Imarflex IG-377GL Manual
Læs nedenfor 📖 manual på dansk for Imarflex IG-377GL (2 sider) i kategorien Ovn. Denne guide var nyttig for 15 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/2
SPECIFICATION:
MODEL NO.: -377 IG GL
GAS TYPE: LPG
GAS PRESSURE (Pa): 2800Pa
HEAT LOAD (kW):
Left Burner: 5 4. kW
Right Burner: 5.0kW
IGNITER BATTERY SIZE: Battery AA
BOX DIMENSION: 750*430*225mm
UNIT DIMENSION: 710*370*210mm
GROSS WEIGHT: 9.4kg.
UNIT WEIGHT: 6.0kg.
IMPORTANT SAFEGUARDS:
1. Read all instruction carefully before use.
2. Before using the unit, always check the hose and regulator to avoid leakage.
3. Put the unit in stable surface and keep it away from the edge of the co unter to
avoid accident.
4. Keep curtains, furniture, appliances, flammable materials, etc. away from the
unit.
5. Children should be supervised to ensure that they do not play with the appliance.
6. This appliance is not intended for use by person (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliances by a responsible for their safety.
7. Do not use gas other than LPG.
8. This appliance is designed for cooking and not intended for any other purpose.
9. If you notice that the flame is not normal or you smell gas leakage, turn OFF the
unit and bring it to the nearest Authorized Service Center.
10. Do not use this unit for outdoor use.
11. not use this unit other than its intended use. Do
12. For household use onl y.
13. Save this instruction manual for future reference.
DESCRIPTION OF PARTS:
INSTALLATION:
1. Check all parts of the gas stove, including the
following:
Control knob (2pcs)
4pcs. footing
2. Clean the interface of gas-in, then connect it to the
joining part and tighten it with a hose clip.
3. Connect 3/8” or 9.5mm hose at the gas stove inlet pipe
and the other end in the regulator/valve.
4. Check the joining with soap water to see for any
leakage of gas.
5. Do not forget to put Type Battery at the bottom of AA
the unit.
Note:
- This is electronic ignition a battery-operated –
ignition.
- Battery not included in the packaging.
6. Place the gas stove away from the wall or ceiling. (See
gure 3.)
HOW TO USE:
1. Make sure that the control knob is in OFF position.
2. Open the regulator/valve of the gas tank. (pull or twist)
3. Push the control knob and turn it counter clockwise until click sound is heard. The ame
will ignite automatically .
4. If ignition fails due to faulty gas flow, turn the control knob back to OFF position and
repeat instruction #3.
5. If you want to use both rings with high flame, turn the control knob as shown in (1).
6. If you want to use both rings with medium flame, turn the control knob as shown in (2).
7. If you want to use the medium ame of the inner ring, turn the control knob as shown in
(3).
8. If you want to use the low ame of the inner ring, turn the control knob as shown in (4).
9. If the ames become yellowish, adjust the gas and air mixture control to produce
luminous ames.
10. After use always turn OFF the regulator/valve of the gas tank.
Produkt Specifikationer
| Mærke: | Imarflex |
| Kategori: | Ovn |
| Model: | IG-377GL |
