BIOS Setup Manual

BIOS Setup

BIOS (Basic Input and Output System) is a UEFI interface that allows you to setup and configure your system for optimum use.

Using your mouse and keyboard, users can change BIOS settings, monitor CPU temperature, select the boot device priority and

view system information such as the CPU name, DRAM capacity, and the BIOS version.

To access the BIOS setup program, press the <Delete> key during the POST (Power-On Self-Test) when the power is turned on.

BIOS Setup Program Function Keys

< >< > ↑ ↓ Move the selection bar to select an item

< >< > ← → Move the selection bar to select the screen

<Enter> or <Double Click> Execute command or enter the submenu

<Esc> or <Right Click> Main Menu: Exit the BIOS Setup program

Submenus: Exit current submenu

<+> Increase the numeric value or make changes

<-> Decrease the numeric value or make changes

<F1> General Help

<F2> Restore the previous BIOS settings for the current submenus

<F3> Load the Optimized BIOS default settings for the current submenu

<F4> Save all the changes and exit the BIOS Setup program

Main

This setup page includes all the items in standard compatible BIOS

Advanced

This setup page includes all the items of BRIX enhanced features.

Chipset

Platform Controller Hub additional features configuration.

Security

Change, set or disable supervisor and user password. Configuration supervisor password allows you to restrict access to the

system and BIOS Setup.

A supervisor password allows you to make changes in BIOS Setup.

A user password only allows you to view the BIOS settings but not to make changes.

Boot

This setup page provides items for configuration of boot sequence.

Save & Exit

Save all the changes made in the BIOS Setup program to and exit. (Pressing can also carry out this task.)<F10>

Abandon all changes and the previous settings remain in effect. Pressing to the confirmation message will exit BIOS Setup. <Y>

(Pressing can also carry out this task.) <Esc>

Produkt Specifikationer

Mærke:	Gigabyte
Kategori:	Skrivebord
Model:	GB-BSi7A-6500
Vekselstrømsindgangsspænding:	100 - 240 V
Bredde:	119.4 mm
Dybde:	112.6 mm
Højde:	34.4 mm
Produktfarve:	Sort
Produkttype:	Mini PC barebone
Wi-Fi:	Ja
Bluetooth:	Ja
Opbevaringstemperatur (T-T):	-20 - 60 °C
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Processorkerner:	2
VESA montering:	Ja
Panel montering grænseflade:	75 x 75,100 x 100 mm
Driftstemperatur (T-T):	0 - 35 °C
Husmateriale:	Aluminium
Strømforsyningstype:	Ekstern AC-adapter
Udgangsspænding for vekselstrømsadapter:	19 V
Bluetooth-version:	4.2
DC-in-stik:	Ja
Intel® Wireless Display (Intel® WiDi):	Ja
Processorfrekvens:	2.5 GHz
Processorserie:	Intel® Core™ i7
Processor boost frekvens:	3.1 GHz
Processortråde:	4
Maksimal intern hukommelse:	32 GB
On-board grafikkort, model:	Intel® HD Graphics 520
On-board grafikkort:	Ja
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	2.0
Slot til kabellås:	Ja
Understøttede Windows-operativsystemer:	Windows 10 Home,Windows 10 Pro,Windows 7 Home Basic,Windows 7 Home Premium,Windows 7 Professional,Windows 8.1,Windows 8.1 Pro
Lydsystem:	Realtek ALC255
Processorproducent:	Intel
Processormodel:	i7-6500U
HDMI-version:	1.4a
DisplayPort-version:	1.2
Kabellåseslids type:	Kensington
Kombineret hovedtelefon/mikrofon-port:	Ja
Vekselstrømsadapterens udgangsstrøm:	3.42 A
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	1
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Indbygget processer:	Ja
Processorgeneration:	6th gen Intel® Core™ i7
Kabinettype:	0,46L størrelse PC
Intel® Flex Memory Access:	Ja
Intel® Trusted Execution Teknologi:	Ingen
Intel® TSX-NI:	Ingen
Intel® Stabil Billede Platformsprogram (SIPP):	Ingen
Intel® klar video teknologi:	Ja
Kølingstype:	Passiv
Processor sokkel:	LGA 1356 (stik B2)
Processor litografi:	14 nm
Thermal Design Power (TDP):	15 W
PCI Express slots version:	3.0
PCI Express-konfigurationer:	1x4,4x1
Processor kodenavn:	Skylake
Intel® InTru™ 3D Teknologi:	Ja
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ja
Intel® Insider™:	Ja
Intel® Sikker Nøgle:	Ja
Intel® My WiFi Teknologi (Intel® MWT):	Ja
Intel® Smart Response Teknologi:	Ja
Intel® Identity Protection Teknologi (Intel® IPT):	Ja
Intel® Mindre Forretnings-fordele (Intel® SBA):	Ja
Intel® Quick Sync Video Teknologi:	Ja
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® OS Guard:	Ja
Termiske overvågningsteknologier:	Ja
Intel® Smart Cache:	Ja
Fejlkorrigerende kode:	Ingen
Hukommelsesbåndbredde (maks.):	34.1 GB/sek.
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	2
Hukommelses slots type:	SO-DIMM
Understøttede hukommelsesclock-hastigheder:	2133 Mhz
LAN Kontroller:	Intel I219LM
Hukommelseskanaler:	Dual-channel
Maksimal grafikadapterhukommelse:	32768 MB
PCI Ekspres x1 slots:	2
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte:	1
L3-cache:	4 MB
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte:	1
Antal understøttede skærme:	3
Grafikadapter familie:	Intel
Antal mini DisplayPorts:	1
Konfliktfri:	Ja
