92798 Cape Arago Hwy, Coos Bay, OR 541 97420 | -888-3517 | Toll Free 1- -800 867 6863 | kksound.com-
PU R E P R E A M P
Thank you for choosing the Pure Preamp!
This extremely versatile and small belt-clip unit was designed for the frequencies of an acoustic guitar, but it
can also be used for many other pre-amplification needs.
The Pure Preamp features an internal gain adjustment trim pot inside the box. It adjusts the degree of
pre-amplification. You can turn it with a small screwdriver. The adjustable gain range is covered by a factor 1 to
10. This means, you can boost your incoming signal up to the 10- fold amount.
The Pure Preamp is manufactured using K&K's "full size" component philosophy. We are convinced that most
miniature components do not provide the best possible sound quality. We use only top quality through-hole
capacitors for exceptional dynamic, depth of field and highest resolution.
The Pure Preamp features an extra wide band midrange filter, which is absolutely great in combination with the
Pure pickups. Its simple and noiseless circuit provides unsurpassed clarity and power and the internal gain
trimmer allows you to dial in the precise amplification factor needed for your instrument.
The Pure Preamp is powered by a 9-volt battery. Please open the lid and insert a battery before first use. The
snap-off lid simply lifts off. There is no need to remove any screws. Important: Please do not tamper with the
screw on the bottom of the preamp!
TECHNICAL DATA
Frequency response: 10 - 30,000 Hz
Input 1/4", 1 Mega Ohm
Output: 1/4", 10 KOhm
Bass: roll off @100Hz
Midrange: super wide band @1.5kHz
Treble: 10Khz
Size: 2 ½ x 3
Battery Consumption: less than 1 milli Ampere - 9-volt 180 hours
