THE BASICS
Oi! THIS IS A PRECISION INSTRUMENT
Treat with the same care that you would your
bike’s other parts: your spokes, your derailleurs,
your rear lights, your rear.
If you’re in doubt about how to mount, use, or
troubleshoot the Oi, visit the Knog website or,
of course, your local bike shop.
NOT SUITABLE
FOR AERO
CYLINDRICAL
BAR
SIZE MATTERS:
SHAPE MATTERS:
22.2mm
only
S
M
A
L
L
O
i
F
I
T
S
:
L
A
R
G
E
O
i
F
I
T
S
:
23.8 - 31.8
mm
Oi! DON’T FORGET
WARRANTY:
2 years on materials and workmanship.
K N O G . C O M . AU
For more information
Pour plus d’information
Für weitere Informationen
Para más información
詳細については
Oi! GET IT ON
POSITION ON A
CYLINDRICAL PART OF
THE HANDLEBAR THAT
YOU FIND COMFORTABLE,
BUT IS NOT CURVED OR
TAPERED.
If you have the Large Oi but a
23.8, 25.4, or 26mm diameter
bar you’ll need to put the
appropriate spacer on your
bar to make Oi sit flush. Make
sure gap faces straight up.
If your bar is 23.8mm, place the
rubber tape provided inside the
larger spacer.
TAKE OUT THE Oi LUXE &
REMOVE THE HEX BOLT
using the hex key provided.
1
2
3
Ø 23.8
Ø 25.4
Ø 26.0
Oi! GET IT ON
ASSEMBLE BELL ON HANDLEBAR UPSIDE DOWN.
INSERT SCREW, BUT DO NOT TIGHTEN.
ROTATE BELL
UNTIL BOTTOM
OF HAMMER IS
HORIZONTALLY
ALIGNED WITH
CENTER OF
HANDLEBAR.
TIGHTEN SCREW.
4
5
Please note: this may not suit every cable configuration
