Lenovo 10w
Hardware Maintenance Manual
First Edition (March 2022)
© Copyright Lenovo 2022.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.
Contents
About this manual . . . . . . . . . . . . iii
Chapter 1. Safety information . . . . . . 1
General safety . . . . . . . . . . . . . . . . 1
Electrical safety . . . . . . . . . . . . . . . . 1
Safety inspection guide . . . . . . . . . . . . . 3
Handling devices that are sensitive to electrostatic
discharge . . . . . . . . . . . . . . . . . . 3
Grounding requirements . . . . . . . . . . . . 4
Safety notices (multilingual translations) . . . . . . 4
Chapter 2. General checkout . . . . . 21
What to do first . . . . . . . . . . . . . . . 21
Checking the ac power adapter . . . . . . . . 22
Checking the battery and operational charging . . 22
Chapter 3. Locations . . . . . . . . . 25
Locating computer controls and connectors . . . 25
Overview . . . . . . . . . . . . . . . 25
Lenovo 10w Detachable Keyboard (for
selected models) . . . . . . . . . . . . 26
Locating FRUs and CRUs . . . . . . . . . . . 28
Major FRUs and CRUs . . . . . . . . . . 29
Miscellaneous parts . . . . . . . . . . . 31
Looking up FRU information . . . . . . . . . . 31
Chapter 4. FRU replacement
notices . . . . . . . . . . . . . . . . . 33
Service tool kit . . . . . . . . . . . . . . . 33
Screw notices . . . . . . . . . . . . . . . 33
Chapter 5. Removing or replacing a
FRU. . . . . . . . . . . . . . . . . . . 35
General guidelines. . . . . . . . . . . . . . 35
Before servicing the computer . . . . . . . . . 35
Disable Fast Startup and the built-in battery . . 35
1010 Lenovo Integrated Pen (for selected
models) . . . . . . . . . . . . . . . . . . 36
1020 Pen dummy (for selected models) . . . . . 36
1030 LCD unit and LCD cable . . . . . . . . . 36
1040 I/O board cable. . . . . . . . . . . . . 38
1050 Built-in battery . . . . . . . . . . . . . 39
1060 Charger cable bracket . . . . . . . . . . 40
1070 I/O board bracket . . . . . . . . . . . . 41
1080 Rear camera and rear camera bracket . . . . 41
1090 Pen charger cable. . . . . . . . . . . . 42
1100 Microphone board cable . . . . . . . . . 42
1110 I/O board and function board cable . . . . . 43
1120 Pogo pin cable . . . . . . . . . . . . . 44
1130 Speaker assembly . . . . . . . . . . . 44
1140 Front camera with cable . . . . . . . . . 45
1150 Microphone board, microphone rubber and
rear LED rubber . . . . . . . . . . . . . . . 45
1160 Wireless LAN antennas. . . . . . . . . . 46
1170 Heatsink . . . . . . . . . . . . . . . 47
1180 System board . . . . . . . . . . . . . 48
1190 Base cover assembly . . . . . . . . . . 49
Appendix A. Notices . . . . . . . . . . 51
Appendix B. Abbreviation table . . . . 53
© Copyright Lenovo 2022 i
ii Lenovo 10w Hardware Maintenance Manual
About this manual
This manual contains service and reference information for the following products:
Lenovo 10w Machine types (MT): 82SU and 82ST
Use this manual along with the advanced diagnostic tests to troubleshoot problems.
Important:
• This manual is intended only for trained service technicians who are familiar with products. Use this
manual along with the advanced diagnostic tests to troubleshoot problems effectively.
• Depending on the model, some hardware configuration and software programs might not be available on
the computer. Some statements in this manual might not be applicable to the computer.
• Before servicing a product, be sure to read all the information under Chapter 1 “Safety information” on
page 1.
© Copyright Lenovo 2022 iii
iv Lenovo 10w Hardware Maintenance Manual
Chapter 1. Safety information
This chapter presents following safety information that you need to be familiar with before you service a
notebook computer.
• “General safety” on page 1
• “Electrical safety” on page 1
• “Safety inspection guide” on page 3
• “Handling devices that are sensitive to electrostatic discharge” on page 3
• “Grounding requirements” on page 4
• “Safety notices (multilingual translations)” on page 4
General safety
Follow these rules to ensure general safety:
• Observe good housekeeping in the area of the machines during and after maintenance.
• When lifting any heavy object:
1. Ensure that you can stand safely without slipping.
2. Distribute the weight of the object equally between your feet.
3. Use a slow lifting force. Never move suddenly or twist when you attempt to lift.
4. Lift by standing or by pushing up with your leg muscles; this action removes the strain from the
muscles in your back. Do not attempt to lift any object that weighs more than 16 kg (35 lb) or that you
think is too heavy for you.
• Do not perform any action that causes hazards to the customer, or that makes the equipment unsafe.
• Before you start the machine, ensure that other service technicians and the customer's personnel are not
in a hazardous position.
• Place removed covers and other parts in a safe place, away from all personnel, while you are servicing the
machine.
• Keep your tool case away from walk areas so that other people will not trip over it.
• Do not wear loose clothing that can be trapped in the moving parts of a machine. Ensure that your sleeves
are fastened or rolled up above your elbows. If your hair is long, fasten it.
• Insert the ends of your necktie or scarf inside clothing or fasten it with a nonconductive clip, about 8
centimeters (3 inches) from the end.
• Do not wear jewelry, chains, metal-frame eyeglasses, or metal fasteners for your clothing, because metal
objects are good electrical conductors.
• Wear safety glasses when you are hammering, drilling, soldering, cutting wire, attaching springs, using
solvents, or working in any other conditions that might be hazardous to your eyes.
• After service, reinstall all safety shields, guards, labels, and ground wires. Replace any safety device that
is worn or defective.
• Reinstall all covers correctly before returning the machine to the customer.
• Fan louvers on the machine help to prevent overheating of internal components. Do not obstruct fan
louvers or cover them with labels or stickers.
Electrical safety
Observe the following rules when working on electrical equipment.
© Copyright Lenovo 2022 1
Important:
• Use only approved tools and test equipment. Some hand tools have handles covered with a soft material
that does not insulate you when working with live electrical currents.
• Many customers have, near their equipment, rubber floor mats that contain small conductive fibers to
decrease electrostatic discharges (ESD). Do not use this type of mat to protect yourself from electrical
shock.
• Find the room emergency power-off (EPO) switch, disconnecting switch, or electrical outlet. If an electrical
accident occurs, you can then operate the switch or unplug the power cord quickly.
• Do not work alone under hazardous conditions or near equipment that has hazardous voltages.
• Disconnect all power before:
– Performing a mechanical inspection
– Working near power supplies
– Removing or installing main units
• Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the customer
to power off the wall box that supplies power to the machine, and to lock the wall box in the off position.
• If you need to work on a machine that has exposed electrical circuits, observe the following precautions:
– Ensure that another person, familiar with the power-off controls, is near you. That person must be there
to switch off the power, if necessary.
– Use only one hand when working with powered-on electrical equipment; keep the other hand in your
pocket or behind your back.
CAUTION:
An electrical shock can occur only when there is a complete circuit. By observing the above rule,
you may prevent a current from passing through your body.
– When using testers, set the controls correctly and use the approved probe leads and accessories for
that tester.
– Stand on suitable rubber mats (obtained locally, if necessary) to insulate you from grounds such as
metal floor strips and machine frames.
Observe the special safety precautions when you work with very high voltages. Instructions for these
precautions are in the safety sections of maintenance information. Use extreme care when measuring high
voltages.
• Regularly inspect and maintain your electrical hand tools for safe operational condition.
• Do not use worn or broken tools and testers.
• Never assume that power has been disconnected from a circuit. First, check that it has been powered off.
• Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors,
nongrounded power extension cables, power surges, and missing safety grounds.
• Do not touch live electrical circuits with the reflective surface of a plastic dental mirror. The surface is
conductive; such touching can cause personal injury and machine damage.
• Do not service the following parts with the power on:
– Power supply units
– Fans
– Units similar to those listed above
This practice ensures correct grounding of the units.
• If an electrical accident occurs:
– Use caution; do not become a victim yourself.
– Switch off power.
– Send another person to get medical aid.
2Lenovo 10w Hardware Maintenance Manual
Safety inspection guide
The purpose of this inspection guide is to assist you in identifying potentially unsafe conditions. As each
machine was designed and built, required safety items were installed to protect users and service
technicians from injury. This guide addresses only those items. You should use good judgment to identify
potential safety hazards due to attachment of non-ThinkPad / non-Lenovo features or options not covered by
this inspection guide.
If any unsafe conditions are present, you must determine how serious the apparent hazard could be and
whether you can continue without first correcting the problem.
Consider these conditions and the safety hazards they present:
• Electrical hazards, especially primary power (primary voltage on the frame can cause serious or fatal
electrical shock)
• Explosive hazards, such as a damaged CRT face or a bulging capacitor
• Mechanical hazards, such as loose or missing hardware
To determine whether there are any potentially unsafe conditions, use the following checklist at the
beginning of every service task. Begin the checks with the power off, and the power cord disconnected.
Checklist:
1. Check exterior covers for damage (loose, broken, or sharp edges).
2. Turn off the computer. Disconnect the power cord.
3. Check the power cord for:
a. A third-wire ground connector in good condition. Use a meter to measure third-wire ground
continuity for 0.1 ohm or less between the external ground pin and the frame ground.
b. The power cord should be the authorized type specified for your computer. Go to:
https://
support.lenovo.com/partslookup.
c. Insulation must not be frayed or worn.
4. Check for cracked or bulging batteries.
5. Remove the cover.
6. Check for any obvious non-ThinkPad / non-Lenovo alterations. Use good judgment as to the safety of
any non-ThinkPad / non-Lenovo alterations.
7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or
other liquids, or signs of fire or smoke damage.
8. Check for worn, frayed, or pinched cables.
9. Check that the power-supply cover fasteners (screws or rivets) have not been removed or tampered
with.
Handling devices that are sensitive to electrostatic discharge
Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to
electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects.
Protect against ESD damage by equalizing the charge so that the machine, the part, the work mat, and the
person handling the part are all at the same charge.
Notes:
1. Use product-specific ESD procedures when they exceed the requirements noted here.
Chapter 1 Safety information.3
2. Ensure that the ESD protective devices you use have been certified (ISO 9000) as fully effective.
When handling ESD-sensitive parts:
• Keep the parts in protective packages until they are inserted into the product.
• Avoid contact with other people.
• Wear a grounded wrist strap against your skin to eliminate static on your body.
• Prevent the part from touching your clothing. Most clothing is insulative and retains a charge even when
you are wearing a wrist strap.
• Use a grounded work mat to provide a static-free work surface. The mat is especially useful when
handling ESD-sensitive devices.
• Select a grounding system, such as those listed below, to provide protection that meets the specific
service requirement.
Note: The use of a grounding system to guard against ESD damage is desirable but not necessary.
– Attach the ESD ground clip to any frame ground, ground braid, or green-wire ground.
– When working on a double-insulated or battery-operated system, use an ESD common ground or
reference point. You can use coax or connector-outside shells on these systems.
– Use the round ground prong of the ac plug on ac-operated computers.
Grounding requirements
Electrical grounding of the computer is required for operator safety and correct system function. Proper
grounding of the electrical outlet can be verified by a certified electrician.
Safety notices (multilingual translations)
The safety notices in this section are provided in the following languages:
• English
• Arabic
• Brazilian Portuguese
• French
• German
• Hebrew
• Japanese
• Korean
• Spanish
• Traditional Chinese
DANGER
4Lenovo 10w Hardware Maintenance Manual
DANGER
DANGER
DANGER
DANGER
DANGER
DANGER
Chapter 1 Safety information.5
DANGER
6Lenovo 10w Hardware Maintenance Manual
PERIGO
Chapter 1 Safety information.7
PERIGO
PERIGO
PERIGO
PERIGO
8Lenovo 10w Hardware Maintenance Manual
PERIGO
PERIGO
PERIGO
DANGER
DANGER
Chapter 1 Safety information.9
DANGER
DANGER
DANGER
DANGER
DANGER
10 Lenovo 10w Hardware Maintenance Manual
DANGER
VORSICHT
VORSICHT
VORSICHT
VORSICHT
Chapter 1 Safety information.11
VORSICHT
VORSICHT
VORSICHT
VORSICHT
12 Lenovo 10w Hardware Maintenance Manual
Chapter 1 Safety information.13
14 Lenovo 10w Hardware Maintenance Manual
Chapter 1 Safety information.15
16 Lenovo 10w Hardware Maintenance Manual
Chapter 1 Safety information.17
18 Lenovo 10w Hardware Maintenance Manual
Chapter 1 Safety information.19
20 Lenovo 10w Hardware Maintenance Manual
Chapter 2. General checkout
Before you go to the checkout instructions, ensure that you read the following important notes.
Important notes:
• Only certified trained personnel should service the computer.
• Before replacing any FRU, read the entire page on removing and replacing FRUs.
• When you replace FRUs, it is recommended to use new nylon-coated screws.
• Be extremely careful during such write operations as copying, saving, or formatting. Drives in the computer
that you are servicing sequence might have been altered. If you select an incorrect drive, data or programs might be
overwritten.
• Replace a FRU only with another FRU of the correct model. When you replace a FRU, make sure that the model
of the machine and the FRU part number are correct by visiting
https://support.lenovo.com/partslookup.
• A FRU should not be replaced because of a single, unreproducible failure. Single failures can occur for a variety
of reasons that have nothing to do with a hardware defect, such as cosmic radiation, electrostatic discharge, or
software errors. Consider replacing a FRU only when a problem recurs. If you suspect that a FRU is defective, clear
the error log and run the test again. If the error does not recur, do not replace the FRU.
• Be careful not to replace a nondefective FRU.
What to do first
When you return a FRU, you must include the following information in the parts exchange form or parts return
form that you attach to it:
1. Name and phone number of service technician
2. Date of service
3. Date on which the machine failed
4. Date of purchase
5. Failure symptoms, error codes appearing on the display, and beep symptoms
6. Procedure index and page number in which the failing FRU was detected
7. Failing FRU name and part number
8. Machine type, model number, and serial number
9. Customer's name and address
Note: During the warranty period, the customer may be responsible for repair costs if the computer damage
was caused by misuse, accident, modification, unsuitable physical or operating environment, or improper
maintenance by the customer. Following is a list of some common items that are not covered under warranty
and some symptoms that might indicate that the system was subjected to stress beyond normal use.
Before checking problems with the computer, determine whether the damage is covered under the warranty
by referring to the following list:
The following are not covered under warranty:
• LCD panel cracked from the application of excessive force or from being dropped
• Scratched (cosmetic) parts
• Distortion, deformation, or discoloration of the cosmetic parts
• Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force
• Damage caused by liquid spilled into the system
© Copyright Lenovo 2022 21
• Damage caused by the improper insertion of a personal-computer card (PC card) or the installation of an
incompatible card
• Improper disc insertion or use of an external optical drive
• Fuses blown by attachment of a non-supported device
• Forgotten computer password (making the computer unusable)
• Sticky keys caused by spilling a liquid onto the keyboard
• Use of an incorrect ac power adapter on laptop products
The following symptoms might indicate damage caused by non-warranted activities:
• Missing parts might be a symptom of unauthorized service or modification.
• Check for obvious damage to a hard disk drive. If the spindle of a hard disk drive becomes noisy, the hard
disk drive might have been dropped or subject to excessive force.
Checking the ac power adapter
If the computer fails only when the ac power adapter is used:
• If the power problem occurs only when the docking station or the port replicator is used, replace the
docking station or the port replicator.
• If the system status indicator does not blink three times when an ac power source is connected, check the
power cord of the ac power adapter for correct continuity and installation.
• If the computer does not charge during operation, go to “Checking the battery and operational charging”
on page 22.
Note: Noise from the ac power adapter does not always indicate a defect.
Checking the ac power adapter
1. Connect the computer to a power outlet and turn on the computer.
2. Start the Vantage app, and locate the Power section. The ac power adapter information is displayed.
Ensure that you use the ac power adapter that is shipped with the computer to provide enough power to the
computer. Otherwise a message will be displayed, prompting you that the computer will not be charged or
will be charged slowly.
Checking the battery and operational charging
Checking the battery
This system supports only batteries specially designed for this specific system and manufactured by Lenovo
or an authorized manufacturer. The system does not support unauthorized batteries or batteries designed for
other systems. If an unauthorized battery or a battery designed for another systems is installed, the system
will not charge.
Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and
provides no warranties for failures or damage arising out of their use.
Move your pointer to the battery-status icon in the Windows
® notification area to check the battery status.
The battery-status icon displays the percentage of battery power remaining and how long you can use your
computer before you must charge the battery.
Checking the operational charging
1. Discharge the battery to 50% or lower.
2. Perform operational charging. Click the battery status icon in the Windows notification area to display
detailed battery information. If it indicates that the battery is not charging, replace the battery.
22 Lenovo 10w Hardware Maintenance Manual
3. Check the battery status again. If the same error still exists, replace the system board.
Chapter 2 General checkout.23
24 Lenovo 10w Hardware Maintenance Manual
Chapter 3. Locations
Locating computer controls and connectors
Overview
Lenovo Integrated Pen* Microphone
Camera Webcam privacy shutter
Touch screen Power button
Volume button Audio connector
Power connector / USB-C® 3.2
connector Gen 1 Speakers
Pogo interface connector
* for selected models
© Copyright Lenovo 2022 25
Rear Camera
Lenovo 10w Detachable Keyboard (for selected models)
Depending on the model, your tablet might come with a Lenovo 10w Detachable Keyboard (referred to as
keyboard). Attach the keyboard to your tablet so that you can transform your tablet into a portable notebook
computer.
Overview
Pogo pin with guide pin Touchpad
Attach your computer to the keyboard
Align the keyboard guide pins with the tablet guide pin connectors in the direction shown by the arrows.
When the keyboard gets close enough, it magnetically attaches to your tablet. Then, you can adjust the
tablet to your prefer viewing angle (within 180 degrees).
26 Lenovo 10w Hardware Maintenance Manual
To detach your computer, you can easily remove the keyboard by pulling it away.
Chapter 3 Locations.27
Locating FRUs and CRUs
This topic introduces the following service parts:
• “Major FRUs and CRUs” on page 29
• “Miscellaneous parts” on page 31
Notes:
• Each FRU is available for all types or models, unless otherwise specified.
• CRU statement for customers:
You can resolve some problems with your product with a replacement part you can install yourself, called a
“Customer Replaceable Unit” or “CRU.” Some CRUs are designated as self-service CRUs and others are
designated as optional-service CRUs. Installation of self-service CRUs is your responsibility. For optional-service
CRUs, you can either install the CRU yourself or you can request that a Service Provider install the CRU according to
the warranty service for your product. If you intend on installing the CRU, Lenovo will ship the CRU to you. CRU
information and replacement instructions are shipped with your product and are available from Lenovo at any time
upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic
version of this manual can be found at
https://support.lenovo.com. Click Documentation and then follow the on-
screen instructions to find the manual for your product. You might be required to return the defective CRU. When
return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the
replacement CRU; and (2) you might be charged for the replacement CRU if Lenovo does not receive the defective
CRU within thirty (30) days of your receipt of the replacement CRU. See your Lenovo Limited Warranty
documentation for full details.
• Your computer contains the following types of CRUs and FRUs:
– Self-service CRUs: Refer to parts that can be installed or replaced easily by customer themselves or by trained
service technicians at an additional cost.
– Optional-service CRUs: Refer to parts that can be installed or replaced by customers with a greater skill level.
Trained service technicians can also provide service to install or replace the parts under the type of warranty
designated for the customer’s machine.
– FRUs: Refer to parts that must be installed or replaced only by trained service technicians. If customers choose
to replace the FRUs by themselves, the product warranty might be affected.
28 Lenovo 10w Hardware Maintenance Manual
Major FRUs and CRUs
Chapter 3 Locations.29
Table 1. Major FRUs and CRUs
No. FRU description Self-service
CRU
Optional-service
CRU
1I/O board cable No No
2Funciton board cable No No
3LCD unit No No
4I/O board bracket No No
5I/O board No No
6Heatsink No No
7System board No No
8Speaker assembly No No
9Pogo pin cable No No
10 Charger cable bracket No No
11 Base cover assembly No No
12 Lenovo 10w Detachable Keyboard* Yes No
13 Built-in battery No No
14 Microphone board No No
15 Rear LED rubber No No
16 Microphone rubbers No No
17 Front camera with cable No No
18 Wireless LAN antennas No No
19 Microphone board cable No No
20 Rear camera No No
21 Rear camera bracket No No
22 Pen charger cable No No
23 LCD cable No No
24 Lenovo Integrated Pen* Yes No
25 Pen dummy* Yes No
aLenovo factory recovery USB key* No No
bPower cord Yes No
cMiscellaneous parts kits (see “Miscellaneous parts” on page 31) No No
dac power adapter* Yes No
* for selected models
Notes:
• Depending on the computer model, your computer might look different from the illustration above.
30 Lenovo 10w Hardware Maintenance Manual
• The Lenovo factory recovery USB key is used to restore the Microsoft Windows operating system. It a
might not come with the computer, and a user might order it from
https://pcsupport.lenovo.com/
lenovorecovery, though additional shipping and handling fees might apply.
Miscellaneous parts
Table 2. Miscellaneous part
FRU descriptions Self-service
CRU
Optional-service
CRU
Screw kit
• M1.2 x L2, black (2)
• M1.6 x L1.7, silver (4)
• M1.6 x L2.3, black (25)
• M1.6 x L3.5, black (6)
No No
Looking up FRU information
For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to:
https://support.lenovo.com/partslookup
Chapter 3 Locations.31
32 Lenovo 10w Hardware Maintenance Manual
Chapter 4. FRU replacement notices
Read this chapter carefully before replacing any FRU.
Service tool kit
Ensure that the following service tool kit is prepared before you service a notebook computer.
No. Tool name Tool type
1 Phillips-head screwdriver 1 Common tool
2 Phillips-head screwdriver 2 Common tool
3 Conductive tweezers Common tool
4 Silicone grease Consumable tool
5 Polyamide tape Consumable tool
6 Mylar tape Consumable tool
7Eraser Consumable tool
8 Electrical tape Consumable tool
9 Double-sided tape Consumable tool
10 Conductive tape Consumable tool
Notes:
• Specifications of the Phillips-head screwdriver 2:
– Screwdriver head diameter: ≤ φ2.0 mm
– Screwdriver head length: ≥ 15 mm
• The silicone grease can be applied to the surfaces of the microprocessor and heatsink to eliminate air
gaps.
Screw notices
Loose screws can cause a reliability problem. In your computer, this problem is addressed with special
nylon-coated screws that have the following characteristics:
• They maintain tight connections.
• They do not easily come loose, even with shock or vibration.
• They are harder to tighten.
Do the following when you service the computer:
• Keep the screw kit in your tool bag. For the part number of the screw kit, go to:
https://support.lenovo.com/partslookup
Tighten screws as follows:
• Plastic to plastic
© Copyright Lenovo 2022 33
Turn an additional angle of 90 degrees after the screw head touches the surface of the plastic part.
• Logic card to plastic
Turn an additional angle of 180 degrees after the screw head touches the surface of the logic card.
Notes:
• Ensure that you use the correct screw. It is recommended to use new screws for replacements. If you
have a torque screwdriver, tighten all screws firmly to the torque specified in the screw information table
for each step.
• Ensure torque screwdrivers are calibrated correctly following country specifications.
34 Lenovo 10w Hardware Maintenance Manual
Chapter 5. Removing or replacing a FRU
This chapter provides instructions on how to remove or replace a FRU.
General guidelines
When removing or replacing a FRU, be sure to observe the following general guidelines:
1. Do not try to service any computer unless you have been trained and certified. An untrained person runs
the risk of damaging parts.
2. Before replacing any FRU, review Chapter 4 “FRU replacement notices” on page 33.
3. Begin by removing any FRUs that have to be removed before replacing the failing FRU. Any such FRUs
are listed at the beginning of each FRU replacement section. Remove them in the order in which they are
listed.
4. Follow the correct sequence in the steps for removing a FRU, as given in the illustrations by the numbers
in square callouts.
5. When turning a screw, turn it in the direction as given by the arrow in the illustration.
6. When removing a FRU, move it in the direction as given by the arrow in the illustration.
7. To put the new FRU in place, reverse the removal procedure and follow any notes that pertain to
replacement.
8. When replacing a FRU, use the correct screws as shown in the replacement procedures.
DANGER
Before removing any FRU, turn off the computer, unplug all power cords from electrical outlets,
disable the built-in battery, and then disconnect any interconnecting cables.
Attention:
• After replacing a FRU, do not turn on the computer until you have made sure that all screws, springs, and
other small parts are in place and none are loose inside the computer. Verify this by shaking the computer
gently and listening for rattling sounds. Metallic parts or metal flakes can cause electrical short circuits.
• The system board is sensitive to, and can be damaged by ESD. Before touching it, establish personal
grounding by touching a ground point with one hand or by using an ESD strap.
Before servicing the computer
Carefully read this topic before servicing the computer.
Disable Fast Startup and the built-in battery
Before replacing any CRU, ensure that you disable Fast Startup first and then disable the built-in battery.
To disable Fast Startup:
1. Go to Control Panel and view by Large icons or Small icons.
2. Click Power Options, and then click Choose what the power buttons do on the left pane.
3. Click Change settings that are currently unavailable at the top.
4. If prompted by User Account Control (UAC), click Yes.
© Copyright Lenovo 2022 35
5. Clear the Turn on fast startup check box, and then click Save changes.
To disable the built-in battery:
1. Enter the setup utility.
2. Select Configuration ➙ Disable Built-in Battery and press Enter.
3. Select Yes in the Setup Confirmation window. The built-in battery is disabled and the computer turns off
automatically. Wait three to five minutes to let the computer cool.
1010 Lenovo Integrated Pen (for selected models)
Depending on models, your tablet might come with a Lenovo Integrated Pen.
Removal steps of the Lenovo Integrated Pen
1020 Pen dummy (for selected models)
Depending on models, your tablet might come with a pen dummy.
Removal steps of the pen dummy
1030 LCD unit and LCD cable
For access, remove these FRUs in order:
• “1010 Lenovo Integrated Pen (for selected models)” on page 36
• “1020 Pen dummy (for selected models)” on page 36
36 Lenovo 10w Hardware Maintenance Manual
Removal steps of the LCD unit and LCD cable
Step Screw (quantity) Color Torque
1M1.2 × 2.0 mm, flat-head, nylon-coated (2) Black 0.039±0.015 Nm
(0.4±0.05 kgf-cm)
Note: Loose the screws in step 1 with Phillips-head screwdriver 2, see “Service tool kit” on page 33.
Chapter 5 Removing or replacing a FRU.37
When installing: Ensure that the connectors are attached firmly.
1040 I/O board cable
For access, remove these FRUs in order:
• “1010 Lenovo Integrated Pen (for selected models)” on page 36
• “1020 Pen dummy (for selected models)” on page 36
• “1030 LCD unit and LCD cable” on page 36
38 Lenovo 10w Hardware Maintenance Manual
Removal steps of the I/O board cable
When installing: Ensure that the connectors are attached firmly.
1050 Built-in battery
DANGER
Use only the authorized battery specified for the computer. Any other battery could ignite or
explode.
Important notice for replacing a battery
Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no
warranties for failures or damage arising out of their use.
The Vantage app provides an automatic battery diagnostic test that determines if the built-in battery is defective. A
built-in battery FRU should not be replaced unless this diagnostic test shows that the battery is defective. The only
exception to this is if the built-in battery is physically damaged or a customer is reporting a possible safety issue.
If the Vantage app is not installed on the computer, the customer should download and install the program to diagnose
the built-in battery, before getting a non-physically damaged built-in battery replaced. Note that the replacement of a
physically damaged built-in battery is not covered by the warranty.
For access, remove these FRUs in order:
• “1010 Lenovo Integrated Pen (for selected models)” on page 36
• “1020 Pen dummy (for selected models)” on page 36
• “1030 LCD unit and LCD cable” on page 36
• “1040 I/O board cable” on page 38
Chapter 5 Removing or replacing a FRU.39
Removal steps of the built-in battery
Step Screw (quantity) Color Torque
2M1.6 × 2.3 mm, flat-head, nylon-coated (4) Black 0.1±0.015 Nm
(1.1±0.05 kgf-cm)
When installing: Ensure that the connector is attached firmly.
1060 Charger cable bracket
For access, remove these FRUs in order:
• “1010 Lenovo Integrated Pen (for selected models)” on page 36
• “1020 Pen dummy (for selected models)” on page 36
• “1030 LCD unit and LCD cable” on page 36
Removal steps of the charger cable bracket
Step Screw (quantity) Color Torque
1M1.6 × 2.3 mm, flat-head, nylon-coated (4) Black 0.1±0.015 Nm
(1.1±0.05 kgf-cm)
2M1.6 × 3.5 mm, flat-head, nylon-coated (2) Black 0.1±0.015 Nm
(1.1±0.05 kgf-cm)
40 Lenovo 10w Hardware Maintenance Manual
Produkt Specifikationer
Mærke: | Lenovo |
Kategori: | Tablet |
Model: | 10w |
Har du brug for hjælp?
Hvis du har brug for hjælp til Lenovo 10w stil et spørgsmål nedenfor, og andre brugere vil svare dig
Tablet Lenovo Manualer
11 December 2024
7 December 2024
9 Oktober 2024
30 September 2024
20 September 2024
19 September 2024
6 September 2024
31 August 2024
24 August 2024
24 August 2024
Tablet Manualer
- Tablet SilverCrest
- Tablet Acer
- Tablet Denver
- Tablet Sencor
- Tablet TCL
- Tablet Sony
- Tablet Samsung
- Tablet Panasonic
- Tablet Philips
- Tablet Lenco
- Tablet LG
- Tablet Doro
- Tablet Gigaset
- Tablet Apple
- Tablet Logitech
- Tablet Konrow
- Tablet Google
- Tablet HP
- Tablet AOC
- Tablet Easypix
- Tablet Grundig
- Tablet Motorola
- Tablet Asus
- Tablet Gigabyte
- Tablet Toshiba
- Tablet Pyle
- Tablet OnePlus
- Tablet Butler
- Tablet Adj
- Tablet Creative
- Tablet Thomson
- Tablet Hyundai
- Tablet Aiwa
- Tablet Nokia
- Tablet AKAI
- Tablet Hisense
- Tablet Maxell
- Tablet Hannspree
- Tablet Trevi
- Tablet Blaupunkt
- Tablet Honeywell
- Tablet Razer
- Tablet Medion
- Tablet Olivetti
- Tablet Haier
- Tablet Huawei
- Tablet TechniSat
- Tablet Vivax
- Tablet PocketBook
- Tablet Yarvik
- Tablet Wacom
- Tablet Telefunken
- Tablet Vtech
- Tablet Packard Bell
- Tablet Microsoft
- Tablet Alcatel
- Tablet Zebra
- Tablet Plum
- Tablet Xiaomi
- Tablet Aiptek
- Tablet Krüger&Matz
- Tablet Viewsonic
- Tablet Dell
- Tablet RugGear
- Tablet Fujitsu
- Tablet CAT
- Tablet Tesla
- Tablet MSI
- Tablet Polaroid
- Tablet Energy Sistem
- Tablet Bush
- Tablet Binatone
- Tablet Honor
- Tablet Salora
- Tablet Nevir
- Tablet TrekStor
- Tablet Lava
- Tablet Vodafone
- Tablet Overmax
- Tablet Infinix
- Tablet Newland
- Tablet ECS
- Tablet Archos
- Tablet RCA
- Tablet Hema
- Tablet ECG
- Tablet Navitel
- Tablet Pantech
- Tablet AudioSonic
- Tablet SPC
- Tablet ZTE
- Tablet Lark
- Tablet Barnes & Noble
- Tablet Kobo
- Tablet Amazon
- Tablet GoClever
- Tablet Gemini
- Tablet Intenso
- Tablet BlackBerry
- Tablet Evolveo
- Tablet VIZIO
- Tablet Zagg
- Tablet Bauhn
- Tablet Vorago
- Tablet Majestic
- Tablet ESTAR
- Tablet Audiovox
- Tablet Rand McNally
- Tablet Vivitar
- Tablet Bq
- Tablet Dragon Touch
- Tablet Aqprox
- Tablet Oregon Scientific
- Tablet Aluratek
- Tablet Terratec
- Tablet Lexibook
- Tablet Prestigio
- Tablet Realme
- Tablet GoGen
- Tablet Kogan
- Tablet Micromax
- Tablet Cyrus
- Tablet Insignia
- Tablet Xoro
- Tablet Manta
- Tablet CnMemory
- Tablet TechBite
- Tablet Logic
- Tablet Media-Tech
- Tablet I.safe Mobile
- Tablet Ferguson
- Tablet Allview
- Tablet Proscan
- Tablet Sonim
- Tablet Cresta
- Tablet Brigmton
- Tablet Sunstech
- Tablet Sylvania
- Tablet Exagerate
- Tablet Coby
- Tablet Bigben Interactive
- Tablet Wolder
- Tablet Tesco
- Tablet Disgo
- Tablet Laser
- Tablet Naxa
- Tablet Ricatech
- Tablet Arnova
- Tablet Mpman
- Tablet Cello
- Tablet Logicom
- Tablet Ematic
- Tablet Ingo
- Tablet Difrnce
- Tablet Iget
- Tablet Nextbook
- Tablet Memup
- Tablet Engel Axil
- Tablet Odys
- Tablet Primux
- Tablet DEXP
- Tablet Eken
- Tablet Tom-tec
- Tablet Mediacom
- Tablet Billow
- Tablet Empire
- Tablet Woxter
- Tablet Advantech
- Tablet Kurio
- Tablet Linx
- Tablet Leap Frog
- Tablet Elements
- Tablet Getac
- Tablet Approx
- Tablet I-onik
- Tablet Empire Electronix
- Tablet Vulcan
- Tablet Storex
- Tablet ModeCom
- Tablet Skytex
- Tablet Electrovaya
- Tablet Durabook
- Tablet Mymaga
- Tablet Vinci
- Tablet Vizmo
- Tablet General Dynamics Itronix
- Tablet Xplore
- Tablet Bookeen
- Tablet I-Joy
- Tablet Hamlet
- Tablet Leotec
- Tablet ADS-TEC
- Tablet Nabi
- Tablet Sungale
- Tablet Digiland
- Tablet Best Buy
- Tablet Unitech
- Tablet Fossibot
- Tablet Control4
- Tablet Bluebird
- Tablet Logic Instrument
Nyeste Tablet Manualer
19 Januar 2025
19 Januar 2025
15 Januar 2025
14 Januar 2025
14 Januar 2025
14 Januar 2025
14 Januar 2025
14 Januar 2025
14 Januar 2025
14 Januar 2025
