DT2000XLP-TUN
OWNER’S MANUAL
FLYING INSECT TRAP
Thank you for purchasing
the DYNATRAP®
Flying Insect Trap!
This product may be covered by one or more U.S. patents
or pending patent applications. See www.DynaTrap.com/patents
IMPORTANT, RETAIN
FOR FUTURE REFERENCE:
READ CAREFULLY
WARNING: When using electric appliances, basic precautions should always be followed, including the following:
– To disconnect, turn all controls to the off (“O”) position, then remove plug from outlet.
– Unplug from outlet when not in use and before servicing or cleaning.
– To reduce the risk of electrical shock, do not put appliance in water or other liquid.
– This appliance is provided with double insulation. Use only identical replacement parts.
CAUTION: To reduce the risk of injury from moving parts, unplug before servicing.
WARNING: Risk of Electric Shock.
See instructions for Servicing of Double-Insulated Appliances.
IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions before using the DynaTrap
® Flyilng Insect Trap and keep for future reference.
1. Always turn unit off and disconnect plug before servicing or cleaning.
2. Do not position the unit near heat, gas, oil or other flammable materials.
3. Mount out of reach from children.
4. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or
damaged, or if it has been dropped into water.
5. The electrical adapter provided with this product is equipped with a 2-conductor cord and a 2-prong.
If the plug does not fully fit in the outlet, contact a qualified electrician. To reduce the risk of electrical shock,
only plug into a properly installed outlet. Do not attempt to defeat this safety feature.
6. Do not insert fingers or any foreign objects into the unit while it is connected to an electrical outlet.
7. Collected insects within the unit may contribute to fire, so clean insects from the unit frequently.
8. Do not clean this product with water spray. Do not place where it can fall into water, or near flammable materials.
9. Do not touch fan while in motion.
10. Do not abuse cord—never carry or hang unit by cord or yank it to disconnect from receptacle.
Keep cord away from sharp edges.
11. If using outdoors, use only extension cords with a tag stating “Suitable for Use with Outdoor Appliances.”
12. Use only extension cords that have plug and receptacles that match the product plug.
Replace or repair damaged cords.
13. Only use attachments recommended or sold by the manufacturer
14. SERVICING OF DOUBLE-INSULATED APPLIANCES - In a double-insulated appliance, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding
be added to the appliance. Servicing of a double-insulated appliance requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts for a double-insulated appliance must be
identical to those parts in the appliance. The symbol must be identical to those parts in the appliance. A double-insulated
appliance is marked with the words “DOUBLE INSULATION”, “DOUBLE-INSULATED” or the symbol.
Problem: Correction:Possible cause:
Bulbs do not illuminate
and fan does not spin.
No electrical power. 1. Check plug, receptacle, and fuse or circuit breaker.
Bulbs illuminate, but fan
does not spin.
Shorted fan. 1. UNPLUG UNIT: Examine fan to see that it is free from
foreign material, dirt or build-up of dead insects.
2. Clean unit as in “CLEANING” section.
Fan spins, but bulbs do
not illuminate.
1. Bulbs not seated
properly.
2. Burnt out bulbs
1. Check all sockets for proper bulb seating and alignment.
2. Replace bulbs if needed following instructions under
“Replacing Bulb.”
TROUBLESHOOTING
INSTALLATION & OPERATING INSTRUCTIONS
1. Unpack unit. Save carton for off-season storage (if needed). Remove cardboard insert from the retaining cage.
2. Place the air damper assembly in the retaining cage with the crossbar
facing up. Align the six damper notches with the matching notches on the
retaining cage.
3. Place the trap on the retaining cage and twist clockwise to the lock
position.
4. If hanging the unit, place it approximately 3 - 6 feet above floor or
ground for optimal catch-rate and easy access for cleaning. Unit can also
be placed on the floor or ground.
5. Turn power switch to “ON” position. The switch is located under the upper
housing near the light bulbs.
6. For best catch results leave unit on at all times, except when cleaning
or servicing.
7. Catch rate activity will be higher at night. For best catch results, place unit
away from other competing light sources.
8. It is recommended to place the unit 20 - 40 feet away from where people
will be sitting.
9. This unit is all-weather resistant – designed for outdoor use including
rainy conditions. Intended for household and commercial, indoor
and outdoor use.
10. To reduce the risk of electric shock, this appliance has a polarized plug
(one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the
plug in any way.
CLEANING
Frequent cleaning will prolong the life of the unit, ensure fire prevention and provide for more efficient operation.
1. Remove the retaining cage by holding the trap securely and twisting counter clockwise.
2. Grasp the edge of the crossbar and pull up firmly to remove damper assembly.
3. Dispose of contents and clean any build up from the inside of the retaining cage with a small brush.
4. Attach the air damper assembly to retaining cage and reattach to trap with a clockwise twist to the lock position.
IMPORTANT: DO NOT press or push against the screen windows while cleaning or assembling.
REPLACING BULBS Replace with DynaTrap® bulbs #32050 (or equivalent T5 Type - 120V/6W UVA Bulbs)
The light bulb life expectancy is approximately 3,000 hours (or about 4 months), and should be replaced regularly to ensure
optimal UV effectiveness. Even though the bulb’s light may be visible to you, it’s ability to attract insects diminishes over time.
1. Turn power switch to “OFF” position. UNPLUG UNIT (1), and allow bulbs to cool before replacing.
2. Remove screw from clear plastic light socket covers (2).
3. Remove both clear plastic light socket covers.
4. Carefully turn bulb counterclockwise and then pull bulb straight out (3).
5. Locate and insert new bulbs into sockets, carefully turn clockwise, and make sure the prongs of the bulb are seated properly.
6. Replace clear plastic light socket covers and secure with screw.
HOW THE DYNATRAP®
INSECT TRAP WORKS
Flying insects are attracted to the unit by the UV light
and CO2 that is generated by the photo-catalysis
between the UV lamps and the special TiO2 coating.
The fan then pulls the insects into the screened
base, trapping them until they dehydrate and die.
The base can be removed, allowing the contents to
be periodically emptied into the trash. Monitor the
insects trapped in the retaining cage, through the
see-through screen, and empty when compartment
becomes full.
31 2
A000-402.2018.10
ON/OFF
SWITCH
POWERFUL
YET QUIET FAN
LOOP FOR
HANGING
(OPTIONAL)
AUTOMATIC
DAMPER
CLOSES WHEN
TURNED OFF
PREVENTING
LIVE INSECTS
FROM ESCAPING
TIO2 COATED
SURFACE
RETAINING
CAGE
2 UV LAMPS
LIMITED WARRANTY
DYNAMIC guarantees to the original purchaser that this product is free from defective materials and workmanship. This
warranty is limited to remedy any defective part for a period of one year from date of original date of purchase. Retain
your original receipt as proof of purchase. This warranty does not apply to the light bulb, nor to, in our judgment, misuse
or abuse. If this unit has been altered, no warranty is in force. This warranty does not apply if this unit is purchased outside
the United States, Canada and Mexico. In no case shall DYNAMIC be liable for any accidental, punitive, consequential, or any
other damages of any kind for breach of this or any other warranty, expressed or implied, whatsoever. Some states do not
allow limitation on how long an implied warranty lasts, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
REPLACEMENT PARTS
32050 2, 6-Watt UV Replacement Bulbs
To see all replacement and accessory parts available for your DynaTrap, including UV-bulbs, fans,
retaining cages, and more, visit www.DynaTrap.com.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD AND COMMERCIAL, INDOOR AND OUTDOOR USE
ALIGNING
NOTCHES (6)
CROSSBAR
AIR DAMPER ASSEMBLY
RETAINING CAGE
This device complies with Performance Standards
for Light-Emitting Products, 21 DFR, Part 1040,
Chapter 1, Subchapter J, Radiological health.
Dynamic Solutions Worldwide, LLC
12247 W. Fairview Ave.
Milwaukee, WI 53226
1-877-403-TRAP (8727)
customercare@dsw-llc.com
www.DynaTrap.com
