Side 1/2
3-7/8"
98mm
5-1/8"
129mm
3-3/16"
80mm
4-3/4"
120mm
2-1/4"
57mm
9/16"
29mm
1-3/4"
44mm
R E F E R E N C E
5032i
5032cf
5032gr
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage. Un numéro de série valable est exigé pour la couverture de la garantie.
Features,specifications and appearance are subject to change without notice.
Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman International, Consumer Division, 8500 Balboa Boulevard, Northridge, CA 91329 USA
www.infinitysystems.com
© 2009 Harman International Industries,Incorporated.All rights reserved.Tous droits réservés.s Part No.REF5032OM1/09
Infinity is a trademark of Harman International Industries,Incorporated, registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries,Incorporated,déposée aux États-Unis et/ou dans d’autres pays.
Declaration of Conformity
We,Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group,Inc.
Château du Loir,France 1/09
5032i 5032cf
BL (T-m) 3.25 3.25
DCR (ohms) 2.30 2.30
Mms (g) 10.22 10.22
Sd (sq cm) 103.9 103.9
Cms (μm/N) 521 521
Vas (l) 7.89 7.89
Fs (Hz) 69.0 69.0
Qes 0.96 0.96
Qms 6.94 6.94
Qt 0.85 0.85
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.

Produkt Specifikationer

Mærke: Infinity
Kategori: Højttaler
Model: REF5032CF

Har du brug for hjælp?

Hvis du har brug for hjælp til Infinity REF5032CF stil et spørgsmål nedenfor, og andre brugere vil svare dig


Højttaler Infinity Manualer

Infinity

Infinity FPS-1000 Manual

16 December 2024
Infinity

Infinity Prelude MTS Stand Manual

2 December 2024
Infinity

Infinity Primus P362 Manual

2 December 2024
Infinity

Infinity Reference RS 4 Manual

1 December 2024
Infinity

Infinity Reference RS 5 (5) Manual

1 December 2024
Infinity

Infinity Primus P252 Manual

1 December 2024
Infinity

Infinity Prelude MTS Tower Manual

1 December 2024
Infinity

Infinity RABOS Manual

1 December 2024
Infinity

Infinity Prelude Forty Manual

1 December 2024
Infinity

Infinity Alpha 25ES Manual

1 December 2024

Højttaler Manualer

Nyeste Højttaler Manualer

NGS

NGS WILD Space 2 Manual

17 December 2024
Canton

Canton Chrono SL 520.2 Manual

16 December 2024
Canton

Canton GLE 456 Center Manual

16 December 2024
Canton

Canton Vento 820.2 Manual

16 December 2024
Canton

Canton Chrono SLS 780 DC Manual

16 December 2024
Canton

Canton In Wall 500 LCR Manual

16 December 2024
Canton

Canton InWall 949 LCR Manual

16 December 2024
Canton

Canton InWall 845 LCR Manual

16 December 2024
Canton

Canton InCeiling 855 Manual

16 December 2024
Canton

Canton Atelier 950 Manual

16 December 2024
