Side 1/36
MOBILE COOLING
CFX5
CFX5 25, CFX5 35, CFX5 45, CFX5 55, CFX5 55IM, CFX5 75DZ, CFX5 95DZ
EN Portable fridge
Operating manual.....................................................3
Dometic CFX5EN
English
1Important notes.............................................................................................................................. 3
2Explanation of symbols....................................................................................................................3
3Safety instructions........................................................................................................................... 4
4Scope of delivery............................................................................................................................6
5Accessories....................................................................................................................................6
6Intended use..................................................................................................................................7
7Technicial description......................................................................................................................8
8Before first use.............................................................................................................................. 10
9Operation.................................................................................................................................... 13
10Cleaning and maintenance.............................................................................................................26
11 Troubleshooting........................................................................................................................... 27
12Warranty......................................................................................................................................29
13Disposal...................................................................................................................................... 29
14Technical data.............................................................................................................................. 29
1 Important notes
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure that you install, use, and maintain
the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and that you understand and agree to abide by the terms and
conditions as set forth herein. You agree to use this product only for the intended purpose and application and in accordance with the instructions, guidelines, and warnings as
set forth in this product manual as well as in accordance with all applicable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may
result in an injury to yourself and others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com.
2 Explanation of symbols
A signal word will identify safety messages and property damage messages, and also will indicate the degree or level
of hazard seriousness.
DANGER!
Indicates a hazardous situation that, if not avoided, will result in death or serious injury.
WARNING!
Indicates a hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION!
Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE Supplementary information for operating the product.
3
ENDometic CFX5
3Safety instructions
DANGER! Electrocution hazard
On boats: If the device is powered by the mains, ensure that the power supply has a residual current
device (RCD), a residual current circuit breaker (RCCB), or a ground fault circuit interrupter (GFCI).
Installation, especially in potentially damp areas, must be in accordance with all applicable installation
regulations.
Do not touch exposed cables with your bare hands. This applies especially when operating the device
from the AC mains.
Before starting the device, ensure that the power supply line and the plug are dry.
WARNING! Explosion hazard
Do not store any explosive substances such as spray cans with a flammable propellant in the cooling
device.
WARNING! Elecotrocution hazard
Do not operate the cooling device if it is visibly damaged.
If the cooling device's power cable is damaged, it must be replaced with a suitable power cable or
assembly available from the manufacturer or its service agent to prevent safety hazard.
This cooling device may only be repaired by qualified personnel. Improper repairs can lead to
considerable hazards.
Plug the device to sockets that ensure proper connection especially when the device needs to be
earthed.
WARNING! Fire hazard
When positioning the cooling device, ensure that the supply cord is not trapped or damaged.
Do not locate multiple portable socket-outlets or portable power supplies at the rear of the device.
In the event of any damage to the refrigerant circuit:
• Keep open flames and potential ignition sources away from the cooling device.
• Ventilate the room well.
•Switch off the cooling device.
For cooling devices with R600a refrigerant: The refrigeration circuit contains a small quantity of an
environmentally friendly but flammable refrigerant. It does not damage the ozone layer and does not
increase the greenhouse effect. Any leaking refrigerant may ignite.
Keep the ventilation openings on the device housing or in installations free of obstructions.
Do not use any mechanical objects or other means to speed up the defrosting process, unless they
have been recommended by the manufacturer for this purpose.
Do not open or damage the refrigerant circuit.
Do not use electrical devices inside the cooling device unless they are recommended by the
manufacturer for that purpose.
WARNING! Health hazard
This cooling device is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the cooling device by a person responsible for their safety.
Children must be supervised to ensure that they do not play with the device.
Cleaning and user maintenance must not be carried out by unsupervised children.
4
Dometic CFX5EN
CAUTION! Electrocution hazard
Before starting the cooling device, ensure that the power supply line and the plug are dry.
Disconnect the cooling device from the power supply
• Before each cleaning and maintenance
•Aer every use
CAUTION! Health hazard
To avoid contamination of food, observe the following instructions:
• Check if the cooling capacity of the cooling device is suitable for storing the food to be cooled.
• Food may only be stored in its original packaging or in suitable containers.
•Opening the cooling device for long periods of time can cause significant increase of the
temperature in the compartments of the device.
• Clean regularly surfaces that can come in contact with food and accessible drainage systems.
If the cooling device is le empty for long periods:
•Switch off the cooling device.
•Defrost the cooling device.
• Clean and dry the cooling device.
• Leave the lid open to prevent mold from developing within the cooling device.
NOTICE! Damage hazard
Check that the voltage specification on the data plate corresponds to that of the energy supply.
Only connect the cooling device as follows:
• With the DC connection cable to a DC power supply in the vehicle
• With the AC connection cable to an AC power supply
Never pull the plug out of the socket by the cable.
If the cooling device is connected to a DC outlet, disconnect the cooling device and other power
consuming devices from the battery before connecting a quick charging device.
If the cooling device is connected to a DC outlet, disconnect the cooling device or switch it off when
turning off the engine. Otherwise the battery may be discharged.
The cooling device is not suitable for transporting caustic materials or materials containing solvents.
The insulation of the cooling device contains flammable cyclopentane and requires special disposal
procedures. Deliver the cooling device at the end of its life-cycle to an appropriate recycling center.
Do not place the cooling device near open flames or other heat sources (heaters, direct sunlight, gas
ovens, etc.).
Risk of overheating! Ensure at all times that there is a minimum of 50 mm ventilation on all sides of
the cooling device. Keep the ventilation area free of any objects that could obstruct the air flow to the
cooling components. Do not use or store the cooling device in closed compartments or areas with
none or minimal air flow.
Do not fill the inner container with ice or fluids.
Never immerse the cooling device in water.
Protect the cooling device and cables against heat and moisture.
The cooling device shall not to be exposed to rain.
5
ENDometic CFX5
4Scope of delivery
Item in on page6Fig.QuantityDescription
1 1 Portable fridge
21 Connection cable for DC connection
31 Connection cable for AC connection
5Accessories
Available as accessory (not included in scope of delivery):
Designation Ref. no.Model
Protective cover
PC25 9620012808 CFX5 25
PC35 9620012806 CFX5 35
PC45 9620012805 CFX5 45
PC55 9620012810CFX5 55
CFX5 55IM
PC75 9620012811 CFX5 75DZ
PC95 9620012807 CFX5 95DZ
Fridge slide
SLD53545U 9620012454CFX5 35
CFX5 45
6
Dometic CFX5EN
Designation Ref. no.Model
SLD55U 9620012455 CFX5 55
CFX5 55IM
SLD75U 9620012456 CFX5 75DZ
SLD95100U 9620012457 CFX5 95DZ
Quick fixing kit
QFK25 9600000166 CFX5 25
CFX5 45
QFK3545 9600029599 CFX5 35
CFX5 45
Dometic Anderson cable ANDC-DC 9620012862 suits all models
Hardwiring Kit HWK-DC 9600024832 suits all models
Mobile Cooling app –suits all models
Note that the app may not be available in your country.
6Intended use
The cooling device is suitable for cooling food. The cooling device is also suitable for use on vehicles.
The cooling device is designed to be operated from a DC on-board power supply of a vehicle or boat, from a DC
auxiliary battery or from an AC power supply.
The cooling device is suitable for camping use.
The cooling device is intended to be used in household and similar applications such as:
•Staff kitchen areas in shops, offices and other working environments
• Farm houses
• Clients in hotels, motels and other residential type environments
• Bed and breakfast type environments
• Catering and similar non-retail applications
This product is only suitable for the intended purpose and application in accordance with these instructions.
This manual provides information that is necessary for proper installation and/or operation of the product. Poor
installation and/or improper operation or maintenance will result in unsatisfactory performance and a possible
failure.
The manufacturer accepts no liability for any injury or damage to the product resulting from:
• Incorrect installation, assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer
•Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product specifications.
7
ENDometic CFX5
7Technicial description
A low maintenance refrigerant circuit with compressor provides the cooling. The generous insulation and the
powerful compressor ensure efficient and fast cooling.
The cooling device is portable.
The cooling device can withstand a short-term inclination of 30°, for example on boats.
7.1Scope of functions
• Power supply with priority circuit for connecting to the AC power supply
•Three-level battery monitor to protect the vehicle battery (switches off automatically at low battery voltage)
•Display with temperature gauge in °C and °F
•Temperature setting: In steps of 1 °C (1 °F)
• Integrated Bluetooth and WiFi function hence controllable using an app
• Foldable carry handles
• USB charger for portable devices such as mobile phones
• Removable wire basket
• Integrated bottle opener
• Ice makerCFX5 55IM only:
7.2Operating and display elements
Lid latches ( on page8)Fig.
Operating panel ( on page9)Fig.
8
Dometic CFX5EN
Item Description Explanation
1Switches the cooling device on when the button is pressed briefly
Switches the cooling device off when the button is pressed for three seconds
Returns to the previous menu
2 Display : AC power supply is connected
: DC power supply is connected
: Bluetooth is activated
: WiFi is activated
: Display is locked
: Compressor is working
: Ice maker is working (CFX5 55IM only)
3Press to navigate upwards or to increase the selected value.
Press to navigate downwards or to decrease the selected value.
Press and simultaneously for 3 s to lock or unlock the display.
4Press to select a menu or to save the selected value.
Connection sockets ( on page10)
Fig.
9
ENDometic CFX5
Item Description
1 Connection socket AC voltage supply
2 AC fuse holder
3 DC fuse cover
4Connection socket DC voltage supply
8 Before first use
NOTE Before starting the cooling device for the first time, clean it inside and outside with a damp cloth
for hygienic reasons (see on page26).
Cleaning and maintenance
10
Dometic CFX5EN
Reversing the lid opening
To reverse the lid opening proceed as shown:
CFX5 55, CFX5 55IM
11
ENDometic CFX5
CFX575DZ, CFX5 95DZ
12
Dometic CFX5EN
Selecting the temperature units
Proceed as shown:
9Operation
9.1Avoiding food waste
To avoid food waste, note the following
Keep temperature fluctuation as low as possible. Only open the cooling device as oen and for as long as
necessary. Store the foodstuff in such a way that the air can still circulate well.
Adjust the temperature to the quantity and type of the foodstuff.
Foodstuff can easily absorb or release odor or taste. Always store foodstuff covered or in closed containers/
bottles.
9.2Saving energy
Choose a well ventilated location which is protected from direct sunlight.
Allow warm food to cool down first before placing it in the cooling device to keep cool.
Do not open the cooling device more oen than necessary.
Do not leave the cooling device open for longer than necessary.
If the cooling device has a basket: For optimal energy consumption, position the basket according to its position
on delivery.
On a regularly basis, ensure the lid seal still fits properly.
Avoid unnecessarily low temperatures.
9.3 Connecting the cooling device
Connecting to a DC source
NOTICE! Damage hazard
For protection of the device the DC cable supplied includes a fuse inside the plug. Do remove thenot
fused DC plug. Only use the DC cable supplied.
13
ENDometic CFX5
Proceed as shown:
Connecting to the Portable Battery Pack PLB40 or the Hardwiring Kit HWK-DC (accessories)
Proceed as shown:
14
Dometic CFX5EN
Connecting to an AC power supply
DANGER! Electrocution hazard
Never handle plugs and switches with wet hands or if you are standing on a wet surface.
If you are operating the cooling device on board a boat from a AC power supply, you must install a
residual current circuit breaker between the AC power supply and the cooling device. Seek advice
from a trained technician.
Proceed as shown:
9.4Using the battery monitor
The cooling device is equipped with a battery monitor that provides a 3-stage battery protection. The battery
protection prevents excessive discharging when the cooling device is connected to a vehicle starter battery or
maximises the use of a supply battery.
If the cooling device is operated when the vehicle ignition is switched off, the cooling device switches off
automatically as soon as the supply voltage falls below a set level. The cooling device will switch back on once the
battery has been recharged to the restart voltage level.
NOTICE! Damage hazard
When switched off by the battery monitor, the battery will no longer be fully charged. Avoid starting
repeatedly or operating current consumers without longer charging phases. Ensure that the battery is
recharged.
NOTE When the cooling device is supplied by the starter battery, select the battery monitor mode
“HIGH”. If the cooling device is connected to a supply battery, the battery monitor mode “LOW” will
suffice.
15
Produkt Specifikationer
| Mærke: | Dometic |
| Kategori: | Køleboks |
| Model: | CFX5 55IM |
Har du brug for hjælp?
Hvis du har brug for hjælp til Dometic CFX5 55IM stil et spørgsmål nedenfor, og andre brugere vil svare dig
Køleboks Dometic Manualer
28 Februar 2025
2 Januar 2025
2 Januar 2025
2 Januar 2025
2 Januar 2025
2 Januar 2025
19 September 2024
12 September 2024
7 September 2024
5 September 2024
Køleboks Manualer
- Køleboks Sencor
- Køleboks Metabo
- Køleboks OK
- Køleboks AEG
- Køleboks Mobicool
- Køleboks Waeco
- Køleboks Makita
- Køleboks Worx
- Køleboks Livoo
- Køleboks Klarstein
- Køleboks Princess
- Køleboks Nedis
- Køleboks Emerio
- Køleboks Vitrifrigo
- Køleboks Hisense
- Køleboks TriStar
- Køleboks Adler
- Køleboks Black And Decker
- Køleboks Campingaz
- Køleboks Camry
- Køleboks Crivit
- Køleboks Ezetil
- Køleboks Mestic
- Køleboks Outwell
- Køleboks Rocktrail
- Køleboks Eurom
- Køleboks Outfit
- Køleboks Clatronic
- Køleboks Quigg
- Køleboks Hikoki
- Køleboks Bomann
- Køleboks Michelin
- Køleboks Comfee
- Køleboks Orbegozo
- Køleboks Exquisit
- Køleboks Keter
- Køleboks G3 Ferrari
- Køleboks Ambiano
- Køleboks Unold
- Køleboks Ardes
- Køleboks ECG
- Køleboks Eldom
- Køleboks EcoFlow
- Køleboks WAGAN
- Køleboks Asaklitt
- Køleboks Orion
- Køleboks Rotel
- Køleboks Gio’Style
- Køleboks Royal Catering
- Køleboks Chefman
- Køleboks Avanti
- Køleboks Kayoba
- Køleboks Campart
- Køleboks T.I.P.
- Køleboks NewAir
- Køleboks Nutrichef
- Køleboks Adventuridge
- Køleboks Quintezz
- Køleboks Nabo
- Køleboks Guzzanti
- Køleboks Igloo
- Køleboks Halfords
- Køleboks Zorn
- Køleboks Seecode
- Køleboks Koolatron
- Køleboks CaterGator
- Køleboks Hofer - Adventuridge
- Køleboks Campart Travel
- Køleboks Isotherm
- Køleboks Engel
- Køleboks EvaKool
- Køleboks MSW
- Køleboks Mycoolman
- Køleboks Brass Monkey
- Køleboks Coors
- Køleboks Corona
- Køleboks Tripcool
Nyeste Køleboks Manualer
9 April 2025
9 April 2025
9 April 2025
4 Januar 2025
4 Januar 2025
29 December 2024
27 December 2024
27 December 2024
27 December 2024
27 December 2024
