Equip Universal surface mounting box Manual
Equip
Flat panel steun
Universal surface mounting box
Læs nedenfor 📖 manual på dansk for Equip Universal surface mounting box (1 sider) i kategorien Flat panel steun. Denne guide var nyttig for 4 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/1
www.equip-info.net
1. Take away the bottom cover and loosen up
the two screws inside.
3. Follow the color-coding to position
T568A or T568B wiring.
T568A T568B
Pin 1 Pin 1White/Green White/Orange
Pin 2 Pin 2Green Orange
Pin 3 Pin 3White/Orange White/Green
Pin 4 Pin 4Blue Blue
Pin 5 Pin 5White/Blue White/Blue
Pin 6 Pin 6Orange Green
Pin 7 Pin 7White/Brown White/Brown
Pin 8 Pin 8Brown Brown
5. Fasten the screws to secure both
the braid and the cable jacket.
2. Strip approximately 30mm of the cable jacket,
and separate to 4 pair each.
4. Use the KRONE impact tool to punch down
and connect the wires.
6. Then assemble the bottom cover with the screw.
Then complete the installation.
Cat.5e / 6 wall outlet
30mm
