BLADELESS HEPA &
CARBON FILTER
TOWER FAN
GBF40WH
無葉HEPA及活性炭過濾
直立風扇
Please read this instruction manual carefully
before use and keep it for future reference
請於使用前仔細閱讀本說明書並加以保存
220-240V~50-60Hz
1
MAIN PARTS
Remove
control
Power
on/off
Timer
Sleeping
mode
Oscillation
Natural
wind mode
Speed-
Soft wind
Natural wind
Timer icon
Oscillation
angle
Oscillation
Timer
Speed
Mode
Power
Oscillation
Timer
Speed
Mode
Power
Filter
and cover
Air outlet
Control panel
Bottom
turntable
Speed+
Adapter input plug
output
plug
3
PRODUCT SIZE
󾙓󾙒󾙔󾙖
󾙔󾙘󾙙 󾙓󾙛󾙗
After taking the bladeless fan out of the package, take out the protective
piece of the adapter, place the fan on a stable ground or desktop, insert
the output plug of the power adapter (DC24V 1.5A) into the power input
interface at the bottom of the fan head, and then The adapter input plug
plugs into a household electrical outlet.
The fan enters the standby state, and the display lights up " - - ". Power
on the fan by touching the power button on the control panel, or using
the remote control to for operation.
USING GUIDE
The power interface of the fan is located on the side of the bottom turntable;
the fan is worked with 8 speeds when power on by default .
4
OPERATION GUIDE
Pay attention!
Do not forcibly turn the fan's oscillation angle or external force
to hinder its normal oscillation process, otherwise it may
damage the mechanical structure of the fan and affect its use.
1 POWER ON/OFF、
After plug on press the Power button“ ”, the machine will enter the normal
work model. Press the Power button “ ” again, the machine will enter the
standby state.
2 ADJUST THE WIND SPEED、
After power on, press the Speed button “ ” or press the “ +/- ”of the remote
control to adjust the speed, the display will show corresponding speed. When
it is in the highest speed “12 ”, if you touch the speed button “ ” again, the
speed will continue to cycle from speed 1. The speed will not cycle during
remote control operation.
3 MODE SETTING、
Press the Mode “ ” on machine or remote control to set the wind mode, wind
model will change according to Normal wind-Nature wind-Sleeping wind.
Nature wind mode: This icon of Nature wind “ ” will light up, the display screen
will show “ ” , the wind speed simulates the natural wind, and the change of
large and small winds.
Sleeping wind mode: the icon of the sleeping mode “ ” will light up, the display
screen will show “ ” , the wind speed will be changed to suitable for sleep.
4 TIMER SETTING、
Press the Timer button “ ” for timer adjustment during the machine is working,
the “ h ” will flash and display the timer time. The digit will will flash 5S means the
setting the timer successfully and the timer will start running. The timer setting
can be up to 12 hours. When “ 00 ” hours are displayed, the timer function is
turned off.
5 OSCILLATION SETTING、
Press the Oscillation button “ ” start the oscillation funtion, the max scillation
angle can be 120° Each time touching the Oscillation button “ ” , the oscillation .
angle will be 60°, 90°, and 120° in turn, until the oscillation function is turned off.
5
MAINTENANCE
Pay attention!
Before cleaning and maintenance, the power supply must be
disconnected, the whole machine should not be immersed in
water, and the machine should not be sprayed.
It is recommended to clean and maintain the machine every 3 to 4 weeks
to ensure that the fan works more efficiently and the air outlet is cleaner.
Remove the filter of the machine, use a vacuum cleaner or a dry brush for
cleaning, use a low-humidity dish towel to wipe the dust on the place where
the filter is placed, put the filter back and cover it after drying.
In order to ensure the purification effect, the filter can be replaced regularly
depending on the actual situation, and the customer service staff can be
consulted for the purchase of special accessories.
When cleaning the appearance of the product, please wipe the product
with a soft and clean cloth. To remove stubborn stains, be sure to use a
mild and neutral detergent. After cleaning, wait for the surface to dry before
turning it on.
6 DISPLAY LIGHT STATUS、
In normal wind and natural wind modes, if there is no operation for 60 seconds,
the screen brightness will be reduced by half, and if there is no operation for 10
minutes, the screen will turn off. In sleeping wind mode, if there is no operation
for 30s, the screen brightness will be reduced by half, and if there is no operation
for 5 minutes, the screen will automatically turn off.
Pull the buckle
upward to open the
filter screen cover
Activated
carbon filter
HEPA
filter
6
