THANK YOU FOR PURCHASING ERICA SYNTHS
BLACK SERIES MODULE!
Erica Black Series include high-end, unique functionality and
superior quality modules. Only the best, highest quality compo-
nents are used, all inputs and outputs are protected against
undesired overvoltage. When designing Black Series, we put
design and usability superior. Big knobs are assigned to key
functions of the module, which makes Black Series ideal for live
performances. Enjoy!
Erica Synths Black Double Bass is unique module that combines
two transistor suboscillators (-1 and -2 octaves) and lowpass
filter. It will turn any VCO or beeper into massive bass sound with
CV control over octave mix and cuto frequency. Sync input that
resets suboscillators on incoming pulse, provides even more
versatility in sound design. The module can be also provide
aggressive distortion, when used with percussive sounds like
bassdrums.
FEATURES:
Two transistor based -1 and -2 octaves suboscillators
Manually and CV controlled fade between suboscillators
Manually and CV controlled lowpass VCF
Suboscillator synchronisation input
Individual outputs of suboscillators
Limiter on the output to avoid clipping
Signal Thru output
CV level attenuators
SPECS:
Audio input level …………..………-5V - +5V
CV level (full sweep)…….……....-5V - +5V
Power consumption…..............+50mA, -39mA
Module width……………….....……10HP
Module depth………………..……..35mm
CLR CVSBMIX CVSYNC IN OUT
-1 OUTTHRUIN -2 OUT
BLACK DOUBLE BASS
SUBMIX CV LVL
SUBMIX
COLO UR CV LVL
DRY/WET
COLO UR
-1 OCT-2 OCT
Use this knob to control the mix
between the suboscillators.
CCW setting is -2 octaves
suboscillator, CW setting is -1
octave suboscillator. SUBMIX
CV is added to the SUBMIX
knob setting
This is lowpass VCF cuto
manual control knob. Non
resonant lowpass VCF is
in series with
suboscillators, so you can
control the harmonic
content of the output
signal. Full CW setting
leaves the VCF fully open.
CLR CV is added to the
COLOUR knob setting
This is Colour CV
(VCF cuto frequency)
attenuator
These are dedicated -1
and -2 octave
suboscillator outputs. Try
to run those through two
VCAs controlled by EGs
that receive gates from
two sequencers or two
channels of the same
sequencer. This way
you’ll get two basslines
that are perfectly in tune,
but have dierent
rhythmic patterns
This is the main output of
the module – the sum of
suboscillators and the
VCF
This is the VCF cutoCV
input
This is Submix CV attenuator
This is manual Dry/Wet
control, where Dry is the
original audio signal, Wet is
the sum of suboscillators
and lowpass VCF.
This is audio thru output.
Basically, it copies the input
signal and buers it.
This is audio input of the
module. Experiment with
dierent waveforms and
percussive sounds and see,
how the module reacts!
This is suboscillator
synchronisation input. The rising
edge of the incoming signal will
reset the suboscillator cycle.
Experiment with the frequency
of a sync oscillator and find the
sweet spots!
This is suboscillator mix CV
input
DOUBLE BASS
