UNITED KINGDOM • CUSTOMER SERVICE

tel 020 8247 9300 customerservice@clasohlson.co.uk www.clasohlson.co.uk 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZe-mail internet postal

Ver. 20181212

Digital time switch

Art.no 18-2029 Modell EMT757-UK

18-2175 EMT757-UK

36-2901 EMT757

36-4600 EMT757

36-5035 EMT757x2

Please read theentire instruction manual before using theproduct and save it for

future reference. We apologise for any text or photographic errors and any changes

in technical data. If you have any questions concerning technical problems please

contact our Customer Service Department.

Product Description

Digital time switch with 20 on/off activations per day.

• CD

• Random function (random on and off activation)

• LCD-display

• Safety shuttered socket

Buttons and Functions

Set time

Note: Thetime switch must be in normal mode (time) before setting of time and week

day. Push to return to normal mode.CLOCK

1. Push and hold until theweek indicator blinks.SET

2. Push ▲ ▼+ to change week day forward, or − to change week day backwards.

Theselected week day is shown in thedisplay.

3. Push to conﬁrm. Thehour setting blinks in thedisplay.SET

4. Use ▲ ▼+ and − to set hours.

5. Push to conﬁrm. Theminute setting blinks in thedisplay.SET

6. Use ▲ ▼+ and − to set minutes.

7. Push to return to normal mode.CLOCK

Summer/Winter time

Press and at thesame time to switch between summer and winter time. CLOCK ▼−

“S” is shown on thedisplay to indicate summer time.

Installation of programme

1. Push to set thetime switch in AUTO mode.ON/OFF

2. When thedisplay is in normal mode, press ▲+ to return to settings mode. “1ON”

is shown on thedisplay’s bottom left corner. “1” indicates program number 1 (of 20).

“ ” “ ”ON indicates thetime for activation. OFF indicates thetime for off activation.

3. Use ▲ ▼+ and − to change theprogram number according to thefollowing sequence:

1ON → → → → 1OFF …… 20ON 20OFF (countdown)d ON/OFF

4. After selected program, push to set week day for on and off activation.SET

5. Use ▲+ to change week days. Thedays will be changed in thefollowing

combinations:

MO TU WE TH FR SA SU; MO → → → → → → TU WE TH FR SA SU:

MO WE FR; TU TH SA; SA SU; MO TU WE; TH FR SA;

MO TU WE TH FR; MO TU WE TH FR SA

6. Push to conﬁrm. Thehour setting blinks in thedisplay.SET

7. Use ▲ ▼+ and − to set hours.

8. Push to conﬁrm. Theminute setting blinks in thedisplay.SET

9. Use ▲ ▼+ and − to set minutes.

10. Press to return to normal mode.CLOCK

Countdown function

Set thecountdown time

Thecountdown interval is from 1 second to 99 hours, 59 minutes and 59 seconds.

1. When thedisplay is in normal mode, press ▼− to return to thecountdown function.

Thedisplay shows “d ON” or “d OFF”. indicates that thecountdown function is d

activated.

2. Push until “ON” or “OFF” blinks on thedisplay.SET

3. Use ▲ ▼+ and − ON OFF ON to switch between or . set theduration for how

long thedevice/output will be ON (thedevice/output will be turned off after

thecountdown). set theduration for how long thedevice/output will be OFF OFF

(thedevice/output will be turned on after thecountdown).

4. Push to conﬁrm. Thetimer display blinks.SET

5. Use ▲ ▼+ and − to set hours.

6. Push to conﬁrm. Theminutes display blinks.SET

7. Use ▲ ▼+ and − to set minutes.

8. Push to conﬁrm. Theseconds blink.SET

9. Use ▲ ▼+ and − to set seconds.

10. Push to conﬁrm and then push to return to normal mode.SET CLOCK

Start thecountdown

1. Set thecountdown time according to theinstructions above.

2. Connect thedevice to thetime switch and connect thetime switch to awall socket.

3. Push to set thetime switch in AUTO mode.ON/OFF

4. Push to start thecountdown function. “CD” will blink to conﬁrm that CD

CD-mode is activated.

5. When thecountdown has come to 00:00:00, thee.g. lamp turns on or off depending

on what has been programmed.

Random on and off activation

1. Connect thedevice to thetime switch and connect thetime switch to awall socket.

2. Push to set thetime switch in AUTO mode.ON/OFF

3. Push RND. Anicon with theletter “R” will appear to conﬁrm that theRND-mode is

activated. Theoutput is now off for 26 to 42 minutes before it randomly turns on.

Theoutput then stays on for 10 to 26 minutes before it turns off again.

Turning thelamp on and off manually

Push to manually activate or deactivate thetime switch.ON/OFF

ON Thevoltage turns on regardless of thesetting and theconnected device

can be used.

AUTO Thetime switch operates according to pre-set program.

OFF Thevoltage turns off and theconnected device cannot be used.

Safety

• Thetime switch is intended for use indoors and may not be used outdoors!

• Devices connected to thetime switch must be constructed for thesame voltage

according to thespeciﬁcations below.

• Thebuilt-in batteries are fully charged after approx. 2 hours use.

• Make sure that theelectrical socket that theproduct is plugged into is easily

accessible in case it and theconnected product need to be quickly disconnected

from themains electricity.

• Do not connect products of this type to each other.

• Do not cover theproduct.

Troubleshooting

Display is blank: Plug thetimer switch into awall socket and press [ RESET ] to reset it.

Responsible disposal

This symbol indicates that this product should not be disposed of with

general householdwaste. Thisapplies throughout theentire EU. Inorder

to prevent any harm to theenvironment or health hazards caused by

incorrect waste disposal, theproduct must be handed in for recycling

so that thematerial can be disposed of in aresponsible manner.

Whenrecycling your product, take it to your local collection facility or

contact theplace of purchase. Theywill ensure that theproduct is

disposed of in anenvironmentally sound manner.

Specifications

Mains Supply 230 V AC, 50 Hz

Max load 1800 W

Operating Temperature 0–55 °C

Class IP20

Minimum time interval 1 minute

1. LCD-display

2. – Indication on thedisplay S

for summer time.

3. CLOCK – Press to return to normal mode (time).

4. SET – Sets time and week day and also conﬁrms settings.

5. ▼− – Adjusts time, week, and program group.

6. ▲+ – Adjusts time, week, and program group.

7. – Changes function on thetime switch. ON, AUTO or OFF.ON/OFF

8. RND – Randomly activates on and off when thetime switch is in AUTO mode.

9. CD – Starts or stops thecountdown function when thetime switch is in AUTO mode.

10. – Press one time to reset thetime switch to factory settings.RESET

11. Plug socket

Use

Time display

Theclock is showing 12 or 24 hour display. To change between 12 and 24 hour

display, press and hold until thedisplay changes thetime format.CLOCK

• At 12 hour display “AM” or “PM” is shown on thedisplay.

• At 24 hour display neither AM nor PM is shown on thedisplay.
