Dell XPS One 2710
Owner’s Manual
Computer model: XPS One 2710
Regulatory model: W06C | Regulatory type: W06C001
Contents | 3
Contents
1 Before You Begin . . . . . . . . . . . . . . . . . . . . . . . 11
Turn Off Your Computer and Connected Devices . . 11
Recommended Tools. . . . . . . . . . . . . . . . . . . . . 11
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 12
2 After Working Inside Your Computer. . . . . . . 13
3 Technical Overview . . . . . . . . . . . . . . . . . . . . . 15
Inside View of Your Computer . . . . . . . . . . . . . . . 15
System-Board Components . . . . . . . . . . . . . . . . 16
4 Removing the Back Cover. . . . . . . . . . . . . . . . 19
Procedure 19 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Replacing the Back Cover . . . . . . . . . . . . . . . . 21
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6 Removing the Converter Board . . . . . . . . . . . 23
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Replacing the Converter Board . . . . . . . . . . . 25
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8 Removing the Optical Drive . . . . . . . . . . . . . . 27
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9 Replacing the Optical Drive . . . . . . . . . . . . . . 29
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4 | Contents
10 Removing the System-Board Shield. . . . . . . . 31
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11 Replacing the System-Board Shield . . . . . . . . 33
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 33
12 Removing the Power-Supply Unit . . . . . . . . . 35
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
13 Replacing the Power-Supply Unit. . . . . . . . . . 37
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 37
14 Removing the Memory Module(s). . . . . . . . . . 39
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
15 Replacing the Memory Module(s). . . . . . . . . . 41
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 41
16 Removing the Coin-Cell Battery. . . . . . . . . . . 43
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
17 Replacing the Coin-Cell Battery . . . . . . . . . . . 45
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 45
18 Removing the Stand. . . . . . . . . . . . . . . . . . . . . 47
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
19 Replacing the Stand . . . . . . . . . . . . . . . . . . . . . 49
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Contents | 5
20 Removing the Hard Drive . . . . . . . . . . . . . . . . 51
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
21 Replacing the Hard Drive . . . . . . . . . . . . . . . . 53
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Postrequisites 53 . . . . . . . . . . . . . . . . . . . . . . . . . .
22 Removing the Hard-Drive Cage . . . . . . . . . . . 55
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
23 Replacing the Hard-Drive Cage . . . . . . . . . . . 57
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Postrequisites 57 . . . . . . . . . . . . . . . . . . . . . . . . . .
24 Removing the Power-Supply Fan . . . . . . . . . . 59
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
25 Replacing the Power-Supply Fan . . . . . . . . . . 61
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 61
26 Removing the TV-Tuner Mini-Card . . . . . . . . 63
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
27 Replacing the TV-Tuner Mini-Card . . . . . . . . 65
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 65
28 Removing the Wireless Mini-Card . . . . . . . . . 67
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
29 Replacing the Wireless Mini-Card . . . . . . . . . 69
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6 | Contents
30 Removing the mSATA Mini-Card . . . . . . . . . . 71
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
31 Replacing the mSATA Mini-Card. . . . . . . . . . . 73
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 73
32 Removing the Processor Heat-Sink Fan. . . . . 75
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
33 Replacing the Processor Heat-Sink Fan . . . . . 77
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 77
34 Removing the Processor Heat-Sink . . . . . . . . 79
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
35 Replacing the Processor Heat-Sink . . . . . . . . 81
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 81
36 Removing the Processor . . . . . . . . . . . . . . . . . 83
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
37 Replacing the Processor . . . . . . . . . . . . . . . . . 85
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 86
38 Removing the Trim Cover . . . . . . . . . . . . . . . . 87
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
39 Replacing the Trim Cover . . . . . . . . . . . . . . . . 89
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Contents | 9
60 Removing the Display Panel . . . . . . . . . . . . . 133
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
61 Replacing the Display Panel . . . . . . . . . . . . . 139
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . 140
62 Removing the Camera Module . . . . . . . . . . . 141
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
63 Replacing the Camera Module . . . . . . . . . . . 143
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . 143
64 Removing the Microphone Modules . . . . . . 145
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
65 Replacing the Microphone Modules . . . . . . 147
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . 147
66 Removing the Infrared (IR) Module . . . . . . . 149
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
67 Replacing the Infrared (IR) Module. . . . . . . . 151
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . 151
68 Removing the Antenna Module(s) . . . . . . . . 153
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
69 Replacing the Antenna Module(s). . . . . . . . . 155
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . 155
10 | Contents
70 System Setup . . . . . . . . . . . . . . . . . . . . . . . . . 157
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Entering System Setup . . . . . . . . . . . . . . . . . . . 157
Changing Boot Sequence . . . . . . . . . . . . . . . . . 162
Clearing Forgotten Passwords . . . . . . . . . . . . . . 163
Clearing CMOS Settings . . . . . . . . . . . . . . . . . . 164
71 Flashing the BIOS . . . . . . . . . . . . . . . . . . . . . . 165
Before You Begin | 11
1Before You Begin
Turn Off Your Computer and Connected Devices
CAUTION: To avoid losing data, save and close all open files and exit all open
programs before you turn off your computer.
1Save and close all open files and exit all open programs.
2Click Start and click Shut Down.
Microsoft Windows shuts down and then the computer turns off.
NOTE: If you are using a different operating system, see the documentation
of your operating system for shut-down instructions.
3Disconnect your computer and all attached devices from their electrical outlets.
4Disconnect all telephone cables, network cables, and attached devices from
your computer.
5After the computer is unplugged, press and hold the power button for about
5 seconds to ground the system board.
Recommended Tools
The procedures in this document may require the following tools:
•Phillips screwdriver
•Plastic scribe
12 | Before You Begin
Safety Instructions
Use the following safety guidelines to protect your computer from potential damage and
ensure your personal safety.
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
WARNING: Disconnect all power sources before opening the computer cover or
panels. After you finish working inside the computer, replace all covers, panels,
and screws before connecting to the power source.
CAUTION: To disconnect a network cable, first unplug the cable from your
computer and then unplug the cable from the network device.
CAUTION: To avoid damaging the computer, ensure that the work surface is flat
and clean.
CAUTION: To avoid damaging the components and cards, handle them by their
edges and avoid touching pins and contacts.
CAUTION: Only a certified service technician is authorized to remove the
computer cover and access any of the components inside the computer. See the
safety instructions for complete information about safety precautions, working
inside your computer, and protecting against electrostatic discharge.
CAUTION: Before touching anything inside your computer, ground yourself by
touching an unpainted metal surface, such as the metal at the back of the
computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,
not on the cable itself. Some cables have connectors with locking tabs or
thumb-screws that you must disengage before disconnecting the cable. When
disconnecting cables, keep them evenly aligned to avoid bending any connector
pins. When connecting cables, ensure that the connectors and ports are
correctly oriented and aligned.
After Working Inside Your Computer | 13
2After Working Inside Your Computer
After you complete the replacement procedures, ensure the following:
•Replace all screws and ensure that no stray screws remain inside your computer
•Connect any external devices, cables, cards, and any other part(s) you removed
before working on your computer
•Connect your computer and all attached devices to their electrical outlets
CAUTION: Before turning on your computer, replace all screws and ensure
that no stray screws remain inside the computer. Failure to do so may damage
your computer.
14 | After Working Inside Your Computer
16 | Technical Overview
System-Board Components
1 display-power cable connector 2 camera-cable connector
3 Infrared-module cable connector 4 memory-module connector (DIMM 1)
5 memory-module connector (DIMM 2) 6 wireless mini-card connector
7 mSATA mini-card connector 8 CMOS jumper
9 speaker-cable connector 10 coin-cell battery socket
11 power-button cable connector 12 converter-board cable connector
13 volume/display-settings controls
cable connector
14 I/O-board connector
13
18
15
21
7
17
1 2 3
5
6
8
101112 9
16
14
19
20
22
24
25
26
23
4
Technical Overview | 17
15 password jumper 16 TV-tuner mini-card connector
17 hard-drive data-cable connector 18 optical-drive data-cable connector
19 optical-drive power-cable connector 20 hard-drive power-cable connector
21 main (8-pin) power-cable connector 22 LVDS-cable connector
23 processor socket 24 touchscreen-cable connector
25 processor (4-pin) power-cable connector 26 processor heat-sink fan-cable connector
18 | Technical Overview
Removing the Back Cover | 19
4Removing the Back Cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 11. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 13. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1Place the computer face-down on a clean and flat surface.
2Loosen the captive screws that secure the back cover to the inner frame.
3Slide the back cover toward the top of the computer and lift the back cover off
the computer base.
1 back cover 2 captive screws (2)
3 inner frame
2
1
3
20 | Removing the Back Cover
Replacing the Back Cover | 21
5Replacing the Back Cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 11. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 13. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1Place the back cover over the inner frame and slide the back cover toward the
bottom of the computer.
2Tighten the captive screws that secure the back cover to the inner frame.
22 | Replacing the Back Cover
24 | Removing the Converter Board
Replacing the Converter Board | 25
7Replacing the Converter Board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 11. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 13. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1Align the screw holes on the converter board with the screw holes on the
computer base.
2Replace the screws that secure the converter board to the computer base.
3Connect the converter cable to the converter board.
4Connect the display-backlight cable to the convertor board and secure the tab.
Postrequisites
1Replace the back cover. See "Replacing the Back Cover" on page 21.
26 | Replacing the Converter Board
Removing the Optical Drive | 27
8Removing the Optical Drive
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 11. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 13. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Prerequisites
1Remove the back cover. See "Removing the Back Cover" on page 19.
Procedure
1Remove the screws that secure the optical-drive assembly to the computer base.
2Gently lift the optical-drive assembly from the computer base and disconnect the
power and data-cable connector from the optical-drive assembly.
1 optical-drive assembly 2 screws (4)
3 power and data-cable connector 4 power and data cables
3
2
1
4
28 | Removing the Optical Drive
3Remove the screws that secure the optical-drive brackets to the optical drive.
4Remove the optical-drive brackets from the optical drive.
1 screws (4) 2 optical-drive brackets (2)
3 optical drive
2
1
3
32 | Removing the System-Board Shield
36 | Removing the Power-Supply Unit
7 Lift the power-supply unit off the computer base.
1 power-supply unit 2 screws (4)
3 processor power-supply cable connector 4 main power-supply cable connector
5 power-port cable 6 power-supply indicator cable connector
7 power-supply fan cable connector
1
6
3
5 47
2
Replacing the Power-Supply Unit | 37
13 Replacing the Power-Supply Unit
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 11. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 13. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the power-supply unit with the screw holes on the
computer base and replace the screws that secure the power-supply unit to the
computer base.
2 Connect the power-supply fan cable to the power-supply unit.
3 Connect the power-supply indicator cable to the power-supply unit.
4 Connect the power-port cable to the power-supply unit.
5 Route the processor and main power-supply cables through their routing guides.
6 Connect the processor and main power-supply cables to the system board.
Postrequisites
1 Replace the I/O panel. See "Replacing the I/O Panel" on page 93.
2 Replace the trim cover. See "Replacing the Trim Cover" on page 89.
3 Replace the system-board shield. See "Replacing the System-Board Shield" on
page 33.
4 Replace the stand. See "Replacing the Stand" on page 49.
5 Replace the back cover. See "Replacing the Back Cover" on page 21.
42 | Replacing the Memory Module(s)
