7. Factory Reset
System reset (long press ≥3s).
8. USB-C input
The USB-C socket isn’t just a charging port, it plays up to 24 bit
96kHz directly from USB input. It will take <40 minutes for a high-
powered US B charger to fully charge GO blu. Use the enclosed
USB 'Type A' to 'Type C' cable, smart charger or a regular charger
up to 6.3V.
Note: To switch the audio source from B luetooth to USB, please stop music playback and
disconnect the GO blu from the Bluetooth source. Connect the USB-C input (8) to the U SB audio
source via a USB cable and selec t the GO blu as the playback device.
To switch from USB to Blue tooth transmission, disconnect the GO blu from the audio device
and reconnect the Bluetooth device.
The default setting of the phone does not allow charging of the GO blu (except in exclusive mode).
Tip: Exclusive mode is when the device outputs only the sound of the currently used application. Only
a few applications have an exclusive mode setting; in general there is no difference to charging the
GO blu between turning exclusive mode on or off. However some applications allow charging with
exclusive mode on.
9. LED for Battery Status
LED Status
Green* > 60%
Yellow* 10% >
Red* 10%
*Battery LED will flash when it is charging and will go out when it is fully charged.
10. Microphone
Built-in mic for hands-free calls when paired with your smartphone.
Tip: To wake up your phone's voice assistant, long-press the multi-function knob.
Note: Current instructions apply to firmware version 3.05 and higher.
Tip: For the required driver and all the latest firmw are updates please visit our website:
www.ifi-audio.com/download-hub/ ifi-audio.com Ver1.3
Digital filters
To enter/exit filter selection mode, short-press button (1) three
times, a beep will sound, then press button (3) to selec t filter. See
item (4) for digital filter mode LED colours.
"STD" Standard, modest filtering, modest pre and post ringing
"MIN" Minimum phase, slow roll-off, minimum pre and post ringing
2. Multi-function knob
Controls:
- Volume control (turn)
- Play/Pause (a short click)
- Skip forward (two short clicks)
- Skip back (three short clicks)
- Wake up voice assistant (long press)
Answer the phone:
- Answer the call (short press)
- Hang up (long press)
3. Settings, Bluetooth pairing, Voice alert on/off,
Digital filter mode and restore factory settings
This button cycles between (Please refer to item 4):
Off XBass X Space XBass + XSpace (short press) > > >
Pairing (long press ≥ 3s, indicator flashes red/blue)
Restore factor y settings (press and hold for ≥ 15s, indicator
flashes white 3 times)
4. Sound effects and Bluetooth status LED
The LED colour scheme indicates the current sound effects and
Bluetooth status of GO blu.
LED Mode
Yellow XBass
Cyan XSpace
White XBass + XSpace
Off -
Bluetooth
LED Status
Off Wireless Bluetooth (Connected)
Blue (flashing) Wireless Bluetooth (Awaiting connection)
Blue/Red (flashing) Wireless Bluetooth (Pairing)
Pairing
From switch on, the GO blu will blink blue as it searches for a previously paired device. If a stored
device is not found, it will automatically enter pairing mode and blink blue/red.
To enter pairing mode, long-press button (3) until Bluetooth Mode LED flashes blue / red. To pair,
look for ‘GO blu’ in the list of available Bluetooth devices on your phone.
The GO blu is able to store up to 8 paired Bluetooth devices.
Digital filter
LED Mode
Green STD
Magenta MIN
Note: Short press the power button 3 times to enter the digital filte r mode adjustment, then
short press the filter mode selection button (3) to change the digita l filter type. Short press
the power button 3 times again to kee p the current selection and exit the digital filter
selection mode (it will beep). It will also e xit the filter mode and retain the filter selected if
no butto n is pressed for 30 seconds.
7
45 6
Specications
Chipset: Qualcomm QCC 5100 Series
Input: USB-C
TM
Bluetooth 5.1 ( AAC, SBC, aptX, aptX HD,
aptX Adaptive, aptX LL, LDAC, LHDC/HWA Codec)
Power System: Charging via USB-C, BC V1.2 compliant up to
1000mA charging current and 6.3 volts
Headphone Outputs:
Balanced: 4.4mm
UnB AL: 3.5mm
Power Output:
Balanced: 245mW @ 32Ω; 5.6V @ 60
UnB AL: 165mW @ 32Ω; 2.8V @ 60
Output Impedance:
Balanced: <1Ω
UnB AL: <1Ω
SNR:
Balanced: 111dBA
UnB AL: 106.5dBA
DNR: 120dB(A) (BAL/UnBAL)
THD + N:
Balanced: <0.009% (6.5mW/2.0V @ 60)/
UnB AL: <0.03% (100mW/1.27V @ 16Ω)
Frequency Response: 20Hz - 45kHz (-3dB)
Battery: Lithium-polymer 450mAh approx. ~10 hours
Dimensions: 54 x 34 x 13 mm
2.1" x 1.3" x 0.5
Net weight: 27 g (0.95 oz)
Warranty period: 12 months
*Specications are subject to cha nge without notice.
8 9 10
1. Power on/off, Bluetooth format annunciation,
Voice alert on/off and digital filter mode on/off
Power switch
Long press and hold the power switch for ≥ 3s to power on/off the GO blu.
Bluetooth format annunciation
Press the power switch twice and the voice will announce the
Bluetooth format you are currently receiving.
Voice annunciation on/off
In the shutdown state, first press the Bluetooth pairing key (3)
without releasing it, and then press the power key to turn it on.
The operation method of turning off and turning on voice
annunciation is the same.
Note: After turning off the voice annunciation, the c urrent B luetooth format and sampling
freque nc y will no longer be announced.
1 2 3
Restore factory settings
LED Status
White Restore factory settings
Note: You need to use the factory reset in the power-on state, during which no other operations
can be performed; when the factory reset is successful, the white light will flash 3 times with a
beep sound. After the operation is successful, the device will be in the power-on state.
Warning: Restoring the factory settings will clear all the memorized Bluetooth addresses, XBass
and XSpace will be turned off, and voice (decoding format) announcement will be turned on.
5. Balanced 4.4mm headphone output
Connect balanced 4.4mm headphones.
6. S-Balanced 3.5mm headphone output
Connect 3.5mm headphones.
