually through the software

package provided.

6 Input Power Cord .

Heavy-duty, extra long power cord.

7 Input Circuit Breaker .

Resettable circuit breakers provide Input optimal overload

Protection.

Contact your dealer, or email tech@cpsww.com. Refer to replacement battery pack number for , for RB0690X2A PR500LCDRT1U RB0670X4A

PR750LCDRT1U RB0690X4B PR1000LCDRT1U and for .

Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery. Service the battery under the supervision of

personnel knowledgeable of batteries and their precautions. Servicing the battery should only be performed by trained personnel.

Replacement of batteries located in an OPERATOR ACCESS AREA.

CAUTION! When replacing batteries, replace with the same number of the following battery: for HR9-6FR(BB) PR500LCDRT1U and

PR1000LCDRT1U,BP7-6FR(BB) for PR750LCDRT1U.

CAUTION! Risk of Energy Hazard, 6V, maximum 8 Ampere-hour batteries. Before replacing batteries, remove conductive jewelry such as

chains, wrist watches, and rings. High energy through conductive materials could cause severe burns.

CAUTION! Risk of battery explosion, if battery is replaced by an incorrect type. Dispose of used battery according to the instructions.

CAUTION! To reduce the risk of fire, connect only to a circuit provided with 20 amperes maximum branch circuit overcurrent protection in

accordance with the National Electric Code, ANSI/NFPA 70.

CAUTION! Use only the specified type of battery. See your dealer for replacement batteries.

CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries in a fire, as they may explode. Follow all local

ordinances regarding proper disposal of batteries.

CAUTION! Do not open or mutilate the batteries. Release electrolyte is harmful to the skin and eyes and may be toxic.

CAUTION! A battery can present a high risk of short circuit current and electrical shock.

Take the following precautions before replacing the battery:

1. Remove all watches, rings or other metal objects.

2. Only use tools with insulated handles.

3. Do not lay tools or metal parts on top of battery or any terminals.

4. Wear rubber gloves and boots.

5. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove source of ground. CONTACT WITH A GROUNDED

BATTERY CAN RESULT IN ELECTRICAL SHOCK! The likelihood of such shock will be reduced if such grounds are removed during installation

and maintenance (applicable to a UPS and a remote battery supply not having a grounded circuit)

BATTERY REPLACMENT PROCEDURE:

Line mode

Select SW

Press

UPS Status Display Capacity Display Digital Value Display

Load

Cap

Battery

Cap

Input

Voltage

Output

Voltage

Run

Time

% of

Load

% of

Battery

Initial V X -- X V V

1st V X -- X V V

2nd V X -- X V V

3rd V X -- X V V

4th V X -- X V

5th (return) V X -- X V V

(overload) V X -- V -- -- -- -- -- V --

Battery Mode

Select SW

Press

UPS Status Display Capacity Display Digital Value Display

Load

Cap

Battery

Cap

Input

Voltage

Output

Voltage

Run

Time

% of

Load

% of

Battery

Initial X V -- X V V

st X V -- X V V

nd X V -- X V V

rd X V -- X V V

th X V -- X V

5th (return) X V -- X V V

Press>4sec

(sound disable)

X V V X -- -- -- -- -- --

Press>4sec

again(sound enable)

X V X X -- -- -- -- -- -- --

overload X V -- V -- -- -- -- V --

“V” illuminated , “X” Not illuminated, “— “ either

IMPORTANT SAFETY WARNINGS

INSTALLING YOUR UPS SYSTEM

1. Remove two screws and right side

front panel.

2. Disconnect the black and red cable.

LCD STATUS DEFINITION

BATTERY REPLAC

MENT

8 USB port .

USB communication port for management software.

9. Serial Port

Serial port allows connection and communication between the UPS and the

computer.

10. SNMP/HTTP Network slot

Remove the cover panel to install optional RMCARD that allows remote

monitoring and control UPS on networks.

11. Site Wire Fault Indicator

This LED will illuminate to warn the user that a wiring problem exists within

the AC receptacle, such as a bad ground, missing ground or reversed

wiring. If illuminated, disconnect all equipment and contact an electrician to

ensure outlet is properly wired.

12. EPO (Emergency Power Off) port

The interface can be used to connect to switches for emergency power off.

BASIC OPERATION

When you first receive the

unit, plug in the unit to fully

charge the battery.

Unplug the unit and turn Power

Off when first connecting your

computer and peripherals.

3. Remove two retaining

screws and pull

out battery cabin.

*Note:Both USB and Serial can not be used simultaneously.

Install PowerPanel

® Business

Edition software on the primary

computer connected to UPS with

either a serial cable or USB cable.

1 2

Produkt Specifikationer

Mærke:	CyberPower
Kategori:	Uafbrydelig strømforsyning (UPS)
Model:	Smart App Sinewave PR500LCDRT1U
Bredde:	438.15 mm
Dybde:	241.3 mm
Højde:	44.45 mm
Vægt:	8981 g
Produktfarve:	Sort
Skærmtype:	LCD
Pakkevægt:	11475 g
Pakkedybde:	335.28 mm
Pakkebredde:	528.32 mm
Pakkehøjde:	157.48 mm
Batteriteknologi:	Blybatterier (VRLA)
Formfaktor:	Reolbeslag/tårn
Opbevaringstemperatur (T-T):	-15 - 45 °C
Relativ luftfugtighed ved opbevaring (H-H):	0 - 95 %
Antal USB 2.0-porte:	1
Driftstemperatur (T-T):	0 - 40 °C
Udgangseffekt:	400 W
LED-indikatorer:	Ja
Udgangsspænding:	120 V
Kabellængde:	3 m
Antal understøttede batterier:	2
Opladningstid for batteri:	6 t
Bæredygtighedscertifikater:	RoHS,ENERGY STAR
Driftshøjde:	0 - 3000 m
Ikke-drift højde:	0 - 15000 m
Indgangsfrekvens:	57/63 Hz
Lydalarmer:	Ja
Strømbeskyttelsesfunktioner:	Overbelastning
Strøm faktor:	0.8
Antal serielle porte:	1
Strømstik:	NEMA 5-15P
Sikkerhed:	UL1778, CSA C22.2 NO.107.3-05, FCC DOC Class A
AC udgange, antal:	7 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5–15R
Overspænding energivurdering:	1030 J
Indgående driftsspænding (maks.):	150 V
Rackkapacitet:	1U
Output strømkapacitet (VA):	0.5 kVA
Indgående driftsspænding (min.):	80 V
Udgangs driftsspænding (min.):	- V
Udgangs driftsspænding (maks.):	120 V
UPS topologi:	Interaktivt indgangsstik
Bølgeform:	Sine
Typisk backup tid ved halv styrke:	12 min.
Typisk backup tid ved fuld styrke:	3 min.
Hot-swap batteri:	Ja
Automatisk spændingsregulering (AVR):	Ja
Uddgående frekvens:	60 Hz
Nødstrøm Off (EPO):	Ja
EMI/RFI støjfiltrering:	Ja
