Side 1/1

IN THE BOX

JF4 Freedom Sprint Bluetooth Headphones

Magnet Sealed JayBird Carry Case

3 pairs regular eartips (S,M,L)

3 pairs secure fitting ear cushions (S,M,L)

1 pair of optional ear hooks

USB Cable

User Manual

CHARGING

Charging the battery before use is recommended but

not required. The headphones ship pre-charged

however initial charge will vary.

Low battery is indicated by the status indicator blinking

red with an audible tone every 20 seconds. Connect

micro USB charging cable with the charging port of

headphones under the USB cover on the right earpiece.

Connect cable to the USB slot of any PC or Mac. The

status indicator will be red while charging and will turn

off when fully charged. JayBird also offers an AC power

adapter (sold separently).

PAIR MODE

Begin with headphones powered off.

Push and hold top button for 8 seconds

until status light alternates red and blue. You

are now in pair mode. See your phone/music

device manual for pair instructions.

Pass code is 0000.

8 sec

PAIR MODE (detailed step by step instructions)

1. Place headphones and mobile phone within 1 meter of each other.

2. Put headphones into pair mode by pushing top button for 8 seconds (LED will flash red & blue).

3. On your music device, turn Bluetooth on and search for Bluetooth devices.

Select “Freedom 4” in the Bluetooth device list.

4. Enter password or PIN No:”0000” on your mobile phone if prompted.

5. If required, after pairing, select “Freedom 4” in the Bluetooth device list and press “connect”.

6. After successful connecting, the blue light blinks twice every 4 seconds.

PAIRING WITH A BLUETOOTH ADAPTER

1. Place headphones and mobile phone within 1 meter of each other.

2. Put the headphones into pair mode as outlined on prior page.

3. If using BAU Universal Bluetooth Adapter put adapter into pair mode also (see BAU manual).

4. Plug the Bluetooth adapter into the music device and play a song.

5. The headphones and adapter will pair automatically (pass code of adapter must be 0000)

6. After successful pairing and connecting, the LED status indicator on the headphones will blink

twice every 4 seconds.

POWER ON/OFF

Power on: Push & hold top button for 6 seconds.

Power off: Push & hold top button for 3 seconds.

Note

- If the pairing is not successful, switch off headphones by pushing the top button for 3 seconds, and then re-pair according to the steps outlined above.

- After pairing is successful, paired devices will remember each other. Unless pairing information is deleted, there is no need to pair again.

- The headphones will connect with the latest paired device. If you want to pair with other Bluetooth devices, switch off the Bluetooth function of the

current Bluetooth device, and then pair and connect it with the new Bluetooth device according to steps outlined above.

Note

Freedom Sprint does not support apt-X CD quality audio even though it’s offered on JayBird Bluetooth adapters.

PAIRING WITH SEVERAL BLUETOOTH DEVICES

The headphones can connect with two devices at most. A mobile phone with

HFP profile; and a device with A2DP profiles. If you want to pair two Bluetooth

devices, please refer to the following steps.

1. Firstly, pair the headphones with the Bluetooth adapter

2. Disconnect the Bluetooth adapter from the iPhone or iPod

3. Pair and connect the headphones with the mobile phone

4. Reconnect the Bluetooth adapter, will connect with headphones automatically.

Not all the mobile phones support all the functions listed. Please refer to the instruction of your mobile phone. When the volume is adjusted to max or min,

you will hear a indication sound. For some mobile phones, when you accept a call on the phone, the call will be sent to the mobile phone. You can switch the

call to headphones by using top button on headphones or through phone. Please refer to the instruction of your mobile phone for further information.

Function Status Indication Operation

Voice dial Standby mode Short tone Press & hold top button for 2 seconds

Redial Standby mode Short tone Double click top button

Volume Up Music/Call mode NA Short presses of Vol+ button

Volume Down Music/Call mode NA Short presses of Vol - button

Answer Call Incoming Call Short tone Press top button

Reject Call Incoming Call Short tone Press & hold top button for 2 seconds

End Call During Call Short tone Press top button

During Call Short tone Press & hold top button for 2 seconds

Mute During Call Dbl tone 5 sec Double click top button

Unmute During Call NA Double click top button

Switch b/w phone

& headset mode

Note

Mobile phones that support HSP and A2DP profiles simultaneously may block the

Bluetooth adapter from reconnecting to the headphones.

Key

Short push of adjacent button

Push and hold of adjacent button

For some of mobile phones, when they are playing music, the music will transmit to the speaker of mobile phone. If this happens, select “transmit the

sound through Bluetooth” in the “setting” of music play interface, and then choose "Freedom 4” in the device list. Please refer to the instruction

of your mobile phone for further information. When the volume of headphones is adjusted to max or min,you will hear a tone. Remote control the

function such as next track, previous track, etc require your mobile phone to support AVRCP. Please refer to your mobile phone user manual or

Bluetooth transmitter for further info.

Function Status Indication Operation

Volume up Music/Call mode NA Short presses of Vol+ button

Volume Down Music/Call mode NA Short presses of Vol - button

Play/Pause Music Mode Short tone Press top button

Next track Music Mode Short tone Long press of Vol - button

Back track Music Mode Short tone Long press of Vol + button

Charging LED Indicator Status of headphones

Red light is on Charging

Red light is off Finished charging

Pairing LED Indicator Status of headphones

red and blue alternating Pair Mode

Blue double blink every 2 sec Standby mode

Blue periodic blinking Connected to device

Red double blinking over 30 sec Low battery

Tone Indicator Status of headphones

Two tones every 5 sec Conversation mode and mic mute

Tone every 30 seconds Low battery

JF4 Specifications

Bluetooth Version V2.1 + EDR

(newer versions offer no

benefits for headphones)

Profile Headset, handsfree, A2DP, AVRCP

Effective Range 10 meters (30 feet)

Working time Music & calls up to 4.5 hours

Standy time Up to 150 hours

Input voltage DC 5A 100mA

Charging time Approximately 2 hours

Dimensions 16 x 35 x 8 mm

Weight Approx 16 g

Care and maintenance

Keep dry and do not store in a damp place

Do not put the product in direct sunlight for extended periods of time

or in hot areas.

High temperature will shorten the life of the electronic device, destroy

the battery, and distort certain plastic.

Do not expose the product to extreme cold.

Do not disassemble the product.

Do not drop the headphones.

Do not use chemicals or detergent to clean the product.

If the product fails to work contact JayBird support at jaybirdgear.com

INSTALL EAR CUSHIONS

Three sizes of patented

secure fit ear cushions

are included. The correct

size for your ear will be

the ones which fit snugly

into the bowl of your ear

and lock into the top as

shown. Further guidance

on the next 3 pages.

01 LEFT (L) AND RIGHT (R) MARK ON TOP SIDE

CUT AWAY FOR POSITIONING GUIDANCE

OUTDOORS / GYMS

KEEP THE MUSIC DEVICE AT OR ABOVE WAIST LEVEL ON YOUR RIGHT SIDE

THE SAME SIDE AS THE HEADPHONE ANTENNA.

Your body is 80% water. Water blocks low power radio signal like Bluetooth.

In the absence of nearby ceilings for signal bounce, your body can block the

signal between the music device and the headphones. When outdoors or in

gyms the use of armbands or wrist-worn music players are recommended.

Having your music player in your pants pocket below waist level may produce

varied results as your body can get between the music device & headphones.

L M S

LOCK THE TIP OF THE EAR

CUSHION INTO THE TOP OF

THE BOWL OF THE EAR AS

SHOWN.

YOU SHOULD HAVE A SNUG

FIT WITH CONTACT ON THE

LOWER, BACK AND TOP

PORTIONS OF THE BOWL OF

THE EAR.

WHEN OUTDOORS WEAR

YOUR MUSIC DEVICE IN

THIS ZONE TO AVOID

SIGNAL BLOCKAGE

FROM YOUR BODY.

HAVING THE DEVICE IN A

POCKET ON YOUR LEG MAY

PRODUCE VARIED RESULTS

AS YOUR UPPER BODY CAN

GET BETWEEN THE DEVICES.

LET US TAKE CARE OF YOU

TAKE A MOMENT TO REGISTER YOUR

LIFETIME WARRANTY AGAINST SWEAT

jaybirdgear.com/intheclubnow

No login or account setup required.

04 TAKE CARE OF YOURSELF AS WELL

& LISTEN RESPONSIBLY

Avoid excessive volume levels

and prolonged periods of listening.

Do not use around road traffic.

USER GUIDE

FREEDOM SPRINT BLUETOOTH HEADPHONES (JF4)

BEFORE WE GET STARTED REMEMBER THESE 4 THINGS...

COMMANDS

WARRANTY

Full warranty details at jaybirdgear.com/warranty

+1.866.244.3399

WARNING: Due to the isolating characteristics of these headphones do not use while driving, Riding a bike or where vehicular trafﬁc

is present, or in any other activity where failure to hear surrounding sounds could be dangerous. Use of these headphones at

excessive volumes may cause permanent hearing damage. Always turn the volume down before use. Take caution in regards to

inserting objects into ear canal, use at own risk.

Bluetooth is a trademark owned by Bluetooth SIG, Inc. USA, and licensed to JayBird Gear LLC. iPhone is a trademark of

Apple, Inc., registered in the U.S. and other countries. Manufactured under European patent no EP1410607B1 &

corresponding foreign patents

Assembled in China

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications to device will void the user’s authority to operate the device. The battery is recycled.

Do not dispose of the battery in fire, as it may cause explosion.

TO COVER ALL FITTING

PREFERENCES, EARHOOKS

ARE INCLUDED AS AN

ALTERNATIVE SECURE FIT

OPTION.

MAKING A CALL PLAYING MUSIC

STATUS LIGHT SPECIFICATIONS & CARE

01 02

03 04

05 06

07 08

09 10

11 12

13 14

15 16

17 18

19 20

21 22

3 or 6 sec

LED status light

GREAT SOUND PERFORMANCE IS IN

SELECTING THE RIGHT SIZE EARTIP

WE LOVE GREAT SOUND. MAKE SURE YOU HEAR IT.

Because everyone’s ears are different, make sure to try out all sizes of

eartips. Only with the perfect size eartips will you enjoy snug fit &

optimum sound quality.
