Safety & Compliance Notices: Notice Concerning FCC Regulations: You are
cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment. This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: (a) Reorient or relocate the receiving antenna;
(b) move this unit; (c) increase the separation between the equipment and receiver; connect the (d)
equipment into an outlet on a circuit different from that to which the receiver is connected; (e) be
sure that all cables are properly shielded, using a choke or ferrite where appropriate; (f) consult the
dealer or an experienced radio/television technician for help.
User Guide (English)
For more information about this product (system
requirements, compatibility information, etc.), product
registration, or product support, visit m-audio.com. For safety
and warranty information, visit m-audio.com/warranty.
Package Contents: Micro DAC, USB extension cable,
coaxial digital cable, carrying pouch, user guide
1. USB Port: Insert this connector to a USB port on your
computer (powered on). The connection will supply the
necessary power to Micro DAC.
If necessary, use the included USB extension cable so
Micro DAC does not block any adjacent connections on
your computer.
2. Power Indicator: This light illuminates when Micro DAC is
powered on.
3. Headphone Output: Connect standard 1/8” (3.5mm)
stereo headphones to analog output.
4. Coaxial Output: Use the included coaxial digital cable to
connect this digital output to the coaxial input of a receiver
or playback device.
5. Impedance Selector: Set this switch to the higher setting
(HI) if you are using headphones (connected to the
headphone output) with low impedance (approximately
64 Ω).
Note: To set the volume, adjust the volume level on your
connected headphones, receiver or playback device, or your
computer’s sound card.
Guía del usuario (Español)
Para más información acerca de este producto (requisitos de
sistema, información de compatibilidad, etc.), registro o
soporte del producto, visite m-audio.com. Para información
sobre la seguridad y la garantía, visite m-audio.com/warranty.
Contenido del paquete: Micro DAC, cable alargador USB,
cable coaxial digital, cartuchera de transporte, guía del usuario
1. Puerto USB: Inserte este conector en un puerto USB de su
ordenador (encendido). La conexión suministrará la
corriente necesaria al Micro DAC.
De ser necesario, utilice el cable alargador USB incluido
para que el Micro DAC no obstruya ninguna otra conexión
adyacente en su ordenador.
2. Indicador de encendido: Esta luz se ilumina cuando el
Micro DAC está encendido.
3. Salida para auriculares: Conecte auriculares estéreo
estándar de 3,5 mm (1/8 pulg.) a esta salida.
4. Salida coaxial: Utilice el cable digital coaxial incluido para
conectar esta salida digital a la entrada coaxial del receptor
o dispositivo de reproducción.
5. Selector de impedancia: Ajuste este interruptor al valor
más alto (HI) si está utilizando auriculares (conectados a la
salida para auriculares) con baja impedancia
(aproximadamente 64 Ω).
Nota: Para regular el volumen, ajuste el nivel de volumen en
sus auriculares, receptor o dispositivo de reproducción
conectados, o en la tarjeta de sonido de su ordenador.
Technical Specifications
Analog Outputs: (1) 1/8” (3.5mm) headphone
Digital Outputs: (1) coaxial
Power: via USB connection
Dimensions (WxDxH): 2.8” x 0.9” x 0.4” / 70 x 24 x 10 mm
Weight: 0.06 lbs. / 0.03 kg
Specifications are subject to change without notice.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter. For best audio quality, avoid using this
device in a high RF-radiated environment. RSS Statement for Canadian models: This device
complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device This unit does
not exceed the Class B limits for radio noise emission from digital apparatus set out in the radio
interference re
g
ulations of the Canadian Department of Communications.
ESD/EFT Warning: This unit may contain a microcomputer for signal processing and
control functions. In very rare situations, severe interference, noise from an external
source, or static electricity may cause it to lock up. In the unlikely event that this should
happen, turn off the unit, wait at least five seconds, and then turn it back on again. In an
environment with radio frequency interference, the unit may malfunction and resume
normal operation after removal of the interference.
Trademarks and Licenses: M-Audio is a trademark of inMusic Brands, Inc., registered in
the U.S. and other countries. All other product or company names are trademarks or registered
trademarks of their respective owners.
User Guide
Guía del usuario
Guide d’utilisation
Guida per l’uso
Benutzerhandbuch
English
Español
Français
Italiano
Deutsch
1
2
3
4
5
1
2
3
4
5
