BACK PANEL

FEATURES & FUNCTIONS

Questions? Visit www.ihome.com

LIMITED ONE YEAR WARRANTY

QUESTIONS? visit www.ihome.com

Model: iWBTW200

Quick Start Guide

GETTING STARTED

Before use, remove the battery pull tab

from the bottom of the unit. Connect the

included AC adapter to the DC jack

located on the back of the unit and

connect the other end to a working wall

outlet.

Connecting the Unit

Step One

SETTING THE ALARM

Each step must be completed while display is ﬂashing or setting will time-out

without any changes saved.

1. Press and hold the for 2 seconds until the alarm time display and Alarm Button

alarm icon ﬂash.

2. Press the to adjust the alarm time to the desired time (hold for – or + Buttons

rapid setting).

Make sure you set the correct AM/PM alarm time. The PM indicator

appears to the left of the display.

3. Press the Alarm Button to conﬁrm the alarm time setting. The alarm schedule

will ﬂash: 7 (every day), 5 (weekdays) or 2 (weekend only). Press the – or +

Buttons to select the desired alarm schedule.

4. Press the to conﬁrm the alarm schedule. Now use the Alarm Button – or +

Buttons to set the wake to source:

Tones: Wake to built-in tones. Press the or– + Buttons to cycle through tones.

Bluetooth: Wake to audio from a connected Bluetooth device.

Beep: Wake to beeping sound.

5. Press the to conﬁrm. Now use the Alarm Button – or + Buttons to control the

alarm volume and press the Alarm Button once more to conﬁrm all settings. 2

beeps will conﬁrm alarm setting is complete. The alarm icon will remain on the

display, indicating the alarm is armed.

6. To turn o a sounding alarm and reset it to come on the next day at the same

time, press the to reset alarm.Alarm Button

Press and release the as needed to preview the alarm and to Alarm Button

toggle the alarm ON (indicated by the alarm icon) or OFF (no alarm icon).

PREVIEWING THE ALARM

PROGRAMMABLE SNOOZE

WIRELESS CHARGING

Check the Wireless Charging LED under the iHome badge for

charging status:

Slow blinking LED: Device is charging properly.

Solid LED: Device is charged.

Rapid blinking LED: Device is not charging properly. Reposition

device.

(LED may continue to blink slowly when iOS devices are fully charged.)

CAUTION: Remove metal protective or magnetic case from phone

before charging. When charging phone, do not place

magnetic-striped or other metal objects on the charger. Doing so

could damage the object or this unit. Qi compatible phones with

metallic looking ﬁnishes will charge normally.

APPLE WATCH CHARGING

BATTERY BACK-UP

The unit comes with a CR-2450 back-up battery installed to

provide continuous alarm operation and clock settings in the event

of a temporary power failure. Remove the battery pull tab before

use. When the battery icon on the clock display is ﬂashing, it is time

to replace the back-up battery. The battery compartment is

located on the bottom of the unit.

1. Make sure the AC adapter is

connected, or you will lose your time

and alarm settings during battery

replacement.

2. Use a Phillips screwdriver to open

the battery compartment door.

3. Remove the exhausted battery from

the compartment and insert 1

CR-2450 battery, checking that the

+ side is facing you. Replace the

compartment door. Do not

overtighten.

WARNING: Lithium batteries can explode or cause burns if disassembled,

shorted, recharged, exposed to water, ﬁre, or high temperatures. Do not

place loose batteries in a pocket, purse, or other container containing metal

objects, mix with used or other battery types, or store with hazardous or

combustible materials. Store in cool, dry, ventilated area. Follow applicable

laws and regulations for transport and disposal.

• Do not ingest the battery, Chemical Burn Hazard. This product contains a

coin/button cell battery. If the coin/button cell battery is swallowed, it can

cause severe internal burns in just 2 hours and can lead to death.

• Keep new and used batteries away from children. If the battery

compartment does not close securely, stop using the product and keep it

away from children. If you think batteries might have been swallowed or

placed inside any part of the body, seek immediate medical attention.

• Attention should be drawn to the environmental aspects of battery

disposal.

Supports:

• Qi compatible phones (also works with plastic cases up to 3mm thick*)

Place Qi compatible device face up on the charging rest as pictured below:

The Apple Watch Magnetic Charging Module

works with Apple Watch, Apple Watch Sport

and Apple Watch Edition. Place your watch on

the charger with the watch face turned upward

until the battery indicator on the watch shows

it is charged.

(You can deactivate ‘Nightstand Mode’ in the

settings of your Apple Watch to eliminate a

duplicate time display.)

Bluetooth Speaker + Triple Charging

TIMEBASE PRO+

DST Switch (Daylight Savings)

USB Charging (5V/1A)

DC Jack for power supply

(12V/2.7A)

-1 +1 Auto

DST

DSTusb cha rgi ng

usb cha rgi ng

usb cha rgi ngDC 12V, 2.7A

DC 12V, 2.7A

Bluetooth Pairing Button/LED

Connecting to Bluetooth

Step Two

• Turn on your Bluetooth device and make it

‘discoverable’ by turning on Bluetooth mode.

• Press and hold the Bluetooth Pairing

Button on the TIMEBASE PRO+ to enter

pairing mode.

• Select ‘iHome iWBTW200’ on your device’s

Bluetooth menu to connect!

iHome

iWBTW200

Battery Backup

Compartment

(for clock accuracy)

*Before use, remove battery pull tab

from bottom panel.

Alarm

Indicator

Low Backup

Battery

Indicator

PM Indicator

DISPLAY ICONS

-1 +1 Au to

D S T

D S Tus b c h a r g i n g

us b c h a r g i n g

us b c h a r g i n gDC 12V, 2.7A

D C 12V, 2. 7A

RESET

TEST

Setting the Time

Step Three

• Press and hold the until the Time Button

clock display begins to ﬂash.

• Use the +/- Buttons to adjust the time.

• Press the Time Button to conﬁrm the time.

• The year will ﬂash on the display. Use the

+/- Buttons to adjust the year, and press the

Time Button again to conﬁrm.

• The month will ﬂash on the display. Use the

+/- Buttons to adjust the month, and press

the again to conﬁrm. Time Button

• The date will ﬂash on the display. Use the

+/- Buttons to adjust the date, and press the

Time Button again to conﬁrm all settings.

0QVG Make sure to set the

correct AM/PM time. The

PM indicator will appear

on the left side of the

display. There is no AM

indicator.

BOTTOM PANELFRONT PANEL

1. To program Snooze, press and hold the ZZZ Button during normal

operation (when no alarm is sounding).

2. Press the to select a snooze time between 1-29 minutes.+ or - Buttons

3. Press the ZZZ Button to conﬁrm Snooze setting. When the alarm is

sounding, press down on the ZZZ Button to temporarily silence the

alarm (9 minutes is the default).

When set to Auto, clock will

automatically update twice a year.

To manually adjust, switch to -1 to

lose an hour and + 1 to gain an hour.

When used in the directed manner, this unit has been designed and manufactured to ensure your

personal safety. H use can result in potential electrical shock or ﬁre hazards. owever, improper

Please read and follow all safety and operating instructions carefully before installation and use, and

keep these instructions handy for future reference. Take special note of all warnings listed in these

instructions and on the unit.

1. Water and Moisture – The unit should not be used near water. For example: near a bathtub,

washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.

2. Ventilation – The unit should be situated so that its location or position does not interfere with

its proper ventilation. For example, it should not be situated on a bed, sofa, rug or similar

surface that may block ventilation openings. Also, it should not be placed in a built-in

installation, such as a bookcase or cabinet, which may impede the ﬂow of air through the

ventilation openings.

3. Heat – The unit should be situated away from heat sources such as radiators, heat registers,

stoves or other appliances (including ampliﬁers) that produce heat.

4. Power Sources – The unit should be connected to a power supply only of the type described in

the operating instructions or as marked on the appliance. Only use the AC adapter that came

with the unit.

5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them. It is always best to have a clear

area from where the cable exits the unit to where it is plugged into an AC socket.

6. Cleaning – Clean only with dry cloth.

7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not

spilled into any openings or vents located on the product.

8. Attachments – Do not use attachments not recommended by the product manufacturer.

9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect

the antenna or cable system during a lightning storm or when it is left unattended and unused

for long periods of time. This will prevent damage to the product due to lightning and

power-line surges.

10. Overloading – Do not overload wall sockets, extension cords, or integral convenience

receptacles as this can result in a risk of ﬁre or electric shock.

11. Damage Requiring Service – The unit should be serviced by qualiﬁed service personnel when:

A. the power supply cable or plug has been damaged.

B. objects have fallen into or liquid has been spilled into the enclosure.

C. the unit has been exposed to rain.

D. the unit has been dropped or the enclosure damaged.

E. the unit exhibits a marked change in performance or does not operate normally.

12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a

month or longer, remove batteries before storage

13. Servicing – The user should not attempt to service the unit beyond those methods described

in the user manual. Service methods not covered in the operating instructions should be

referred to qualiﬁed service personnel.

14. Magnetic Interference: This product’s speakers contain powerful magnets which could cause

interference or damage to sensitive equipment such as hard drives, CRT televisions and

monitors, as well as medical, scientiﬁc, and navigational devices. Keep this unit away from these

products at all times.

15. Only use attachments/accessories speciﬁed by the manufacturer. This product is suitable for

use in tropical and/or moderate climates.

16. The unit should be serviced by qualiﬁed service personnel when the enclosure damaged or

does not operate normally.

17. No naked ﬂame sources, such as lighted candles, should be placed on the apparatus.

18.

WARNING: To reduce the risk of ﬁre or electric shock, do not expose this product to rain or moisture.

19. CAUTION – Danger of explosion if battery is incorrectly replaced. Replace only with the same

or equivalent type.

20. Do not dispose of batteries in the household trash or ﬁre

21. The mains plug of power adaptor is used as the disconnect device, it shall remain readily

operable.

IMPORTANT SAFETY INSTRUCTIONS

iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI),

warrants this product to be free from defects in workmanship and materials, under

normal use and conditions, for a period of one (1) year from the date of original

purchase. Should this product fail to function in a satisfactory manner, it is best to ﬁrst

return it to the store where it was originally purchased. Should this fail to resolve the

matter and service still be required by reason of any defect or malfunction during the

warranty period, SDI will repair or, at its discretion, replace this product without charge.

This decision is subject to veriﬁcation of the defect or malfunction upon delivery of this

product to the Factory Service Center authorized by Customer Service.

If service is required, please visit ihome.com/support/contact to obtain a Return

Authorization Number. A copy of the sales receipt is required to validate in-warranty

coverage.

Disclaimer of Warranty

NOTE: This warranty is valid only if the product is used for the purpose for which it was

designed. It does not cover (i) products which have been damaged by negligence or

willful actions, misuse or accident, or which have been modiﬁed or repaired by

unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive

heat; (iii) damage to digital media players, CD’s or tape cassettes (if applicable); (iv) the

cost of shipping this product to the Factory Service Center and its return to the owner.

This warranty is valid only in the United States of America and does not extend to

owners of the product other than to the original purchaser. In no event will SDI or any of

its aliates, contractors, resellers, their ocers, directors, shareholders, members or

agents be liable to you or any third party for any consequential or incidental damages,

any lost proﬁts, actual, exemplary or punitive damages. (Some states do not allow

limitations on implied warranties or exclusion of consequential damages, so these

restrictions may not apply to you.) This warranty gives you speciﬁc legal rights, and you

may also have other rights which vary from state to state. Your acknowledgment and

agreement to fully and completely abide by the above mentioned disclaimer of warranty

is contractually binding to you upon your transfer of currency (money order, cashier's

check, or credit card) for purchase of your SDI product.

Wireless Charging Status LED

Wireless Charging Area

POWER

WIRELESS CHARGING REST

- Press to Turn ON/OFF

PLAY/PAUSE

- Press to Play/Pause audio or

answer calls

- Press & Hold to end/ignore calls

- Press & Hold to activate

Google/Siri on paired device

ZZZ (SNOOZE/DI MMER)

APPLE WATCH CHARGER

- Press to stop sounding alarm/

reset for the next day

TIME SET

ALARM SET

- Press to Preview

- Press Again to Arm/Disarm

- To set alarm, press & hold

until display starts to ﬂash

(adjust with and press+ - /

alarm to conﬁrm)

- To set clock, press &

hold until display starts

to ﬂash (adjust with + -/

and press time to conﬁrm)

- Repeat for year, month,

and date

PLUS | MINUS

- Press to adjust volume and settings

Connect a standard USB cable

(not included) to charge devices.

The unit must be c onnected to DC

power in order to c harge devices.

- Press to snooze a sounding alarm

- Press repeatedly to adjust display

brightness

WIRELESS CHARGING

STATUS LED

Apple Watch

Charger

-Press and hold to enter

pairing mode

-Press and release to cancel

pairing

Produkt Specifikationer

Mærke:	IHome
Kategori:	Højttaler
Model:	Timebase Pro+ iWBTW200

Har du brug for hjælp?

Hvis du har brug for hjælp til IHome Timebase Pro+ iWBTW200 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Højttaler IHome Manualer

IHome Zenergy Sunrise Manual

3 September 2024

IHome Playglow+ iBT820 Manual

3 September 2024

IHome Playpro iBT700 Manual

3 September 2024

IHome PlayGlow Mini IBT800 Manual

3 September 2024

29 August 2024

29 August 2024

29 August 2024

29 August 2024

IHome TIMEBASE iBTW20 Manual

29 August 2024

IHome iBT4 Manual

29 August 2024

Højttaler Manualer

Nyeste Højttaler Manualer

NGS WILD Space 2 Manual

17 December 2024

Canton Chrono SL 520.2 Manual

16 December 2024

Canton GLE 456 Center Manual

16 December 2024

Canton Vento 820.2 Manual

16 December 2024

Canton Chrono SLS 780 DC Manual

16 December 2024

Canton In Wall 500 LCR Manual

16 December 2024

Canton InWall 949 LCR Manual

16 December 2024

Canton InWall 845 LCR Manual

16 December 2024

Canton InCeiling 855 Manual

16 December 2024

Canton Atelier 950 Manual

16 December 2024
