Side 1/5
• Working Voltage DC 1.5V
• Battery 1 × AAA battery(1.5V )
• Working Current 55~65mA
• Standby Current 9.5μA~11μA
• Transmission Distance Without obstacle 100m
• Transmission Frequency 433.29MHz
• Working Temperature -20℃~50℃
• Humidity ≤90%rh (non-condensing)
• Weight 35.5g(battery not included) 46.7g(battery included)
• Dimension Transmitter: 80.0mm*38.2mm*13.3mm Magnet: 80.0mm*14.8*12.9mm (L*W*H)
Installation manual |
Wireless Contact Sensor
Instalační manuál | Detektor dveře/okna
Inštalačný manuál | Detektor dvere / okná
Website : www.iget.eu E-mail : sales@iget.eu
Battery replacement instructions/ Výměna baterie/ Výmena batérie
Trigger Mode Clarication/ Funkce Trigger/ Funkcie Trigger
Trigger Mode Mód Triggeru Mód Triggeru VýznamClarification Význam
Close Zatvorený Deactivated when triggered Deaktivován pro všechny režimy alarmu Deaktivovaný pre všetky režimy alarmuZavřený
Instant Okamžitý Okamžitý Activated when ARM/HOME ARM Aktivní když je režim alarmu Aktivován/
Režim Doma
Aktívny keď je režim alarmu Aktivovaný /
Režim Doma
24 Hours 24 Hodin 24 Hodín Activated even when DISARM Aktivní vždy i při režimu alarmu Deaktivace Aktívna vždy aj pri režime alarmu
Deaktivácia
Home Režim Doma Režim Doma Deactivated when DISARM/HOME ARM Neaktivní pokud je režim alarmu Deaktivace/
Režim Doma
Neaktívne ak je režim alarmu Deaktivácia /
Režim Doma
Door Chime Uvítací Gong Uvítací Gong No alarm but clanking Bez alarmu, ale uvítací gong (např. pro
obchody)
Bez alarmu, ale uvítací gong (napr. pre
obchody)
Delay Zpoždění Oneskorenie Wait few seconds before alarm Čeká několik vteřin před aktivací alarmu Čaká niekoľko sekúnd pred aktiváciou
alarmu
①Insert the flat blade of a small screwdriver into the pry-off slot of transmitter,
twist the blade to remove the cover.
①Stiskněte tlačítko dolů pomocí palce a druhou rukou otevřete kryt detektoru.
①Stlačte tlačidlo nadol pomocou palca a druhou rukou otvorte kryt detektora.
②Replace with 1xAAA battery.
②Vyměňte 1xAAA baterii.
②Vymeňte 2x AA batérie.
Features
Parameters
Appearance
The M3P4 wireless contact sensor is an accessory of iGET SECURIT Y M3 series smart alarm system.It's fashion design, energy
saving, and low battery warning supported. The main panel will send a SMS to user for battery replacement when needed.It's
easy to setup and works well with most doors and windows. When transmitter and magnet are apart, the sensor triggers alarm.
Two great features:
- Transmitter can be put on either of magnet's left or right side.
- When "Ready to Arm" feature turned on, DMC01O will ask the system to inform user for checking the door or window if
closed well or not when it received Arm command with its transmitter and magnet are apart.
SECURITY M3P4
Exclusive importer of products Shenzhen Dinsafe Intelligence Co., Ltd.
for the Czech Republic and Slovak Republic
INTELEK spol. s.r.o., Vlárská 22, 627 00 Brno
SUPPORT: http: //www.iget.eu/helpdesk
Copyright © 2015 INTELEK spol. s r.o. All rights reserved.
LED Indication
Magnet Transmitter
LED ashes once: Door/window is opened and transmitter sends signal to the main panel.
LED lights stays on: Low battery, please replace the battery immediately.
LED Indicator
PCB Layout
Operating Instructions
Installation & Notice
1. Working principle
The transmitter sends trigger signal to main panel paired when the magnet mounted near is moved apart.
2. Pairing with main panel by App
①Scan the QR code printed on the sensor.
②The pairing result would be confirmed by SMS sent from main panel.
• Open the case and remove the battery insulative strip.
• Pairing to main panel by App before installing.
• Attach the transmitter and magnet seperately on door/window and its frame with double-side sticky tape or fix with screws.
Transmitter can be put on either of magnet's left or right side.
• Make sure the distance between transmitter and magnet is less than 1cm and at the same level.
• Avoid installing the sensors in area with a large amount of metal or electric wire.
Less than 1cm
