Side 1/4
Precautions
Location
Using the unit in the following locations can result in a malfunction.
• In direct sunlight.
• Locations of extreme temperature or humidity.
• Excessively dusty or dirty locations.
• Locations of excessive vibration.
• Close to magnetic elds.
Power supply
Be sure to turn the power switch to OFF when the unit is not in use.
Remove the battery in order to prevent it from leaking when the unit is
not in use for extended periods.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception
interference. Operate this unit at a suitable distance from radios and
televisions.
Handling
To avoid breakage, do not apply excessive force to the switches or
controls.
Care
If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not use
liquid cleaners such as benzene or thinner, or cleaning compounds or
ammable polishes.
Keep this manual
After reading this manual, please keep it for later reference.
Keeping foreign matter out of your equipment
Never set any container with liquid in it near this equipment. If liquid gets
into the equipment, it could cause a breakdown, re, or electrical shock.
Be careful not to let metal objects get into the equipment.
THE FCC REGULATION WARNING (for USA)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If items such as cables are included with this equipment, you must
use those included items.
Unauthorized changes or modication to this system can void the
user’s authority to operate this equipment.
Notice regarding disposal (EU only)
If this symbol is shown on the product, manual, battery, or
package, you must dispose of it in the correct manner to avoid
harm to human health or damage to the environment. Contact
your local administrative body for details on the correct dis-
posal method. If the battery contains heavy metals in excess
of the regulated amount, a chemical symbol is displayed
below the symbol on the battery or battery package.
IMPORTANT NOTICE TO CONSUMERS
This product has been manufactured according to strict specica-
tions and voltage requirements that are applicable in the country
in which it is intended that this product should be used. If you have
purchased this product via the internet, through mail order, and/or
via a telephone sale, you must verify that this product is intended
to be used in the country in which you reside.
WARNING: Use of this product in any country other than that for
which it is intended could be dangerous and could invalidate the
manufacturer’s or distributor’s warranty.
Please also retain your receipt as proof of purchase otherwise your
product may be disqualied from the manufacturer’s or distribu-
tor’s warranty.
* All product names and company names are the trademarks or regis-
tered trademarks of their respective owners.
SYNCHRONIZED NCE MUSIC PLAYERDA
アフターサービス
修理、および商品のお取り扱いについてのご質問、ご相談は、
お客様相談窓口へお問い合わせください。
お客様相談窓口
PHS等一部の電話ではご利用できません。固定電話また
は携帯電話からおかけください。
受付時間 月曜～金曜 10:00 ～ 17:00
（祝祭日、窓口休業日を除く）
●サービス・センター :
〒168-0073　東京都杉並区下高井戸1-18-16　2F
■お願い
1. 保証書に販売年月日等の記入がない場合は無効となります。記入できないと
きは、お買い上げ年月日を証明できる領収書等と一緒に保管してください。
2. 保証書は再発行致しませんので、紛失しないように大切に保管してください。
コルグ
SyncDancing 保証書
本保証書は、保証規定により無償修理をお約束するものです。
お買い上げ日 年 月 日
販売店名
CALIFORNIA USA ONLY
Perchlorate Material– special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
CAN ICES-3 B / NMB-3 B.
use the jog switch to set the tempo from
= 30 to 252 (BPM). Slide
and hold the jog switch to make the tempo continue to change.
Using this device as a metronome
When using this device as a metronome, set the beat and rhythm.
1. Press the MODE buon to display the Beat or Rhythm seing
screens.
2. Press the SYNC buon to switch the playback sound to a metronome.
3. Use the jog switch to set the beat and rhythm.
Beat: Select a beat from (0 beat) to (9 beat).
Rhy thm:
Se lect a rhyt h m pat ter n from (Quar ter Notes),
(Duplets), (Quadruplets : (Triplets : , , ), or
, , ).
Changing the metronome sound
The metronome sound (tone) on this device can be changed.
1. Press the MODE buon to display the Tone seing screen.
2. Select one of the tones from to .
 Theseseingwillbestoredinthedevice.However,theseingswillnotbe
storedifthedeviceisnotturnedointheordinarymanner(suchaswhenthe
baeryrunout).
Synchronization
The count timing for two or more SyncDancing devices can be synchro-
nized. The SyncDancing device that drives the base tempo is called the
“master”, and the other SyncDancing devices that will follow that tempo
in sync are called “slaves”.
 Thisdeviceusesinfraredcommunicationwhensyncingwithotherdevices.
Donotusethesyncfunctionsaroundotherdevicesthatuseinfraredlight,or
aroundplasmaTVs.
1. Match the protruding part of
the SyncDancing that will be
the master to the recessed part
of the SyncDancing that will
be the slave, as shown in the
diagram.
2. Press the SYNC button on
the SyncDancing that will be
the master.
TIP When synchronizing three or
more devices, connect the SyncDancing that will be the slave, as
shown in the diagram below., and press the SYNC buon on the
master SyncDancing device.
 Oncethesynchronizationseingshavebeenmade,theslaveSyncDancing’s
seingswillbereplacedwiththoseofthemaster.(ExcepttheVolumeandDelay
seings.)
 SynchronizationwillbecancelediftheTempo,Beat,orSongseingsare
changed.
Muting the device
The song and metronome sounds can be muted.
1. Hold down the SYNC buon. Press the SYNC buon to cancel
muting.
Specications
Tempo:
=30–252/min (BPM), 0–9 beat, Beat: Rhythm: Quarter Notes,
Duplets, Triplets, Quadruplets, Song: 20 songs, Tempo accuracy: ±0.1,
Speaker: dynamic speaker, Synchronization communications method:
infrared, Power supply: 3V lithium baery CR 2032, Baery life: approxi-
mately 5 hours (continuous use at Tempo = 120, Beat = , Rhythm =
, Volume = 49 x 22 x 22 mm / 1.93” x ), Dimensions (WxDxH):
0.87” x 0.87”, Weight: 10 g / 0.35 oz. (including baery), Included items:
Owner’s Manual, CR2032 lithium baery (3V),
ear pad, carrying case
* Specications and appearance are subject to change without notice
for improvement.
Master Slave Slave
Thank you for purchasing the Korg SyncDancing SYNCHRO-
NIZED DANCE MUSIC PLAYER.
Features on this device
1. SYNC buon (Hold down : Mute)
2. MODE buon (Hold down :
Power)
3. Display
4. Jog Switch
TIP Operate the jog switch by slid-
ing it in the direction of the
arrow.
5. Ear clip
Attach the device to your ear as
shown in the diagram at right.
Attaching the device
To aach the device to your ear, open
the ear clip, place the round part near
the hollow part of your ear around the earhole, and
then close the ear clip.
 theroundpartcanrotateamaximumof220degrees.
Itwillbreakifyouaempttorotateitfartherthanthis.
As th is a smal l and lightwe ig ht devi c e, th ere is a r isk
that small ch ildren m ay pla ce it in the ir mouth an d ingest it.
Keepthedeviceoutofreachandstoreitawayfromsmallchildren.
Inserting the battery
 Wheninsertingorreplacingthebaery,turnothedevice’spower.
 Makesuretoobservethecorrectpolarity.
Turning on the power
1. To turn on the power, hold down the MODE button until the
display lights.
2. To turn off the power, hold down the MODE button until the
display goes dark.
 Theentiredisplaywillblinkifthebaeryhasworndown.Whenthishap-
pens,replacethebaeryassoonaspossible.
Using this device
Press the MODE button to switch between the setting screens for
Song ( ), Volume ( ), Delay ( ), Beat () (, Tempo ),
Rhythm ( ), and Tone ( ), in that order.
Playing back a song
Set the song to play back using this device.
1. Press the MODE buon to display the Song seing screen.
2. Select a song from to . Press the SYNC buon to play back
the selected song.
Adjusting the song’s playback timing
You can adjust the amount of time (delay) that will pass before playing
back the song after the device is aached .
1. Press the MODE buon to display the Delay seing screen.
2. Set the delay time. The number indicates how many seconds will
pass before playback begins.
Setting the volume
1. Press the MODE buon to display the Volume seing screen, and
use the jog switch to select the volume from (Volume: Low) to
(Volume: High).
 Thisdevice’svolumehasbeensettobealileloud,sinceitmaybeused
whenpracticingmusicalinstruments.Ifthedeviceseemstooloud,fastenitto
yourearatapositionslightlyawayfromtheearhole.
 Toprotectyourhearing,avoidusingthisdeviceforlongperiodsoftime
Setting the tempo
1. Press the MODE buon to display the Tempo seing screen, and
5
1. Slide the lid open. 2. Pull the lid
diagonally upwards,
and then insert the
baery.
1 2 3 4
Song List
1. Frederic Chopin, Nocturne
Op.9 No.2
2. Scarborough Fair
3. Coppelia Wal
4. W.A.Mozart, Eine kleine
Nachtmusik
5. Rodríguez Peña
6. Dos Guitarras
7. La golondrina
8. Recuerdos de la Alhambra
9. Comin' Thro' the Rye
10. Humoresque
11. Johann Strauss 2：
Fruhlingsstimmen Op.410
12. Chopin Etudes Op. 10, No.3
13. Torna a Surriento
14. Zigeunerweisen
15. Old Folks at Home
（Swanee River)
16. Santa Lucia
17. Wiegenlied Schubert
Lullaby
18. Red Sails In The Sunset
19. Oh! Susanna
20. Russian folk dance
“Kalinka” and “Troika”
220°
Rhythm Pattern List

Produkt Specifikationer

Mærke: Korg
Kategori: Ikke kategoriseret
Model: SY-1D

Har du brug for hjælp?

Hvis du har brug for hjælp til Korg SY-1D stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Korg Manualer

Korg

Korg Pitchstrap Manual

18 December 2024
Korg

Korg STB1 Manual

11 December 2024
Korg

Korg Sample Builder Manual

11 December 2024
Korg

Korg ST-SV1-BK Manual

11 December 2024
Korg

Korg PC-400 Manual

5 September 2024
Korg

Korg USB Boot Utility Manual

28 August 2024
Korg

Korg SY-1D Manual

28 August 2024
Korg

Korg Magnetune MG1 Manual

18 August 2024
Korg

Korg AW-LT100B Manual

14 August 2024
Korg

Korg IE-1M Manual

4 August 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Philips

Philips Quick Clean Pot QCP10 Manual

24 December 2024
Philips

Philips Senseo HD7002 Manual

24 December 2024
Profoto

Profoto RFi Softbox Octa Manual

24 December 2024
Philips

Philips GoGear PAC009 Manual

24 December 2024
Koenic

Koenic KVRWD 21624 Manual

24 December 2024
Koenic

Koenic KAP 2523 Manual

24 December 2024
Koenic

Koenic KWC 13725 Manual

24 December 2024
Koenic

Koenic KAF 2110 W Manual

24 December 2024
Philips

Philips HD9921 Manual

24 December 2024
Philips

Philips Senseo HD7008 Manual

24 December 2024
