Denver TWE-49ENC Manual

Denver Headset TWE-49ENC

Læs nedenfor 📖 manual på dansk for Denver TWE-49ENC (2 sider) i kategorien Headset. Denne guide var nyttig for 30 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Side 1/2
234
Usage Instructions
1. Pairing the earbuds with your smartphone
Step 1. The earbuds would turn on once the cover of charging case is opened
(no need to take the earbuds out of it first), or long press the touch panels of
both earbuds to turn on the earbuds, with voice prompt of ‘Power on’.
Step 2. RED and WHITE LED would start blinking on both the earbuds.
Both of the earbuds would automatically pair with each other within 5 secs.
Once they are paired with each other, one of the earbuds would show a RED
and WHITE LED blinking alternatively, which means they are ready to pair
with your smartphone.
Step 3. Now switch on Bluetooth in your smartphone to search for nearby
devices and pair with the name ‘ ’ with voice promptDenver TWE-49
‘Connected’ after the pairing succeed. Enter ‘0000’ if prompted for password.
The earbuds would re-connect with smartphone automatically after pairing.
Notes:
The L or R earbud can be used alone to pair with your smartphone, and
thus only mono sound is available.
2. During Music Playback
2.1 Touch the L or R panel ONCE to Play / Pause the track
2.2 Touch the L or R panel TWICE to skip to Next track
2.3 Touch the L or R panel THREE TIMES to skip to Prev. track
2.4 Long touch the L or R panel for 3 seconds to trigger the Siri or Google
Assistant.
3. During Calls
3.1 Touch the L or R panel ONCE to attend the incoming call / end the call.
3.2 Touch the L or R panel for 2 seconds to reject the incoming call.
With total 4 mics for perfect calls (ENC): The earbuds will reduce the wind
and noise interference, so your words always come through loud and clear.
4. Charge the Earbuds & Charging Case
4.1 Put the earbuds back into the charging case and close the cover of it,
the earbuds power off and start charging automatically.
4.2 When the Case is charging, the case indicator blinks, and indicator glows
when the case is fully charged.
5. Product Parameters
Model name: TWE-49ENC
Bluetooth version: 5.3
Bluetooth name: Denver TWE-49 (L / R / Both Earbuds)
Standby time: Approx. 20 hours
Music time: 6.5 hours
Earbuds battery capacity: 3.7V 40 mAh x L / R
Charging case battery capacity: 3.7V 230 mAh
Touch panel
Please notice - All products are subject to change without any notice.
We take reservations for errors and omissions in the manual.
EN EN EN
Safety information
Please read the safety instructions carefully before using the product for the
first time and keep the instructions for future reference.
1. This product is not a toy. Keep it out of reach of children.
2. Warning: This product includes lithium polymer batteries.
3. Keep product out of the reach of children and pets to avoid chewing and
swallowing.
4. Product operating and storage temperature is from 0 degree Celsius to 40
degree Celsius. Under and over this temperature might affect the function.
5. Never open the product. Touching the inside electrics can cause electric
shock. Repairs or service should only be performed by qualified personnel.
6. Do not expose to heat, water, moisture, direct sunlight!
7. Please remove the earphones in case of any leakage or excessive heat
from the product to avoid burns or rash.
8. Please protect your ears against loud volume. Loud volume can damage
your ears.
9. Bluetooth wireless technology operates within a range of about 10 m (30
feet). The maximum communication distance may vary depending on the
presence of obstacles (people, metal objects, walls, etc.) or the electro-
magnetic environment.
10. Microwaves emitting from a Bluetooth device may affect the operation of
electronic medical devices.
11. The unit is not waterproof. If water or foreign objects enter the unit, it may
result in fire or electric shock. If water or a foreign object enters the unit,
stop use immediately.
Delivery Content:
1. Two earbuds (L / R) 2. USB charging cable
3. Charging case 4. Instruction manual
True Wireless Stereo Earbuds
TWE-49ENC
EN
Earbuds
touch panel
Charging case
indicator
denver.eu
www.facebook.com/denver.eu
Instruction Manual
1 432
T arbudsrue Wireless Stereo E
TWE-49ENC
EN
Earbuds
touch panel
Cha rgin g ca se
indic ato r
denver.eu
www.facebook. com/denver .eu
Instruc tion Manual
5
Electric and electronic equipment and included batteries contains materials, components and
substances that can be hazardous to your health and the environment, if the waste materials
(discarded electric and electronic equipment and batteries) are not handled correctly.
Electric and electronic equipment and batteries are marked with the crossed out trash can sym-
bol, as below. This symbol signifies that electric and electronic equipment and batteries should
not be disposed of with other household waste, but should be disposed of separately.
As the end user it is important that you submit your used batteries to the appropriate and desig-
nated facility. In this manner you make sure that the batteries are recycled in accordance with
legislature and will not harm the environment.
All cities have established collection points, where electric and electronic equipment and
batteries can either be submitted free of charge at recycling stations and other collection sites,
or be collected from the households. Additional information is available at the technical depart-
ment of your city.
Hereby, Denver A/S declares that the radio equipment type DENVER TWE-49ENC is in compli-
ance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at
the following internet address: Please enter: and then click the search ICON on toplinedenver.eu
of website. Write model number: TWE-49ENC. Now enter product page, and red directive is
found under downloads/other downloads.
Operating Frequency Range: 2402 MHz - 2480 MHz
Max Output Power: 4 dbm
DENVER A/S
Omega 5A, Soeften
DK-8382 Hinnerup
Denmark
www.facebook.com/denver.eu
Denver A/S reserve the rights for print errors
Denver A/S cannot be held responsible for any technical or typographical errors and reserves the
right to make changes to the product and manuals without prior notice.
If you detect any inaccuracies or omissions, please inform us at the address on the back cover.
ALL RIGHTS RESERVED, COPYRIGHT DENVER A/S
Warning: Lithium battery inside
EN
Version 1 1.
Contact
Nord ics
H dquarterea
Denver A/S
Omega 5A, Soeften
DK- 82 Hi erup 83 nn
Denmark
Phone: +45 86 61 22 00
(Push “1” for su ort) pp
E-Mail
For tec ical quest ns, please write to: hn io
su ort. @denver.eu pp hq
For all other quest ns please write to: io
contact .hq@denver.eu
Benelux
DEN R B ENELUX B.V . VE
Ba outswaar r 13C+D rw de
3 9 HE Woer n 44 de
The therlands Ne
Phone: 0 0-3437 623 90
E-Mail: su ort.nl@den r.eu pp ve
Spain/Portugal
DEN R S P AIN S.A VE
Ronda Augustes y L s L iere, nº 23 nave 16 oui um
Parque cnológico Te
46980 PATE A RN
Valencia (Spain)
Spain
Phone: +34 960 6 88304
Mail: support.es@de nver.e u
Portugal:
Phone: +35 12 24 0 4 55 29
E-Mail: denve r.service@s atfie co m l.
Ger ny ma
Den r Germany GmbH Service ve
Max-Emanuel- r. 4 St
94036 Passau
Phone: +49 851 379 9 4036
E-Mail
su ort. de@d en r.eu pp ve
Fairfix GmbH x
Repair and service
Rud -Diesel-Str. 3 TOR 2olf
5 59 Ni rka e38 ede ss l
(for TV, E-Mobility overboards/Balanc oards, /H eb
Smartphones & Tablets)
Tel +4 9 851 379 9 69 .: 36
E-Ma : den r@ irfixx.de il ve fa
Austria
Lurf P remium Service GmbH
Deutschstrasse 1
1230 Wien
Phone: +43 1 90 3085 4
E-Mail: den r@lurfs ervic e.at ve
If your country is not st above, li ed
please write an email to
su ort@denver.eupp
DENVER A/S
Omega 5A, Soeften
DK- 82 Hi erup 83 nn
Denmark
denver.eu
fac ook.com nver.eueb /de
TWE-49ENC
denver.eu
11/05/2023
