1. INTRODUCTION

For use with Ei168RC RadioLINK Bases (fitted with

RC Series Alarms) and RadioLINK Smoke and

Carbon Monoxide (CO)Alarms.

The Remote Control Switch allows you, without the

use of ladders or chairs, to:

• Test the Smoke/Heat/CO Alarms.

• Locate the Smoke/Heat/CO Alarm sensing fire/CO

by silencing all the other alarms (for 10 minutes). This

is of great benefit, particularly at night as the source of

the fire/CO can be quickly traced audibly. This is ideal

for larger systems as people nearest the fire/CO can

be quickly evacuated and/or control a fire if it is small.

• Memory Locate: The Locate button also identifies

which alarms have previously sensed fire/CO. This is

very useful when troubleshooting systems of multiple

smoke, heat and/or CO alarms (see section 4 - Alarm

Memory Function).

• Hush Nuisance Alarms: These can be silenced by

pressing and releasing the Hush switch.

• Fire & CO Indicators: In a Fire only System the Fire

indicator on the will flash to indicate a fire hasEi411H

been detected.

If there is a fire, immediately evacuate the premises

and telephone the fire brigade from outside. Do not

silence the alarm unless you are sure there is no

fire.

In a mixed RadioLINK Fire & CO System the Fire or

CO indicator on the will flash to indicate thatEi412

Fire (smoke/heat) or Carbon Monoxide has been

detected.

If there is a fire, immediately evacuate the premises

and telephone the fire brigade from outside. Do not

silence the alarm unless you are sure there is no

fire.

If CO has been detected, open doors & windows

while evacuating the premises. Telephone the

appropriate authorities to report a Carbon Monoxide

alarm has been activated.

2. INSTALLATION

1. Position the Remote Control Switch 1.2 metres

(approx) up on a wall in a suitable position on an exit

route. Avoid locating near metal objects.

2. Securely attach the mounting box of the unit to the

wall using the fixing screws supplied. Note: The

Ei411H / 412 should not be recessed mounted - only

the surface mounting box supplied should be used.

3. Carefully slide the battery switch into the ‘ON’

position (see Figure 1). On the Ei411H two red light

indicators will flash in sequence to indicate power-up,

on the Ei412 three red light indicators with flash in

sequence.

4. It is essential that you House Code your Remote

Control Switch with your Smoke/Heat/CO Alarms and

any RadioLINK accessories to prevent false alarms and

other interference with nearby systems (see below).

To House Code your Remote Control Switch:

a) Place all the RadioLINK Smoke/Heat/CO alarms

and accessories into House Code mode within 15

minutes, as described in their instruction leaflets.

b) Also, within the same 15 minutes, place the Remote

Control Switch into House Code mode by pressing and

holding the House Code button until the RF indicator

red light turns on. Immediately release the button and

the RF indicator red light will now flash continuously

(for 15 minutes) to show it is in House Code mode.

c) The Remote Control Switch will now send a radio

message every 5 seconds to indicate it is in House

Code mode. All Smoke/Heat/CO Alarms and

accessories within range that are also in House Code

mode themselves, will memorise the House Code of

the Remote Control Switch.

d) Check that the number of amber light flashes (for

RadioLINK Bases) or blue light flashes (for

RadioLINK Smoke Alarms) or RF indicator red light

flashes (for CO Alarm & Remote Control Switch)

correspond with the number of units in the system

(e.g. smoke alarms plus the Remote Control Switch).

For example, with 3 RadioLINK bases and one

Remote Control Switch you should see 4 amber light

flashes from each base and 4 RF indicator red light

flashes on the Remote Control Switch.

e) The Remote Control Switch and Smoke/CO alarms

will exit the House Code mode by itself after

approximately 15 minutes without further user

intervention.

(However, this could result in problems with nearby

systems, if their units are being House Coded at the

same time. If this is the case exit House Code mode

by pressing and holding the House Code button until

the RF indicator red light comes on continuously (i.e.

use the same method as to enter House Code mode).

Release the button and the RF indicator red light will

go out, indicating that the Remote Control Switch and

Smoke/CO alarms have exited House Code mode.

f) To remove other RadioLINK accessories from

House Code mode follow instructions as described in

their installation leaflets.

g) Fix the Remote Control Switch assembly to the

mounting box using the screws provided.

h) Using the Test switch, verify that the Remote

Control Switch activates all the alarms in the system

(If some or all of the alarms have not been activated,

then the House Coding procedure should be

repeated. If there are still some problems, see the

section 5 on “Troubleshooting”).

Clearing the House Codes:

It may sometimes be necessary to clear the House

Codes (e.g. if you wanted to use the Remote Control

Switch with different alarms).

To clear the House Codes:

• Unscrew the Remote Control Switch assembly from

the mounting box.

• Press and hold the House Code button for over 6

seconds until the RF indicator red light turns on

continuously and then flashes slowly. Immediately

release the button and the RF indicator red light will

go out.

• Re-attach to the mounting box.

Note clearing the House Codes will now reset the

Remote Control Switch to the original factory setting.

It will now only communicate with un-coded alarms

(see base/smoke alarm instruction leaflet for

information on how to un-code the bases/smoke

alarms).

3. USING REMOTE CONTROL

Ei411H Remote Control Switch Functionality

Indicators

1.When a RadioLINK smoke or heat alarm is

activated, the Fire light on the Remote Control switch

will flash rapidly for 2 minutes. After this period the

rate will change to one flash every 30 seconds and

will continue for 24 hours before turning off.

Ei412 Remote Control Switch Functionality

Indicators

1.When a RadioLINK smoke or heat alarm is

activated, the Fire light on the Remote Control switch

will flash rapidly for 2 minutes. After this period the

rate will change to one flash every 30 seconds and

will continue for 24 hours before turning off.

2.When a RadioLINK Carbon Monoxide alarm is

activated, the Carbon Monoxide light on the Remote

Control Switch will flash rapidly for 2 minutes. After

this period the rate will change to one flash every 30

seconds and will continue for 24 hours before turning

off.

After 24 hours a previously sensed Fire/CO Alarm

can be indentified by using the alarm memory

function (see section 4).

What to do when the Alarms sounds

1.If there is a fire, immediately evacuate the premises

and telephone the fire brigade from outside.

If the Carbon Monoxide light is flashing, open doors &

windows while evacuating the premises. Telephone

the appropriate authorities to report a Carbon

Monoxide alarm has been activated.

2. When a Smoke/Heat alarm sounds and the cause

is not obvious, immediately press the ‘Locate’ switch.

This will silence all the alarms except those sensing

the fire.

3. Locate the alarm(s) sensing fire audibly. Be

careful, check doors are not warm and that there is no

sign of smoke before you open them (See escape

plan in Smoke Alarm instructions for further details).

4. If you are fully satisfied that there is no fire but the

Smoke/Heat alarm is still continuing to alarm then

press the ‘Hush’ switch.

The Remote Control Switch allows you to Locate,

Hush or Test units as follows:-

• Locate Switch – primarily used to identify the

Smoke/Heat/CO Alarm sensing fire/CO.

When all the alarms are sounding due to a fire/CO (or

nuisance alarm):

Press and release the spring loaded Locate switch.

The RF indicator red light will come on continuously

for 3 seconds to indicate that an RF signal is being

transmitted.

This will silence all the alarms except those sensing

fire/CO.

This is a very useful feature. For example, consider

twelve alarms sounding simultaneously, then the unit

sensing the fire/CO can be identified audibly and the

premises evacuated or the problem quickly resolved.

• Hush Switch - used to silence nuisance alarms.

This should only be pressed after the Locate switch

has been used to identify the Smoke/Heat/CO alarm

that triggered the system, and it is determined that no

fire or CO is present.

Models:

Ei411H

Ei412

Contains vital information on the product’s operation and

installation. Read and retain carefully. If you are just

installing this product the manual MUST be given to

the householder.

The Ei411H is a RadioLINK Remote Control Switch for

use with Fire Alarm Systems only. A Fire Alarm may

contain a combination of Smoke, Heat & Multi-Sensor

Alarms.

The Ei412 is a RadioLINK Remote Control Switch for

use with mixed Fire & Carbon Monoxide Alarm

Systems.

WARNING:

The Ei411H is for use with the following

models of RadioLINK Base / Alarm:

Ei168RC

Ei405

Ei405TY

Ei605MRF

Ei605MTYRF

Base fitted with Ei161RC Smoke Alarm

Base fitted with Ei164RC Heat Alarm

Base fitted with Ei166RC Smoke Alarm

RadioLINK Smoke Alarm

Module fitted with Ei605 Series Smoke Alarm

Module fitted with Ei605TY Series Smoke Alarm

The Ei412 works with all of the above plus

the Ei262 Carbon Monoxide Alarm

Ei262 CO Alarm with Integrated RadioLINK

Do not use any other models of RadioLINK

Base / Alarm

1 2 3 45

House Code Button

ON/OFF Battery Switch

Figure 1

Remote Control

For use with Ei168RC RadioLINK Bases (with RC Series

Alarms), RadioLINK Smoke and Carbon Monoxide (CO) Alarms

RF Light Indicator

located here

A16111-R4-EI411&412-UC-ENG 3/3/10 2:39 PM Page 1

Produkt Specifikationer

Mærke:	Ei Electronics
Kategori:	Skifte
Model:	Ei411H
Bredde:	88 mm
Dybde:	42 mm
Højde:	88 mm
Vægt:	212 g
Produktfarve:	Hvid
Batteriteknologi:	Lithium
Relativ luftfugtighed ved drift (H-H):	15 - 95 %
Driftstemperatur (T-T):	0 - 40 °C
Indikator for batteriniveau:	Ja
Forbindelsesteknologi:	Trådløs
Strømkilde type:	Batteri
Antal knapper:	3
RF-transmissionsfrekvens:	868 Mhz
RF-transmissionsområde:	150 m
Indbygget batteri:	Ja
